0 3 CF65/75/85 series ZF 8/16S-151/181 and 16S-221 gearboxes TECHNICAL DATA 6-1 6. ZF 8/16S-151/181 AND 16S-221 GEARBOXES 6.1 GENERAL Gearbox type Each gearbox has a type-plate attached to it, ZF gearbox type-plate Type of gearbox 2. Series no. (ZF) 3. Parts list (ZF) 4. Specification no. 5. Pulse generator ratio 6. Gearbox ratio 7. Engine speed using PTO 8. PTO speed 9. Gearbox oil capacity 10. Oil specification V300049 1 2 4 3 8 6 7 10 9 Output shaft bearing axial play 0.00 - 0.10 mm Bearing axial play, main and input shafts 0.00 - 0.10 mm Auxiliary shaft bearing axial play 0.00 - 0.10 mm Retaining element 168 N Heavy-duty spring force 191 N ᓻ 200337 |
