DAF CF65, CF75, CF85 Series . Manual - part 349





3

CF65/75/85 series

General

CLUTCH

2-5

2.2 SYSTEM DESCRIPTION OF CLUTCH PROTECTION

Pulling off in too high a gear puts excessive
stress on the clutch. The clutch protection
system makes it difficult to drive off in too high a
gear. The clutch protection system prevents
driving away in the 3

rd

or higher gear. If

nevertheless a higher gear is selected to pull off
in, a yellow warning will be activated on DIP
(selected gear too high) and an acoustic signal
will sound when accelerating. At the same time
the accelerator pedal signal will be ignored, so
that acceleration is not possible.

To be able to drive away, a lower gear than the
3

rd

must be selected. Located on the gearbox

are the switches for the gate 3/4 (1) and the
low-range switch (2).

V300841

1

2

1.

Gearbox switch for gate 3/4 (F120)

2.

Low-range switch (E595)

The VIC electronic unit receives and transmits
the signals for the clutch protection system.

The clutch protection system is activated when:
-

gearbox is in 3

rd

gear or higher and

-

speed is lower than 5 km/h and

-

the clutch is depressed.

10

ᓻ 200337

3

CLUTCH

General

CF65/75/85 series

2-6

2.3 OVERVIEW DRAWING, MAIN CYLINDER

1.

Thrust pin with eye

2.

Thrust pin adjustment

3.

Thrust pin

4.

Piston

5.

Valve

6.

Spring

V300410

3

4

5

6

2

1

10

ᓻ 200337

3

CF65/75/85 series

General

CLUTCH

2-7

2.4 OVERVIEW DRAWING, CF75/85 CLUTCH SERVO

A

A

8

3 2

7

1

6

10

5

11

4

9

V300412

Cross-section A - A
1.

Servo piston

2.

Air valve

3.

Spring

4.

Pressure pin

5.

Air piston

6.

Fluid piston

7.

Pressure spring

8.

Bleed bore

9.

Bleed

10. Vent opening
11. Wear indicator

10

ᓻ 200337

3

CLUTCH

General

CF65/75/85 series

2-8

2.5 OVERVIEW DRAWING, CF65 CLUTCH SERVO

V3 00 436

17

31

16

19

18

20

21

22

23

24

25

26

27

28

29

30

32

2

1

6

7

8

9

10

11

12

11

10

11

13

14

15

3

4

5

1.

Rubber protective bellows

2.

End-plate

3.

O-ring

4.

Push rod

5.

Fastening ring for push rod

6.

Split seal

7.

Piston

8.

Piston seal

9.

Conical spring

10. Circlip
11. Washer
12. Seal, hydraulic part, front
13. Seal, hydraulic part, rear
14. Split bearing
15. Booster housing
16. Bleed nipple

17. Vent opening
18. Blow-off nipple
19. Piston seal
20. O-ring
21. O-ring
22. Piston
23. Pressure spring
24. O-ring
25. Spring seat housing
26. Inlet valve
27. Spring seat
28. Reset spring
29. O-ring
30. Connector housing
31. Socket head screw
32. Air filter

10

ᓻ 200337
