M162 ENGINE CONTROLS 1F1-7 41 44 45 56 57 58 59 60 62 64 65 66 67 71 72 73 74 75 76 77 78 79 80 81 82 83 86 87 89 00 01 02 03 04 05 08 09 10 11 17 18 19 20 21 23 24 25 26 27 29 30 31 34 35 40 Failure code Description Coolant temperature sensor open Coolant temperature sensor short Coolant temperature sensor signal failure Intake temperature sensor open Intake temperature sensor short Intake temperature sensor signal failure Low battery voltage HFM sensor signal failure HFM sensor signal failure(Low) HFM sensor signal failure(High) Crankshaft position sensor signal failure (no engine revolution signal) Crankshaft position sensor signal failure (rpm > max. value) No.1 cylinder recognition failure Crankshaft position sensor signal failure (gab recognition failure) Transmission coding failure CAN communication failure : ASR - Transponder signal failure CAN communication failure : TCU(A/T only) CAN communication failure : TOD(E32 only) - - CAN communication failure : communication initialization failure Fuel pump relay short(PWR) Fuel pump relay open/short(GND) Purge valve short Fa ilure code Description Purge valve open/short Condenser fan(HI) relay short(PWR) Condenser fan(HI) relay short(GND) No.1 knock sensor signal failure No.2 knock sensor signal failure No.1 cylinder synchronization failure - - Cluster S/W defectave No ignition voltage output(No.1 ignition coil) No ignition voltage output(No.2 ignition coil) No ignition voltage output(No.3 ignition coil) Crankshaft position sensor adaptation failure Start signal recognition failure No.1 injector short(PWR) No.1 injector open/short(GND) No.2 injector short(PWR) No.2 injector open/short(GND) No.3 injector short(PWR) No.3 injector open/short(GND) No.4 injector short(PWR) No.4 injector open/short(GND) High oxygen sensor voltage Low oxygen sensor amplifying voltage Oxygen sensor operating failure Not excessive lean indication in oxygen sensor(during coasting) Oxygen sensor heater short(PWR) Oxygen sensor heater open/short(GND) Low oxygen sensor voltage SELF DIAGNOSIS FAILURE CODE |
