8W-90 CONNECTOR LOCATIONS

DESCRIPTION AND OPERATION

INTRODUCTION

This section provides illustrations identifying com-

ponent and connector locations in the vehicle. A con-
nector index is provided. Use the wiring diagrams in

each section for connector number identification.
Refer to the index for the proper figure number.

CONNECTOR/GROUND LOCATIONS

For items that are not shown in this section N/S is

placed in the Fig. column.

Connector
Name/Number

Color

Location

Fig.

4WD Switch

BK

Left Side of
Transfer Case

22,
26

A/C Compressor
Clutch

BK

At Compressor

8,
10,
11

A/C Heater
Control or Heater
Control

BK

At HVAC
Control

13,
14

A/C High
Pressure Switch

Left Side of
Compressor

N/S

A/C Low Pressure
Switch

Right Rear of
Engine
Compartment

3

A/C Low
Temperature
Cut-0ut Switch

BK

Right Rear of
Engine
Compartment

3

Airbag Control
Module

YL

Lower Center of
Instrument
Panel

13

Ambient Air
Temperature
Sensor

Radiator Top
Support

1

Ash Reciever
Lamp

BK

Upper Center of
Instrument
Panel

14

Automatic
Day/Night Mirror

BK

Top of
Windshield

15

Battery
Temperature
Sensor

BK

At Battery

5

Blower Motor

BK

Upper Center of
Instrument
Panel

14

Brake Lamp
Switch

GY

At Brake Pedal
Arm

N/S

Brake Pressure
Switch

BK

At Anti-Lock
Brake Controller

7

Connector
Name/Number

Color

Location

Fig.

C105

Right Fender
Side Shield

1, 3,
4

C106

Power
Distribution
Center

5

C128

BK

Right Fender
Side Shield

N/S

C129

BK

Near Oxygen
Sensor 1/2
Downstream

22

C200

BK

Lower Left of
Instrument
Panel

13,
16,
17

C228

BK

Left Door

18

C240

BK

Left Door

18

C243

NAT

Right Side of
Instrument
Panel

18

C244

NAT

Right Side of
Instrument
Panel

18

C246

Lower Left of
Instrument
Panel

13,
16,
18

C247

Lower Left of
Instrument
Panel

13,
16,
18

C248

BK

At Power Seat

18

C325

Top of Liftgate

29

C326

Top of Liftgate

29

C331

NAT

Left B Post

18

C332

NAT

Right B Post

18

C333

BK

Near License
Lamp

N/S

C349

Overhead A/C

15

DN

8W - 90 CONNECTOR LOCATIONS

8W - 90 - 1

Connector
Name/Number

Color

Location

Fig.

C352

BK

Left Inner
Fender

6,
28

C401

NAT

Center High
Mounted Stop
Lamp

29

Camshaft Position
Sensor

GY

At Distributor

21

Capacitor No.1

BK

Right Side of
Engine

N/S

Capacitor No.2

BK

Left Side of
Engine

12

Center High
Mounted Stop
Lamp No.1

BK

Liftgate

N/S

Center High
Mounted Stop
Lamp No.2

BK

Liftgate

N/S

Center High
Mounted Stop
Lamp No.3

BK

Liftgate

N/S

Central Timer
Module-C1

GN

Right Side of
Instrument
Panel

13

Central Timer
Module-C2

BK

Right Side of
Instrument
Panel

13

Cigar Lighter

NAT

Upper Center of
Instrument
Panel

14

Clockspring - C1

At Steering
Wheel

13

Clockspring - C2

BK

At Steering
Wheel

N/S

Clockspring - C3

YL

At Steering
Wheel

13,
16

Coil On Plug No.1
(4.7L)

BK

Left Side of
Engine

12

Coil On Plug No.2
(4.7L)

BK

Right Side of
Engine

11

Coil On Plug No.3
(4.7L)

BK

Left Side of
Engine

12

Coil On Plug No.4
(4.7L)

BK

Right Side of
Engine

11

Coil On Plug No.5
(4.7L)

BK

Left Side of
Engine

12

Coil On Plug No.6
(4.7L)

BK

Right Side of
Engine

11

Connector
Name/Number

Color

Location

Fig.

Coil On Plug No.7
(4.7L)

BK

Left Side of
Engine

12

Coil On Plug No.8
(4.7L)

BK

Right Side of
Engine

11

Controller
Anti-Lock Brake -
C1

BK

At Anti-Lock
Brake Controller

7

Controller
Anti-Lock Brake -
C2

BK

At Anti-Lock
Brake Controller

7

Crankshaft
Position Sensor

BK

Rear of Engine

21

Data Link
Connector

BK

Lower Left of
Instrument
Panel

13,
16

Daytime Running
Lamp Module

BK

Left Front Inner
Fender

5

Driver Cylinder
Lock Switch

Driver Door

19

Driver Door Ajar
Switch

BK

Driver Door

N/S

Driver Door Lock
Motor/Ajar Switch

BK

Driver Door

19

Driver Door
Window Motor

BK

Driver Door

19

Driver Power
Mirror

BK

Driver Door

19

Driver Power
Window/Door
Lock Switch

BK

Driver Door

19

Duty Cycle
Evap/Purge
Solenoid

GY

At Throttle Body

3

Electric Brake
(Trailer Tow)

BL

Lower Left of
Instrument
Panel

17

Engine Coolant
Temperature
Sensor

BK

At Thermostat
Housing

3

Front Dome Lamp

BK

At Headliner

15

Fuel Injector No.1

BK

At Injector

8,
10,
12

Fuel Injector No.2

BK

At Injector

9,
11

Fuel Injector No.3

BK

At Injector

8,
10,
12
