Citroen C3 (2017 year). Instruction

191

Driving

B618_en_Chap06_conduite_ed01-2016

Under-inflation alert

Reinitialisation

Before reinitialising the system, ensure
that the pressures of the four tyres are
correct for the use of the vehicle and in
line with the recommendations on the
tyre pressure label.
The under-inflation alert can only
be relied on if the reinitialisation of
the system has been done with the
pressures in the four tyres correctly
adjusted.
The under-inflation detection system
does not give a warning if a pressure is
incorrect at the time of reinitialisation.

This is given by fixed illumination of
this warning lamp, accompanied by
an audible signal and, depending on
equipment, the display of a message.

It is necessary to reinitialise the system every
time one or more tyre pressures are adjusted,
and after changing one or more wheels.

Reduce speed immediately, avoid

excessive steering movements and sudden
braking.

F Stop the vehicle as soon as it is safe to

do so.

If you have a compressor, such as the one

in the temporary puncture repair kit, check
the pressures of the four tyres when cold.

If it is not possible to make this check

immediately, drive carefully at reduced
speed.

or
F In the event of a puncture, use the

temporary puncture repair kit or the spare
wheel (depending on equipment).

The loss of pressure detected does not
always cause visible bulging of the tyre.
Do not satisfy yourself with just a visual
check.

The alert is maintained until the system
is reinitialised.

192

Driving

B618_en_Chap06_conduite_ed01-2016

Reinitialisation of the system must be done with
the ignition on

and the vehicle stationary:

- in the vehicle configuration menu, for

vehicles fitted with a display screen,

- using the instrument panel display or the

button on the dashboard, for vehicles
without a display screen.

Touch screen

Monochrome screen C

Operating fault

The flashing and then fixed illumination of the
under-inflation warning lamp accompanied
by illumination of the Service warning lamp
indicates a fault with the system.
A message appears, accompanied by an
audible signal.

In this case, under-inflation monitoring of the
tyres is no longer assured.
Have the system checked by a CITROËN
dealer or a qualified workshop.

Before doing anything to the system,
the pressures of the four tyres must be
checked and the system reinitialised.

Instrument panel display

Reinitialisation of the function is done
in the Driving

menu.

F In the Driving

menu, select the "Driving

functions

" tab.

In the page, select the "Under-inflation

initialisation

" function.

F Select "Yes

" to confirm.

The reinitialisation is confirmed by the display
of a message and an audible signal.

Reinitialisation of the function is
done in the "Personalisation-
configuration

" menu of the screen.

F Select the "Define the vehicle

parameters

" menu.

Make a short press on this button

to access the menu.

Select the corresponding item

then confirm.

A high tone audible signal confirms the
reinitialisation.
A low tone audible signal indicates that the
reinitialisation was not completed.

Dashboard button

Make a long press on this button.

A high tone audible signal confirms the
reinitialisation.
A low tone audible signal indicates that the
reinitialisation was not completed.

F Select the "Comfort

" menu.

F Select the "Tyre inflation

" menu.

F Select the "Reinitialisation

" function.

F Select "Yes

" to confirm.

The reinitialisation is confirmed by an audible
signal.

193

Driving

B618_en_Chap06_conduite_ed01-2016

ConnectedCAM CITROËN™*

This camera, installed at the top of the
windscreen and connected wirelessly, permits:
- the taking of photos and videos by pressing

the dedicated control,

- the sending of the vehicle's GPS

coordinates to a smartphone,

- the recording of secure videos: a sensor

(accelerometer) automatically triggers the
camera in the event of an impact,

- the sharing of photos and videos by

email, text and on social media via the
"ConnectedCAM CITROËN™" application
on a smartphone.

* Depending on the country of sale.

As the use of the ConnectedCAM
CITROËN™ is under your control and
your responsibility, you must ensure
that data protection regulations (images
of other people, vehicle number plates,
protected buildings, etc.), the highway
code and road safety regulations are
complied with. Check first that your
insurance company accepts the films
collected from the ConnectedCAM
CITROËN

™ as evidence.

Operation

In order to be able to use all of the functions of

the camera, you must carry out the following

operations:
F download the "ConnectedCAM

CITROËN™

" application onto a smartphone,

pair the smartphone with the camera

following the instructions given by the

application.

Pairing is necessary at the first connection.
After this it will be automatic.
The default pairing code is: ConnectedCam.

F Press and hold this button to switch the

camera on.

The indicator lamp in the button comes on.

Off

F Press and hold this button to switch the

camera off.

The indicator lamp in the button switches off.

If you switch the camera off manually, it will
remain off even after restarting the vehicle. You
must switch it back on manually.

When the camera is switched on, video
recording is automatic and permanent.

194

Driving

B618_en_Chap06_conduite_ed01-2016

Managing photos and videos

Press this button briefly to take a

photo.

An audible signal confirms that the request has
been taken into account.

F Press and hold this button to

record a video.

An audible signal confirms that the request has
been taken into account.
Using the "ConnectedCAM CITROËN™"
application, you will then be able to share
your photos and videos automatically and
immediately on social media or by email.
A "micro USB" port also permits retrieval of the
data from the camera onto other media such
as: computers, tablets, etc.

System reset

Operating fault

Pressing and holding these two buttons
simultaneously resets the system.
This action clears all the data recorded on the
camera and resets the camera's default pairing
code.

If a system fault occurs, the indicator
lamp in the button flashes.

Have it checked by a CITROËN dealer or a
qualified workshop.

As a safety precaution, the driver
must not use the ConnectedCAM
CITROËN™ application accessible
from a smartphone while driving. They
must carry out all actions requiring
sustained attention when the vehicle is
stationary.

195

Practical information

B618_en_Chap07_info-pratiques_ed01-2016

TOTAL & CITROËN

Partners in performance and
protecting the environment

Innovation in the search for
performance

For over 40 years, the TOTAL Research and
Development departments have developed lubricants
for CITROËN, to match the latest technical innovations
on CITROËN vehicles, both for competition and for
everyday motoring.
For you, this is an assurance that you will obtain the
best performance from your engine.

Optimum protection for
your engine

By having your CITROËN vehicle
serviced with TOTAL lubricants, you are
contributing towards improving the life
and performance of your engine, while
also protecting the environment.

196

Practical information

B618_en_Chap07_info-pratiques_ed01-2016

Fuel tank

Capacity of the tank:
- Petrol: approximately 45 litres.
- Diesel: approximately 42 or 50 litres (depending on version).

Low fuel level

Refuelling

When the low fuel level is reached,
this warning lamp in the instrument
panel comes on, accompanied by
an audible warning, a message and
the last bar of the fuel gauge flashes
in red.

To refuel in complete safety:
F You must switch off the engine.
F

Open the filler flap.

A label on the inside of the fuel filler flap
reminds you of the type of fuel to use,
depending on your engine type.
Additions of fuel must be of at least 5 litres to
be registered by the fuel gauge.

When it first comes on, about 5 litres of fuel
remain in the tank.
Until sufficient fuel has been added, this
warning lamp appears every time the ignition
is switched on, accompanied by an audible
warning and a message. This audible warning
and message are repeated with increasing
frequency as the fuel level drops towards "0".
Refuel as soon as possible to avoid running
out.

Opening the filler cap may result in an inrush of
air. This is entirely normal and results from the
sealing of the fuel system.

If your vehicle is fitted with Stop & Start,
never refuel with the engine in STOP
mode; you must switch off the ignition
using the key, or the START/STOP
button if your vehicle has Keyless Entry
and Starting.

For more information on Running
out of fuel (Diesel), refer to the
corresponding section.

Take care to select the pump that delivers

the correct type of fuel for your vehicle.

Introduce the key into the cap then turn it to

the left, or turn the cap manually to the left
(depending on version).

197

Practical information

B618_en_Chap07_info-pratiques_ed01-2016

Remove the cap and place it on its support

(on the filler flap).

F Introduce the filler nozzle and push it in as

far as possible before starting to refuel (risk
of blowback).

Maintain this position throughout the

refuelling operation.

Once you have finished refuelling:
F

Refit the filler cap.

Turn the key to the right then remove it

from the cap, or turn the cap manually to
the right (depending on version).

Push the fuel flap to close it.

If you are filling your tank to the top, do not
persist after the 3

cut-off; this could cause

malfunctions.
Your vehicle is fitted with a catalytic converter,
which helps to reduce the level of harmful
emissions in the exhaust gases.
For petrol engines, you must use unleaded
fuel.
The filler neck is narrower, allowing only
unleaded petrol nozzles to be introduced.

Your vehicle is equipped with a safety device
which cuts off the fuel supply in the event of a
collision.

Fuel cut-off

If you have put in the wrong fuel
for your vehicle, you must have the
fuel tank drained and filled with
the correct fuel before starting the
engine.

198

Practical information

B618_en_Chap07_info-pratiques_ed01-2016

Misfuel prevention (Diesel)*

When a petrol filler nozzle is introduced into
the fuel filler neck of a Diesel vehicle, it comes
into contact with the flap. The system remains
closed and prevents filling.
Do not persist but introduce a Diesel type
filler nozzle.

* Depending on the country of sale.

Mechanical device which prevents filling the tank of a Diesel vehicle with petrol. It avoids the risk of
engine damage that can result from filling with the wrong fuel.

It remains possible to use a fuel can to
fill the tank.
In order to ensure a good flow of fuel,
do not place the nozzle of the fuel can
in direct contact with the flap of the
misfuel prevention device and pour
slowly.

Travelling abroad

As Diesel fuel pump nozzles may
be different in other countries, the
presence of the misfuel prevention
device may make refuelling impossible.
Not all Diesel vehicles are fitted with
misfuel protection, so before travelling
abroad, we recommend that you check
with the CITROËN dealer network,
whether your vehicle is suitable for the
fuel pumps in the country in which you
intend to travel.

Operation

199

Practical information

B618_en_Chap07_info-pratiques_ed01-2016

Fuel used for petrol engines

The petrol engines are compatible with
bio-fuels that conform to current and future
European standards and can be obtained from
filling stations:

Fuel used for Diesel
engines

The Diesel engines are compatible with
biofuels that conform to current and future
European standards and can be obtained from
filling stations:

- Petrol that meets the EN228

standard, mixed with a bio-
fuel meeting the EN15376
standard.

- Diesel fuel that meets

standard EN590 mixed with
a biofuel that meets standard
EN14214 (possibly containing
up to 7 % Fatty Acid Methyl
Ester),

The use of B20 or B30 fuel
meeting standard EN16709
is possible in your Diesel
engine. However, this use,
even occasional, requires
strict application of the special
servicing conditions referred to as
"Arduous conditions".

- Diesel fuel that meets

standard EN16734 mixed with
a biofuel that meets standard
EN14214 (possibly containing
up to 10 % Fatty Acid Methyl
Ester),

Paraffinic Diesel fuel that
meets standard EN15940
mixed with a biofuel that
meets standard EN14214
(possibly containing up to 7 %
Fatty Acid Methyl Ester).

The use of any other type of (bio)
fuel (vegetable or animal oils, pure
or diluted, domestic fuel...) is strictly
prohibited (risk of damage to the engine
and fuel system).

The only petrol additives authorised for
use are those that meet the B715001
standard.

For more information, contact a CITROËN
dealer or a qualified workshop.

The only Diesel additives authorised for
use are those that meet the B715000
standard.

Travelling abroad

Certain fuels could damage the engine of
your vehicle. In certain countries, the use of
a particular fuel may be required (specific
octane rating, specific sales name…) to
ensure correct operation of the engine.
For any additional information, contact your
dealer.

200

Practical information

B618_en_Chap07_info-pratiques_ed01-2016

Snow chains

In wintry conditions, snow chains improve traction as well as the behaviour of the vehicle when braking.

Use only the chains designed to be fitted to the
type of wheel fitted to your vehicle:

Original tyre size

Type of chain

185/65 R15

Link of 9 mm

maximum

195/65 R15

205/55 R16

205/50 R17

Cannot be fitted with chains

For more information on snow chains, contact a
CITROËN dealer or a qualified workshop.

Advice on installation

If you have to fit the chains during a

journey, stop the vehicle on a flat surface
on the side of the road.

Apply the parking brake and position any

wheel chocks to prevent movement of your
vehicle.

Fit the chains following the instructions

provided by the manufacturer.

Move off gently and drive for a few

moments, without exceeding 30 mph
(50 km/h).

Stop your vehicle and check that the snow

chains are correctly tightened.

Take account of the legislation in force
in your country on the use of snow
chains and the maximum running speed
authorised.

The snow chains must be fitted only
to the front wheels. They must never
be fitted to "space-saver" type spare
wheels.

Avoid driving with snow chains on roads
that have been cleared of snow, to
avoid damaging your vehicle's tyres and
the road surface. If your vehicle is fitted
with alloy wheels, check that no part of
the chain or its fixings is in contact with
the wheel rim.

It is strongly recommended that before
you leave, you practise fitting the snow
chains on a level and dry surface.

201

Practical information

B618_en_Chap07_info-pratiques_ed01-2016

Very cold climate screen

Removable screen which prevents the accumulation of snow at the radiator cooling fan.

Before fitting or removing the screen,
ensure that the engine is off and
the cooling fan has stopped. It is
recommended that the screen be fitted
and removed by a CITROËN dealer or a
qualified workshop.

Fitting

F Offer up the screen to the front of the front

bumper lower grille.

Press on the screen to engage its fixing

clips.

Removal

F Use a screwdriver as a lever to unclip each

fixing clip in turn.

Do not forget to remove the very cold
climate screen:
- when the exterior temperature

exceeds 10° C (e.g. in summer),

when towing,

at speeds above 75 mph (120 km/h).

202

Practical information

B618_en_Chap07_info-pratiques_ed01-2016

You must observe the maximum trailer
weight, indicated on the registration
certificate or in the technical
specification for your vehicle.

Towing a trailer

We recommend the use of genuine
CITROËN towbars and their harnesses
that have been tested and approved
from the design stage of your vehicle,
and that the fitting of the towbar is
entrusted to a CITROËN dealer or a
qualified workshop.
If the towbar is not fitted by a
CITROËN dealer, it must still be
fitted in accordance with the vehicle
manufacturer's instructions.

Your vehicle is primarily designed for
transporting people and luggage, but it may
also be used for towing a trailer.

Driving with a trailer places greater
demands on the towing vehicle and the
driver must take particular care.
For more information on Driving
advice

, particularly when towing, refer

to the corresponding section.

For more information on Weights (and
the towed loads which apply to your
vehicle) refer to the corresponding
section.

Closer

For towing, the closer must be removed if fitted
on your vehicle.
It is located behind the lower air intake grille.

To remove it, consult a CITROËN dealer or a
qualified workshop.

203

Practical information

B618_en_Chap07_info-pratiques_ed01-2016

Load reduction mode

System which manages the use of certain
functions according to the level of charge
remaining in the battery.
When the vehicle is being driven, the load
reduction function temporarily deactivates
certain functions, such as the air conditioning,
the heated rear screen...
The deactivated functions are reactivated
automatically as soon as conditions permit.

System which manages the duration of use of
certain functions to conserve a sufficient level
of charge in the battery.
After the engine has stopped, you can
still use functions such as the audio and
telematics system, windscreen wipers, dipped
beam headlamps, courtesy lamps, etc. for
a maximum combined duration of about
forty minutes.

Energy economy mode

Switching to economy mode

A message appears in the instrument panel
screen indicating that the vehicle has switched
to economy mode and the active functions are
put on standby.
If a telephone call is being made at this time, it
will be maintained for around 10 minutes with
the Bluetooth

hands-free system of your audio

system.

Exiting economy mode

These functions are reactivated automatically
next time the vehicle is driven.
In order to restore the use of these functions
immediately, start the engine and let it run:
- for less than ten minutes, to use the

equipment for approximately five minutes,

- for more than ten minutes, to use the

equipment for up to approximately
thirty minutes.

Let the engine run for the duration specified to
ensure that the battery charge is sufficient.
Do not repeatedly and continuously restart the
engine in order to charge the battery.

A flat battery prevents the engine from
starting.
For more information on the 12 V
battery

, refer to the corresponding

section.

204

Practical information

B618_en_Chap07_info-pratiques_ed01-2016

Changing a wiper blade

Before removing a front
wiper blade

Within one minute after switching off

the ignition, operate the wiper stalk to
position the wiper blades vertically on the
windscreen,

or
F

From one minute after switching off the

ignition, reposition the arms manually.

Fitting

Put the corresponding new wiper blade in

place and clip it.

Fold down the wiper arm carefully.

Removing

Raise the corresponding wiper arm.

Unclip the wiper blade and remove it.

After fitting a front wiper
blade

Switch on the ignition.

Operate the wiper stalk again to park the

wiper blades.

Replacement of the arms must be done
by a CITROËN dealer or a qualified
workshop.

205

Practical information

B618_en_Chap07_info-pratiques_ed01-2016

Roof bars

Observe the fitting instructions and the
conditions of use given in the information
provided with the roof bars.

For safety reasons and to avoid damaging the
roof, it is essential to use transverse roof bars
that are approved for your vehicle.

Maximum load, distributed over the roof
bars, for a loading height not exceeding
40 cm: 70 kg.
This value is subject to change, please
check the maximum load stated in the
instructions provided with he roof bars.
If the height exceeds 40 cm, adapt the
speed of the vehicle to the profile of the
road to avoid damaging the roof bars
and the fixings on the vehicle.
Please refer to national legislation so as
to meet the requirements on carrying
objects that are longer than the vehicle.

To install the roof bars, you must secure
them only to the four anchorage points in the
roof frame. These points are masked by the
vehicle's doors when closed.

The roof bar fixings include a stud that should
be introduced into the aperture at each
anchorage point.

Recommendations

Distribute the load evenly, avoiding

overloading on one side.

Arrange the heaviest part of the load as

close as possible to the roof.

Anchor the load securely and fit a warning

flag if part of it overhangs the vehicle.

Drive gently, as the vehicle will be more

liable to the effects of side winds (vehicle
stability may be affected).

Remove the roof bars as soon as they are

no longer needed.

206

Practical information

B618_en_Chap07_info-pratiques_ed01-2016

Bonnet

Open the left-hand front door.

The location of the interior bonnet
release lever prevents opening of the
bonnet when the left-hand front door
is shut.
When the engine is hot, handle the
exterior safety catch and the stay with
care (risk of burns), using the protected
area.
When the bonnet is open, take care not
to damage the safety catch.

Lift the safety catch and raise the bonnet.

Unclip the stay from its housing and place

it in the support slot to hold the bonnet
open.

Opening

Pull the release lever, located at the bottom

of the door aperture, towards you.

The cooling fan may start after switching off the engine: take care with articles and
clothing that might be caught by the fan blades.

Do not open the bonnet under very
windy conditions.

Closing

Take the stay out of its support slot.

Clip the stay back into its housing.

F Lower the bonnet and release it at the end

of its travel.

Pull on the bonnet to check that it has

latched correctly.

Because of the presence of electrical equipment under the bonnet, it is recommended that
exposure to water (rain, washing, ...) be limited.

Before doing anything under the
bonnet, deactivate the Stop & Start
system to avoid any risk of injury
resulting from an automatic change to
START mode.

Citroen C3 (2017 year). Instruction - part 13
