2007 ENGINE

4.0L - Service Information - Nitro

DESCRIPTION

4.0L ENGINE

Fig. 1: 4.0L ENGINE
Courtesy of CHRYSLER LLC

The 4.0L Liter (244 Cubic Inches) 60° V-6 engine is a single overhead camshaft design with hydraulic lifters
and four valves per cylinder The engine does not have provisions for a free wheeling valve train. See Fig. 1.



2007 Dodge Nitro R/T

2007 ENGINE 4.0L - Service Information - Nitro





2007 Dodge Nitro R/T

2007 ENGINE 4.0L - Service Information - Nitro



Fig. 2: Cylinder Numbering & Firing Order
Courtesy of CHRYSLER LLC

The cylinders are numbered from front to rear, with the right bank odd numbered, and the left bank even
numbered The firing order is 1-2-3-4-5-6. See Fig. 2.



2007 Dodge Nitro R/T

2007 ENGINE 4.0L - Service Information - Nitro



Fig. 3: Engine Identification
Courtesy of CHRYSLER LLC

The engine identification number (2) is located on the rear of engine block just below the left cylinder head (1).
See Fig. 3.

DIAGNOSIS AND TESTING

INTRODUCTION

1 - REAR OF LEFT CYLINDER HEAD
2 - ENGINE IDENTIFICATION NUMBER



2007 Dodge Nitro R/T

2007 ENGINE 4.0L - Service Information - Nitro



Engine diagnosis is helpful in determining the causes of malfunctions not detected and remedied by routine
maintenance.

These malfunctions may be classified as either mechanical (e.g, a strange noise), or performance (e.g, engine
idles rough and stalls).

Refer to ENGINE MECHANICAL and ENGINE PERFORMANCE for possible causes and corrections of
malfunctions. Refer to FUEL SYSTEM for the fuel system diagnosis.

Additional tests and diagnostic procedures may be necessary for specific engine malfunctions that cannot be
isolated with the Service Diagnosis charts. Information concerning additional tests and diagnosis is provided
within the following:

Cylinder Compression Pressure Test

Cylinder Combustion Pressure Leakage Test

Cylinder Head Gasket Failure Diagnosis

Intake Manifold Leakage Diagnosis

Lash Adjuster (Tappet) Noise Diagnosis

Engine Oil Leak Inspection

ENGINE MECHANICAL

CONDITION

POSSIBLE CAUSES

CORRECTION

NOISY VALVES

1. High or low oil level in
crankcase.

1. Check and correct engine oil
level.

2. Thin or diluted oil.

2. Change oil to correct viscosity.

3. Thick oil

3. (a.) Change oil and filter.



(b.) Run engine to operating
temperature.



(c.) Change oil and filter again.

4. Low oil pressure.

4. Check and correct engine oil
level.

5. Dirt in tappets/lash adjusters.

5. Replace rocker arm/hydraulic
lash adjuster assembly.

6. Worn rocker arms.

6. Inspect oil supply to rocker
arms.

7. Worn tappets/lash adjusters.

7. Install new rocker
arm/hydraulic lash adjuster
assembly.

8. Worn valve guides.

8. Replace cylinder head(s).

9. Excessive runout of valve seats
on valve faces.

9. Grind valve seats and valves.

10. Missing adjuster pivot.

10. Replace rocker arm/hydraulic
lash adjuster assembly.
