DAF XF105. Manual - part 81

0

©

 200528

1-29

DMCI engine management system

TECHNICAL DATA

XF105 series

1.17 STARTER MOTOR

A

C

B

i400726

1

4

5

9

13

17

21

25

29

33

37

41

45

49

53

57

60

62

A

Electronic unit connection point

B

Description of connection point

C

Reading at connection point (Ubat = battery voltage)

D

Measuring unit

E

Explanatory notes (if applicable)

F

Additional information available in Technical Data at "X" mark

A

B

C

D

E

F

B9

Output signal earth starter motor

(B010)

0

VDC

If starter motor is active

about

1.5

VDC

If engine is running

0

TECHNICAL DATA

1-30

©

 200528

DMCI engine management system

XF105 series

1.18 GLOW COMPONENTS

Glow plug relay

Glow element

A

C

B

i400726

1

4

5

9

13

17

21

25

29

33

37

41

45

49

53

57

60

62

A

Electronic unit connection point

B

Description of connection point

C

Reading at connection point (Ubat = battery voltage)

D

Measuring unit

E

Explanatory notes (if applicable)

F

Additional information available in Technical Data at "X" mark

A

B

C

D

E

F

C32

Output signal glow relay (G014)

0

V DC

Glow relay active

Ubat

V DC

Glow relay not active

C39

Input signal glow relay active (G014) Ubat

V DC

Glow relay activated

0

V DC

Glow relay not active

Supply voltage

Ubat

Resistance value of coil

21

 ≥ 10%

Supply voltage

Ubat

Rated output

1.9 kW

≥ 10%

Resistance value

0.25

 ≥ 10%

0

©

 200528

1-31

DMCI engine management system

TECHNICAL DATA

XF105 series

1.19 WASTE GATE VALVE

A

C

B

i400726

1

4

5

9

13

17

21

25

29

33

37

41

45

49

53

57

60

62

A

Electronic unit connection point

B

Description of connection point

C

Reading at connection point (Ubat = battery voltage)

D

Measuring unit

E

Explanatory notes (if applicable)

F

Additional information available in Technical Data at "X" mark

A

B

C

D

E

F

C8

Output signal waste gate valve

(B368)

-

%

Depending on the desired boost

pressure, earth-controlled duty

cycle

X

C59

Earth waste gate valve (B368)

0

V DC

0

TECHNICAL DATA

1-32

©

 200528

DMCI engine management system

XF105 series

(1) Check duty cycle with the multimeter by plus

measurement pin at C59 and less measurement pin

at C8.

10% duty cycle, earth-controlled, plus

measurement pin C8 less measurement pin

C59

  0

  5

10

15

20

25

U (V)

i401021

Supply voltage

approx. 24 V

Air pressure

approx. 10 bar

Control signal

earth-controlled

duty cycle

(1)

Duty cycle voltage level

approx. 12 V

Frequency of duty

cycle signal

circa 160 Hz

MX375

MX410

Duty cycle (%)

Output pressure, output

"2" (bar)

Output pressure, output

"2" (bar)

0

0.3

0.3

10

0.3

0.3

50

1.5

2.5

90

3.0

5.0

95

3.0

5.0

100

0.3

0.3
