M162 ENGINE CONTROLS 1F1-67 CAMSHAFT POSITION SENSOR 1 Bolt (M6 X 14) ......................................... 9-11Nm Removal & Installation Procedure 1. Disconnect the wiring connector from the camshaft position sensor. 2. Unscrew the bolt (2) and remove the camshaft position sensor. Installation Notice 3 Shim Tightening Torque 9 - 11 Nm 3. Check the clearance and replace the shim if necessary. 4. Check the O-ring for damage and replace it if necessary. 5. Installation should follow the removal procedure in the reverse order. |
