114

Safety

Locations for ISOFIX child seats

In accordance with European regulations, this table indicates the options for installing ISOFIX child seats on vehicle seats fitted with ISOFIX mountings.

In the case of universal and semi-universal ISOFIX child seats, the ISOFIX size category, determined by a letter from

A

 to

G

, is indicated on the child seat

next to the ISOFIX logo.

Weight of the child/indicative age

Under 10 kg

(group 0)

Up to about 6

months old

Under 10 kg

(group 0)

Under 13 kg

(group 0+)

Up to about 1 year old

From 9 - 18 kg

(group 1)

From about 1 to 3 years old

Type of ISOFIX child seat

Carrycot

"rearward facing"

"rearward

facing"

"forward facing"

ISOFIX size category

F

G

C

D

E

C

D

A

B

B1

B2

B3

Row 1

(a)

Not ISOFIX

Row 2

(b)

Rear seat

behind the

driver

IL (c)

IL

IUF/IL

Centre rear

seat

(f)

 and

seat behind the

front passenger

IL (d)

Row 3

(b) (e)

Not ISOFIX

Key

(a)

 Refer to the current legislation in the country in which you are driving before placing a child in this seat position.

(b)

 To install a rearward-facing or forward-facing child seat on a rear seat, adjust the rear seat to the fully back position with the backrest straightened.

(c)

 Installing a carrycot on this seat may prevent the use of one or more of the other seats in this row.

(d)

 Adjust the front passenger seat without height adjuster to the fully back position.

115

Safety

5

(e)

 Installing child seats with a support leg is prohibited in the third row.

(f)

 On some versions, the central seat is not equipped with ISOFIX mountings.

IUF

 Seat suitable for installing a forward-facing ISOFIX Universal seat secured using the upper strap.

IL

 Seat suitable for an ISOFIX Semi-Universal child seat, which may be either:

–  rearward-facing, fitted with an upper strap or a support leg.

–  "forward facing" fitted with a support leg.

–  a carrycot fitted with an upper strap or a support leg.

For more information on

ISOFIX child seats

 and in particular on securing the upper strap, refer to the corresponding section.

i-Size child seats





i-Size child seats have two latches that are anchored to the two rings

A

.

These i-Size child seats also have:

–  either an upper strap that is attached to ring

B

.

–  or a support leg that rests on the vehicle floor, compatible with the approved i-Size seat position.

Their role is to prevent the child seat from tipping forward in the event of a collision.

For more information on the

ISOFIX mountings

, refer to the corresponding section.

Locations for i-Size child seats

In accordance with the new European regulations, this table indicates the options for installing i-Size child seats on seats in the vehicle fitted with i-Size

approved ISOFIX mountings.

Seat position

i-Size child restraint system

Row 1

(a)

Passenger seat

Not i-Size

Row 2

(b) (c) (d)

i-U

Row 3

(b)

Not i-Size

Key

(a)

 Refer to the current legislation in the country in which you are driving before placing a child in this seat position.

(b)

 To install a rearward-facing or forward-facing child seat on a rear seat, adjust the rear seat to the fully back position with the backrest straightened.

116

Safety

(c)

 Adjust the front seat to its maximum height.

(d)

 On some versions, the central seat is not equipped with ISOFIX mountings.

i-U

 Suitable for forward-facing and rearward-facing "Universal" i-Size restraint systems.

i-UF

 Only suitable for forward-facing "Universal" i-Size restraint systems.

Manual child lock









Mechanical system to prevent opening of the

sliding side door using its interior lever.





Locking/Unlocking

►  Rotate the control located on the edge of the

side door

up

 to

lock

 it, or

down

 to

unlock

 it.

Electric child lock









Remote control system to prevent opening of

the rear doors (sliding side door(s), side-hinged

doors or tailgate) using their interior controls.

Activation/Deactivation













►  With the ignition on, press this button to

activate/deactivate the child lock.

When the indicator lamp is on, the child lock is

activated.

Any other status of the indicator lamp

indicates a malfunction of the electric

child lock.

Have it checked by a CITROËN dealer or a

qualified workshop.

With the child lock activated, it is still

possible to open the doors from outside.

This system is independent and in no

circumstances does it take the place of

the central locking control.

Check the status of the child lock each time

you switch on the ignition.

Always keep the electronic key with you when

leaving the vehicle, even for a short time.

In the event of a serious impact, the electric

child lock is switched off automatically to

permit the exit of the rear passengers.

117

Driving

6

Driving recommendations

►  Observe the driving regulations and remain

vigilant whatever the traffic conditions.

►  Monitor your environment and keep your

hands on the wheel to be able to react to

anything that may happen any time.

►  Drive smoothly, anticipate the need for

braking and maintain a longer safety distance,

especially in bad weather.

►  Stop the vehicle before performing operations

that require sustained attention (e.g. settings).

►  During long trips, take a break every 2 hours.

Important!

Never leave the engine running in a

closed space without sufficient

ventilation.

 Internal combustion engines emit

toxic exhaust gases such as carbon

monoxide. Danger of poisoning and death!

In very severe wintry conditions

(temperature below -23°C), let the engine

run for 4 minutes before moving off, to ensure

the correct operation and durability of the

mechanical components of your vehicle

(engine and gearbox).

Never drive with the parking brake

applied

. Risk of overheating and

damaging the braking system!

Never park the vehicle and never

leave the engine running on a

flammable surface (e.g. dry grass, dead

leaves).

The vehicle exhaust system is very

hot, even several minutes after the engine

stops. Risk of fire!

Never drive on surfaces covered with

vegetation (e.g. tall grass,

accumulated dead leaves, crops, debris)

such as a field, a country lane overgrown

with bushes or a grassy verge.

This vegetation could come into contact with

the vehicle's exhaust system or other systems

which are very hot. Risk of fire!

Make sure you do not leave any item in

the passenger compartment which could

act like a magnifying glass under the effect of

the sun's rays and cause a fire. Risk of fire or

damage to interior surfaces!

Never leave the vehicle unattended,

with the engine running

. If you have to

leave your vehicle with the engine running,

apply the parking brake and put the gearbox

into neutral or position

N

 or

P

 (depending on

the type of gearbox).

Never leave children inside the vehicle

unsupervised

.

On flooded roads

We strongly advise against driving on flooded

roads, as this could cause serious damage to the

engine or gearbox, as well as to your vehicle's

electrical systems.





If the vehicle absolutely must drive through a

flooded section of road:

►  Check that the depth of the water does not

exceed 15 cm, taking account of waves that

might be generated by other users.

►  Deactivate the Stop & Start function.

►  Drive as slowly as possible without stalling. In

all cases, do not exceed 6 mph (10 km/h).

►  Do not stop and do not switch off the engine.

On leaving the flooded road, as soon as safety

conditions allow, make several light brake

applications to dry the brake discs and pads.

If in doubt about the state of your vehicle,

contact a CITROËN dealer or a qualified

workshop.

118

Driving

Noise (Electric)

On the outside

Due to the vehicle’s quiet operation when

driving, the driver must pay particular attention.

When manoeuvring, the driver must always

check the vehicle's immediate surroundings.

At speeds of up to 19 mph (30 km/h), the

pedestrian horn warns other road users of the

vehicle’s presence.

Cooling the traction battery

The cooling fan comes on during

charging to cool the on-board charger and the

traction battery.

On the inside

During use, you may hear certain perfectly

normal noises specific to electric vehicles, such

as:

–  Traction battery relay when starting.

–  Vacuum pump when braking.

–  Vehicle tyres or aerodynamics when driving.

–  Jolting and knocking noise during hill starts.

Towing

Driving with a trailer places greater

demands on the towing vehicle and

particular care must be taken.

Do not exceed the maximum towable

weights.

At altitude:

 reduce the maximum load by

10% per 1,000 metres of altitude; the lower

air density at high altitudes decreases engine

performance.

New vehicle:

 do not tow a trailer until the

vehicle has driven at least 620 miles

(1,000 kilometres).

If the outside temperature is high, let the

engine idle for 1 to 2 minutes after the

vehicle comes to a stop, to help it to cool.

Before setting off

Nose weight

►  Distribute the load in the trailer so that the

heaviest items are as close as possible to the

axle and the nose weight (at the point where it

joins your vehicle) approaches the maximum

permitted without exceeding it.

Tyres

►  Check the tyre pressures of the towing

vehicle and of the trailer, observing the

recommended pressures.

Lighting

►  Check the electrical signalling on the trailer

and the headlamp beam height of your vehicle.

If a genuine CITROËN towing device is

used, the rear parking sensors will be

deactivated automatically to avoid the audible

signal.

When driving

Cooling

Towing a trailer uphill causes the coolant

temperature to increase. The maximum towable

load depends on the gradient and the exterior

temperature. The fan’s cooling capacity does not

increase with engine speed.

►  Reduce speed and lower the engine speed to

limit the amount of heating produced.

►  Pay constant attention to the coolant

temperature.

If this warning lamp and the

STOP



warning lamp come on, stop the

vehicle and switch off the engine as soon as

possible.

Brakes

Using the engine brake is recommended to limit

the overheating of the brakes. Braking distances

are increased when towing a trailer.

Side wind

Bear in mind that the vehicle will be more

susceptible to wind when towing.

119

Driving

6

Anti-theft protection

Electronic immobiliser

The remote control contains an electronic chip

which has a special code. When the ignition is

switched on, this code must be recognised in

order for starting to be possible.

A few seconds after switching off the ignition,

this system locks the engine control system,

therefore preventing the engine from being

started in the event of a break-in.

In the event of a fault, you are informed

by illumination of this warning lamp, an

audible signal and a message on the screen.

The vehicle will not start; contact a CITROËN

dealer as soon as possible.

Starting/switching off the

engine

Starting

The parking brake must be applied.

►

With a manual gearbox

, place the gear

lever in neutral, fully depress the clutch pedal

and keep the pedal down until the engine starts.

►

With an automatic gearbox

, place the

selector in position

P

 then depress the brake

pedal.

With the conventional key / With the

remote control key

1. Stop

 position.

2. Ignition on

 position.

3. Starting

 position.

►  Insert the key into the ignition switch. The

system recognises the starting code.

►  Unlock the steering column by simultaneously

turning the steering wheel and the key.

In certain circumstances, you may have

to turn the steering wheel firmly to move

the wheels (if the wheels are against a kerb,

for example).

►  Turn the key to position

2

, Ignition On, to

activate the engine pre-heating system.

►  Wait until this warning lamp goes off in

the instrument panel, then turn the key to

position

3

 without pressing the accelerator pedal,

to operate the starter motor until the engine

starts. As soon as the engine starts, release the

key so it returns to position

2

.

The warning lamp does not come on if

the engine is already warm. In some

climatic conditions, the following

recommendations should be followed:

–  In mild conditions, do not leave the engine

at idle to warm up but move off straight away

and drive at moderate speed.

–  Depending on version, if the air

conditioning is activated and the exterior

temperature exceeds 35 °C, the engine’s

idle speed may increase, up to 1,300 rpm,

depending on the cooling requirements.

–  In wintry conditions, the pre-heater warning

lamp will stay on for a longer period after

switching on the ignition; wait until it goes off

before starting.

– In

very severe wintry

conditions

 (temperature below -23 °C), to

ensure correct operation and durability of your

vehicle’s mechanical components (engine

and gearbox),

leave the engine running for

4 minutes

 before moving off.

Never leave the engine running in an

enclosed area without adequate ventilation:

internal combustion engines emit toxic

exhaust gases, such as carbon monoxide.

Danger of poisoning and death!

120

Driving

With

Petrol engines

, after a cold start,

pre-heating the catalytic converter can

cause noticeable engine vibrations when

stationary, with the engine running, for

anything up to 2 minutes (accelerated idle

speed).

If the engine does not start straight away,

switch off the ignition.

Wait a few seconds before operating the

starter motor again. If the engine does not

start after several attempts, do not keep

trying: you risk damaging the starter motor

and the engine.

Contact a CITROËN dealer or a qualified

workshop.

With the Keyless Entry and Start





►  Place the remote control inside the vehicle, in

the recognition zone.

►  Press the "

START/STOP

" button.

With a manual gearbox, the steering column

unlocks and the engine starts more or less

instantly.

With the EAT8 automatic gearbox, the engine

starts more or less instantly.

The warning lamp does not come on if

the engine is already warm. In some

climatic conditions, it is advised to follow the

recommendations below:

–  In mild conditions, do not leave the engine

to warm up while stationary, but move off

straight away and drive at moderate speed.

–  Depending on version, if the air

conditioning is activated and when the

exterior temperature exceeds 35°C, the idle

engine speed can accelerate up to 1,300

rpm depending on the air conditioning

requirements.

–  In wintry conditions, when the ignition is

switched on, the duration of lighting of the

preheating indicator lamp is extended. Wait

until it goes off before starting the engine.

– In

very severe wintry

conditions

 (temperature below -23°C),

to ensure correct operation and preserve

the lifespan of the vehicle's mechanical

components, engine and gearbox,

leave the

engine running for 4 minutes

 before moving

off.

Never leave the engine running in an

enclosed area without adequate ventilation:

internal combustion engines emit toxic

exhaust gases, such as carbon monoxide.

Danger of poisoning and death!

With

Petrol engines

, after a cold start,

pre-heating the catalytic converter can

cause noticeable engine vibrations when

stationary, with the engine running, for

anything up to 2 minutes (accelerated idle

speed).

For

Diesel vehicles

, when the

temperature is below zero,

starting will only occur once the pre-heating

warning lamp goes off.

If this warning lamp comes on after pressing

the "START/STOP" button, keep the brake

or clutch pedal depressed until the warning

lamp goes off, without pressing the "START/

STOP" button again, until the engine starts

and is running.

The "Keyless Entry and Start" system

remote control must be within the

recognition zone.

Never leave the vehicle with the engine

running and with the remote control on your

person.

If the remote control leaves the recognition

zone, a message is displayed.

Move the remote control into the zone in

order to be able to start the engine.

If one of the starting conditions is not

met, a message is displayed on the

instrument panel. In some circumstances, you

121

Driving

6

must turn the steering wheel while pressing

the "START/STOP" button to assist unlocking

of the steering column. A message is

displayed.

Switching off

►  Immobilise the vehicle, with the engine at

idle.

►  With a manual gearbox, ideally put the gear

lever into neutral.

►  With an automatic gearbox, ideally select

position

P

.

With the conventional key/With the

remote control key

►  Turn the key all the way to position

1 (Stop)



and remove it from the ignition.

►  To lock the steering column, turn the steering

wheel until it locks.

To facilitate unlocking of the steering

column, it is recommended that the

wheels be returned to the straight ahead

position before switching off the engine.

►  Check that the parking brake is correctly

applied, particularly on sloping ground.

Never switch off the ignition before the

complete immobilisation of the vehicle.

With the engine off, the braking and steering

assistance systems are also turned off: risk of

loss of control of the vehicle.

As a safety measure, never leave the

vehicle without taking the remote control

with you, even for a short time.

Avoid attaching heavy objects to the key

or the remote control, which would weigh

down on its blade in the ignition switch and

could cause a malfunction.

Key left in the ignition

When opening the driver's door, an alert

message is displayed, accompanied by

an audible signal, to remind you that the key

is still in the ignition switch at position

1

(Stop)

.

If the key has been left in the ignition switch

at position

2 (Ignition on)

, the ignition will be

switched off automatically after one hour.

To switch the ignition back on, turn the key

to position

1 (Stop)

, then back to position

2

(Ignition on)

.

With Keyless Entry and Start

►  With the remote control in the recognition

zone, press the "

START/STOP

" button.

With a manual gearbox, the engine stops and

the steering column locks.

With the EAT8 automatic gearbox, the engine

stops.

If the vehicle is not immobilised, the

engine will not stop.

To avoid any risk of jamming the pedals:

–  only use mats which are suited to the

fixings already present in the vehicle; these

fixings must be used,

–  never place one mat on top of another.

The use of mats not approved by CITROËN

may interfere with access to the pedals and

hinder the operation of the cruise control /

speed limiter.

The mats approved by CITROËN have two

fixings located below the seat.

Starting/Switching off the

electric motor

Starting

The drive selector must be in mode

P

.

►  If using a conventional or remote control

key, depress the brake pedal and turn the key

to position

3

 until the motor starts, without

depressing the accelerator. As soon as the motor

starts, release the key so it returns to position

2

.

►  If using Keyless Entry and Start, depress the

brake pedal and briefly press the "

START/STOP

"

button.

►  Keep your foot on the brake pedal until the

READY

 indicator lamp comes on and an audible

signal is emitted, indicating that the vehicle is

ready to drive.

122

Driving

►  With your foot on the brake, select mode

D



or

R

.

►  Release the brake pedal, then accelerate.

On starting, the instrument panel lights up and

the power indicator cursor moves to the "neutral"

position. The steering column automatically

unlocks (you may hear a sound and feel the

steering wheel move).

Switching off

►  If using a conventional or remote control

key, turn the key fully to position

1 (Stop)

.

►  If using Keyless Entry and Start, press the

"

START/STOP

" button.

Before exiting the vehicle, check that:

–  The drive selector is in mode

P

.

– The

READY

 indicator lamp is off.

The drive selector moves automatically

to mode

P

 when the motor is switched off

or when the driver's door is opened.

If the driver's door is opened while the

required conditions for switching off are

not met, an audible signal is emitted,

accompanied by the display of a warning

message.

Special case with Keyless

Entry and Start

Switching on the ignition with

Keyless Entry and Start





With the "Keyless Entry and Start"

electronic key inside the vehicle, pressing

the "

START/STOP

" button,

without depressing

any of the pedals

, allows the ignition to be

switched on.

►  Press this button again to switch off the

ignition and allow the vehicle to be locked.

Back-up starting

A back-up reader is fitted to the steering column,

to enable the engine to be started if the system

fails to detect the key in the recognition zone, or

if the battery in the electronic key is flat.





►  Place and hold the remote control against the

back-up reader.

►

With a manual gearbox

, place the gear lever

in neutral, then fully depress the clutch pedal.

►

With an automatic gearbox or a drive

selector

, select mode

P

, then depress the brake

pedal.

►  Press the "

START/STOP

" button.

The engine starts.

Remote control not recognised

with Keyless Entry and Start

If the remote control is no longer in the

recognition zone, a message appears on the

instrument panel when closing a door or trying to

switch off the engine.

►  Press the "

START/STOP

" button for about

3 seconds to confirm switching off the engine,

then contact a CITROËN dealer or a qualified

workshop.

Forced switch-off with Keyless Entry

and Start

In case of emergency only, the engine can be

switched off without conditions (even when

driving).

123

Driving

6

►  To do this, press and hold the "

START/

STOP

" button for about 5 seconds.

In this case, the steering column locks as soon

as the vehicle stops.

"Key off" mode

"

Key off

" mode allows you to lock the vehicle

while leaving the engine running without the

key or Keyless Entry and Start being inside the

vehicle.

This mode allows electrical devices to continue

operating to ensure thermal comfort, vehicle

security and operation of the vehicle systems

needed for the task.







KEY

OFF



►  To activate or deactivate this mode, press this

button (the button's indicator lamp is on when

the mode is activated).

With an electric motor, this mode remains

active for about 10 minutes after the

vehicle is locked.

Manual parking brake

Application

►  With your foot on the brake pedal, pull

the parking brake lever up to immobilise your

vehicle.

Release on level ground

►  With your foot on the brake pedal, pull the

parking brake lever up gently, press the release

button, then lower the lever fully.

When the vehicle is being driven, this

warning lamp coming on, accompanied

by an audible signal and a message, indicates

that the parking brake is still applied or has not

been fully released.

When parking on a slope or on a steep

slope with a loaded vehicle, turn the

wheels against the kerb then apply the

parking brake.

Pressing the brake pedal facilitates the

application and release of the manual

parking brake.

With a manual gearbox, engage a gear

and then switch off the ignition.

With an automatic gearbox, place the

gear selector in position

P

, then switch

off the ignition.

Electric parking brake

In automatic mode, this system applies the

parking brake when the engine is switched off

and releases it when the vehicle moves off.









At any time, with the engine running:

►  To apply the parking brake, briefly pull the

control.

►  To release it, briefly push the control while

pressing the brake pedal.

Automatic mode is activated by default.

This automatic operation can be deactivated in

certain situations.

Indicator lamp

This indicator lamp comes on both on the

instrument panel and on the control to

confirm that the parking brake has been applied,

accompanied by display of the message

"

Parking brake applied

".

The indicator lamp goes out to confirm the

release of the parking brake, accompanied by

the display of the message "

Parking brake

released

".

124

Driving

The indicator lamp flashes in response to a

manual request to apply or release the brake.

In the event of a battery failure, the

electric parking brake will not operate.

As a safety measure, with a manual gearbox,

if the parking brake is not applied, immobilise

the vehicle by engaging a gear.

As a safety measure, with an automatic

gearbox or drive selector, if the parking brake

is not applied, immobilise the vehicle by

placing the supplied chock against one of the

wheels.

Contact a CITROËN dealer or a qualified

workshop.





Before leaving the vehicle, check that the

parking brake is applied: the parking

brake indicator lamps on the instrument panel

and the control must be on fixed.

If the parking brake is not applied, there is an

audible signal and a message is displayed on

opening the driver's door.

Never leave a child alone inside the

vehicle, as they could release the parking

brake.

When the vehicle is parked: on a

steep slope, heavily loaded or during

towing

With a manual gearbox, turn the wheels

toward the pavement and engage a gear.

With an automatic gearbox or a drive selector,

turn the wheels toward the pavement and

select mode

P

.

When towing, the vehicle is approved for

parking on slopes of up to 12%.

Manual operation

Manual release

With the ignition on or engine running:

►  Press the brake pedal.

►  While maintaining pressure on the brake

pedal, briefly push the control.

If the brake pedal is not depressed, the

parking brake is not released and a

message is displayed.

Manual application

With the vehicle stationary:

►  Briefly pull the control.

The control indicator lamp flashes to confirm the

application request.

Automatic operation

Automatic release

First ensure that the engine is running and that

the driver's door is closed.

The electric parking brake gradually releases

automatically as the vehicle moves off.

With a manual gearbox

►  Fully depress the clutch pedal and engage

first gear or reverse.

►  Depress the accelerator pedal and release

the clutch pedal.

With an automatic gearbox

►  Depress the brake pedal.

►  Select position

D

,

M

 or

R

.

►  Release the brake pedal and depress the

accelerator pedal.

With a drive selector

►  Depress the brake pedal.

►  Select mode

D

,

B

 or

R

.

►  Release the brake pedal and depress the

accelerator pedal.

With an automatic gearbox or drive

selector, if the brake does not release

automatically, check that the front doors are

properly closed.

When stationary with the engine running,

do not depress the accelerator pedal

unnecessarily. Risk of parking brake release.

125

Driving

6

Automatic application

With the vehicle stationary, the parking brake

is applied automatically when the engine is

switched off.

It is not applied automatically if the

engine stalls or enters STOP mode with

Stop & Start.

In automatic mode, the parking brake

can be manually applied or released at

any time using the control.

Special cases

Immobilising the vehicle with the

engine running

To immobilise the vehicle with the engine

running, briefly pull the control.

Parking the vehicle with the brake

released

In very cold conditions (ice), applying the

parking brake is not recommended.

To immobilise the vehicle, engage a gear or

place the chocks against one of the wheels.

With an automatic gearbox or drive

selector, mode

P

 is automatically

selected when the ignition is switched off. The

wheels are blocked.

For more information on

Free-wheeling

, refer

to the corresponding section.

With an automatic gearbox or a drive

selector, if you open the driver's

door while mode

N

 is engaged, an audible

signal will sound and mode

P

 will be

engaged. The audible signal stops when the

driver's door is closed.

Deactivating automatic

operation

In some situations, for example when it is

extremely cold or when towing (e.g. caravan,

breakdown), it may be necessary to deactivate

automatic operation of the system.

►  Start the engine.

►  Use the control to apply the parking brake, if

it is released.

►  Take your foot fully off the brake pedal.

►  Keep the control pushed in the release

direction for 10 to a maximum of 15 seconds.

►  Release the control.

►  Depress and hold the brake pedal.

►  Pull the control in the application direction for

2 seconds.

This indicator lamp on the instrument

panel comes on to confirm deactivation of

the automatic functions.

►  Release the control and the brake pedal.

From this point onwards, only the manual

functions, using the control, allow the parking

brake to be applied and released.

►  Follow this procedure again to reactivate

automatic operation (confirmed by the indicator

lamp on the instrument panel going out).

Emergency braking

If depressing the brake pedal fails to provide

effective braking or in exceptional circumstances

(e.g. driver unwell, assisted driving), the vehicle

can be braked by sustained pulling on the

electric parking brake control. Braking continues

for as long as the control is kept pulled, and

ceases when the control is released.

The ABS and DSC systems stabilise the vehicle

during emergency braking.

If emergency braking malfunctions, the message

"

Parking brake fault

" will be displayed on the

instrument panel.

If the ABS and DSC systems

malfunction, indicated by lighting

one or both warning lamps on the instrument

panel, the vehicle’s stability is no longer ensured.

►  In this case, ensure the vehicle's stability by

successive and repeated "pull-release" actions

on the electric parking brake control until the

vehicle comes to a complete stop.

126

Driving

Hill start assist

This system keeps the vehicle briefly stationary

(for approximately 2 seconds) when making a hill

start, while you transfer your foot from the brake

pedal to the accelerator pedal.

The system is only active when:

–  The vehicle is completely stationary, with your

foot on the brake pedal.

–  Certain slope conditions are met.

–  The driver’s door is closed.

Do not leave the vehicle while it is being

held temporarily by hill start assist.

If someone needs to get out of the vehicle

with the engine running, apply the parking

brake manually. Then check that the parking

brake indicator lamp and the

P

 indicator lamp

in the electric parking brake control are on

fixed.

The hill start assist function cannot be

deactivated. However, using the parking

brake to immobilise the vehicle interrupts its

operation.

Operation





Facing uphill, with the vehicle stationary,

the vehicle is held for a short time when the

driver releases the brake pedal:

–  If first gear or neutral is engaged on a manual

gearbox.

–  If mode

D

 or

M

 is selected on an automatic

gearbox.

–  If mode

D

 or

B

 is selected on the drive

selector.





Facing downhill, with the vehicle stationary

and reverse gear engaged, the vehicle is held

for a short time when the driver releases the

brake pedal.

Malfunction

If the event of a malfunction, these

warning lamps light up on the

instrument panel, accompanied by the display of

a message.

Have it checked by a CITROËN dealer or a

qualified workshop.

5-speed manual gearbox

Engaging reverse gear





►  With the clutch pedal fully depressed, you

must place the gear lever in neutral.

►  Move the gear lever to the right, then pull it

back.

Only engage reverse gear when the

vehicle is stationary with the engine at

idle.

As a safety precaution and to facilitate

engine starting:

–  always select neutral,

–  depress the clutch pedal.

127

Driving

6

6-speed manual gearbox

Engaging 5

th

 or 6

th

 gear

►  Move the gear selector fully to the right to

engage 5

th

 or 6

th

 gear.

Failure to follow this instruction could

cause permanent damage to the gearbox

(inadvertent engagement of 3

rd

 or 4

th

 gear).

Engaging reverse gear





►  Raise the ring under the knob and move the

gear lever to the left, then forwards.

Only engage reverse gear when the

vehicle is stationary with the engine at

idle.

As a safety precaution and to facilitate

engine starting:

–  always select neutral,

–  depress the clutch pedal.

Automatic gearbox (Type

1)

8-speed automatic gearbox which offers a choice

between the comfort of automatic operation or

manual gear changing.

Two driving modes are available:

–

Automatic

 operation for electronic

management of the gears by the gearbox:

–

Manual

 operation for sequential changing of

the gears by the driver.

In automatic mode, you can still change gear

manually using the steering-mounted controls

(e.g. when overtaking).

Gear selector

To turn the gear selector in complete

safety, it is recommended that you keep

your foot on the brake pedal.

P.

Park.

R.

Reverse.

N.

Neutral.

D.

Drive (automatic operation).

M.

Manual (manual operation with sequential

changing of the gears).

Position

N

 can be used in traffic jams or

in a car wash tunnel.

Steering mounted controls





►  Pull the right-hand "

+

" or left-hand "

-

" control

paddle towards you to change up or down.

128

Driving

The steering mounted controls do not

allow neutral to be selected and reverse

gear to be engaged or disengaged.

Information displayed on

the instrument panel

When you move the selector or press button

M

,

the corresponding gear and indicator lamp are

shown on the instrument panel.

The "

-

" symbol is displayed if a value is invalid.

►  If the message "

Foot on the brake

" is

displayed on the instrument panel, press

the brake pedal firmly.

Starting the vehicle

►  With your foot on the brake, select

position

P

.

►  Start the engine.

If the conditions are not met, there is an audible

signal, accompanied by a message on the

instrument panel screen.

►  Release the parking brake, unless it is set to

automatic mode (with electric parking brake).

►  Select position

R

,

N

 or

D

.

If you are setting off from a steep slope

with a loaded vehicle,

depress the

brake pedal

, select position

D

, release the

parking brake, unless it is set to automatic

mode (with electric parking brake), then

release the brake pedal.

►  Gradually release the brake pedal.

Or

►  Accelerate gradually in order to release the

electric parking brake (if it is set to automatic

mode).

The vehicle moves off immediately.

If

P

 is displayed on the instrument panel

but the selector is in another position,

place the selector in position

P

 to allow the

engine to be started.

If position

N

 is selected inadvertently while

driving, allow the engine to return to idle, then

select position

D

 to accelerate.

When the engine is running at idle with

the brakes released, if position

R

,

D

 or

M



is selected, the vehicle moves even without

the accelerator being pressed.

Never leave children inside the vehicle

unsupervised.

As a safety measure, never leave the vehicle

without taking your key or remote control with

you, even for a short time.

When carrying out maintenance with the

engine running, apply the parking brake and

select position

P

.

With an automatic gearbox, never try to

start the engine by pushing the vehicle.

Automatic operation

►  Select position

D

 for

automatic



changing of the gears.

The gearbox then operates in auto-adaptive

mode, without any intervention on the part of the

driver. It continuously selects the most suitable

gear according to the driving style, the road

profile and the load in the vehicle.

►  For maximum acceleration without

touching the selector, fully depress the

accelerator pedal (kick-down).

The gearbox changes down automatically or

holds the gear selected until the maximum

engine speed is reached.

When braking, the gearbox changes down

automatically to provide effective engine braking.

If you release the accelerator sharply, the

gearbox will not shift to a higher gear for safety

reasons.

Never select position

N

 while the vehicle

is moving.

Never select positions

P

 or

R

 unless the

vehicle is completely stationary.

Temporary manual control

of gear changes

You can temporarily assume control of gear

changing using the "

+

" et "

-

” steering-mounted

controls. The gear change request will be

executed if the engine speed permits.

129

Driving

6

This function allows you to anticipate certain

situations, such as overtaking another vehicle or

approaching a bend in the road.

After a few seconds with no inputs via the control

paddles, the gearbox reverts to automatic

operation.

Creeping (moving without

using the accelerator)

This function facilitates manoeuvring of the

vehicle at low speed (when parking, in traffic

jams, etc.).

When the engine is at idle, with the parking

brake released and gear position

D

,

M

 or

R



selected, the

vehicle begins to creep forward



as soon as you take your foot off the brake pedal

(even without pressing the accelerator).

As a safety precaution, never leave the

vehicle with the engine running and the

doors closed.

Manual operation

►  With the selector in position

D

, press

button

M

 to enable 6-speed

sequential



gear changing.

The indicator lamp for the button comes on.

►  Operate the "

+

" or "

-

" steering mounted

controls.

M

 appears and the engaged gears are

shown in succession on the instrument

panel.

►  You can revert to automatic operation at any

time by pressing button

M

 again.

The indicator lamp for the button goes off.

In manual mode, there is no need to

release the accelerator pedal while

changing gear.

It is only possible to change from one

gear to another if the vehicle speed and

engine speed permit.

If the engine speed is too low or too high,

the selected gear flashes for a few

seconds, then the gear actually engaged is

shown.

When the vehicle is stationary or moving very

slowly, the gearbox automatically selects gear

M1

.

To preserve the brakes while descending

a steep incline, use engine braking to

reduce your speed (change down or select a

lower gear).

Keeping the brake pedal pressed

continuously for long periods can overheat

the brakes, with the risk of damaging the

braking system or making it inoperative.

Only use the brakes when necessary, to slow

or stop the vehicle.

Depending on the road configuration

(e.g. mountainous road), manual

operation may be preferable.

Automatic operation may not always be

suitable, and does not enable engine braking.

Invalid value during manual

operation

This symbol is displayed if a gear is not

engaged correctly (gear selector between

two positions).

►  Place the selector "correctly" at a position.

Switching off the vehicle

Before switching off the engine, select position

P

 then apply the parking brake to immobilise

the vehicle, unless this is set to automatic mode

(with electric parking brake).

Check that mode

P

 has been engaged and that

the electric parking brake has been applied

automatically; if not, apply it manually.

The corresponding indicator lamps in the

selector and the electric parking brake control

lever must be on, as well as those on the

instrument panel.

A point of resistance may be noticed

when moving to position

P

.

If the selector is not in position

P

, when the

driver's door is opened or approximately 45

seconds after the ignition is switched off,
