P2172-HIGH AIRFLOW/VACUUM LEAK DETECTED (INSTANTANEOUS ACCUMULATION) (CONTINUED) 5. RESISTANCE IN THE (F855) 5-VOLT SUPPLY CIRCUIT Turn the ignition off. Disconnect the Throttle Body harness connector. Disconnect the C2 PCM harness connector. CAUTION: Do not probe the PCM harness connectors. Probing Is the resistance above 100 ohms? Yes >> Go To 6 No >> Repair the excessive resistance in the (F855) 5-volt Sup- ply circuit. Perform the POWERTRAIN VERIFICATION TEST. (Refer 6. (F855) 5-VOLT SUPPLY CIRCUIT SHORTED TO GROUND Measure the resistance between ground and (F855) 5-volt Supply cir- Is the resistance above 100 ohms? Yes >> Go To 7 No >> Repair the short to ground in the (F855) 5-volt Supply cir- cuit. Perform the POWERTRAIN VERIFICATION TEST. (Refer HB ENGINE ELECTRICAL DIAGNOSTICS 9 - 919 |
