Fig. 45: Fuel Filter/Water Separator Components
Courtesy of CHRYSLER LLC

10. WATER-IN-FUEL (WIF) SENSOR REPLACEMENT: The combination fuel drain valve/WIF sensor

(6) is located on the bottom of the fuel filter housing.

The WIF sensor is not a separately serviceable item. If diagnostics have led you to replace this sensor,
then the whole fuel filter assembly needs to be changed.



2007 Dodge Nitro R/T

2007 ENGINE Fuel System - Nitro



Fig. 46: Fuel Filter/Water Separator Components
Courtesy of CHRYSLER LLC

11. FUEL HEATER ELEMENT REPLACEMENT: The fuel heater element (1) is located in the fuel filter

housing (8). To replace heater, the entire housing assembly must be replaced.

12. Drain fuel filter. See previous steps.



2007 Dodge Nitro R/T

2007 ENGINE Fuel System - Nitro



Fig. 47: Fuel Filter/Water Separator Components
Courtesy of CHRYSLER LLC

13. Disconnect electrical connectors (2), (3) and (4).



2007 Dodge Nitro R/T

2007 ENGINE Fuel System - Nitro



Fig. 48: Disconnecting/Connecting Quick-Connect Fittings At Housing & Removing/Installing
Housing Assembly
Courtesy of CHRYSLER LLC

14. Disconnect quick-connect fittings (1), (2) and (4) at housing.

15. Remove housing mounting nuts (3).

16. Remove housing assembly.
