HORN
DIAGNOSIS AND TESTING
HORN
The most reliable, efficient, and accurate means to diagnose the horn system requires the use of a scan
tool and the proper Diagnostic Procedures information.
Refer to the appropriate wiring information.
WARNING: DISABLE THE AIRBAG SYSTEM BEFORE ATTEMPTING ANY STEERING WHEEL, STEERING
COLUMN, SEAT BELT TENSIONER, SIDE AIRBAG, OR INSTRUMENT PANEL COMPONENT DIAGNOSIS OR
SERVICE. DISCONNECT AND ISOLATE THE BATTERY NEGATIVE (GROUND) CABLE, THEN WAIT TWO MIN-
UTES FOR THE AIRBAG SYSTEM CAPACITOR TO DISCHARGE BEFORE PERFORMING FURTHER DIAGNO-
SIS OR SERVICE. THIS IS THE ONLY SURE WAY TO DISABLE THE AIRBAG SYSTEM. FAILURE TO TAKE
THE PROPER PRECAUTIONS COULD RESULT IN ACCIDENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
REMOVAL
1. Disconnect and isolate the battery negative cable.
2. Remove the grille (Refer to 23 - BODY/EXTERIOR/
GRILLE - REMOVAL).
3. Remove the horn mounting fasteners.
4. Disconnect the electrical harness connector and
remove the horns.
INSTALLATION
1. Connect the electrical harness connector to the
horns.
2. Position
horns
and
install
mounting
fastener.
Tighten fastener.
3. Install grille (Refer to 23 - BODY/EXTERIOR/
GRILLE - INSTALLATION).
4. Connect battery negative cable.
HB
HORN SYSTEM - SERVICE INFORMATION
8H - 15
