5 General location of components LOCATION OF COMPONENTS 1-3 1 2 3 4 F585 Sensor for engine coolant level Back of header tank 20 G015 Contact relay Along printed circuit, central box 10 G065 Heater fan relay Right-hand side of heater unit 6 G066 Lifting-gear takeover relay In lifting gear distributor box 29 G170 Auxiliary-heating fan relay Along printed circuit, central box 21 G203 Starting-motor takeover relay On starting motor 36 G239 Engine brake takeover relay Along printed circuit, central box 14 G247 Auxiliary-heating fan relay Along printed circuit, central box 21 G257 Recirculation valve microrelay Right-hand side of heater unit 1 G259 N-10-PTO control relay Along printed circuit, on right-hand 13 G267 Air-conditioning microrelay Right-hand side of heater unit 2 G279 Heater fan transfer microrelay Right-hand side of heater unit 4 G723 Connection for central door locking In the central box 30 8 ǹ 0009 |
