1B1-12  M162 ENGINE MECHANICAL

19. Disconnect the engine ground wire.

15. Remove the automatic transmission dipstick guide tube.

16. Disconnect the wire of alternator.

17. Disconnect the wire of starter motor and remove the starter

motor.

18. Disconnect the engine main harness ground.

M162 ENGINE MECHANICAL  1B1-13

20. Disconnect following sensors connector.

l

HFM sensor.

l

Coolant temperature sensor.

l

2 knock sensors.

l

Camshaft and crankshaft sensors.

21. After removing the ignition coil cover, disconnect the ignition

coil connector.

22. Remove the harness cover and disconnect the 6 injection

valve connectors. Disconnect the main harness

23. Separate the hose toward engine from canister purge

solenoid valve.

24. Remove the automatic transmission oil cooler line.

1B1-14  M162 ENGINE MECHANICAL

Tightening Torque

30 Nm

29. Remove the exhaust manifold and exhaust pipe.

Installation Notice

25. Separate the vacuum hose for brake booster.

26. Separate the other vacuum hoses.

27. Remove the propeller shaft from the front axle.

Installation Notice

28. By rotating the crankshaft from the front of engine, remove

the 6 torque converter mounting bolts from the engine
ring gear plate.

Tightening  Torque

81 - 89 Nm

M162 ENGINE MECHANICAL  1B1-15

30. Remove the transmission mounting bolts and separate

the transmission from the engine.

Installation Notice

Tightening Torque

65 Nm

31. Remove the bolts for engine mounting bracket.

Installation Notice

Tightening  Torque

50 - 75 Nm

32. Hook the chain to the bracket of engine and by using a

hoist or crane, carefully separate the engine assembly
from the vehicle.

33. Installation should follow the removal procedure in the

reverse order.
