Fig. 338: Removing/Installing Floor Console
Courtesy of CHRYSLER LLC

23. Install the floor console, see INSTALLATION.

Fig. 339: Removing/Installing Fasteners And Close Out Panels
Courtesy of CHRYSLER LLC

24. Install the close out panels and the bolts to the lower I/P and tighten to 2.5 N.m (22 in. lbs.).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 340: Instrument Panel, Slots & Moldings
Courtesy of CHRYSLER LLC

25. Align the right and left A-pillar trim tabs on the moldings (3) to the top cover slot of the instrument panel

(1).

26. Align the two clips on the molding to the slots (2) on the A-pillar. Snap the A-pillar trim molding (3) into

place using hand pressure.

27. Connect the negative battery cable to the battery.

STRIKER - GLOVE BOX DOOR LATCH

REMOVAL

STRIKER - GLOVE BOX DOOR LATCH

1. Before proceeding with the following repair procedure, review all warnings and cautions. See

WARNING.

2. Open the glove box.

3. Remove the two striker screws and remove the latch striker.

INSTALLATION

STRIKER - GLOVE BOX DOOR LATCH

1. Before proceeding with the following repair procedure, review all warnings and cautions. See

WARNING.

2. Install the striker and install the two screws.

3. Loosen the screws to adjust if necessary.

INTERIOR



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



BASE - FLOOR CONSOLE

REMOVAL

BASE - FLOOR CONSOLE

Fig. 341: Floor Console Shift Bezel
Courtesy of CHRYSLER LLC

1. Using a trim stick C-4755 or equivalent, pry the shift bezel out of the floor console.

2. If equipped, remove electrical connectors attached to shift bezel.

Fig. 342: Console Lid, End Cap & Electrical Connectors
Courtesy of CHRYSLER LLC

3. Open console lid (1).

4. Using a trim stick C-4755 or equivalent, release the fasteners at the four locations around the floor

console end cap (2).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



5. Disconnect electrical connectors (3) from end cap (2).

6. Remove end cap (2).

Fig. 343: Removing/Installing Floor Console
Courtesy of CHRYSLER LLC

7. Remove ash cup (3) from console (1).

8. Remove bin (4) from console (1).

9. Remove two screws (2) from front of console (1).

10. Remove two screws (5) from rear of console (1) located inside the console bin.

11. Lift console (1) at back and remove.

INSTALLATION

BASE - FLOOR CONSOLE

Fig. 344: Removing/Installing Floor Console
