Citroen C6 (2011 year). Instruction

7.43

111

01 FIRST STEPS

On/Off and volume adjustment.

Selection of the display on the screen from the modes:
AUDIO, trip computer (TRIP), air conditioning (CLIM) and
hands-free kit (TEL). The TEL button is not active if the
hands-free kit option is not fi tted.

Selection of the source: radio, CD and CD changer.

4. Displaying of the general menu.

Cancellation of the current operation/return to the previous
screen.

Confi rmation.

Automatic search for a lower/higher frequency.
Selection of previous/next CD or MP3 track.

8. TA

(Traffi c Announcement) function on/off.

Long press: access to the PTY
(radio Programme TYpes) mode.

9. Displaying of the list of local stations, of the tracks on the CD

or of the MP3 directories.

10. CD eject.

11. Buttons 1 to 6:

Selection of a stored radio station.

Selection of a CD in the CD changer.

Long press: storing of a station.

12. Selection of the FM1, FM2, FMast and AM wavebands.

13. Selection of a lower/higher radio frequency.

Selection of the previous/next CD.

Selection of the previous/next MP3 directory.

14. Setting the audio options: front/rear balance, left/right

balance, loudness, sound ambiences.

15. The DARK button changes the screen display for greater

driving comfort at night.
1st press: lighting of the upper banner only.
2nd press: black screen display.
3rd press: return to the standard display.

7.45

03 AUDIO

Press the SOURCE button several

times in succession and select the

radio.

Press the BAND AST button to select

a waveband: FM1, FM2, FMast, AM.

Briefl y press one of the buttons to

carry out an automatic search of

the radio stations.

Press one of the buttons to carry out a

manual search of the radio stations.

Press the LIST REFRESH button to

display the list of stations received

locally (30 stations maximum).

To update this list, press for more than

two seconds.

Select ACTIVATE FREQUENCY

FOLLOWING (RDS) then press OK.

RDS appears on the display.

Select the FM WAVEBAND

PREFERENCES function then

press OK.

Select AUDIO FUNCTIONS then

press OK.

Press the MENU button.

FM WAVEBAND PREFERENCES

ACTIVATE FREQUENCY FOLLOWING (RDS)

The external environment (hills, buildings, tunnels, basement car parks) may block reception, including
in RDS mode. This is a normal effect of the way in which radio waves are transmitted and does not
indicate any failure of the audio equipment.

RDS

The RDS, if displayed, enables you to continue listening to the same

station by automatic retuning to alternative frequencies. However, in

certain conditions, coverage of an RDS station may not be assured

throughout the country as radio stations do not cover 100 % of

the territory. This explains the loss of reception of the station during

a journey.

RADIO

SELECTING A STATION

7.46

Insert circular compact discs only.

Some anti-pirating systems, on original discs or CDs

copied using a personal recorder, may cause faults

which are no refl ection on the quality of the original

player.

Without pressing the EJECT button, insert a CD in

the player, play begins automatically.

To play a disc which has already been

inserted, press the SOURCE button

several times in succession and

select CD.

Press one of the buttons to select a

track on the CD.

Press the LIST REFRESH button to

display the list of tracks on the CD.

Press and hold one of the buttons for

fast forward or backward.

Insert an MP3 compilation in the player.

The audio equipment searches for all of the music

tracks, which may take anything between a few

seconds and several tens of seconds, before play

begins.

On a single disc, the CD player can read up to 255 MP3 fi les spread

over 8 directory levels. However, it is advisable to keep to a limit of

two levels to reduce the access time before the CD is played.

While the CD is being played, the directory fl ow chart is not followed.

All of the fi les are displayed on a single level.

To play a disc which has already been

inserted, press the SOURCE button

several times in succession and

select CD.

Press one of the buttons to select a

track on the CD.

Press the LIST REFRESH button to

display the list of directories of the

MP3 compilation.

Press and hold one of the buttons for

fast forward or backward play.

PLAYING A CD

MP3 CD

PLAYING AN MP3 COMPILATION

7.47

The MP3 format, an abbreviation of MPEG 1.2 & 2.5 Audio Layer 3,

is an audio compression standard which permits the recording of

several tens of music fi les on a single disc.

In order to be able to play a recorded CDR or CDRW, when recording

it is preferable to select standards ISO 9660 level 1.2 or Joliet.

If the disc is recorded in another format, it may not be played

correctly.

It is recommended that the same recording standard is always used

for an individual disc, with as low a speed as possible (4x maximum)

for optimum sound quality.

In the particular case of a multi-session CD, the Joliet standard is

recommended.

The audio equipment will only play fi les with the extension ".mp3"

with a sampling rate of 22.05 KHz or 44.1 KHz. No other type of fi le

(.wma, .mp4, .m3u...) can be played.

It is advisable to restrict fi le names to 20 characters without using

special characters (e.g. " " ? ; ù) to avoid any playing or displaying

problems.

MP3 CD

INFORMATION AND ADVICE

AUDIO

PLAYING A CD (NOT MP3 COMPATIBLE)

Insert the CDs in the changer

one by one.

Press the SOURCE button several

times in succession and select CD

CHANGER.

Press one of the buttons on the

numeric keypad to select the

corresponding CD.

Press one of the buttons to select a

track on the CD.

Press and hold one of the buttons for

fast forward or backward play.

CD CHANGER

7.48

04 HANDS-FREE KIT

For safety reasons and because they require prolonged attention on

the part of the driver, the operations for pairing a Bluetooth mobile

telephone with the hands-free kit must be carried out with the vehicle

stationary and the ignition on.

Select the accessory which corresponds to the

name of the vehicle, a superimposed confi guration

display appears on the multifunction screen.

Activate the telephone's Bluetooth function and

carry out a search of the Bluetooth accessories

present for the telephone.

Select the YES tab on the display using

the buttons then confi rm by pressing OK.

Enter the vehicle's authentication code (=1234).

Depending on the telephone, you may be asked

to enter this code before the superimposed

confi guration display appears.

YES

The services offered by the hands-free kit depend on the telephone network, the SIM
card and the compatibility of the Bluetooth equipment used.
Consult your telephone's manual and your operator to check which services are
available to you. A list of mobile telephones which offer the best range of services is
available from the network. Consult a CITROËN dealer.

RECEIVING A CALL

An incoming call is announced by a ring and a superimposed display

on the multifunction screen.

Select the YES tab on the display

using the buttons and confi rm by

pressing OK.

Press the end of the steering wheel stalk to accept

the call.

Press the end of the steering wheel stalk for more

than two seconds to access your directory.

If you wish to dial a number, use the keypad on

your telephone.

MAKING A CALL

SCREEN C

PAIRING A TELEPHONE

7.49

USB PLAYER

The system puts together playlists (temporary memory) created over

a period which depends on the capacity of the USB equipment.

The other sources are available during this time.

The playlists are updated each time the ignition is switched off or

each time a USB stick is connected.

When connecting for the fi rst time, the tracks are classifi ed by folder.

When you reconnect, the classifi cation system selected previously is

retained.

Connect the stick to the port, directly or using a lead.

If the audio equipment is switched on, the USB source

is detected as soon as it is connected. Play begins

automatically after a delay which depends on the capacity

of the USB stick.

The fi le formats recognised are .mp3 (mpeg1 layer 3 only),

.wma (standard 9 only), .wav and .ogg.

This unit consists of a USB port and a

Jack socket * . It reads audio fi le formats

(.mp3, .ogg, .wma, .wav...) which are

transmitted from portable equipment

such as a digital player or a USB stick to

your Audio system to be listened to via

the vehicle's speakers.

USB stick (1.1, 1.2 and 2.0) or Ipod

generation 5 or later:

- the playlists accepted are of the type

m3u, .pls, .wpl.,

- the Ipod

lead is essential,

- navigation through the fi le base is by

means of the steering wheel controls,

- the battery of the portable equipment

can charge automatically.

Other Ipod

players of earlier generations

and players using the MTP protocol * :

- play via Jack-Jack lead only

(not supplied),

- navigation through the fi le base is from

the portable equipment.

The list of compatible equipment is available from CITROËN dealers.

USING THE USB

CONNECTING A USB STICK

* According to vehicle.

7.50

USB PLAYER

USING THE USB SOCKET

Press LIST briefl y to display the list

of Folders/Genres/Artists/Playlists on

the USB equipment.

Navigate through the list using the

left/right and up/down buttons.

Confi rm the selection by pressing OK.

The lists available are Artist, Genre and Playlist

(as defi ned on the iPod

Selection and Navigation are described in steps 1 to 5 above.

Do not connect a hard disc or USB devices other than audio

equipment to the USB socket. This could damage your installation.

CONNECTING AN IPOD

VIA THE USB SOCKET

Press one of these buttons to gain

access to the previous/next track on

the classifi cation list currently being

played.

Press and hold one of the buttons for

fast forward or backward play.

Press one of these buttons to gain

access to the previous/next Genre,

Folder, Artist or Playlist on the

classifi cation list currently being

played.

Press and hold LIST to display the

different classifi cations.

Select by Folder/Artist/Genre/Playlist,

press OK to select the classifi cation

required, then press OK

again to confi rm.

- by Folder: all folders containing audio

fi les recognised on the peripheral

device, classifi ed in alphabetical order

without following the fl ow chart.

- by Artist: all of the artist names

defi ned in the ID3 Tags, classifi ed in

alphabetical order.

- by Genre: all of the genres defi ned in

the ID3 Tags.

- by Playlist: in accordance with the

playlists recorded on the USB device.

7.51

Saisir code authentification

Del

2 3 4 5 6 7 8 9

BLUETOOTH FUNCTIONS

For safety reasons and because they require prolonged attention

on the part of the driver, the operations for pairing of the Bluetooth

mobile telephone with the Bluetooth hands-free system of your

audio equipment must be carried out with the vehicle stationary and

the ignition on.

Activate the telephone's Bluetooth

function.

A window is displayed with "Searching...".

Press the MENU button.

In the menu, select:

- Bluetooth telephone function - Audio

- Bluetooth confi guration

- Perform a Bluetooth search

The services offered depend on the network, the SIM card and the
compatibility of the Bluetooth equipment used.
Consult your telephone's manual and your operator to fi nd out which
services are available to you. A list of mobile telephones which offer the
best range of services is available from the network. Consult a CITROËN
dealer.

BLUETOOTH TELEPHONE

SCREEN C

The TELEPHONE menu permits access to the following functions in

particular: Directory * , Call list, Pairing management.

The fi rst 4 telephones recognised are displayed in this window.

A virtual keypad is displayed on the screen:

enter a code with at least 4 digits.

Confi rm by pressing OK.

"Pairing of Name_telephone successful" appears on the screen.

Select the telephone to be connected from the list. Only one

telephone can be connected at a time.

A message is displayed on the screen of the

telephone chosen: to accept the pairing, enter

the same code on the telephone, then confi rm by

pressing OK.

If pairing fails, the number of attempts is not limited.

The automatic connection authorised is only active after the

telephone has been confi gured.

The directory and the call list can be accessed after the

synchronisation period.

PAIRING A TELEPHONE

The pairing can also be initiated from the telephone.

* if your telephone hardware is fully compatible.

7.52

YES

RECEIVING A CALL

An incoming call is announced by a ring and a superimposed display

on the multifunction screen.

Initiate the pairing between the telephone and

the vehicle. This pairing can be initiated from

the vehicle's telephone function menu or via the

telephone's keypad. See steps 1 to 10 on the

previous pages. During the pairing phase, the vehicle

must be stationary with the key in the ignition.

Select the telephone to be connected from the telephone function

menu.

The audio system connects to a newly paired telephone

automatically.

Select the YES tab on the display

using the buttons and confi rm by

pressing OK.

Press the steering wheel control OK to accept the

call.

From the Bluetooth telephone function Audio menu, select Manage

the telephone call then Call, Call list or Directory.

Press the end of the steering wheel control for more

than two seconds to gain access to your directory.

To dial a number, use your telephone's keypad,

with the vehicle stationary.

MAKING A CALL

BLUETOOTH AUDIO STREAMING

(AVAILABLE DURING THE YEAR)

Wireless transmission of the telephone's music fi les via the audio

equipment. The telephone must be able to manage the appropriate

bluetooth profi les (Profi les A2DP/AVRCP).

* In certain cases, playing of the Audio fi les must be initiated from

the keypad.

** If the telephone supports the function.

Activate the streaming source by

pressing the SOURCE button * . The

tracks to be played can be controlled

as usual via the buttons on the Radio

control panel and the steering wheel

controls ** . The contextual information

can be displayed on the screen.

7.53

07 CONTROL SHORT-CUTS

STEERING WHEEL CONTROLS

RADIO: selection of the next stored station.
CD CHANGER: selection of the next CD.
Selection of the next item on a menu.

RADIO: selection of the previous stored station.
CD CHANGER: selection of the previous CD.
Selection of the previous item on a menu.

RADIO: automatic search for a higher frequency.
CD/CD CHANGER/MP3: selection of the next track.
CD/CD CHANGER: continuous press: fast forward play.
Selection of the previous item.

RADIO: automatic search for a lower frequency.
CD/CD CHANGER/MP3: selection of the previous track.
CD/CD CHANGER: continuous press: backward play.
Selection of the next item.

Volume increase.

Volume decrease.

Mute: by pressing
the volume increase
and decrease buttons
simultaneously.

Restore the sound by
pressing one of the two
volume buttons.

-  Change of sound source.
-  Confi rmation of a selection.
-  Pick up/Hang up the telephone.
-  Press for more than 2 seconds:

access to the telephone menu.

7.54

08 CONFIGURATION

Press the MENU button.

Using the arrows, select

the PERSONALISATION

CONFIGURATION function.

Press to confi rm the selection.

Using the arrows, select the DISPLAY

CONFIGURATION function.

Press to confi rm the selection.

Using the arrows, select the ADJUST

DATE AND TIME function.

Adjust the settings one by one

confi rming by pressing the OK button.

Next select the OK tab on the screen

then confi rm.

DISPLAY CONFIGURATION

ADJUST DATE AND TIME

PERSONALISATION CONFIGURATION

ADJUSTING THE DATE AND TIME

SCREEN C

7.55

date and time adjustment

day/month/year adjustment

hour/minute adjustment

choice of 12 h/24 h mode

p y

DISPLAY FLOW CHART display C

TRIP COMPUTER

MAIN FUNCTION

* The parameters vary according to vehicle

(refer to the "Multifunction displays" section).

CHOICE A

choice A1
choice A2

CHOICE B...

track random play (RDM)

activate/deactivate

FM BAND PREFERENCES

alternative frequencies (RDS)

activate/deactivate

regional mode (REG)

activate/deactivate

radio-text information (RDTXT)

activate/deactivate

AUDIO CD PREFERENCES

CD changer repeat (RPT)

activate/deactivate

ENTER DISTANCE TO DESTINATION

distance: x km

WARNING LOG

diagnostics

video brightness adjustment

normal video

inverse video

brightness (- +) adjustment

STATUS OF FUNCTIONS *

functions activated or deactivated

PERSONALISATION-CONFIGURATION

DEFINE THE VEHICLE PARAMETERS *

DISPLAY CONFIGURATION

CHOICE OF LANGUAGE

Deutsch

English

Espanol

Français

Italiano

Nederlands

Portugues

Portugues-brasil

7.56

AIR CONDITIONING

SWITCH OFF AIR CONDITIONING (A/C OFF)

SIMULTANEOUS LH-RH CONTROL

activate/deactivate

TELEPHONE

BLUETOOTH CONFIGURATION

CONNECT/DISCONNECT A DEVICE

Telephone function

Audio Streaming function

CONSULT THE PAIRED DEVICE

DELETE A PAIRED DEVICE

PERFORM A BLUETOOTH SEARCH

MANAGE THE TELEPHONE CALL

TERMINATE THE CURRENT CALL

ACTIVATE SECRET MODE

CALL

CALLS LIST

DIRECTORY

7.57

QUESTION

SOLUTION

ANSWER

There is a difference in

sound quality between

the different audio

sources (radio, CD,

CD changer...).

Check that the audio settings (Volume, Bass,

Treble, Ambience, Loudness) are adapted to

the sources listened to. It is advisable to set

the AUDIO functions (Bass, Treble, Front-Rear

Balance, Left-Right Balance) to the middle

position, select the musical ambience "None"

and set the loudness correction to the "Active"

position in CD mode or to the "Inactive" position

in radio mode.

For optimum sound quality, the audio settings (Volume, Bass, Treble,

Ambience, Loudness) can be adapted to the different sound sources,

which may result in audible differences when changing source (radio, CD,

CD changer...).

The CD is ejected

automatically or is not

played by the player.

- Check that the CD is inserted in the player the

right way up.

- Check the condition of the CD: the CD cannot

be played if it is too damaged.

- Check the content in the case of a recorded

CD: consult the advice in the "Audio" section.

- The audio equipment's CD player does not

play DVDs.

- Due to inadequate quality, certain recorded

CDs will not be played by the audio system.

The CD is inserted upside down, is unplayable, does not contain any audio

data or contains an audio format which the player cannot play.

The CD is protected by an anti-pirating protection system which is not

recognised by the audio equipment.

FREQUENTLY ASKED QUESTIONS

The CD player sound

is poor.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in

suitable conditions.

The audio equipment settings (bass, treble, ambiences) are unsuitable.

Set the treble or bass level to 0, without selecting

an ambience.

7.58

QUESTION

SOLUTION

ANSWER

The stored stations do

not function (no sound,

87.5 Mhz is displayed...)

An incorrect waveband is selected.

Press the BAND AST button to return to the

waveband (AM, FM1, FM2, FMAST) on which the

stations are stored.

The traffi c announcement

(TA) is displayed. I do

not receive any traffi c

information.

Tune to a radio station which broadcasts traffi c

information.

The radio station is not part of the regional traffi c information network.

The quality of reception

of the radio station

listened to gradually

deteriorates or the

stored stations do

not function (no

sound, 87.5 Mhz is

displayed...).

The vehicle is too far from the transmitter used by the station listened to or

there is no transmitter in the geographical area through which the vehicle

is travelling.

The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

Activate the RDS function to enable the system

to check whether there is a more powerful

transmitter in the geographical area.

This phenomenon is normal and does not

indicate a failure of the audio equipment.

Have the aerial checked by a CITROËN dealer.

Sound cut-outs of

1 to 2 seconds in radio

mode.

During this brief sound cut-out, the RDS searches for any frequency

permitting better reception of the station.

Deactivate the RDS function if the phenomenon

is too frequent and always on the same route.

With the engine off,

the audio equipment

switches off after a few

minutes of use.

When the engine is switched off, the audio equipment operating time

depends on the battery charge.

The switch-off is normal: the audio equipment switches to economy mode

and switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery

charge.

The message "the audio

system is overheated"

appears on the display.

Switch the audio system off for a few minutes to

allow the system to cool.

In order to protect the installation if the surrounding temperature is too

high, the audio equipment switches to an automatic thermal protection

mode leading to a reduction of the volume or stopping of the playing of

the CD.

Citroen C6 (2011 year). Instruction - part 13
