Fig. 2: Pressure Plate
Courtesy of CHRYSLER LLC

1. Remove transmission.

2. Mark position of pressure plate (1) on flywheel with paint or a scriber for assembly reference, if clutch is

not being replaced.

3. Loosen pressure plate bolts evenly and in rotation to relieve spring tension and avoid warping the plate.

4. Remove pressure plate bolts and pressure plate and disc.

INSTALLATION

DISC CLUTCH/PRESSURE PLATE



2007 Dodge Nitro R/T

2007 CLUTCH Clutch - Nitro



Fig. 3: Identifying Flywheel, Clutch Pressure Plate & Clutch Alignment Tool
Courtesy of CHRYSLER LLC

1. Lightly scuff sand flywheel face with 180 grit emery cloth, then clean with a wax and grease remover.

2. Lubricate pilot bearing with Mopar® high temperature bearing grease or equivalent.

3. Check runout and operation of new clutch disc.

4. With the disc on the input shaft, check face runout with dial indicator. Check runout at disc hub 6 mm

(1/4 in.) from outer edge of facing. Obtain another clutch disc if runout exceed 0.5 mm (0.020 in.).

5. Position clutch disc on flywheel with side marked flywheel against the flywheel.

6. Insert clutch alignment tool (3) through the clutch disc and into the pilot bearing.

7. Position clutch pressure plate (2) over disc and on the flywheel (1).

8. Install pressure plate bolts finger tight.

NOTE:

Disc must slide freely on transmission input shaft splines.

NOTE:

If not marked, the flat side of disc hub goes towards the flywheel.



2007 Dodge Nitro R/T

2007 CLUTCH Clutch - Nitro



9. Tighten pressure plate bolts evenly and in rotation a few threads at a time.

10. Tighten pressure plate bolts 33 N.m (24 ft. lbs.).

11. Apply light coat of Mopar® high temperature bearing grease or equivalent to clutch disc hub and splines

of transmission input shaft.

12. Install transmission.

DISC CLUTCH/PRESSURE PLATE - 2.8L DIESEL

CAUTION: Use only the factory bolts to mount the pressure plate. The bolts

must be the correct size. If bolts are too short, there isn't enough
thread engagement, if too long bolts interfere with the Dual Mass
Flywheel.

CAUTION: The bolts must be tightened evenly and to specified torque. Failure to

follow these instructions will distort the pressure plate.

CAUTION: Do not over lubricate shaft splines. This will result in grease

contamination of disc.



2007 Dodge Nitro R/T

2007 CLUTCH Clutch - Nitro



Fig. 4: Identifying Flywheel With Side Marked Flywheel Side
Courtesy of CHRYSLER LLC

1. Lightly scuff sand flywheel face with 180 grit emery cloth, then clean with a wax and grease remover.

2. Lubricate pilot bearing with Mopar® high temperature bearing grease or equivalent.

3. Check runout and operation of new clutch disc.

4. With the disc on the input shaft, check face runout with dial indicator. Check runout at disc hub 6 mm

(1/4 in.) from outer edge of facing. Obtain another clutch disc if runout exceed 0.5 mm (0.020 in.).

5. Position clutch disc on flywheel with side marked flywheel side (1) against the flywheel. If not marked,

the flat side of disc hub goes towards the flywheel.

NOTE:

Disc must slide freely on transmission input shaft splines.
