DAF CF65, CF75, CF85 Series . Manual - part 1202

©

 200423

4-3

Removal and installation

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ85 series

5

Installing the air filter element
1.

Fit the air filter element (3) in the air filter
housing.

2.

Fit the air filter cover. Note the arrow (4) on
the air filter cover (2).

3.

Fit all the clamping brackets (1).

4.

Check that the flexible sealing bellows (5) on
the air intake is not damaged. Replace if
necessary.

i400443

1

5

2

4

3

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

4-4

©

 200423

Removal and installation

5

ΧΦ85 series

4.3 REMOVAL AND INSTALLATION, COOLANT FILTER

When the coolant is hot, there is an
overpressure in the cooling system.
Carefully remove the filler cap to
release the overpressure.
Do not remove the filler cap when the
engine is running.
Coolant is a toxic fluid. Contact with
the skin should therefore be
avoided.
In the event of contact with the skin:
remove the liquid with paper or a
cloth, wash with soap and water. If
irritation persists, consult a doctor.
If swallowed: DO NOT induce
vomiting. Rinse mouth, drink two
glasses of water and consult a
doctor.
In the event of inhalation: get fresh
air and rest.
In order to avoid damaging the
cylinder block, do not top up a warm
engine with coolant.

Removing the coolant filter
1.

Place a tray beneath the coolant filter to
collect any escaping coolant.

2.

Remove the filler cap from the expansion
tank.

3.

Turn the shut-off valve (1) clockwise to
the "C" position.

4.

Remove the coolant filter by turning it
counter-clockwise.

Installing the coolant filter
1.

Clean the sealing face of the coolant filter.

2.

Apply a small amount of coolant to the
sealing ring of the coolant filter.

3.

Fit the coolant filter so that the sealing ring
makes contact. Then tighten the filter by
hand

∂ to • of a turn.

4.

Turn shut-off valve (1) anti-clockwise to
the "O" position.

5.

Fit the filler cap on the expansion tank.

6.

Run the engine and check that the coolant
filter seals correctly.

7.

Check the coolant level.

}

O

1

C

M200372

©

 200423

4-5

Removal and installation

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ85 series

5

4.4 REMOVAL AND INSTALLATION, ENGINE OIL FILTER

To prevent skin injury, avoid
unnecessary contact with the
drained engine oil.

Removing the engine oil filter
1.

Place a tray beneath the engine oil filter.

2.

Unscrew the cap (2) a few turns until the
engine oil starts to flow out of the filter.

3.

Remove cap (2) when the engine oil filter is
empty.

4.

Remove the filter element (3) from the filter
housing (1).

Installing the engine oil filter
1.

Replace the sealing ring in the cap (2)

2.

Lightly lubricate the sealing ring with
engine oil.

3.

Fit a new filter element (3) in the filter
housing (1).

4.

Fit the cap (2) and tighten to the specified
torque, see main group "Technical data".

}

4

1

3

2

5

M201049

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

4-6

©

 200423

Removal and installation

5

ΧΦ85 series

4.5 REMOVAL AND INSTALLATION, CENTRIFUGAL FILTER ROTOR

To prevent skin injury, avoid
unnecessary contact with the
drained engine oil.

Removing the centrifugal filter rotor
1.

Clean the cap (3) and the area around it.

2.

Remove the central bolt (4) and cap (3).

3.

Remove the rotor (2) from the cap (3).

Installing the centrifugal filter rotor
1.

Clean the interior of the cap (3).

2.

Check the central bolt (4) for damage.

3.

Replace the sealing ring (5).

4.

Fit the rotor (2) in the cap (3).

5.

Lightly oil the sealing ring (5) with engine oil
and fit the cap (3).

6.

Tighten the central bolt (4) to the specified
tightening torque, see main group "Technical
data".

7.

Start the engine and check for leakage.

8.

Inspect the engine oil level.

}

4

3

2

5

1

M200526
