DAF CF65, CF75, CF85 Series . Manual - part 1180
©
200423
2-1
Gearbox
TECHNICAL DATA
ΧΦ85 series
0
2. GEARBOX
2.1 TIGHTENING TORQUES
The tightening torques specified in this paragraph
are different from the standard tightening torques
cited in the overview of the standard tightening
torques. The other threaded connections not
specified must therefore be tightened to the
torque cited in the overview of standard
tightening torques.
When attachment bolts and nuts are replaced, it
is important - unless stated otherwise - that these
bolts and nuts are of exactly the same length and
property class as those removed.
ZF 8S -151/181 and 16S-151/181/221
gearboxes
ZF 8S-151/181 and 16S-151/181/221 with
integrated retarder
M3023
D
A
B
C
Level check/filler plug (A)
60 Nm
M24 drain plug (B)
60 Nm
M38 drain plug (B)
120 Nm
Drain plug (C/D)
60 Nm
B
C
V300186
D
Drain plug (D)
60 Nm
