DAF CF65, CF75, CF85 Series . Manual - part 1119

©

 200518

1-3

Maintenance intervals

MAINTENANCE SCHEDULE

ΧΦ65/65 (II) series

4

X service
This is the symbol for an X service.

An X service is a mileage-dependent

maintenance check which consists of changing

the engine oil plus a number of visual inspections.

Note:

An X service must be carried out at least once a

year.

Y service
This is the symbol for a Y service.

A Y service is an annual maintenance check

consisting of several maintenance activities plus

changing of the gearbox and rear axle oil.

Note:

If the prescribed oil specification (see

specification manual "Fluids and lubricants") is

complied with, an extended changing interval

may be applied.

Automatic gearboxes are subject to different

changing intervals.

G000086

+

 X service

G000087

+

1x per YEAR

 Y service

(1)

Automatic Allison gearbox

Maintenance group I

Standard changing interval 1 year/maximum

40,000 km

Extended changing interval 3 years/maximum

80,000 km

Maintenance group II

Standard changing interval 1 year/maximum

40,000 km

Extended changing interval 3 years/maximum

160,000 km

Maintenance group III

Standard changing interval 1 year/maximum

40,000 km

Extended changing interval 3 years/maximum

160,000 km

MAINTENANCE SCHEDULE

1-4

©

 200518

Maintenance intervals

4

ΧΦ65/65 (II) series

1.3 EFFECT OF DIESEL FUEL AND PTO HOURS ON MAINTENANCE INTERVALS

Diesel fuels

PTO hours
PTO hours should be converted into mileage

according to the following formula:

1 PTO hour = 40 km

1.4 MAINTENANCE IN SPECIAL OPERATING CONDITIONS

Contact a DAF dealer/main branch or importer for

vehicles used in very specific or heavy

conditions.

The service intervals can be modified, if

necessary, in consultation with the dealer/main

branch or importer to fit the appropriate operating

conditions.

1.5 FIRST SERVICE INSPECTION

The first service inspection should be carried out

between the first 7,500 and 10,000 km or at most

8 weeks after delivery of the vehicle, whichever

comes first.

Note:

If the vehicle is fitted with a clutch wear indicator,

a mark (centre punch) should be made in the

wear indicator cover.

The mark should be placed exactly opposite the

middle of the indicator.

This mark is necessary to allow clutch wear to be

evaluated.

Sulphur content

Engine oil change interval

> 0,2%

Halve interval to max. of 25,000 km

©

 200518

2-1

Maintenance activities

MAINTENANCE SCHEDULE

ΧΦ65/65 (II) series

4

2. MAINTENANCE ACTIVITIES

2.1 OVERVIEW OF MAINTENANCE ACTIVITIES FOR THE FIRST SERVICE

INSPECTION

O Adjust clutch wear indicator mark
O Change the oil filters on automatic gearbox

MAINTENANCE SCHEDULE

2-2

©

 200518

Maintenance activities

4

ΧΦ65/65 (II) series

2.2 OVERVIEW OF ANNUAL MAINTENANCE ACTIVITIES

ANNUAL MAINTENANCE ACTIVITIES (Y-SERVICE)

"Correct, if necessary, after inspection"

CAB AND ELECTRICAL SYSTEM
O Check pedal rubbers
O Check whether the latest version of the ITS manual is kept in the cab
O Replace interior filter element
O Check fluid level of cab tilting pump
O Check cab fastening

ENGINE, COOLING SYSTEM AND FUEL SYSTEM
O Replace air filter element
O Check air inlet dust trapping valve
O Check/adjust valve clearance - see Note 4

Done

O Yes O No

O Check coolant freezing point
O Change coolant - see Note 1

Changed

O Yes O No

O Change fuel fine filter

STEERING GEAR AND BRAKE SYSTEM
O Replace steering gear filter element - see Note 5

Replaced

O Yes O No

O Check steering ball joints
O Replace air dryer filter element
O Check compressor line - See Note 6
O Check brake cylinder fastening
O Check/adjust load-dependent control valve
O Check fastening of universal joint to steering box input shaft

DRIVE AND CHASSIS
O Change differential oil - See Note 2

Changed

O Yes O No

O Check operation of differential lock
O Check drive shaft play
O Change gearbox oil - see Note 3

Changed

O Yes O No

O Check trailer coupling
O Check superstructure attachment

OTHER ACTIVITIES
O Check whether there are any field actions that still need to be performed on the vehicle
