Citroen SpaceTourer (2016 year). Instruction

463

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

Level 1

Level 2

Level 3

Comments

Settings

Secondary page

Setting

the time-date

Date

Date

Enter the date and select the date format.

Date format:

Time

Time

Set the time.

Time Zone

Define the time zone.

Time format:

Select the time format: 12h / 24h.

Synchronisation with
GPS (UTC):

Activate or deactivate synchronisation with
GPS.

Confirm

Save the settings.

Settings

Secondary page

Setting

of the profiles

Profile 1

Enter settings for the profiles.

Profile 2

Profile 3

Common profile

Confirm

Save the settings.

464

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

Press Settings to display the primary
page.

Profile settings

Audio settings

Press Settings to display the primary
page.

Select "Audio settings

Select "Ambience"

"Position"

"Sound"

"Voice"

"Ringtone

On-board audio: Arkamys

Sound

Staging optimises the distribution of
sound in the passenger compartment.

The settings for "Position" (All
passengers, Driver and Front only) are
common to all sources.

Activate or Deactivate "Touch tones",
"Volume linked to speed" and
"Auxiliary input

The sound distribution (or spatialisation
with the Arkamys

system) is audio

processing that allows the quality of the
sound to be adapted according to the
number of passengers in the vehicle.
Available only with the 6-speaker
configuration.

The audio Ambience

settings

(6 ambiences available) as well as the
Bass, Medium and Treble

settings

are different and independent for each
sound source.
Activate or Deactivate "Loudness

Press "Confirm

" to save the settings.

Press "Confirm

Press the "OPTIONS

" button to go to

the secondary page.

Select "Profile 1", "Profile 2",
"Profile 3" or "Common profile

Select "Setting of the profiles

Press this button to enter a name for
the profile using the virtual keypad

As a safety measure and because it
requires the sustained attention of the
driver, changes to settings must only be
done with the vehicle stationary

465

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

Select a "Profile" (1 or 2 or 3) to
associate the "Audio settings

" with it.

Select "Audio settings

Select "Ambience

"Distribution

"Sound

"Voice

"Ringtone

The location for the photograph is
square; the system deforms the original
photograph if in another format.

Initialisation of the profile selected
activates the English language by default.

Press "Confirm

" to save the settings.

Press "Confirm" to accept the
transfer of the photograph.

Press "Confirm

" again to save the

settings.

Press this button to add a photograph
to the profile.

Insert a USB memory stick containing
the photograph in the USB port.
Select the photograph.

Press this button to initialise the
profile selected.

466

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

Press Settings to display the primary
page.

Press the "OPTIONS

" button to go to

the secondary page.

Press the "OPTIONS

" button to go to

the secondary page.

Press the "OPTIONS

" button to go to

the secondary page.

Select "System settings

Select "Screen configuration

Select "Units

" to change the units

for distance, fuel consumption and
temperature.

Select "Languages

" to change the

language.

Activate or deactivatre "Automatic
scrolling

Adjust the brightness of the screen.

Select "Factory settings" to return
to the initial settings.

Select "System info" to display the
versions of the different modules
installed in the system.

Modifying system settings

Returning the system to factory settings
activates the English language by
default.

Select "Animation

Select "Brightness

Select the language

Press Settings to display the primary
page.

Press the "OPTIONS

" button to go to

the secondary page.

Select "Setting the time-date

Setting the date

467

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

Press Settings to display the primary
page.

Press the "OPTIONS

" button to go to

the secondary page.

Select "Date

Select "Time

Select "Setting the time-date

Adjustment of the time and date is only
available if synchronisation with GPS is
deactivated.
The change between winter and
summer time is done by changing the
time zone.

The system does not automatically
manage the change between winter
and summer time (depending on
country).

Setting the time

Press this button to define the date.

Press this button to adjust the time
using the virtual keypad.

Press "Confirm

Press this button to define the time
zone.

Select the display format of the date.

Select the display format for the time
(12h / 24h).

Activate or deactivate
synchronisation with GPS (UTC).

468

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

Radio

QUESTION

ANSWER

SOLUTION

The quality of reception of
the radio station listened
to gradually deteriorates
or the stored stations do
not function (no sound,
87.5 Mhz is displayed...).

The vehicle is too far from the transmitter used by the station
listened to or there is no transmitter in the geographical area
through which the vehicle is travelling.

Activate the "RDS" function by means of the
short-cut menu to enable the system to check
whether there is a more powerful transmitter in
the geographical area.

The environment (hills, buildings, tunnels, basement car parks...)
block reception, including in RDS mode.

This phenomenon is normal and does not indicate
a fault with the audio system.

The aerial is absent or has been damaged (for example when going
through a car wash or into an underground car park).

Have the aerial checked by a franchised dealer.

I cannot find some radio
stations in the list of
stations received.

The station is not received or its name has changed in the list.

Press on the "Update list" button in the "Radio
stations" secondary menu.

Some radio stations send other information in place of their name
(the title of the song for example).
The system interprets this information as the name of the station.

The name of the radio
station changes.

Frequently asked questions

The following table groups together the answers to the most frequently asked questions concerning your audio system.

469

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

Media

QUESTION

ANSWER

SOLUTION

Playback of my USB
memory stick starts only
after a very long wait
(around 2 to 3 minutes).

Some files supplied with the memory stick may greatly slow down
access to reading the memory stick (multiplication by 10 of the
catalogue time).

Delete the files supplied with the memory stick
and limit the number of sub-folders in the file
structure on the memory stick.

Some characters in the
media information are not
displayed correctly while
playing.

The audio system does not display some types of characters.

Use standard characters to name tracks and
folders.

Playing of streaming files
does not start.

The peripheral device connected does not support automatic play.

Start the playback from the device.

The names of tracks and
the track length are not
displayed on the screen
when streaming audio.

The Bluetooth profile does not allow the transfer of this information.

470

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

QUESTION

ANSWER

SOLUTION

I cannot connect my
Bluetooth telephone.

The telephone's Bluetooth function may be switched off or the
telephone may not be visible.

Check that your telephone's Bluetooth function is
switched on.
Check in the telephone settings that it is "visible
to all".

The Bluetooth telephone is not compatible with the system.

You can check the compatibility of your
telephone at the brand's website (services).

The volume of the
telephone connected
in Bluetooth mode is
inaudible.

The volume depends both on the system and on the telephone.

Increase the volume of the audio system, to
maximum if required, and increase the volume of
the telephone if necessary.

The ambient noise level has an influence on the quality of
telephone communication.

Reduce the ambient noise level (close the
windows, reduce the booster fan speed, slow
down, ...).

Some contacts are
duplicated in the list.

The options for synchronizing contacts are synchronizing the
contacts on the SIM card, the contacts on the telephone, or both.
When both synchronizations are selected, some contacts may be
duplicated.

Select "Display SIM card contacts" or "Display
telephone contacts".

Contacts are not shown in
alphabetical order.

Some telephones offer display options. Depending on the settings
chosen, contacts can be transferred in a specific order.

Modify the display setting in the telephone
directory.

The system does not
receive SMS text messages.

The Bluetooth mode does not permit sending SMS text messages
to the system.

Telephone

471

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

QUESTION

ANSWER

SOLUTION

In changing the setting
of treble and bass the
equalizer setting is
deselected.

The selection of an equalizer setting imposes the settings for treble
and bass and vice-versa.

Modify the treble and bass or equalizer settings
to obtain the desired musical ambience.

In changing the equalizer
setting, treble and bass
return to zero.

When changing the
balance settings, the
distribution setting is
deselected.

The selection of a distribution setting imposes the balance settings
and vice-versa.

Modify the balance or distribution settings to
obtain the desired musical ambience.

When changing a
distribution setting,
the balance setting is
deselected.

Settings

472

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

QUESTION

ANSWER

SOLUTION

There is a difference in
sound quality between the
different audio sources.

For optimum sound quality, the audio settings for Loudness,
Ambience, Treble, Bass and Volume can be adapted to the different
sound sources, which may result in audible differences when
changing source.

Check that the audio settings for Loudness,
Ambience, Treble, Bass and Volume are adapted
to the sources listened to. Adjust the Balance,
Treble and Bass to the middle position, select the
"None" musical ambience and set the loudness
correction to the "Active" position in CD mode or
to the "Inactive" position in radio mode.

With the engine off, the
system switches off after a
few minutes of use.

When the engine is switched off, the system's operating time
depends on the state of charge of the battery.
The switch-off is normal: the system switches to economy mode
and switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery
charge.

473

Audio and Telematics

Spacetourer-VP_en_Chap10d_RD6_ed01-2016

Bluetooth

audio system

Contents

First steps

474

Steering mounted controls - Type 1

475

Steering mounted controls - Type 2

DAB (Digital Audio Broadcasting) radio

480

Media 482
Telephone

487

Frequently asked questions

492

Your audio system is coded in such a way that it will only operate
in your vehicle.

The different functions and adjustments described vary
according to the version and configuration of your vehicle.

As a safety measure and because it requires the sustained
attention of the driver, the pairing of your Bluetooth telephone to
the Bluetooth hands-free audio system must only be carried out
with the vehicle stationary

and the ignition on.

To avoid discharging the battery, the audio system may switch
off after a few minutes if the engine is not running.

474

Audio and Telematics

First steps

Press: On / Off
Rotate: adjust volume.

Short press: change audio source
(Radio; USB; AUX (if a device is
connected); CD; Streaming).
Long press: display the telephone
menu (if a telephone is connected).

Radio:
Short press: display the list of radio
stations.
Long press: update the list.
Media:
Short press: display the list of folders.
Long press: display the sorting
options.

Select the screen display mode,
between:
Date; Audio functions; Trip computer;
Telephone.

Adjust audio settings:
Front/rear fader; left/right balance;
bass/treble; loudness; audio
ambience.
Activation / deactivation of automatic
volume adjustment (linked to the
speed of the vehicle).

Radio:
Manual step by step search up /
down for radio stations.
Select previous / next MP3 track.
Media:
Select previous / next folder / genre /
artist / playlist on the USB device.
Scroll in a list.

Abandon the current operation.
Go up one level (menu or folder).

Confirm or display contextual menu.

Buttons 1 to 6.
Short press: select the preset radio
station.
Long press: preset a station.

Radio:
Automatic step by step search up /
down for radio stations.
Media:
Select previous / next CD, USB,
streaming track.
Scroll in a list.

Access to main menu.

Activate / Deactivate TA (traffic
announcements)
Long press: select type of
announcement.

Select waveband: FM / DAB / AM.

475

Audio and Telematics

Spacetourer-VP_en_Chap10d_RD6_ed01-2016

Steering mounted controls - Type 1

Radio:
Short press: display the list of radio
stations.
Long press: update the list.
Media:
Short press: display the list of folders.
Long press: display the sorting
options.

Decrease volume.

Radio:
Select the previous / next preset
radio station.
Select the previous / next item in a
menu or a list.
Media:
Select of the previous / next track
Select the previous / next item in a
menu or a list.

Mute / Restore sound by
simultaneously pressing the increase
and decrease volume buttons.

Other than telephone calls:
Short press: change audio source
(Radio; USB; AUX (if a device is
connected); CD; Streaming), confirm
if the "Telephone

" menu is open.

Long press: open the "Telephone"
menu.
In the event of a telephone call:
Short press: accept the call.
Long press: reject the call.
During a telephone call:
Short press: open the contextual
telephone menu.
Long press: end the call.

Confirm a selection.

Increase volume.

476

Audio and Telematics

Steering mounted controls - Type 2

Decrease volume.

Mute / Restore sound.

Other than telephone call:
Short press: change audio source
(Radio; USB; AUX (if a device is
connected); CD; Streaming), confirm
if the "Telephone

" menu is open.

Increase volume.

Access to the main menu.

Start voice recognition of your
smartphone via the system.

Radio:
Short press: display the list of radio
stations.
Long press: update the list.
Media:
Short press: display the list of folders.
Long press: display the sorting
options.

Radio:
Select the previous / next preset
radio station.
Select the previous / next item in a
menu or a list.
Media:
Select the previous / next track.
Select the previous / next item in a
menu or a list.

Press the thumbwheel: confirm.

477

Audio and Telematics

Spacetourer-VP_en_Chap10d_RD6_ed01-2016

Menus

"Multimedia

": Media settings, Radio

settings.

Depending on version.

Move from one menu to another.

Enter a menu.

"Trip computer

"Maintenance

": Diagnosis, Warning

log, ... .

"Connections

": Manage

connections, search for devices.

"Telephone

": Call, Directory

management, Telephone
management, End call.

"Personalisation-configuration

Define the vehicle settings, Choice
of language, Display configuration,
Choice of units, Date and time
adjustment.

Press the "MENU

" button.

478

Audio and Telematics

RDS

Short procedure

Long procedure

The external environment (hills,
buildings, tunnels, basement car
parks, ...) may block reception,
including in RDS mode. This is a
normal effect of the way in which radio
waves are transmitted and does not
indicate any failure of the audio system.

Press the "MENU

" button.

Select "Audio functions

Press OK

Select the "FM waveband
preferences

" function.

Press OK

Select "RDS

Press OK, RDS is displayed in the
screen.

In "Radio" mode, press the OK button to
activate or deactivate RDS directly.

RDS, if activated, enables you to continue
listening to the same station by automatic
retuning to alternative frequencies.
However, in certain conditions, coverage
of an RDS station may not be assured
throughout the country as radio stations
do not cover 100 % of the territory. This
explains the loss of reception of a station
that can occur during a journey.

If RDS is not available, the RDS symbol
appears barred in the screen.

Radio

Selecting a station

Press the SOURCE button
repeatedly and select the radio.

Press this button to select a
waveband (FM / AM / DAB).

Press one of the buttons to carry
out an automatic search for radio
stations.

Press one of the buttons to carry out
a manual search up / down for radio
frequencies.

Press this button to display the list of
stations received locally.
To update this list, press for more
than two seconds. The sound is cut
while updating.

Citroen SpaceTourer (2016 year). Instruction - part 30
