VEHICLE SPEED SENSOR
REMOVAL
(1) Raise vehicle on hoist.
(2) Remove passenger side halfshaft and interme-
diate shaft assembly. (Refer to 3 - DIFFERENTIAL &
DRIVELINE/HALF SHAFT - REMOVAL)
(3) Disconnect the speed sensor connector (Fig.
213).
CAUTION: Clean area around speed sensor before
removing to prevent dirt from entering the transaxle
during speed sensor removal.
(4) Remove speed sensor retaining bolt (Fig. 213).
(5) Remove speed sensor from transaxle.
CAUTION: Carefully remove vehicle speed sensor
so that sensor drive gear does not fall into trans-
axle. Should sensor drive gear fall into the trans-
axle during sensor removal, drive gear must be
reattached to sensor.
(6) Remove speed sensor drive gear from speed
sensor.
INSTALLATION
(1) Install pinion gear to speed sensor (Fig. 213).
(2) Using a NEW o-ring, install the speed sensor
to the transaxle (Fig. 213).
(3) Install the bolt and torque to 7 N·m (60 in.
lbs.).
(4) Connect speed sensor connector (Fig. 213).
(5) Install intermediate shaft and passenger side
halfshaft. (Refer to 3 - DIFFERENTIAL & DRIV-
ELINE/HALF SHAFT - INSTALLATION)
(6) Lower vehicle and road test to verify proper
speedometer operation.
Fig. 213 Speed Sensor and Pinion Removal/
Installation—Typical
1 - CONNECTOR
2 - SENSOR
3 - O-RING
4 - GEAR
21 - 132
T850 MANUAL TRANSAXLE
PL/SRT-4
