Dodge Nitro. Manual - part 962

Fig. 60: Installer 6560
Courtesy of CHRYSLER LLC

Fig. 61: Installer - 7829A
Courtesy of CHRYSLER LLC



2007 Dodge Nitro R/T

2007 TRANSFER CASE MP143 - Service Information - Nitro



Fig. 62: Installer - 8152
Courtesy of CHRYSLER LLC

Fig. 63: Installer 8245
Courtesy of CHRYSLER LLC



2007 Dodge Nitro R/T

2007 TRANSFER CASE MP143 - Service Information - Nitro



Fig. 64: Installer - 8693A
Courtesy of CHRYSLER LLC

Fig. 65: Installer, Seal - 9672
Courtesy of CHRYSLER LLC

FLUID

STANDARD PROCEDURE

FLUID DRAIN/REFILL



2007 Dodge Nitro R/T

2007 TRANSFER CASE MP143 - Service Information - Nitro



Fig. 66: Transfer Case MP143 Component Locations
Courtesy of CHRYSLER LLC

1. Raise vehicle.

2. Position drain pan under transfer case.

3. Remove drain and fill plugs and drain lubricant completely.

4. Install drain plug. Tighten plug to 12-15 N.m (9-11 ft. lbs.).

5. Remove drain pan.

6. Fill transfer case to bottom edge of fill plug opening with MOPAR® ATF+4 ATF.

7. Install and tighten fill plug to 12-15 N.m (9-11 ft. lbs.).

8. Lower vehicle.

SEAL-FRONT OUTPUT SHAFT

REMOVAL

FRONT OUTPUT SHAFT SEAL

The front output shaft seal and wear sleeve cannot be serviced in the vehicle. The transfer case must be
disassembled to remove the front output shaft assembly and seal.

1 - FILL PLUG

4 - SHIFT MOTOR

2 - DRAIN PLUG

5 - DAMPENER

3 - ID TAG

6 - REAR OUTPUT SHAFT FLANGE

NOTE:

The fill (2) and drain (3) plugs are both in the rear case.



2007 Dodge Nitro R/T

2007 TRANSFER CASE MP143 - Service Information - Nitro
