Citroen Jumpy (2016 year). Instruction - part 24





.

367

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

TMC (Traffic Message
Channel)

TMC (Traffic Message Channel) is a
European standard on the broadcasting
of traffic information via the RDS
system on FM radio, transmitting traffic
information in real time.
The TMC information is then displayed
on a GPS Navigation system map and
taken into account straight away during
navigation, so as to avoid accidents,
traffic jams and closed roads.

The display of danger areas depends
on the legislation in force and
subscription to the service.

368

12:13

23 °C

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Connected navigation

Network connection provided by the vehicle

OR

Network connection provided by the user

Depending on the equipment level of the vehicle

.

369

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

As a safety measure and because it
requires sustained attention by the
driver, using a smartphone when
driving is prohibited.
All operations must be done with the
vehicle stationary

.

Connected navigation connection

The principles and standards
are constantly changing. For
communication between your
smartphone and the system to operate
correctly, we recommend that you
keep your smartphone's operating
system up to date, and the time and
date on your smartphone and the
system correct.

The services offered with connected
navigation are as follows.
A connected services pack:
- Weather,
-  Filling stations,
-  Car park,
- Traffic,
-  POI, local search.
A Danger area pack.

Activate the Bluetooth function on the
telephone and ensure that it is visible
to all (see the "Connectivity" section).

Connect the USB cable.
The smartphone is in charge mode
when connected by USB cable.

The system is automatically
connected to the modem included
for the "Emergency or assistance
calls" services and does not require
a connection provided by the user via
their smartphone.

On the arrival of "TOMTOM
TRAFFIC", the services are
available.

For access to connected navigation, you
can use the connection provided by the
vehicle via the "Emergency or assistance
call" services or use your smartphone as
a modem.
Activate and enter settings for
sharing the smartphone connection.

Restrictions of use:
-

With CarPlay

®

, connection sharing is

only with a Wi-Fi connection.

-  With MirrorLink

TM

, connection

sharing is only with a USB
connection.

The quality of services depends on the
quality of the network connection.

Select a Wi-Fi connection found by
the system and connect to it (see the
"Connectivity" section).

USB connection

Network connection provided by
the vehicle

Network connection provided by
the user

Bluetooth connection

Wi-Fi connection

370

12:13

23 °C

12:13

23 °C

1

12:13

23 °C

12:13

23 °C

7

27 28

26

29 30

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Level 3

Point of interest on map

.

371

7

28

27

26

29

30

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Level 3

Comments

Navigation

Select the orientation of the map; north up,
vehicle direction up or perspective.

Navigation

TOMTOM TRAFFIC

On connection of the system to a network,
"TOMTOM TRAFFIC" is displayed instead of
"TMC", for use of all of the options available, in
real time.

Navigation

Weather

Select the options.
The map display the route chosen, depending on
options.

Stations

Car park

Traffic

Danger area

Map color

Select the display mode for the map.

POI on map

Commercial

Select the POIs available.

Geographic

Leisure

Public

Travel

Confirm

Save the options.

View map

Modify city

Select or change a city.

Zoom out.

Zoom in.

372

31

32

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Level 3

Level 4

Level 5

Filling stations located

Sort by spaces

Weather information

.

373

31

32

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Level 3

Level 4

Level 5

Comments

Select city

Confirm

Select or change a city.

Around the vehicle

Select or change a city.

On the route

At the destination

Weather

Weather information

Display the weather forecast for the day or the
following days.

Filling stations

Filling stations around the vehicle

Display the list of filling stations and the
associated information (address, prices,
fuels, ...).

Filling stations on the route

Filling stations at the destination

By distance

By price

Car park

Car parks around the vehicle

Display the list of car parks and the associated
information (address, distance, spaces available,
price, ...).

Car parks on the route

Car parks at the destination

Sort by distance

Sort by spaces

Sort by price

Zoom out.
Zoom in.

374

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Level 3

Level 4

Level 5

Select POI

List of danger areas

Traffic observed

.

375

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Level 3

Level 4

Level 5

Comments

Traffic

Traffic observed

Display traffic information in real time: type,
description and duration (in minutes).

Danger areas

List of danger areas

Display danger areas (roadworks, breakdowns,
accidents, ...) in real time.

Points of interest

Points of
interest

Select POI

Display the list of POIs for the location selected.

376

22

23

1

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Settings specific to
connected navigation

For access to connected navigation,
you have to select the option:
"Authorise sending information

".

Select "Options

".

Select "Alerts

".

- "Allow declaration of danger

areas"

- "Guidance to final destination

on foot"

- "Authorise sending

information"

Activate or deactivate:

Activate or deactivate "Warn of
danger zones

".

The display of danger zones is
conditioned by the legislation in force
and subscription to the service.

The temperature displayed at 6 o'clock in the morning
will be the maximum temperature for the day.
The temperature displayed at 6 o'clock in the evening
will be the minimum temperature for the night.

Select "Settings

".

Press Navigation to display the
primary page.

Press the "MENU

" button to go to the

secondary page.

Display the weather

Select "Weather

".

Press this button to display the first
level of information.

Press this button to display the
detailed weather information.

Select "View map

".

Press Navigation to display the
primary page.

Press this button to display the list of
services.

.

377

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

To distribute information on the
declaration of danger zones, you
should check the option: "Allow
declaration of danger areas

".

You can download updates to the
system, danger zones and mapping,
from the brand's website.
The download procedure can be found
in the same place.

Declaration of "Danger
areas"

Press Navigation to display the
primary page.

Press the "Declare a new danger
area" button located in the upper bar
of the touch screen.

Select the option "Type" to choose
the type of "Danger area".

Select the "Speed" option and enter
it using the virtual keypad.

Press "Confirm" to save and
distribute the information.

378

2

7

3

8

4

6

5

12:13

23 °C

531 kHz

1

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Level 3

Bluetooth connection

Wi-Fi network connection

Networks

Share Wi-Fi connection

Connections and subscriptions to services

Functionalities available according to equipment.

Connectivity

.

379

1

1

1

1

6

7

8

2

3

4

5

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Level 2

Level 3

Comments

Connectivity

Secondary page

Bluetooth

connection

All

Display all telephones, connected or
disconnected.

Connected

Display all connected telephones.

Search

Start a search for a device to connect.

Connectivity

Secondary page

Wi-Fi network

connection

Secured

Display secured Wi-Fi networks.

Not secured

Display non-secured Wi-Fi networks.

Stored

Display remembered Wi-Fi networks.

Connectivity

Secondary page

Manage connection

Display the state of the subscription to connected
services, the state of the network connection and
the connection mode.

Connectivity

Secondary page

Share Wi-Fi

connection

Activation

Activate or deactivating the sharing of the Wi-Fi
connection.

Settings

Select a Wi-Fi network found by the system and
connect to it.

Save settings.

Functionalities available according to equipment.

380

1

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Bluetooth

®

 connection

Procedure from the system

Connection sharing

Press on "Telephone" to display the
secondary page.

Press on "Bluetooth connection

".

Select "Search

".

The list of detected telephones is
displayed.

If the pairing procedure fails, it is recommended
that you deactivate and then reactivate the
"Bluetooth" function in your telephone.

The "Mobile internet data" profile
must be activated for connected
navigation (where the vehicle does not
have "Emergency and assistance call"
services), having first activated sharing
of this connection on your smartphone.

The system offers to connect the
telephone with 3 profiles:
- "Telephone

" (hands-free kit, telephone

only),

- "Streaming

" (wireless play of audio files

on the telephone),

- "Mobile internet data

".

Select the name of the chosen
telephone in the list.

Press on "Confirm

".

Select one or more profiles.

Press on the "OPTIONS" button to
go to the secondary page.

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-
free system of your audio system must
be done with the vehicle stationary
and the ignition on.

Procedure from the telephone

Select the name of the system in the
list of devices detected.

In the system, accept the connection request
from the telephone.

Activate the Bluetooth function on the
telephone and ensure that it is "visible
to all" (telephone configuration).

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

Depending on the type of telephone,
you may be asked to accept or not the
transfer of your contacts and messages.

.

381

1

1

1

7

8

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Wi-Fi connection

Sharing the Wi-Fi connection

Managing connections

To protect from any piracy and provide
maximum security for your systems,
it is recommended that you use a
security code or complex password.

The Wi-Fi connection and the sharing
of the Wi-Fi connection are exclusive.

Press "Confirm

".

Press "Confirm" to start the
connection.

Press "Connectivity" to display the
primary page.

Network connection by the smartphone Wi-Fi.

Creation of a local Wi-Fi network by the
system.

Press Connectivity to display the
primary page.

Press Connectivity to display the
primary page.

Press the "OPTIONS

" button to go to

the secondary page.

Press the "OPTIONS

" button to go to

the secondary page.

Press the "OPTIONS

" button to go to

the secondary page.

Select "Wi-Fi network connection

".

Select "Share Wi-Fi connection

".

Select "Manage connection

".

And / Or

Select the "Secured", "Not secured"
or "Stored

" tab.

Select the "Activation" tab to
activate or deactivate sharing of the
Wi-Fi connection.

Select the "Settings

" to change the

name of the system network and the
password.

With this function you can view the access
to connected services, the availability of
connected services and modify the connection
mode.

Using the virtual keypad, enter the
"Key

" for the Wi-Fi network and the

"Password

".

Select a network.

382

12:13

23 °C

531 kHz

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

MirrorLink

TM

 smartphone connection















Content   ..  22  23  24  25   ..
