Citroen C3 (2017 year). Instruction - part 21

Audio and Telematics

Level 1

Level 2

Level 3

Comments

Applications

MirrorLink

Go to or return to the applications already
downloaded to your smartphone and adapted to
MirrorLink

technology.

Go to a menu list depending on the application
chosen.
"Back": abandon the current operation, go up one
level.
"Home": go to or return to the "Car mode" page on
your smartphone.

Go to the primary page of the "Applications"
menu.

12:13

18,5

21,5

23 °C

Audio and Telematics

According to equipment

Level 2

Level 3

4
5
6

Audio and Telematics

Level 2

Level 3

Comments

Applications

Trip computer

Instant

System providing information about the current
journey (range, fuel consumption…).

Trip 1

Trip 2

Back to the Applications page.

12:13

18,5

21,5

23 °C

Audio and Telematics

Level 1

Level 2

Level 3

Audio and Telematics

Level 2

Level 3

Comments

Applications

OPTIONS

Bluetooth

connection

All

Display all telephones detected and saved.

Connected

Display all telephones connected.

Search

Start the search for a device to be connected.

Applications

OPTIONS

Wi-Fi network

connection

Secured

Display the secured Wi-Fi networks.

Not secured

Display the not secured Wi-Fi networks.

Stored

Display the stored Wi-Fi networks.

Applications

OPTIONS

Manage connection

Display the status of the subscription to the
connected services, the status of the network
connection and the connection mode.

Applications

OPTIONS

Share Wi-Fi

connection

Activation

Activate or deactivate the Wi-Fi connection
sharing.

Settings

Select a Wi-Fi network found by the system and
connect.

Save the settings.

Audio and Telematics

connection

Procedure from the system

Connection sharing

Press on "

Connect-App " to display

the primary page.

Press on "

Bluetooth connection ".

Select "

Search ".

The list of detected telephones is
displayed.

If the pairing procedure fails, it is recommended
that you deactivate and then reactivate the
"Bluetooth" function in your telephone.

The "

Mobile internet data " profile

must be activated for connected
navigation (where the vehicle does not
have "Emergency and assistance call"
services), having first activated sharing
of this connection on your smartphone.

The system offers to connect the
telephone with 3 profiles:
-

Telephone " (hands-free kit, telephone

only),

Streaming " (wireless play of audio files

on the telephone),

Mobile internet data ".

Select the name of the chosen
telephone in the list.

Press "

OK " to confirm.

Select one or more profiles.

Press the "

OPTIONS " button to go to

the secondary page.

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-
free system of your audio system must
be done with the

vehicle stationary

and the ignition on.

Procedure from the telephone

Select the name of the system in the
list of devices detected.

In the system, accept the connection request
from the telephone.

Activate the Bluetooth function on the
telephone and ensure that it is "visible
to all" (telephone configuration).

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

Depending on the type of telephone,
you may be asked to accept or not the
transfer of your contacts and messages.

Audio and Telematics

Wi-Fi connection

Sharing the Wi-Fi connection Managing connections

To protect from any piracy and provide
maximum security for your systems,
it is recommended that you use a
security code or a complex password.

The Wi-Fi connection and the sharing
of the Wi-Fi connection are exclusive.

Press "

OK " to confirm.

Press "

OK " to start the connection.

Press "

Connect-App " to display the

primary page.

Network connection by the smartphone Wi-Fi.

Creation of a local Wi-Fi network by the
system.

Press

Connect-App to display the

primary page.

Press

Connect-App to display the

primary page.

Press the "

OPTIONS " button to go to

the secondary page.

Press the "

OPTIONS " button to go to

the secondary page.

Press the "

OPTIONS " button to go to

the secondary page.

Select "

Wi-Fi network connection ".

Select "

Share Wi-Fi connection ".

Select "

Manage connection ".

And / Or

Select the "

Secured ", " Not secured "

or "

Stored " tab.

Select the "

Activation " tab to

activate or deactivate sharing of the
Wi-Fi connection.

Select the "

Settings " to change the

name of the system network and the
password.

With this function you can view the access
to connected services, the availability of
connected services and modify the connection
mode.

Using the virtual keypad, enter the
"

Key " for the Wi-Fi network and the

Password ".

Select a network.

FM/87.5 MHz

87.5MHz

12:13

18,5

21,5

23 °C

FM/87.5 MHz

87.5MHz

12:13

18,5

21,5

23 °C

AM/531 kHz

kHz

12:13

18,5

21,5

23 °C

Audio and Telematics

Radio Media

According to version

Level 1

Level 2

Audio and Telematics

Level 1

Level 2

Comments

Radio Media

Source

Radio

Select change of source.

USB

iPod

AUX

Bluetooth

Radio Media

Frequency / Presets

Frequency

Carry out an automatic or manual search for radio
stations.

Presets

Make a long press on an empty location to preset
a station.

Radio Media

Band

Press the Band button to change waveband.

DAB

Radio Media

List

Radio stations

Open the list and press a radio station to select it.

Audio and Telematics

Level 2

Level 3

13
14
15

10
11

Audio and Telematics

Level 2

Level 3

Comments

Radio Media

OPTIONS

Audio settings

Ambience

Select the sound ambience.

Distribution

Sound distribution by the Arkamys

system.

Sound

Adjust the volume or activate volume linked to
speed.

Voice

Adjust the voice volume.

Ringtone

Adjust the ringtone volume.

Save settings.

Radio Media

OPTIONS

Radio settings

General

Activate or deactivate settings.

Announcements

Save settings.

Radio Media

OPTIONS

Radio stations

Display the list of radio stations for the band
selected.

DAB

Presets

Select a preset radio station.

Frequency

Enter a frequency manually.

Change the screen display mode.

Update the list according to reception.

18 19 20

Audio and Telematics

Level 2

Level 3

Audio and Telematics

Level 2

Level 3

Comments

Radio Media

OPTIONS

Music files

Albums

Choose a selection mode.

Artists

Genres

Playlists

Folders

Radio Media

OPTIONS

Managing photos

USB

Display photos.
The system supports the following image formats:
.gif, .jpg, .jpeg, .bmp, .png, .raw and .tiff with a
maximum file size of 10 Mb per image.

Audio and Telematics

Press

Radio Media to display the

menu.

Press the "

OPTIONS " button to go to

the secondary page.

Press "

Frequency ".

Press "

Frequency ".

Enter the values using the virtual
keypad.
First enter the units then click on the
decimals zone to enter the figures
after the decimal point.

Press one of the buttons for an
automatic search for radio stations.

Press

Radio Media to display the

primary page.

Radio

Selecting a station

Radio reception may be affected by
the use of electrical equipment not
approved by the Brand, such as a USB
charger connected to the 12 V socket.
The exterior environment (hills,
buildings, tunnel, car park, below
ground...) may prevent reception,
even in RDS station tracking mode.
This phenomenon is normal in the
propagation of radio waves and is in no
way indicative of a fault with the audio
system.

Select "

Radio stations " in the

secondary page.

Move the cursor for a manual search
for frequencies up or down.

Select a radio station or frequency.
(refer to the corresponding section)

Press "

Presets ".

Make a long press on one of the
buttons to preset the station.

Preset a station

Press "

OK " to confirm.

Audio and Telematics

Press

Radio Media to display the

primary page.

Press

Radio Media to display the

primary page.

Press the "

OPTIONS " button to go to

the secondary page.

Press the "

OPTIONS " button to go to

the secondary page.

Select "

Radio settings ".

Select "

Radio settings ".

Select "

General ".

Select "

General ".

Select "

Announcements ".

Activate/deactivate "

Station follow ".

Activate / Deactivate "

Display radio

text ".

Activate / Deactivate "

Traffic

announcement ".

Activate/ Deactivate RDS

RDS, if activated, allows you to continue
listening to the same station by automatic
retuning to alternative frequencies.
However, in certain conditions, coverage
of an RDS station may not be assured
throughout the entire country as radio
stations do not cover 100 % of the
territory. This explains the loss of
reception of the station during a journey.

Press "

OK " to confirm.

Press "

OK " to confirm.

Press "

OK " to confirm.

The "Radio Text" function allows
information transmitted by the radio
station, relating to the station or the
song playing, to be displayed.

Display text information

Play TA messages

The TA (Traffic Announcement)
function gives priority to TA alert
messages. To operate, this function
needs good reception of a radio station
that carries this type of message. While
traffic information is being broadcast,
the current media is automatically
interrupted so that the TA message can
be heard. Normal play of the media
previously playing is resumed at the
end of the message.
