50

Ease of use and comfort

General

recommendations for the

seats

For safety reasons, seat adjustments

must only be made when the vehicle is

stationary.

Folding or unfolding the seat backrests

must only be done with the vehicle

stationary.

Before moving the seat backwards,

ensure that there is no person or object

that might prevent the full travel of the seat.

There is a risk of trapping or pinching

passengers if present in the rear seats or of

jamming the seat if large objects are placed

on the floor behind the seat.

Do not place hard or heavy objects on

the backrests forming a table. They could

become dangerous projectiles in the event of

sudden braking or a collision.

–  Do not remove a head restraint without

stowing it; secure it to a support inside the

vehicle.

–  Check that the seat belts remain accessible

to the passenger and easy to fasten.

–  Passengers must never take their seat

without adjusting and fastening their seat belt.

–  In row 3, be careful not to leave your feet

under the row 2 seat while it is being tilted.

–  When a row 3 seat is in the fully folded

position, ensure that the strap is correctly

hooked to the Top Tether fixing of the row 2

backrest: risk of unexpected tipping of the

seat.

Before carrying out the manoeuvres,

check that nothing and no one is

obstructing the moving elements and their

locking.

To avoid sudden folding, take care to hold the

backrest and support it until it is horizontal.

Never

 put your hand underneath the seat

cushion to guide the seat downwards or

upwards, you could get your fingers trapped.

Place your hand on the grip/strap (depending

on equipment) at the top of the seat cushion.

Please note: an incorrectly latched

backrest compromises the safety of

passengers in the event of sudden braking or

an impact.

The contents of the boot may be thrown

forward - risk of severe injury!

Front seats

Correct driving position

Before taking to the road and to make the most

of the ergonomic layout of the instruments and

controls, carry out these adjustments in the

following order:

–  head restraint height.

–  seat backrest angle.

–  seat cushion height.

–  longitudinal seat position.

–  steering wheel height and reach.

–  rear view mirror and door mirrors.





Once these adjustments have been

made, check that the instrument panel

can be viewed correctly from your driving

position.

51

Ease of use and comfort

3

Adjustments

Longitudinal





►  Raise the control and slide the seat forwards

or backwards.

Height

(driver only)





►  If fitted to the vehicle, pull the control

upwards to raise or push it downwards to lower,

as many times as necessary to obtain the

position required.

For more information on the

Seat belts

,

refer to the corresponding section.

Tilting the backrest





►  Push the control backwards then use your

weight and your legs to adjust the backrest.

Lumbar

(driver only)





►  Turn the knob to obtain the desired level of

lumbar support.

Armrest









►  To put the armrest in the vertical position,

raise it until it locks into place.

►  Lower the armrest to return it to the position

for use.

The armrest can be removed from the passenger

seat.

Removing the armrest

►  Raise the armrest into the vertical position.





►  Push the armrest shaft towards the backrest.

►  While holding it in this position, rotate the

armrest towards the rear.

►  Pull the armrest to detach it from the

backrest.

Refitting the armrest



52

Ease of use and comfort



►  Slot the armrest into the backrest, ensuring

that you align the bayonet lugs with the holes.

►  Push the armrest shaft towards the backrest.

►  While holding it in this position, rotate the

armrest towards the front. The armrest is once

again secured onto the backrest.

Storage compartment under

the seat









►  Lift the passenger’s seat cushion to access

the storage compartment.

Retractable position









►  If the centre console inconveniences you,

remove the passenger's seat armrest.

►  Push the control rearwards fully to tilt and

guide the assembly.

This position allows you to transport long loads

inside the vehicle with the doors closed.

When retracted, the maximum permitted weight

on the backrest is 50 kg.

►  To reposition the seat cushion, raise the

backrest until it locks in the raised position.

Heated seat control









►  Approximately 30 seconds after starting the

engine, press the control.

It can be activated when the outside temperature

is below 20°C.

The temperature is controlled automatically.

Pressing again interrupts operation.

If you press the control while the engine

is not running, the request will be

memorised for approximately 2 minutes.





With the two-seat front bench seat, the driver's

seat control switches the heating on or off for the

bench seat’s outer seat.

Do not use the function when the seat

is not occupied.

Reduce the heating intensity as soon as

possible.

When the seat and passenger compartment

have reached a satisfactory temperature,

53

Ease of use and comfort

3

switch the function off; reducing electrical

consumption in turn decreases energy

consumption.

Prolonged use of heated seats is not

recommended for people with sensitive

skin.

There is a risk of burns for people whose

perception of heat is impaired (e.g. illness,

taking medication).

To keep the heated pad intact and to prevent

a short circuit:

–  Do not place heavy or sharp objects on the

seat.

–  Do not kneel or stand on the seat.

–  Do not spill liquids onto the seat.

–  Never use the heating function if the seat

is damp.

Steering wheel

adjustment





►

When stationary

, pull the control lever to

release the steering wheel.

►  Adjust the height and reach.

►  Lower the control lever to lock the steering

wheel.

As a safety precaution, these operations

must only be carried out while the vehicle

is stationary.

Mirrors

Door mirrors

Adjustment





►  Move control

A

 or turn control

C

 (depending

on the version you have) to the right or to the left

to select the corresponding mirror.

►  Move control

B

 or

 C

 (depending on the

version you have) in any of the four directions to

adjust.

►  Return control

A

or

 C

(depending on the

version you have) to its centre position.

As a safety measure, the mirrors should

be adjusted to reduce the blind spots.

The objects observed are, in reality, closer

than they appear.

Take this into account when assessing the

distance of vehicles approaching from behind.

54

Ease of use and comfort

Manual folding

You can manually fold the mirrors (parking

obstruction, narrow garage, etc.)

►  Turn the mirror towards the vehicle.

Electric folding

Depending on equipment, the door mirrors can

be folded electrically.

►  From the inside, with the

ignition on, place control

A

 in the

central position.

►  Pull control

A

 backwards.

►  Lock the vehicle from the outside.

If the mirrors are folded using control

A

,

they will not unfold when the vehicle is

unlocked.

Electric unfolding

The door mirrors are unfolded electrically when

the vehicle is unlocked using the remote control

or key. Unless folding was selected with control

A

, pull the control in the central position towards

the rear again.

Folding/unfolding when locking/unlocking

the vehicle can be deactivated. Contact a

CITROËN dealer or a qualified workshop.

If necessary, the mirrors can be folded

manually.

Heated mirrors









►  Press one of these buttons.

For more information on

Rear screen

demisting/de-icing

, refer to the

corresponding section.

Interior rear view mirror

Equipped with an anti-dazzle system, which

darkens the mirror glass and reduces the

nuisance to the driver caused by the sun,

headlamps of other vehicles, etc.

Manual model

Day/night position





►  Pull the lever to change to the anti-dazzle

"night" position.

►  Push the lever to change to the normal "day"

position.

Adjustment

►  Adjust the mirror to the normal "day" position.

Automatic "electrochrome" model

The electrochrome system uses a sensor that

detects the level of exterior brightness and that

coming from the rear of the vehicle, in order to

automatically and gradually switch between day

and night usage.

To ensure optimum visibility while

manoeuvring, the mirror automatically

brightens when reverse gear is engaged.

The system is deactivated if the load in the

boot exceeds the height of the load space

cover or if the load space cover has items

placed on it.

Child-monitoring mirror









55

Ease of use and comfort

3

A child-monitoring mirror is installed above

the interior rear view mirror. It allows the

vehicle's rear passengers to be observed and

facilitates discussion between the front and rear

passengers without changing the mirror setting

and without turning around. It can be folded

easily to avoid dazzle.

2-seat front bench seat





Central seat

Table position





►  To lower the backrest, pull the tab on the

lower edge of the seat.





The backrest of the central seat of the bench

seat tilts to form a work table, creating a mobile

office (for use while stationary).





The vehicle may also be fitted with a pivoting

table.

►  To return the backrest to the sitting position,

stow the table, then guide it until it locks.

Take care not to jam the tab under the seat

cushion while moving the backrest.





Never use the table while the vehicle is

being driven.

In the event of sudden braking or impact, any

objects on the table might become dangerous

projectiles that could cause injury.

Storage compartment under seats





►  Lift the central seat to access the storage

compartment. This space can be secured by

fitting a padlock (not supplied).

Each time you lock the seat in the sitting

position, make sure that passengers

have access to the seat belt end pieces and

the associated straps.

56

Ease of use and comfort

Side seat

Retractable position





►  Pull the tongue on the top edge of the seat

near the head restraint to tilt and guide the

assembly.

It is placed in the floor of the front seat and thus

forms a continuous flat floor with the loading

space.

This position allows transporting long cargo

inside the vehicle with the doors closed.

When retracted, the maximum weight on the

backrest is 50 kg.

To replace the seat, lift the backrest until the seat

locks into position on the floor.

Never

 put your hand underneath the seat

cushion to guide the seat downwards or

upwards, you could get your fingers trapped.

Always just use the strap.

Before carrying out these manoeuvres, check

that nothing and nobody is obstructing the

moving elements and their locking.

Folded position





►  Lift the yellow crank at the base of the seat to

unlock and lift the assembly into folded position

(seat raised against the backrest) until it locks.

This position allows the transport of high loads

inside the cab.

To replace the seat, push on the yellow crank

under the seat and lower the assembly until the

seat locks into position on the floor.

Never

 put your hand underneath the seat

cushion to guide the seat downwards or

upwards, you could get your fingers trapped.

Place your hand on the front of the seat

cushion.

Before carrying out these manipulations,

check that nothing and nobody is obstructing

the moving elements and their locking.

Rear bench seat (row 2)

For safety reasons, seat adjustments

must only be made when the vehicle is

stationary.

Folding the backrests

First steps:

►  lower the head restraints,

►  if necessary, move the front seats forward,

►  check that nothing or no person might

interfere with the folding of the backrests

(clothing, luggage, etc.),

►  check that the outer seat belts are lying flat

on the backrests.

The folding of the backrest is

accompanied by a slight lowering of the

corresponding seat cushion.

When the backrest is released, the red

indicator is visible in the release grips on the

outer seats.





►  Turn the backrest release handle

1

.

57

Ease of use and comfort

3

►  Guide the backrest down to the horizontal

position.

Repositioning the backrests

First check that the outer seat belts are

lying vertically flat alongside the backrest

latching rings.

►  Put the backrest in the upright position and

push it firmly to latch it home.

►  Check that the red indicator in the release

grip

1

 is no longer visible.

►  Ensure that the outer seat belts are not

trapped during the manoeuvre.

Rear seats (row 2)





Folding the backrests

First steps:

►  lower the head restraints,

►  if necessary, move the front seats forward,

►  check that nothing or no person might

interfere with the folding of the backrests

(clothing, luggage, etc.),

►  check that the outer seat belts are lying flat

on the backrests.

The folding of the backrest is

accompanied by a slight lowering of the

corresponding seat cushion.

When the backrest is released, the red

indicator is visible in the release grips on the

outer seats.

Outer seat (left-hand or right-hand)





►  Turn the backrest release handle

1

.

►  Guide the backrest down to the horizontal

position.

Central seat





►  Pull the backrest release tab

1

.

►  Guide the backrest down to the horizontal

position.

With the central seat, only the strap must

be used.

Repositioning the backrests

Outer seat (left-hand or right-hand)

First check that the outer seat belts are

lying vertically flat alongside the backrest

latching rings.

►  Put the backrest in the upright position and

push it firmly to latch it home.

►  Check that the red indicator on the release

grips

1

 of the outer seats is no longer visible.

►  Ensure that the outer seat belts are not

trapped during the manoeuvre.

Check that the backrest of the upright

central seat is correctly aligned with the

backrests of the outer seats.

Central seat

►  Put the backrest in the upright position and

push it firmly to latch it home.

►  Check that the central seat belt is not trapped

during the manoeuvre.

Rear seats (row 3)





58

Ease of use and comfort

Access to row 3





►  Using the row 2 seat grip, fold the backrest.

►  To reposition it, tilt the backrest backwards

until it locks into place.

Labels in row 3









While driving, it is prohibited to have a

passenger seated next to a seat in the fully

folded position.





If you want to load luggage onto the row 3

backrests while in the table position, the row 2

seats must also be folded down.

Longitudinal adjustment

XL





►  Raise the control and slide the seat forwards

or backwards.

Table position

Placing the backrest in the table position

►  Lower the head restraint as far as it will go.





►  Operate control

1

 to fold the backrest onto

the seat cushion.

Repositioning the backrest

►  Unlock it by pulling control

1

.

►  Return it to its initial position

►  Check that the assembly is anchored

properly.

Fully folded position

XL

Placing the seat in the fully folded position

►  Place the backrest in the table position.



59

Ease of use and comfort

3







►  Lift the bar

2

, located behind the seat, to

release the feet of the seat from their anchorage

in the floor.

►  Tilt the entire seat forwards.

►  Hook the strap

3

 on the row 2 head restraint

rod.

Returning the seat to the sitting position

►  Fold the entire seat backwards.

►  Check that the seat belt is not trapped during

the manoeuvre.

Removing the seat

►  Lower the head restraint as far as it will go.

►  Place the seat in the fully folded position.





►  Pull on the strap

3

 to open the seat

anchorages.

►  While still holding the strap

3

, lift the seat.

Refitting the seat

►  Pull on the strap

3

 to open the seat

anchorages.

►  While still holding the strap

3

, place them in

the anchorage points on the floor.

►  Release the strap

3

.

►  Ensure that no object or feet are obstructing

the rear anchorage points

4

 and that the seat

belt is correctly positioned and available.

►  Fold the seat backwards to fix its rear

anchorage feet.

►  Use the control

1

 to lift the backrest to its

original position.

►  Raise the head restraint.

Head restraint height

adjustment





►  To raise it, pull it upwards as far as possible

(notch).

►  To remove it, press the lug

A

 and pull it

upwards.

►  To put it back in place, engage the head

restraint rods in the openings keeping them in

line with the seat backrest.

►  To lower it, press the lug

A

 and push down on

the head restraint at the same time.

The head restraint has a frame with

notches which prevents it from lowering;

this is a safety device in case of impact.

The adjustment is correct when the upper

edge of the head restraint is level with the

top of the head.

Never drive with the head restraints removed;

they must be fitted and correctly adjusted.

60

Ease of use and comfort

Never drive with passengers seated at

the rear when the head restraints are

removed or not in the high position; the head

restraints must be in place and in the high

position.

For more information on the

Seat belts

,

refer to the corresponding section.

Interior fittings

Mats

Fitting





When fitting it on the driver's side, only use the

mountings present on the carpet.

The other mats are simply laid over the carpet.

Removing/refitting

►  To remove it on the driver's side, move

the seat as far back as possible and give the

fasteners a quarter turn.





►  To refit it, position the mat and replace the

fasteners, giving them a quarter turn.

►  Check that the mat is secured correctly.

To avoid any risk of jamming the pedals:

–  Only use mats which are suited to the

fixings already present in the vehicle; these

fixings must be used.

–  Never fit one mat on top of another.

The use of mats not approved by CITROËN

may interfere with access to the pedals and

hinder the operation of the cruise control/

speed limiter.

The approved mats have two fasteners

located underneath the seat.

Overhead storage unit









This compartment, located above the sun visors,

can be used to store various objects.

Roof and roof storage





Overhead storage compartment and

central storage compartment





The overhead storage compartment

(1)

 is

located above the sun visors and can be used to

store miscellaneous objects.

There is a storage space

(2)

 located in the roof

lining.

The maximum permitted load is 6 kg.

61

Ease of use and comfort

3

In the event of sharp deceleration,

objects placed in the central storage

compartment of the roof may be transformed

into projectiles.

Rear storage compartment

This compartment is accessible from the rear

seats and from the vehicle's boot.

It has a capacity of 60 litres and the maximum

permitted load is 10 kg.





►  To open it from the rear seats, slide the rear

storage compartment shutters.





►  To open it from the vehicle’s boot, place your

thumb on the boot recess then pull the handle.

Open the rear storage compartment with

care, to prevent any objects stored inside

from falling out.

Light ambience

The light ambience settings are

changed via

the

Driving

/

Vehicle

 touch screen menu.

Blind

Opening/Closing









►  Press and hold the button; the blind opens/

closes, stopping when the button is released.

If the blind becomes trapped while

moving, reverse its movement. To do

this, press the relevant control.

When pressing the button to open/close the

blind, the driver must ensure that nothing and

no one might interfere with its movement.

The driver must ensure that passengers use

the blind correctly.

Pay particular attention to children when

operating the blind.

12 V accessory socket(s)





►  Plug in a 12 V accessory (with a maximum

rated power of 120 W) using a suitable adapter.

Observe the maximum power rating to

avoid damaging the accessory.

The connection of an electrical device

not approved by CITROËN, such as a

USB charger, may adversely affect the

operation of vehicle electrical systems,

causing faults such as poor radio reception or

interference with displays in the screens.

62

Ease of use and comfort

USB socket(s)





Socket

1

 enables audio files sent to your audio

system to be played through the vehicle's

speakers.

When the USB socket is used, the

portable device charges automatically.

While charging, a message is displayed if the

power drawn by the portable device exceeds

the current supplied by the vehicle.

For more information about how to use this

equipment, refer to the sections describing

the audio and telematics systems.

* Only on the Citroën Berlingo Van.

Socket

1

 allows a

smartphone to be

connected by Android Auto

®

 or CarPlay

®

,

enabling certain smartphone applications to be

used on the touch screen.

Sockets

1

 and

2

* allow a portable device to be

connected in order to charge it.

For best results, use a cable made or approved

by the device manufacturer.

These applications can be managed using the

steering-mounted controls or the audio system

controls.

220 V/50 Hz socket







AC 220V

50Hz

120W



It is located on the side of the central storage

compartment.

This socket (max. power: 150 W) operates with

the engine running, and with the Stop & Start

system in STOP mode.

►  Lift the protective cover.

►  Check that the green indicator lamp is on.

►  Connect your multimedia or other electrical

device (telephone charger, laptop computer,

CD-DVD player, bottle warmer, etc.).

In the event of a malfunction, the

green indicator lamp flashes.

Have the socket checked by a CITROËN dealer

or a qualified workshop.

Connect only one device at a time to the

socket (do not use extension leads or

multi-socket adapters).

Connect only devices with class II insulation

(shown on the device).

Do not use metal-cased devices (e.g. electric

shaver, etc.).

As a safety measure, if power

consumption is high and power is

required by the vehicle's electrical system

(due to severe weather conditions, electrical

overload, etc.), power to the socket may be

cut off, in which case the green indicator lamp

goes off.

Wireless smartphone

charger







63

Ease of use and comfort

3



This system allows wireless charging of a

portable device such as a smartphone, using the

magnetic induction principle, in accordance with

the Qi 1.1 standard.

The portable device to be charged must be

compatible with the Qi standard, either by design

or by using a compatible holder or shell.

A mat can also be used provided that it is

approved by the Manufacturer.

The charging area is identified by the Qi symbol.

The charger works with the engine running and

with the Stop & Start system in STOP mode.

Charging is managed by the smartphone.

With the Keyless Entry and Start system, the

charger’s operation may be briefly disrupted

when a door is opened or the ignition is switched

off.

Charging

►  With the charging area clear, place a device

in its centre.





When the portable device is detected, the

charger’s indicator lamp lights up green. It

remains lit for the whole time that the battery is

being charged.

The system is not designed to charge

multiple devices simultaneously.

Do not leave metal objects (e.g. coins,

keys, vehicle remote control) in the

charging area while a device is being charged

- Risk of overheating or interrupting the

charging!

When using applications for a long time

in combination with wireless charging,

some smartphones may switch to thermal

safety and cause some functions to stop.

Checking operation

The state of the indicator lamp allows the

operation of the charger to be monitored.

State of the

indicator lamp

Meaning

Off

Engine switched off.

No compatible devices

detected.

Charging complete.

Fixed green

Compatible portable

device detected.

Charging.

State of the

indicator lamp

Meaning

Flashing orange

Foreign object detected in

the charging zone.

Portable device not well

centred in the charging

zone.

Fixed orange

Malfunction of the

portable device's battery

meter.

Device battery

temperature too high.

Charger malfunction.





If the indicator lamp is fixed orange:

–  remove the device, then place it back in the

centre of the charging zone.

or

–  remove the device and try again in a quarter

of an hour.

If the problem persists, have the system checked

by a CITROËN dealer or a qualified workshop.

Floor boxes (Petrol or

Diesel)







64

Ease of use and comfort



There are two boxes located under the rear

passenger footwells.

►  To open them, slide your fingers into the

notch and lift the cover.

Aircraft style tables









►  To put the table back in place, pull it upwards.

As a safety precaution, the aircraft style table

unhooks itself if excessive pressure is applied.

►  To store the table, pull it downwards.

Do not place hard or heavy objects on

the table. Such objects could become

projectiles in the event of sudden

deceleration.

Side blinds





They are fitted to the windows of the sliding side

doors (depending on version).





►  To raise or lower the blind, pull it by the tab.

To avoid damaging the blind:

–  Guide it slowly, using the tab, while

raising or lowering it.

–  Make sure the tab is securely fastened

before opening the door.

High load retaining net









This net, hooked onto the upper mountings and

the lower rings or lugs, enables the use of the full

loading volume, up to the roof:

–  Behind the front seats (row 1) when the rear

seats are folded.

–  Behind the rear seats (row 2).

When positioning the net, check that the

strap loops are visible from the boot; this

will make slackening or tightening them

easier.

Remove the luggage cover shelf or roller

(depending on version).

65

Ease of use and comfort

3

Installation behind row 1





►  Open the covers on the upper mountings

1

.

►  Unroll the high load retaining net.

►  Position one end of the net's metal bar in the

corresponding upper mounting

1

, then do the

same with the other end.

►  Fully extend the straps.





►  Wind each strap around bar

3

 located under

the front seat cushion (row 1), then secure each

spring hook to the ring on the corresponding

strap.

►  Fold down the rear seats.

►  Tighten the straps without raising the bench

seat.

►  Check that the net is hooked and tightened

correctly.

Installation behind row 2





►  Fold or remove the luggage cover.

►  Open the covers on the upper mountings

2

.

►  Unroll the high load retaining net.

►  Position one end of the net's metal bar in the

corresponding upper mounting

2

, then do the

same with the other end.

►  Attach the hook on each of the net's straps

to the corresponding stowing ring

4

 (located on

the floor).

►  Tighten the straps.

►  Check that the net is hooked and tightened

correctly.

Never use the ISOFIX ring, which is for

fixing the strap of a child seat with Top

Tether.

Two-position luggage cover

shelf (removable)

M

M





It can be installed in two different positions: high

and low.

It consists of two sections which can be folded

back on each other.

►  To fold it from the boot, grasp it and fold it

back on itself up to the rear seats. From the
