Citroen C6 (2011 year). Instruction - part 4

T R I P C O M P U T E R

TYRE DEFLATION DETECTION

This function warns you of tyres that are defl ated or punctured, by means of sensors that continuously monitor the

status of the vehicle's wheels, giving you this information on the screen (press the end of the wiper control stalk or on

the "TRIP" button for a permanent display).

Colour screen C

NaviDrive colour display

Display of tyres in good condition

Status from the sensors in the course

of initialisation

T R I P C O M P U T E R

Tyre defl ation alert

The SERVICE warning lamp comes on and a vehicle outline is displayed.
The location of the wheel(s) concerned is clear from the vehicle outline, on which the affected wheel(s) will be fl ashing.

Check the tyre pressures as soon as possible.

Colour screen C

NaviDrive colour display

Tyre very defl ated

Tyre defl ated

Stop immediately, avoiding any sudden actions with the steering wheel or the brakes.
Change the wheel with the affected tyre (whether punctured or very defl ated), then have the tyre repaired and

all the pressures checked at the earliest opportunity.
The wheel with a damaged tyre (either in the boot or under repair) can no longer be detected (information

given by the vehicle outline or by a message) nor is the spare wheel able to be detected.

Puncture

The "STOP" and tyre(s) punctured warning lamps light up, and a vehicle outline is displayed. The location of the

wheel(s) concerned is clear from the vehicle outline, on which the affected wheel(s) will be fl ashing.

Colour screen C

NaviDrive colour display

T R I P C O M P U T E R

Wheel not detected

The SERVICE warning lamp comes on and a vehicle outline is displayed.
The wheel(s) concerned can be identifi ed from the vehicle outline, on which it (they) will be missing. If you have not

changed a wheel, such information indicates that the system is malfunctioning.
Contact a CITROËN dealer or a qualifi ed workshop for the replacement of the faulty sensor(s).

Colour screen C

NaviDrive colour display

The defl ation detection system is a driving aid, but which does not absolve the driver from the need to be vigilant and

responsible.
This system does not remove the need to check the tyres on a regular basis (see "Vehicle identifi cation"), to make

sure that the vehicle is behaving correctly and to avoid premature tyre wear arising from driving too fast etc.
Do not forget to check the pressure in the spare wheel.

All repairs or replacement of tyres on wheels fi tted with sensors must be done by a CITROËN dealer

or a qualifi ed workshop.
The system may suffer from temporary interference caused by radio transmissions on neighbouring

frequencies.

S I G N A L L I N G

DIRECTION INDICATORS

Left, downwards.
Right, upwards.
For a change of direction, move

the control stalk beyond the tight

spot. Stops automatically with the

return of the steering wheel.

Visible alert/headlamp fl ash

Pull the control towards you.
The headlamp fl ash can be made

even with the ignition switched off.

Horn

Press at the centre of the steering

wheel.

HAZARD WARNING LAMPS

This operates all the direction indi-

cators simultaneously.
Only use them to indicate dan-

ger, for an emergency stop or for

driving in abnormal conditions.
The hazard lamps can also be

used with the ignition switched off.

SOUND SIGNAL FOR HEAD-

LAMPS LEFT ON

This operates when the driver's

door is opened, ignition off, to indi-

cate that the vehicle lamps are still

on.
It stops when you close the door,

switch off the lamps or switch on

the ignition.
This signal does not operate if the

automatic lighting of headlamps

or the guide-me-home lighting are

active.

EMERGENCY OPERATION OF

HAZARD WARNING LAMPS

A sudden deceleration of the vehi-

cle causes the hazard lamps to

come on automatically.
They will cease to operate auto-

matically, or manually if you press

the hazard lamps button on the

dashboard.

The direction indicators cannot operate if the hazard warning

lamps are on.

S I G N A L L I N G

LIGHTING CONTROL STALK

All vehicle lamps off

Sidelamps on

Dipped beams/

main beams on

Rotate the ring A forwards.

AUTOMATIC LIGHTING OF

HEADLAMPS

Sidelamps and dipped beams

come on automatically in poor

ambient light, or if the wipers are in

continuous operation. They go out

as soon as the ambient light again

become suffi cient or when the wip-

ers cease to operate.
Activation/deactivation of this func-

tion is possible in the menu "Per-

sonalisation/Confi guration" in the

"Main menu".

Note: Activation of this function

is immediate while deactivation

requires the ignition to be switched

off.

In fog or snow, the light sensor

may detect enough light. The

lights will therefore not come on

automatically.
Take care not to cover the bright-

ness sensor, which is visible from

outside the windscreen, behind

the interior rear view mirror.

GUIDE-ME-HOME LIGHTING

This function switches on your

headlamps, to light your way when

you wish to walk from a carpark,

for example.
This function is activated:

Manually by pulling the con-

trol A towards you, with the

ignition switched off.
Automatically, provided:

The automatic lighting of

headlamps is activated.
To activate the guide-me-

home lighting function, select

in the "Main menu", then

in "Personalisation/Con-

fi guration", the sub-menu for

lighting and signalling, then

activate the function.

See "Multifunction displays".
Note: It is possible to modify the dura-

tion of the guide-me-home lighting

(approx. 60, 30 or 15 seconds) in the

menu "Personalisation/Confi guration".

•

Dipped beams/main beams

dipswitch

Pull the control stalk towards you

to change between dipped beam

and main beam.

S I G N A L L I N G

Front foglamps on

Front foglamps and rear foglamps on

Rotate the ring C forwards.

Switching off

First action rearwards, rear foglamps off.
Second action rearwards, front and rear foglamps off.
Note: the foglamps should be used only in fog or in other conditions of poor

visibility.

FRONT AND REAR

FOGLAMPS (RING C)

Lighting

With dipped/main beams on:
Rotate the ring C forwards.

DAYTIME-RUNNING LAMPS

These come on automatically when

the engine is running:

If the function is activated in

the Main Menu. See "Multi-

function displays".
Provided the lighting control

stalk is on position 0 and all the

headlamps are off.

If the daytime-running lamps are

active, the sidelamps will also be

on (depending on country specifi -

cation).

•

In foggy conditions, if the ambient light is not such that the

headlamps come on automatically, it is up to the driver to switch

on dipped beams, and/or foglamps, manually.

FEATURES

With dipped beams or main beams, the Directional headlamps function turns the headlamps in the direction the

road ahead is taking.
Your vision on bends is considerably enhanced.
Note: An automatic correction of the beam height enables you not to dazzle other drivers.

X E N O N D U A L F U N C T I O N D I R E C T I O N A L

H E A D L A M P S

Function activated

Function deactivated

ACTIVATION/DEACTIVATION

Activated by default, this function

can be activated/deactivated in

the "Main menu" on the multifunc-

tion screen. See "Multifunction dis-

plays".
The activated/deactivated status

is retained when you switch off

the engine.
Note: This function is not active

when the vehicle is stationary,

moving at very low speed, or in

reverse gear.

Should there be a malfunction the "Dipped beams" warning lamp fl ashes. Have the system checked

by a CITROËN dealer or a qualifi ed workshop.

It is recommended to change both Xenon bulbs at the same time if there is a failure of one of

them.

W I P E R S

CONTROL POSITIONS

2: Rapid wipe.
1: Normal wipe.

: Intermittent wipe.

0: Off.

One press downwards:

AUTO: Automatic wipe activated.
Single wipe.

•
•

Position

: The wipe speed adjusts automatically to the speed of the vehicle.

Positions 1 and 2: When the vehicle is stationary, the speed of the wipers

will reduce automatically.
For safety, the wiper system is deactivated when the ignition is

switched off.
When you switch the ignition on again, to reactivate the function:
Return to position 0, then go to the desired position.
Activation of the function is confi rmed by one sweep of the wipers.
Automatic wipe: To activate automatic wipe, place the control stalk on

position 0, then press it downwards. The wipe speed will adjust according to

the intensity of the rain.
Note: One press downwards produces a single wipe, without deactivating

automatic wipe.

Deactivation of automatic wipe:

Go to position

, then return to position 0.

Or stop the engine.

WARNING

Do not cover the rain detector which is located behind the interior rear

view mirror and visible from outside the windscreen.
If washing the vehicle, with ignition on for example in an automatic car

wash, deactivate the wiper system.

•
•

For safety, the wiper system is

deactivated when the ignition is

switched off.

W I P E R S

CHANGING THE WIPER BLADES

If you have to replace them, the wiper blades have to be parked in the maintenance position. For this, switch off the

ignition and then within one minute move the wiper control stalk. The wipers stand up in a vertical position.
After replacement, switch on the ignition and move the wiper control stalk so that the wipers resume their normal

position.
Note: this action places the Piloted Defl ector in the maintenance position.

WINDSCREEN WASH

To operate the windscreen wash, pull the wiper stalk towards you.
The screen wash is accompanied by a timed wipe of the windscreen, the

headlamp wash also activates if the dipped beams are on.
The display of a message indicates that there is only approx. one litre of

screen wash fl uid remaining.

In freezing conditions, always check that the wiper blades are free to

operate.

Remove any accumulation of snow at the base of the windscreen.

W I N D O W S

After a battery disconnection or

if there has been a malfunction,

you have to reinitialise the anti-

pinch function for each window:

Lower the window fully using

the control, then close. It will

rise only a few centimetres.

Press repeatedly on the control

until the window is fully closed.
Keep the control pressed for at

least a few seconds after the

window has fully closed.

WARNING

During this operation, the anti-

pinch protection does not work.

•

CHILD SAFETY

This deactivates the controls in the

rear of the vehicle, both for the rear

windows and for opening the rear

doors from the inside.
For Pack Lounge seats, the seat

slide adjustments, and those for

the front seats from the rear of the

vehicle, are also deactivated.
This is activated by a press on but-

ton A located on the window con-

trol panel.
A message appears to confi rm that

the child safety is activated.
It is still possible to open the doors

from the outside and to operate the

electric windows from the front of

the vehicle.

ELECTRIC OPERATION

The driver uses the controls located

on the door to operate the vehicle’s

electric windows.

SEQUENTIAL OPERATION

An action on the control to the fi rst

notch causes a window movement

which stops as soon as the control

is released.
An action on the control to the

second notch causes the window

to close or open completely, a fur-

ther press on the control stops the

movement.
Note: The window controls also

operate for a limited time after you

have switched off the ignition.

ANTI-PINCH

An anti-pinch device stops the

window from rising. If it meets an

obstacle, it goes back down.

ALWAYS PAY ATTENTION TO WHERE CHILDREN ARE WHEN

OPENING OR CLOSING THE WINDOWS

Always remove the ignition key when leaving the vehicle, even if for a

short time.
Should there be any risk of a person becoming trapped by a window clos-

ing, you should immediately reverse the window movement. To do this,

press on the control concerned.
If the driver is operating the electric window controls for passengers, he

or she should ensure that no passenger is obstructing the window from

closing.
The driver must ensure that the electric windows are used properly by

passengers.
If closing the windows and sun roof using the remote control, the user

must make sure that no person is preventing the windows and/or sun roof

from closing properly.

S T E E R I N G C O L U M N A D J U S T M E N T –

S E AT B E LT H E I G H T A D J U S T M E N T

MANUAL ADJUSTMENT

OF THE STEERING WHEEL

FOR HEIGHT AND REACH

While the vehicle is stationary,

unlock the steering wheel by push-

ing the lever forward.
Adjust the height and the reach

of the steering wheel, then lock

the position by pulling the lever

upwards.

ELECTRICAL ADJUSTMENT

OF THE STEERING WHEEL

FOR HEIGHT OR REACH

While the vehicle is stationary,

adjust the height or the reach of

the steering wheel by moving the

control:

forward or rearward to adjust

the reach
up or down to adjust the

height.

The steering wheel adjustment is

memorised with the driving posi-

tion (See "Memorisation").

•

SEAT BELT HEIGHT

ADJUSTMENT

The correct positioning of the belt

strap is through the middle of the

shoulder. See "Seat belts".
To adjust the seat belt for height,

compress the control and slide it

in the desired direction.

As a matter of safety, the adjustments in your driving position must

be made only while the vehicle is stationary.
First adjust your seat to the most suitable position, then adjust the

position of the steering wheel. See "Memorisation".

THE WELCOME FUNCTION

As the driver’s door is opened

and with the ignition switched off,

the steering wheel moves in order

to facilitate entering or exiting the

vehicle.
You can activate or deactivate this

function by going to the "Personali-

sation-Confi guration" menu of the

multifunction screen.

F R O N T S E AT S

ADJUSTMENT OF THE BACKREST ANGLE

Action the control 1 and adjust the angle of the backrest.
It is possible to tilt the backrest 45° forwards until it locks. To unlock it,

press control 1.

ADJUSTMENTS TO THE HEIGHT AND ANGLE OF

THE HEAD RESTRAINT

To raise it, pull upwards.
To lower it, press on the control 2 to unlock it, and simultaneously on

the head restraint itself.
To adjust the angle of the head restraint, tilt it forwards or rearwards at

the bottom.
To raise it, press control 2 to unlock it, then pull it upwards.

CONTROLS FOR THE HEATED SEATS

The front seats can be heated independently of each other. On the controls

for the heated seats 3 located on the outer side of the seats, rotate the

knob to select any of three heat intensities:

0: Off.
1: Slight heat.
2: Medium heat.
3: Maximum heat.

Note: The heated seats only operate when the engine is running.

SEAT HEIGHT AND SLIDE ADJUSTMENTS

See following page.

F R O N T S E AT S

Do not drive the vehicle with the head restraints removed; these

must be in place, correctly adjusted.

ELECTRICAL ADJUSTMENTS

Adjustment of the backrest angle

To adjust the angle of the backrest, press button A.

Lumbar adjustment

To adjust the backrest lumbar support, press button B.

Seat height and slide adjustments

To slide the seat, press on the horizontal arrows on control C.
To adjust the seat for height, press on the vertical arrows on

control C.

Adjustment of the seat cushion angle

To adjust the seat cushion angle, press on control D.

Note: These adustments remain available for a limited time:

After you have opened a door
After you have switched off the ignition

•
•

M E M O R I S AT I O N

DRIVING POSITIONS

MEMORISED VIA

BUTTONS 1 AND 2

To memorise a driving position:

a. Place the igntion key in

"Drive" position (second posi-

tion).

b. Make your adjustments of the

seat, the steering wheel, the

rear view mirrors and the

Head-up Display.

c. Press successively on but-

ton M then on button 1

(fi rst driving position) or 2

(second driving position).

The memorisation is confi rmed by

a sound signal.
Note: The memorisation of a

new driving position cancels and

replaces the previous one.

The memorisation function allows

to make the following dashboard

adjustments:

Driver's seat
Steering wheel
Exterior rear view mirrors
Head-up display.

See "Steering column adjustment",

"Rear view mirrors" and "Head-up

Display".
You have the possibility to memo-

rise two driving positions using

buttons 1 and 2.

•
•
•
•

RECALL OF A MEMORISED

DRIVING POSITION

Vehicle stationary (ignition

on or engine running)

Press briefl y on button 1 or 2 to

recall the corresponding memo-

rised position.
The completion of the adjustments

is confi rmed by a sound signal.

Vehicle in motion

Keep button 1 or 2 pressed down

to recall the corresponding memo-

rised position.
Note: After a few consecutive

recalls of a memorised driving

position, the function deactivates

until the engine is started.

S E AT B E LT S N O T F A S T E N E D /

U N F A S T E N E D W A R N I N G L A M P S

OPERATION

The driver's and the front and rear

passengers' seats have sensors

that detect non-fastening/unfas-

tening of the seat belts.
The fastened/non-fastened status

of the seat belts for each type of

seat is indicated by the illumination

or fl ashing of the warning lamps 1,

2 and 3.

FUNCTIONING OF THE SYSTEM OF DETECTION

Driver's and front passenger's seats

When you switch on the ignition:

If the driver's seat belt is not fastened, the warning lamp 1 illuminates in

the instrument panel.
If the passenger's seat belt is not fastened, the warning lamp 3 lights up.

Above 20 km/h (12 mph), the warning lamp fl ashes for non-fastening/unfas-

tening, accompanied by a message and a sound signal for around 2 minutes.

Then the warning lamp(s) 1 and/or 3 remain on.

Rear passenger's seats

When you switch on the ignition, warning lamp 2 lights up to make the driver

and any passengers aware.
Once the doors are closed and the engine started, a message tells you the

fastening status of the rear belts for 30 seconds.
After this time, if one or more of the rear belts are not fastened:

Warning lamp 2 comes on, if your speed is less than around 20 km/h

(12 mph).
Warning lamp 2 fl ashes, accompanied by a message and a sound signal

for about two minutes, if your speed is above around 20 km/h (12 mph).

Note:

The detection of non-fastening of rear seat belts is deactivated when

you switch off the ignition or if one of the vehicle's doors is opened.
A child seat installed on the front passenger's seat may not be

detected.

•

The driver, after he has closed the doors and started the engine, must

make sure that the passengers:

Have all fastened their seat belts
Are using the seat belts correctly.

•
•

R E A R V I E W M I R R O R S

Operation of the interior rear-

view mirror

Switch on the ignition and press

button 1.

Warning lamp 2 on (switch on):

automatic mode.
Warning lamp 2 off: automatic

mode off. The mirror stays at

its lightest setting.

Note: For optimal vision, the inte-

rior rear-view mirror lightens when

reverse gear is engaged.

•

AUTOMATIC INTERIOR

REAR-VIEW MIRROR

This provides an automatic and

progressive transition between day

and night use.
To prevent glare, the mirror auto-

matically darkens in relation to the

intensity of light coming from the

rear. It becomes lighter as soon as

the brightness diminishes, there-

fore ensuring optimum visibility.

Content .. 2 3 4 5 ..
