Citroen DS5 (2016 year). Instruction

Audio and Telematics

Level 1

Level 2

Level 3

Comments

Telephone

Bluetooth

Contact

All

View contacts according to presentation choices.
Select a contact or a favourite saved in the
system via the profile selected to start the call.

Telephone

Address

Favourites

Sort the contacts by Surname-First name or First
name-Surname.

Update the contacts from the telephone.

Search

Confirm

Search for a contact in the directory.

Create

Telephone

Ceate a new contact in the system.

Address

Confirm

Telephone

Bluetooth

Calls

All

View calls according to choice of presentation.
Select a contact to start the call.

Incoming

Outgoing

Missed

View details for the contact.

Level 1

Level 2

Settings - Bluetooth

Bluetooth connection

Messages

Email

Audio and Telematics

Level 1

Level 2

Comments

Telephone

Secondary page

Bluetooth

connection

All

Display all telephones, connected or
disconnected, recognised by the system.

Connected

Display all connected telephones.

Search

Start the search for a device to connect.

Telephone

Secondary page

Messages

All

Display messages according to the choice made.

Received

Sent

Telephone

Secondary page

Email

Received

Display emails according to the choice made.

Sent

Not read

Mailbox

Level 1

Level 2

Settings - Bluetooth

Options

Quick messages

Audio and Telematics

Level 1

Level 2

Comments

Telephone

Secondary page

Options

Security

Make driving safe.

Voicemail

Enter and save the number for the telephone
voicemail.

Ringtone

Adjust the ringtone volume.

Statistics

Display data for the telephone connected.

Confirm

Save the options.

Telephone

Secondary page

Quick messages

Delayed

Select a quick message from the categories, as
required.

My arrival

Not available

Other

Create

Create a quick message.

Pairing a Bluetooth

telephone

  As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with theBluetooth hands-free
system of your audio system must be
done with the vehicle stationary  and
the ignition on.

Procedure from the telephone

Select the system name in the list of
devices detected.

In the system, accept the connection request
from the telephone.

Procedure from the system

Press on Telephone to display the
primary page.

Press on Connect telephone .

Select " Search ".
The list of telephones detected is
displayed.

If the pairing procedure fails, it is recommended
that you deactivate and then reactivate the
"Bluetooth" function in your telephone.

The system offers to connect the telephone
with 3 profiles:
-

Telephone (hands-free kit, telephone
only),

Streaming (wireless play of audio files on
the telephone),

Mobile internet data .

Depending on the type of telephone,
you may be asked to accept or not
the transfer of your contacts and
messages.

Select the name of the chosen
telephone in the list.

Press " Confirm ".

Select one or more profiles.

Or.

Activate the Bluetooth function on the
telephone and ensure that it is "visible
to all" (telephone configuration).

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

The " Mobile internet data " profile
must be activated for connected
navigation, having first activated
sharing of this connection on your
smartphone.

Connection sharing

Audio and Telematics

Press on Telephone to display the
primary page.

Select " Bluetooth connection " to
display the list of paired devices.

On return to the vehicle, if the last
telephone connected is present again,
it is automatically recognised and
within about 30 seconds of switching
on the ignition, the connection is
established without any action on your
part (Bluetooth activated).

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used. Check in your telephone's
manual and with your service provider
for the services available to you.

The ability of the system to connect
with just one profile depends on the
telephone.
All three profiles may connect by default.

Go to the brand's website for more information
(compatibility, additional help, ...).

To modify the connection profile :

Automatic reconnection

Press on the "details" button.

Press the " OPTIONS " button to go to
the secondary page.

Press on " Confirm ".

Select one or more profiles.

The profiles compatible with the system
are HFP, OPP, PBAP, A2DP, AVRCP,
MAP and PAN.

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

  Make a short press on the steering
mounted TEL  button to accept an
incoming call.

Make a long press.

on the steering mounted TEL button
to reject the call.

And

Select " End call ".

Press on the name of the telephone
chosen in the list to disconnect it.
Press again to connect it.

Select the basket at top right of the
screen to display a basket alongside
the telephone chosen.

Press on the basket alongside the
telephone chosen to delete it.

Managing paired telephones

This function allows the connection or
disconnection of a peripheral device as
well as the deletion of a pairing.

Press on Telephone to display the
primary page.

Press on the " OPTIONS " button to
go to the secondary page.

Select " Bluetooth connection " to
display the list of paired peripheral
devices.

Deleting a telephone

Audio and Telematics

on the steering mounted button.

Using the telephone is not
recommended while driving.
Park the vehicle.
Make the call using the steering
mounted controls.

Making a call

Calling a new number

Press on Telephone to display the
primary page.

Enter the phone number using the
digital keypad.

Press on " Call " to start the call.

Calling a contact

Press on Telephone to display the
primary page.

Or make a long press

on the steering mounted TEL button.

Select " Contact ".

Select the desired contact from the list offered.

Select " Call ".

Calling a recently used number

Press on Telephone to display the
primary page.

Make a long press

Select " Calls ".

Select the desired contact from the list offered.

It is always possible to make a call
directly from the telephone; as a safety
measure, first park the vehicle.

The access to " Messages " depends on
the compatibility of the smartphone and
the integral system.
Depending on the smartphone, access
to your messages or email may be
slow.

Managing messages

The " Email " function allows email
addresses to be entered for a contact,
but the system is not able to send
emails.

Managing contacts / entries

Press Telephone to display the
primary page.

Select " Contact ".

Select " Create " to add a new contact.

In the " Telephone " tab, enter the
telephone numbers for the contact.

In the " Address " tab, enter the
adresses for the contact.

In the " Email " tab, enter the email
addresses for the contact.

Press on " Answer " to send a quick
message stored in the system.

Press on Telephone to display the
primary page.

Press on the " OPTIONS " button to
go to the secondary page.

Select " Messages " to display the list
of messages.

Select the " All " or " Received " or
" Sent " tab.

Select the detail of the message
chosen in one of the lists

Press on " Call " to start the call.

Press on " Play " to hear the message.

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used.
Check in the manual for your telephone
and with your service provider for the
services available to you.

Audio and Telematics

Managing email

Press on this button to " Modify " the
new quick message(s) created.

Press Telephone to display the
primary page.

Press the " OPTIONS " button to go to
the secondary page.

Select " Email " to display the list of
messages.

Select the " Received " or " Sent " or
" Not read " tab.

Select the email chosen in the list.

Press " Play " to hear the email.

The " Modify " function does not apply
to quick messages already present in
the system.

Access to " Email " depends on the
compatibility of the smartphone and the
integral system.

Managing quick messages

Press on Telephone to display the
primary page.

Press on the " OPTIONS " button to
go to the secondary page.

Select " Messages " to display the list
of messages.

Select the " Delayed " or " My arrival "
or " Not available " or " Other " with
the possibility of creating new
messages.

Select the message chosen in one of
the lists.

Press on " Create " to write a new
message.

Press on " Transfer " to select the
addressee(s).

Press on " Play " to play the message.

12:13

23 °C

Audio settings

Level 1

Settings

Level 2

Choice of color scheme

Audio settings

Audio and Telematics

Level 1

Level 2

Comments

Settings

Profile (1, 2, 3)

Activate the profile selected.

Settings

Audio settings

Ambience

Select the sound ambience.

Distribution

Sound distribution by the Arkamys

system.

Sound

Adjust the volume or activate linked to speed.

Voice

Adjust the voice volume.

Ringtone

Adjust the ringtone volume.

Confirm

Save the settings.

Settings

Turn off screen

Function allowing the display to be switched off.
Pressing the screen reactivates it.

Settings

Color schemes

Having chosen the color scheme, save the
setting.

Level 1

Level 2

Level 3

Settings and tools

Screen configuration

System settings

Information

Languages

Screen configuration

Audio and Telematics

Level 1

Level 2

Level 3

Comments

Settings

Secondary page

Screen

configuration

Animation

Activate or deactivate settings.

Brightness

Adjust the level of brightness.

Confirm

Save the settings.

Settings

Secondary page

System

settings

Units

Distance and fuel
consumption

Set the units used for distance, fuel consumption
and temperature.

Temperature

Factory settings

Reinitialize

Return to the factory settings.

System info

View

View the versions of the different modules
(system, mapping, risk areas) installed in the
system as well as the updates available.

Confirm

Save the settings.

Settings

Secondary page

Languages

All

Select the language then confirm.

Europe

Asia

America

Confirm

Having selected the language, save the setting.

Level 1

Level 2

Settings and tools

Setting the time-date

Setting of the profiles

Level 3
