Citroen C-Elysee (2017 year). Instruction

On-line handbook

If the "MyCITROËN" function is not available on the CITROËN public website for your country,

you can find your handbook at the following address:
http://service.citroen.com/ddb/

Find your handbook on the CITROËN website, under "MyCITROËN".

Select:

Select one of the following means of access to

view your handbook on-line...

This personal and customisable space allows you to establish direct and special contact with the

manufacturer.

the language,
the vehicle, its body style,
the print edition of your handbook appropriate for the date of registration of your vehicle.

Scan this code for direct access to your handbook.

Referring to the handbook on-line also gives

you access to the latest information available,

easily identified by the bookmark, associated

with this symbol:

Key

safety warning

additional information

contributes to the protection of the environment

refer to the page indicated

CITROËN has a presence on every continent,
a complete product range,
bringing together technology and a permanent spirit of innovation,
for a modern and creative approach to mobility.
We thank you and congratulate you on your choice.

Happy motoring!

At the wheel of your new vehicle,
getting to know each system,
each control, each setting,
makes your trips, your journeys
more comfortable and more enjoyable.

This handbook has been designed to help to make the
most of your C-ELYSEE in all circumstances and in
complete safety.
Take the time to read through it so as to familiarise
yourself with your vehicle.
This handbook covers all of the variations in equipment
available across the whole C-ELYSEE range.
Your vehicle will be fitted with only some of the
equipment described in this document, depending on its
trim level, version and the specification for the country in
which it was sold.

The descriptions and illustrations are given as indications
only.
Automobiles CITROËN reserves the right to modify the
technical characteristics, equipment and accessories
without having to update this edition of the handbook.

This document forms an integral part of your vehicle.
Remember to pass it on to the new owner in the event of
the sale of the vehicle.

Contents

C-elysee_en_Chap00a_sommaire_ed01-2016

Instrument panel

Indicator and warning lamps

Service indicator

Distance recorders

Setting the date and time

Trip computer

Monochrome screen C

(Audio system / Bluetooth)

Steering wheel adjustment

Ventilation

Heating

Manual air conditioning

(without display screen)

Electronic air conditioning

(with display screen)

Front demist - defrost

Rear screen demist - defrost

Comfort

Driving recommendations

Starting-switching off the engine

Automatic gearbox (EAT6)

Gear efficiency indicator

Headlamp beam height adjustment

Overview

C-elysee_en_Chap00b_vue-ensemble_ed01-2016

Under-inflation detection

This system automatically checks the pressures of
the tyres when driving and alerts you in the event of
under-inflation.

Exterior

Temporary puncture

repair kit

This kit is a complete system consisting of a compressor and
a sealant cartridge, to allow the temporary repair of a tyre.

Rear parking sensors

This system provides a warning when manoeuvring
backwards by detecting obstacles located behind
the vehicle.

195

227

85 / 87

Overview

C-elysee_en_Chap00b_vue-ensemble_ed01-2016

Interior

Electronic air conditioning (with display screen)

This system, equipped with a display screen, provides you with optimum
control of temperature and air circulation in the passenger compartment.

Speed limiter / Cruise control

These two systems allow you to control the
speed of your vehicle according to a value you
have set.

Audio and communication

systems

These systems benefit from the latest
technology: MP3 compatible audio systems,
USB player, Bluetooth hands-free system,
auxiliary inputs, ...

Audio system / Bluetooth

Audio system

Overview

C-elysee_en_Chap00b_vue-ensemble_ed01-2016

Instruments and controls

Cruise control / speed limiter controls.

Steering wheel adjustment control.

Lighting and direction indicator stalk.

Instrument panel.

Driver's airbag and horn.

Cigarette lighter / 12 V accessory socket.

USB port / auxiliary socket.

Heated seat control.

Fuel filler flap release.

Boot lid release lever*.

Bonnet release.

10.

Fusebox.

11.

Headlamp height adjustment.

12.

Dynamic Stability Control (ESP/ASR)

button

Boot lid release button*.

Alarm warning lamp.

13.

Door mirror adjustment control.

14.

Side adjustable and air vent.

15.

Front door glass demisting/defrosting vent.

* Depending on version.

Overview

C-elysee_en_Chap00b_vue-ensemble_ed01-2016

Instruments and controls

Steering lock and ignition switch.

Wiper and screenwash / trip computer

control stalk.

Central locking button.

Open storage.

Monochrome screen C
(Audio system / Bluetooth).

Adjustable centre air vents.

Windscreen demisting/defrosting vent.

Passenger's airbag.

Glove box.

Passenger's airbag deactivation switch.

Hazard warning lamps button.

10.

Audio system.

11.

Heating / Air conditioning controls.

12.

Ashtray / Cup holder.

13.

Electric window switches.

14.

Gear lever.

15.

Parking brake.

Eco-driving

As a passenger, if you avoid connecting your multimedia devices
(film, music, video game...), you will contribute towards limiting the
consumption of electrical energy, and so of fuel.
Disconnect your portable devices before leaving the vehicle.

Eco-driving

Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO

emissions.

Optimise the use of your gearbox

With a manual gearbox, move off gently, change up without waiting and
drive by changing up quite soon.

With an automatic or electronic gearbox, stay in Drive "D" or Auto "A",
according to the type of gearbox, without pressing the accelerator pedal
heavily or suddenly.

The gear shift indicator invites you to select the most suitable gear:
once the indication is displayed in the instrument panel, follow the
advice straight away.
For vehicles fitted with an electronic or automatic gearbox, this indicator
only appears in manual mode.

Drive smoothly

Maintain a safe distance between vehicles, use engine braking rather
than the brake pedal, and press the accelerator progressively. These
practices contribute towards a reduction in fuel consumption and CO

emissions and also helps reduce the background traffic noise.

If your vehicle has cruise control, make use of the system at speeds
above 25 mph (40 km/h) when the traffic is flowing well.

Control the use of your electrical

equipment

Before moving off, if the passenger compartment is too warm,
ventilate it by opening the windows and air vents before using the air
conditioning.
Above 30 mph (50 km/h), close the windows and leave the air vents
open.
Remember to make use of equipment that can help keep the
temperature in the passenger compartment down (window blinds...).
Switch off the air conditioning as soon as the desired temperature is
attained.
Switch off the demisting and defrosting controls, if not automatic.
Switch off the heated seat as soon as possible.

Switch off the headlamps and foglamp when the level of light does not
require their use.

Avoid running the engine before moving off, particularly in winter; your
vehicle will warm up much faster while driving.

Eco-driving

Limit the causes of excess consumption

Spread loads throughout the vehicle; place the heaviest items in the
bottom of the boot, as close as possible to the rear seats.
Limit the loads carried in the vehicle and reduce wind resistance (roof
bars, roof rack, bicycle carrier, trailer...). Use a roof box in preference.
Remove roof bars and roof racks after use.

At the end of winter, remove snow tyres and refit your summer tyres.

Observe the recommendations on maintenance

Check the tyre pressures regularly, when cold, referring to the label in
the door aperture, driver's side.
Carry out this check in particular:
-  before a long journey,
-  at each change of season,
-  after a long period out of use.
Don't forget the spare wheel and the tyres on any trailer or caravan.

Have your vehicle serviced regularly (engine oil, oil filter, air filter...) and
observe the schedule of operations recommended by the manufacturer.

When refuelling, do not continue after the 3

cut-off of the nozzle to

avoid any overflow.

At the wheel of your new vehicle, it is only after the first 1 800 miles
(3 000 kilometres) that you will see the fuel consumption settle down to
a consistent average.

Monitoring

Instrument panel for petrol - Diesel

Rev counter (x 1 000 rpm).

Screen.

Speedometer (mph or km/h).

Electronic or automatic gearbox

information.

Gear shift indicator.

B. Time.

C. Range for the fuel or AdBlue additive and

the SCR system (miles or km)

Trip distance recorder.

Fuel gauge / Diesel preheater.

Service indicator (miles or km)

then,

total distance recorder.

These two functions are displayed
successively when switching on the ignition

Speed limiter or cruise control settings.

Reminder of service information

Reset the selected function to zero (trip
distance recorder or service indicator)

Adjust the time.

Dials

Screen

Monitoring

C-elysee_en_Chap01_controle-de-marche_ed01-2016

Indicator and warning lamps

Certain warning lamps may come on
in one of two different modes. Only by
relating the type of illumination to the
operating status of the vehicle can it
be ascertained whether the situation is
normal or whether a fault has occurred.

When the ignition is switched on

Certain warning lamps come on for a few
seconds when the vehicle's ignition is
switched on.
When the engine is started, these same
warning lamps should go off.
If they remain on, before moving off, refer to the
information on the warning lamp concerned.

Associated warnings

The illumination of certain warning lamps may
be accompanied by an audible signal and a
message in the multifunction screen.
The warning lamps may come on continuously
(fixed) or flash.

Visual indicators informing the driver that a system is in operation (operation or deactivation indicator lamps) or of the occurrence of a fault
(warning lamp).

Monitoring

Operation indicator lamps

If one of the following indicator lamps comes on, this confirms that the corresponding system has come into operation.

Warning / indicator lamp State

Cause

Action / Observations

Left-hand

direction

indicator

flashing with buzzer.

The lighting stalk is pushed down.

Right-hand

direction

indicator

flashing with buzzer.

The lighting stalk is pushed up.

Dipped beam
headlamps

fixed.

The lighting stalk is in the "Dipped
beam headlamps" position.

Main beam
headlamps

fixed.

The lighting stalk is pulled towards
you.

Pull the stalk to return to dipped beam headlamps.

Front foglamps

fixed.

The front foglamps are switched on
using the ring on the lighting control
stalk.

Turn the ring on the lighting control stalk rearward
twice to switch off the front foglamps.

Rear foglamp

fixed.

The rear foglamp has been switched
on using the ring on the lighting
control stalk.

Turn the ring on the lighting control stalk to the rear to
switch off the rear foglamp.

For more information on the lighting controls, refer to the "Visibility" section.

Monitoring

C-elysee_en_Chap01_controle-de-marche_ed01-2016

Warning / indicator lamp State

Cause

Action / Observations

Diesel engine
pre-heating

fixed.

The key is at position 2 (ignition on) in
the ignition switch.

Wait until the warning lamp goes off before starting.
The period of illumination of the warning lamp is
determined by the ambient conditions (up to about
thirty seconds in very low temperatures).
If the engine does not start, switch the ignition off and
then on, wait until the warning lamp goes off again,
then start the engine.

Parking
brake

fixed.

The parking brake is applied or not
properly released.

Release the parking brake to switch off the warning
lamp, keeping your foot on the brake pedal.
Observe the safety recommendations.
For further information on the parking brake, refer to
the "Driving" section.

Foot on the
brake pedal

fixed.

The brake pedal must be pressed.

With an electronic gearbox, press the brake pedal to
start the engine (lever in position N).
With an automatic gearbox, with the engine running,
press the brake pedal before releasing the parking
brake, to unlock the lever and come out of position P.
If you wish to release the parking brake without
pressing the brake pedal, this warning lamp will
remain on.

flashing.

With an electronic gearbox, if you
hold the vehicle on an incline using
the accelerator for too long, the
clutch overheats.

Use the brake pedal and/or the parking brake.

Monitoring

Warning / indicator lamp State

Cause

Action / Observations

Stop & Start

fixed.

When the vehicle stops (red lights,
traffic jams, ...) the Stop & Start system
has put the engine into STOP mode.

The warning lamp goes off and the engine restarts
automatically in START mode, as soon as you want to
move off.

flashes for a few
seconds, then goes
off.

STOP mode is temporarily
unavailable.
or
START mode is invoked
automatically.

For more information on Stop & Start, refer to the
corresponding section.

Citroen C-Elysee (2017 year). Instruction - part 1
