Fig. 297: Identifying Axle Tubes & Adjuster C-4164
Courtesy of CHRYSLER LLC

9. Loosen differential bearing adjusters through the axle tubes (1) with Adjuster C-4164 (3).

10. Hold differential case while removing bearing caps and adjusters.

11. Remove differential case and tag differential bearing cups and adjusters to indicate location.

12. Clean housing cavity with flushing oil, light engine oil or a lint free cloth.

DISASSEMBLY

DIFFERENTIAL



2007 Dodge Nitro R/T

2007 DRIVELINE Differential & Driveline - Nitro



Fig. 298: Identifying Differential Window, Pinion Gear & Thrust Washer
Courtesy of CHRYSLER LLC

1. Rotate one pinion gear (2) with thrust washer (3) to the differential window (1) and remove gear and

thrust washer.



2007 Dodge Nitro R/T

2007 DRIVELINE Differential & Driveline - Nitro



Fig. 299: Identifying Differential Window, Thrust Washer & Pinion Gear
Courtesy of CHRYSLER LLC

2. Rotate remaining pinion gear (3) with thrust washer (2) to the differential window (1) and remove gear

and washer.



2007 Dodge Nitro R/T

2007 DRIVELINE Differential & Driveline - Nitro



Fig. 300: Removing Differential Side Gears And Thrust Washers
Courtesy of CHRYSLER LLC

3. Remove differential side gears (1) (2) and thrust washers.

ASSEMBLY

DIFFERENTIAL
