GETTING TO KNOW YOUR INSTRUMENT PANEL

Brake Warning Light

This warning light monitors various brake

functions, including brake fluid level and

parking brake application. If the brake

light turns on it may indicate that the

parking brake is applied, that the brake fluid level

is low, or that there is a problem with the Anti-Lock

Brake System reservoir.
If the light remains on when the parking brake has

been disengaged, and the fluid level is at the full

mark on the master cylinder reservoir, it indicates

a possible brake hydraulic system malfunction or

that a problem with the Brake Booster has been

detected by the Anti-Lock Brake System (ABS) /

Electronic Stability Control (ESC) system. In this

case, the light will remain on until the condition has

been corrected. If the problem is related to the

brake booster, the ABS pump will run when

applying the brake, and a brake pedal pulsation

may be felt during each stop.
The dual brake system provides a reserve braking

capacity in the event of a failure to a portion of the

hydraulic system. A leak in either half of the dual

brake system is indicated by the Brake Warning

Light, which will turn on when the brake fluid level

in the master cylinder has dropped below a

specified level.
The light will remain on until the cause is corrected.

NOTE:

The light may flash momentarily during sharp

cornering maneuvers, which change fluid level

conditions. The vehicle should have service

performed, and the brake fluid level checked.
If brake failure is indicated, immediate repair is

necessary.

Vehicles equipped with the Anti-Lock Brake System

(ABS) are also equipped with Electronic Brake

Force Distribution (EBD). In the event of an EBD

failure, the Brake Warning Light will turn on along

with the ABS Light. Immediate repair to the ABS

system is required.
Operation of the Brake Warning Light can be

checked by turning the ignition switch from the OFF

position to the ON/RUN position. The light should

illuminate for approximately two seconds. The light

should then turn off unless the parking brake is

applied or a brake fault is detected. If the light does

not illuminate, have the light inspected by an

authorized dealer.

The light also will turn on when the parking brake

is applied with the ignition switch in the ON/RUN

position.
NOTE:

This light shows only that the parking brake is

applied. It does not show the degree of brake appli

cation.

Door Open Warning Light — If Equipped

This warning light will illuminate when a

door is ajar/open and not fully closed.

This indicator will reflect which doors

are open.

NOTE:

If the vehicle is moving, there will also be a single

chime.

Electric Power Steering Fault Warning

Light

This warning light will turn on when

there's a fault with the Electric Power

Steering (EPS) system

page 143.

WARNING!

Driving a vehicle with the red brake light on is

dangerous. Part of the brake system may have

failed. It will take longer to stop the vehicle. You

could have a collision. Have the vehicle checked

immediately.

WARNING!

Continued operation with reduced assist could

pose a safety risk to yourself and others. Service

should be obtained as soon as possible.

GETTING TO KNOW YOUR INSTRUMENT PANEL

123

Electronic Throttle Control (ETC) Warning

Light

This warning light will illuminate to

indicate a problem with the ETC system.

If a problem is detected while the vehicle

is running, the light will either stay on or

flash depending on the nature of the problem.

Cycle the ignition when the vehicle is safely and

completely stopped and the transmission is placed

in the PARK (P) position. The light should turn off.

If the light remains on with the vehicle running,

your vehicle will usually be drivable; however, see

an authorized dealer for service as soon as

possible.
NOTE:

This light may turn on if the accelerator and brake

pedals are pressed at the same time.
If the light continues to flash when the vehicle is

running, immediate service is required and you

may experience reduced performance, an

elevated/rough idle, or engine stall and your

vehicle may require towing. The light will come on

when the ignition is placed in the ON/RUN or ACC/

ON/RUN position and remain on briefly as a bulb

check. If the light does not come on during starting,

have the system checked by an authorized dealer.

Engine Coolant Temperature Warning

Light

This warning light warns of an

overheated engine condition. If the

engine coolant temperature is too high,

this indicator will illuminate and a single

chime will sound. If the temperature reaches the

upper limit, a continuous chime will sound for

four minutes or until the engine is able to cool;

whichever comes first.
If the light turns on while driving, safely pull over

and stop the vehicle. If the Air Conditioning (A/C)

system is on, turn it off. Also, shift the transmission

into NEUTRAL (N) and idle the vehicle. If the

temperature reading does not return to normal,

turn the engine off immediately and call for service

page 303.

Hood Open Warning Light

This warning light will illuminate when the

hood is left open and not fully closed.

NOTE:

If the vehicle is moving, there will also be a single

chime.

Liftgate Open Warning Light

This warning light will illuminate when the

liftgate is open.

NOTE:

If the vehicle is moving, there will also be a single

chime.

Oil Pressure Warning Light

This warning light will illuminate to

indicate low engine oil pressure. If the

light turns on while driving, stop the

vehicle, shut off the engine as soon as

possible, and contact an authorized dealer.

A chime will sound when this light turns on.
Do not operate the vehicle until the cause is

corrected. This light does not indicate how much oil

is in the engine. The engine oil level must be

checked under the hood.

Oil Temperature Warning Light

This warning light will illuminate to

indicate the engine oil temperature is

high. If the light turns on while driving,

stop the vehicle and shut off the engine

as soon as possible. Wait for oil temperature to

return to normal levels.

124

GETTING TO KNOW YOUR INSTRUMENT PANEL

Seat Belt Reminder Warning Light

This warning light indicates when the

driver or passenger seat belt is

unbuckled. When the ignition is first

placed in the ON/RUN or ACC/ON/RUN

position and if the driver’s seat belt is unbuckled,

a chime will sound and the light will turn on. When

driving, if the driver or front passenger seat belt

remains unbuckled, the Seat Belt Reminder Light

will flash or remain on continuously and a chime

will sound

page 239.

Transmission Temperature Warning

Light — If Equipped

This warning light will illuminate to warn

of a high transmission fluid temperature.

This may occur with strenuous usage

such as trailer towing. If this light turns

on, stop the vehicle and run the engine at idle or

slightly faster, with the transmission in PARK (P) or

NEUTRAL (N), until the light turns off. Once the light

turns off, you may continue to drive normally.

Vehicle Security Warning Light —

If Equipped

This warning light will flash at a fast rate

for approximately 15 seconds when the

vehicle security system is arming, and

then will flash slowly until the vehicle is

disarmed.

ELLOW

ARNING

IGHTS

Adaptive Cruise Control (ACC) Fault

Warning Light — If Equipped

This warning light will illuminate to

indicate a fault in the ACC system.

Contact a local authorized dealer for

service

page 147.

Electronic Park Brake Warning Light

This warning light will illuminate to

indicate the Electronic Park Brake is not

functioning properly and service is

required. Contact an authorized dealer.

Anti-Lock Brake System (ABS) Warning

Light

This warning light monitors the ABS.

The light will turn on when the ignition is

placed in the ON/RUN or ACC/ON/RUN

position and may stay on for as long as

four seconds.
If the ABS light remains on or turns on while

driving, then the Anti-Lock portion of the brake

system is not functioning and service is required as

soon as possible. However, the conventional brake

system will continue to operate normally,

assuming the Brake Warning Light is not also on.

WARNING!

If you continue operating the vehicle when the

Transmission Temperature Warning Light is

illuminated you could cause the fluid to boil over,

come in contact with hot engine or exhaust

components and cause a fire.

CAUTION!

Continuous driving with the Transmission

Temperature Warning Light illuminated will

eventually cause severe transmission damage

or transmission failure.

GETTING TO KNOW YOUR INSTRUMENT PANEL

125

If the ABS light does not turn on when the ignition

is placed in the ON/RUN or ACC/ON/RUN position,

have the brake system inspected by an authorized

dealer.

Electronic Stability Control (ESC) Active

Warning Light — If Equipped

This warning light will indicate when the

ESC system is Active. The ESC Indicator

Light in the instrument cluster will come

on when the ignition is placed in the ON/

RUN or ACC/ON/RUN position, and when ESC is

activated. It should go out with the engine running.

If the ESC Indicator Light comes on continuously

with the engine running, a malfunction has been

detected in the ESC system. If this warning light

remains on after several ignition cycles, and the

vehicle has been driven several miles (kilometers)

at speeds greater than 30 mph (48 km/h), see an

authorized dealer as soon as possible to have the

problem diagnosed and corrected.



The ESC OFF Indicator Light and the ESC Indi

cator Light come on momentarily each time the

ignition is placed in the ON/RUN or ACC/ON/

RUN position.



The ESC system will make buzzing or clicking

sounds when it is active. This is normal; the

sounds will stop when ESC becomes inactive.



This light will come on when the vehicle is in an

ESC event.

Electronic Stability Control (ESC) OFF

Warning Light — If Equipped

This warning light indicates the ESC is off.

Each time the ignition is turned to ON/RUN or ACC/

ON/RUN, the ESC system will be on, even if it was

turned off previously.

Service LaneSense Warning Light —

If Equipped

This warning light will illuminate when the

LaneSense system is not operating and

requires service. Please see an

authorized dealer.

LaneSense Warning Light — If Equipped

The LaneSense Warning Light will be

solid yellow when the vehicle is

approaching a lane marker. The warning

light will flash when the vehicle is

crossing the lane marker

page 166.

Low Fuel Warning Light

When the fuel level reaches

approximately 1.85 gal (7 L) this warning

light will turn on, and remain on until fuel

is added.

A single warning chime will sound with Low Fuel

Warning.

Low Washer Fluid Warning Light —

If Equipped

This warning light will illuminate and a

single chime will sound when the

windshield washer fluid is low.

Engine Check/Malfunction Indicator

Warning Light

The Engine Check/Malfunction Indicator

Light (MIL) is a part of an Onboard

Diagnostic System called OBD II that

monitors engine and automatic

transmission control systems. This warning light

will illuminate when the ignition is in the ON/RUN

position before engine start. If the bulb does not

come on when turning the ignition switch from OFF

to ON/RUN, have the condition checked promptly.
Certain conditions, such as a loose or missing gas

cap, poor quality fuel, etc., may illuminate the light

after engine start. The vehicle should be serviced if

the light stays on through several typical driving

styles. In most situations, the vehicle will drive

normally and will not require towing.
When the engine is running, the MIL may flash to

alert serious conditions that could lead to

immediate loss of power or severe catalytic

converter damage. The vehicle should be serviced

by an authorized dealer as soon as possible if this

occurs.

126

GETTING TO KNOW YOUR INSTRUMENT PANEL

Service AWD Warning Light — If Equipped

This telltale will turn on to indicate that

the All Wheel Drive (AWD) system is not

functioning properly and that service is

required. Contact an authorized dealer.

Service Forward Collision Warning (FCW)

or Pedestrian Emergency Braking (PEB)

Warning Light — If Equipped

This warning light will illuminate to

indicate a fault in the FCW or PEB

Warning System. Contact an authorized

dealer for service

page 233.

Service Stop/Start System Warning Light —

If Equipped

This warning light will illuminate when the

Stop/Start system is not functioning

properly and service is required. Contact

an authorized dealer for service

page 143.

Tire Pressure Monitoring System (TPMS)

Warning Light

The warning light switches on and a

message is displayed to indicate that the

tire pressure is lower than the

recommended value and/or that slow

pressure loss is occurring. In these cases, optimal

tire duration and fuel consumption may not be

guaranteed.
Should one or more tires be in the condition

mentioned above, the display will show the

indications corresponding to each tire.

Each tire, including the spare (if provided), should

be checked monthly when cold and inflated to the

inflation pressure recommended by the vehicle

manufacturer on the vehicle placard or tire inflation

pressure label. If your vehicle has tires of a different

size than the size indicated on the vehicle placard

or tire inflation pressure label, you should

determine the proper tire inflation pressure for

those tires.
As an added safety feature, your vehicle has been

equipped with a TPMS that illuminates a low tire

pressure telltale when one or more of your tires is

significantly underinflated. Accordingly, when the

low tire pressure telltale illuminates, you should

stop and check your tires as soon as possible, and

inflate them to the proper pressure. Driving on a

significantly underinflated tire causes the tire to

overheat and can lead to tire failure. Underinflation

also reduces fuel efficiency and tire tread life, and

may affect the vehicle’s handling and stopping

ability.

WARNING!

A malfunctioning catalytic converter, as

referenced above, can reach higher

temperatures than in normal operating

conditions. This can cause a fire if you drive

slowly or park over flammable substances such

as dry plants, wood, cardboard, etc. This could

result in death or serious injury to the driver,

occupants or others.

CAUTION!

Prolonged driving with the Malfunction Indicator

Light (MIL) on could cause damage to the

vehicle control system. It also could affect fuel

economy and driveability. If the MIL is flashing,

severe catalytic converter damage and power

loss will soon occur. Immediate service is

required.

CAUTION!

Do not continue driving with one or more flat

tires as handling may be compromised. Stop the

vehicle, avoiding sharp braking and steering. If a

tire puncture occurs, repair immediately using

the dedicated tire repair kit and contact an

authorized dealer as soon as possible.

GETTING TO KNOW YOUR INSTRUMENT PANEL

127

Please note that the TPMS is not a substitute for

proper tire maintenance, and it is the driver’s

responsibility to maintain correct tire pressure,

even if underinflation has not reached the level to

trigger illumination of the TPMS low tire pressure

telltale.
Your vehicle has also been equipped with a TPMS

malfunction indicator to indicate when the system

is not operating properly. The TPMS malfunction

indicator is combined with the low tire pressure

telltale. When the system detects a malfunction,

the telltale will flash for approximately one minute

and then remain continuously illuminated. This

sequence will continue upon subsequent vehicle

start-ups as long as the malfunction exists. When

the malfunction indicator is illuminated, the

system may not be able to detect or signal low tire

pressure as intended. TPMS malfunctions may

occur for a variety of reasons, including the

installation of replacement or alternate tires or

wheels on the vehicle that prevent the TPMS from

functioning properly. Always check the TPMS

malfunction telltale after replacing one or more

tires or wheels on your vehicle to ensure that the

replacement or alternate tires and wheels allow

the TPMS to continue to function properly.

ELLOW

NDICATOR

IGHTS

Forward Collision Warning (FCW) or

Pedestrian Emergency Braking (PEB) OFF

Indicator Light — If Equipped

This indicator light illuminates to

indicate that Forward Collision

Warning (FCW) or Pedestrian Emergency

Braking (PEB) is off.

REEN

NDICATOR

IGHTS

Adaptive Cruise Control (ACC) Set With

Target Vehicle Detected Light —

If Equipped

This indicator light will illuminate when

the Adaptive Cruise Control speed is SET

and the vehicle in front is detected

page 147.

Adaptive Cruise Control (ACC) Set With No

Target Detected Light — If Equipped

This indicator light will illuminate when

the Adaptive Cruise Control speed is SET

and there is no vehicle in front detected

page 147.

Cruise Control Set Indicator Light —

If Equipped

This indicator light will illuminate when

the cruise control is set to the desired

speed

page 146.

Front Fog Indicator Light — If Equipped

This indicator light will illuminate when

the front fog lights are on.

CAUTION!

The TPMS has been optimized for the original

equipment tires and wheels. TPMS pressures

and warning have been established for the tire

size equipped on your vehicle. Undesirable

system operation or sensor damage may result

when using replacement equipment that is not

of the same size, type, and/or style. Aftermarket

wheels can cause sensor damage. Using

aftermarket tire sealants may cause the Tire

Pressure Monitoring System (TPMS) sensor to

become inoperable. After using an aftermarket

tire sealant it is recommended that you take

your vehicle to an authorized dealer to have your

sensor function checked.

128

GETTING TO KNOW YOUR INSTRUMENT PANEL

KeySense Indicator Light —

If Equipped

The KeySense indicator is illuminated

when a KeySense key is detected upon

startup of the vehicle. The indicator will

remain lit for the entire key cycle as a

reminder that the KeySense key is in use. While

the KeySense key is in use, the vehicle will respond

to settings associated with the KeySense profile

page 14.

LaneSense Indicator Light — If Equipped

The LaneSense indicator light illuminates

solid green when both lane markings

have been detected and the system is

“armed” and ready to provide visual and

torque warnings if an unintentional lane departure

occurs

page 166.

Parking/Headlights On Indicator Light

This indicator light will illuminate when

the parking lights or headlights are

turned on.

Stop/Start Active Indicator Light —

If Equipped

This indicator light will illuminate when

the Stop/Start function is in “Autostop”

mode

page 143.

Turn Signal Indicator Lights

When the left or right turn signal is

activated, the turn signal indicator will

flash independently and the

corresponding exterior turn signal lamps

will flash. Turn signals can be activated when the

multifunction lever is moved down (left) or

up (right).
NOTE:



A continuous chime will sound if the vehicle is

driven more than 1 mile (1.6 km) with either

turn signal on.



Check for an inoperative outside light bulb if

either indicator flashes at a rapid rate.

HITE

NDICATOR

IGHTS

Adaptive Cruise Control (ACC) Ready

Light — If Equipped

This indicator light will illuminate when

the vehicle equipped with ACC has been

turned on but not set

page 147.

Cruise Control Ready Indicator Light

This indicator light will illuminate when

the cruise control is ready, but not set

page 146.

LaneSense Indicator Light — If Equipped

When the LaneSense system is ON, but

not armed, the LaneSense indicator light

illuminates solid white. This occurs when

only left, right, or neither lane line has

been detected. If a single lane line is detected, the

system is ready to provide only visual warnings if

an unintentional lane departure occurs on the

detected lane line

page 166.

Speed Warning Indicator Light

The white indicator will illuminate along

with a pop-up message (Speed Warning

Set to XX followed by unit), once the

feature is enabled. When the set speed is

exceeded, a continuous chime (up to 10 seconds

or until the speed is no longer exceeded) will sound

along with a Speed Warning Exceeded pop-up

message and the indicator light will turn yellow and

flash.
NOTE:

The number “31” is only an example of a speed

that can be selected.

Set Speed Display

The Set Speed Display indicator light

indicates the set speed for the Cruise

Control and Adaptive Cruise Control

(ACC) settings.

GETTING TO KNOW YOUR INSTRUMENT PANEL

129

LUE

NDICATOR

IGHTS

High Beam Indicator Light

This indicator light will illuminate to

indicate that the high beam headlights

are on. With the low beams activated,

push the multifunction lever forward

(toward the front of the vehicle) to turn on the high

beams. Pull the multifunction lever rearward

(toward the rear of the vehicle) to turn off the high

beams. If the high beams are off, pull the lever

toward you for a temporary high beam on, “flash to

pass” scenario.

ONBOARD DIAGNOSTIC SYSTEM — OBD II

Your vehicle is equipped with a sophisticated

Onboard Diagnostic system called OBD II.

This system monitors the performance of the

emissions, engine, and automatic transmission

control systems. When these systems are

operating properly, your vehicle will provide

excellent performance and fuel economy, as well

as emissions well within current government

regulations.

If any of these systems require service, the

OBD II system will turn on the Malfunction Indicator

Light (MIL). It will also store diagnostic codes and

other information to assist your service technician

in making repairs. Although your vehicle will

usually be drivable and not need towing, see an

authorized dealer for service as soon as possible.

NBOARD

IAGNOSTIC

YSTEM

(OBD II) C

YBERSECURITY

Your vehicle is required to have OBD II and a

connection port to allow access to information

related to the performance of your emissions

controls. Authorized service technicians may need

to access this information to assist with the

diagnosis and service of your vehicle and

emissions system

page 187.

CAUTION!



Prolonged driving with the MIL on could cause

further damage to the emission control

system. It could also affect fuel economy and

driveability. The vehicle must be serviced

before any emissions tests can be performed.



If the MIL is flashing while the vehicle is

running, severe catalytic converter damage

and power loss will soon occur. Immediate

service is required.

WARNING!



ONLY an authorized service technician should

connect equipment to the OBD II connection

port in order to read the VIN, diagnose, or

service your vehicle.



If unauthorized equipment is connected to the

OBD II connection port, such as a

driver-behavior tracking device, it may:



Be possible that vehicle systems,

including safety related systems, could be

impaired or a loss of vehicle control could

occur that may result in an accident

involving serious injury or death.



Access, or allow others to access, infor

mation stored in your vehicle systems,

including personal information.

130

GETTING TO KNOW YOUR INSTRUMENT PANEL

EMISSIONS INSPECTION AND

MAINTENANCE PROGRAMS

In some localities, it may be a legal requirement to

pass an inspection of your vehicle's emissions

control system. Failure to pass could prevent

vehicle registration.

For states that require an Inspection and

Maintenance (I/M), this check verifies

the Malfunction Indicator Light (MIL) is

functioning and is not on when the

engine is running, and that the OBD II system is

ready for testing.
Normally, the OBD II system will be ready.

The OBD II system may not be ready if your vehicle

was recently serviced, recently had a depleted

battery or a battery replacement. If the OBD II

system should be determined not ready for the

I/M test, your vehicle may fail the test.

Your vehicle has a simple ignition actuated test,

which you can use prior to going to the test station.

To check if your vehicle's OBD II system is ready,

you must do the following:
1. Cycle the ignition switch to the ON position,

but do not crank or start the engine.

NOTE:

If you crank or start the engine, you will have to

start this test over.
2. As soon as you cycle the ignition switch to the

ON position, you will see the Malfunction

Indicator Light (MIL) symbol come on as part of

a normal bulb check.

3. Approximately 15 seconds later, one of two

things will happen:



The MIL will flash for about 10 seconds and

then return to being fully illuminated until

you turn OFF the ignition or start the engine.

This means that your vehicle's OBD II

system is not ready and you should not

proceed to the I/M station.



The MIL will not flash at all and will remain

fully illuminated until you place the ignition

in the off position or start the engine. This

means that your vehicle's OBD II system is

ready and you can proceed to the I/M

station.

If your OBD II system is not ready, you should see

an authorized dealer or repair facility. If your

vehicle was recently serviced or had a battery

failure or replacement, you may need to do nothing

more than drive your vehicle as you normally would

in order for your OBD II system to update. A

recheck with the above test routine may then

indicate that the system is now ready.
Regardless of whether your vehicle's OBD II system

is ready or not, if the MIL is illuminated during

normal vehicle operation you should have your

vehicle serviced before going to the I/M station.

The I/M station can fail your vehicle because the

MIL is on with the engine running.

131

(Continued)

STARTING AND OPERATING

STARTING THE ENGINE

Before starting your vehicle, adjust your seat,

adjust both inside and outside mirrors, and fasten

your seat belts.

Start the engine with the gear selector in the

NEUTRAL (N) or PARK (P) position. Apply the brake

before shifting to any driving range.

ORMAL

TARTING

To Turn On The Engine Using ENGINE START/STOP

Button
1. The transmission must be in PARK or

NEUTRAL.

2. Press and hold the brake pedal while pushing

the ENGINE START/STOP button once.

3. The system starts the vehicle. If the vehicle

fails to start, the starter will disengage

automatically after 10 seconds.

4. If you wish to stop the cranking of the engine

prior to the engine starting, push the button

again.

ENGINE START/STOP Button Functions — With

Driver’s Foot Off The Brake Pedal (In PARK Or

NEUTRAL Position)
The ENGINE START/STOP button operates similar

to an ignition switch. It has three positions; OFF,

ACC, and ON/RUN. To change the ignition positions

without starting the vehicle and to use the

accessories, follow these steps:



Start with the ignition in the OFF position.



Push the ENGINE START/STOP button once to

place the ignition to the ACC position (instru

ment cluster will display “ACC”).



Push the ENGINE START/STOP button a second

time to place the ignition to the ON/RUN posi

tion (instrument cluster will display “ON/RUN”).



Push the ENGINE START/STOP button a third

time to return the ignition to the OFF position

(instrument cluster will display “OFF”).

NOTE:

Only press one pedal at a time while driving the

vehicle. Torque performance of the vehicle could

be reduced if both pedals are pressed at the same

time. If pressure is detected on both pedals simul

taneously, a warning message will display in the

instrument cluster

page 113.

WARNING!



When exiting the vehicle, always remove the

key fob from the vehicle and lock your vehicle.



Never leave children alone in a vehicle, or with

access to an unlocked vehicle.



Allowing children to be in a vehicle unattended

is dangerous for a number of reasons. A child

or others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the transmis

sion gear selector.



Do not leave the key fob in or near the vehicle,

or in a location accessible to children, and do

not leave the ignition of a vehicle equipped

with Keyless Enter ‘n Go™ in the ACC or ON/

RUN position. A child could operate power

windows, other controls, or move the vehicle.



Do not leave children or animals inside parked

vehicles in hot weather. Interior heat buildup

may cause serious injury or death.

WARNING!

132

STARTING AND OPERATING

UTO

ARK

AutoPark is a supplemental feature to assist with

placing the vehicle in PARK under certain

situations. It is a back-up system and should not be

relied upon as the primary method by which the

driver shifts the vehicle into PARK.
The conditions under which AutoPark will engage

are outlined on the following pages.

ALWAYS DO A VISUAL CHECK that your vehicle is in

PARK by looking for the “P” in the instrument

cluster display and on the gear selector. As an

added precaution, always apply the parking brake.
If the vehicle is not in PARK and the driver

attempts to turn off the engine, if certain

conditions are met, the vehicle will AutoPark,

automatically shifting the vehicle’s transmission to

the PARK position. The gear selector will

automatically reset itself to the PARK position. The

vehicle’s ignition will then move to the OFF position

(engine off). When AutoPark is activated the

instrument cluster will display the message

“AutoPark Engaged”.
AutoPark will engage when all of these conditions

are met:



Vehicle is equipped with a gear selector



Vehicle is not in PARK



Vehicle speed is 1.2 mph (1.9 km/h) or less



Driver has pushed the ENGINE START/STOP

button

If the vehicle is not in PARK and the driver exits the

vehicle with the engine running, if certain

conditions are met, the vehicle will AutoPark,

automatically shifting the vehicle’s transmission to

the PARK position. The Electric Park Brake SAFE

HOLD feature will also activate in some conditions

page 138.

AutoPark will engage when all of these conditions

are met:



Vehicle is equipped with a gear selector



Vehicle is not in PARK



Vehicle speed is 1.2 mph (1.9 km/h) or less



Driver’s door is ajar



Driver’s seat belt is unbuckled



Brake pedal is not pressed

The message “AutoPark Engaged” will display in

the instrument cluster.

WARNING!



Driver inattention could lead to failure to place

the vehicle in PARK. ALWAYS DO A VISUAL

CHECK that your vehicle is in PARK by verifying

that a solid (not blinking) “P” is indicated in

the instrument cluster display and near the

gear selector. If the “P” indicator is blinking,

your vehicle is not in PARK. As an added

precaution, always apply the parking brake

when exiting the vehicle.



AutoPark is a supplemental feature. It is not

designed to replace the need to shift your

vehicle into PARK. It is a back up system and

should not be relied upon as the primary

method by which the driver shifts the vehicle

into PARK.

CAUTION!

Engine will remain running.

STARTING AND OPERATING

133

(Continued)

AutoPark In Stop/Start Autostop Mode



AutoPark will engage when all of these condi

tions are met:



Vehicle is equipped with a gear selector



Vehicle is not in PARK



Vehicle speed is 1.2 mph (1.9 km/h) or less



Driver’s door is ajar



Driver’s seat belt is unbuckled or brake pedal is

not pressed

The message “AutoPark Engaged” will display in

the instrument cluster.

WARNING!



Never use the PARK position as a substitute

for the parking brake. Always apply the

parking brake fully when exiting the vehicle to

guard against vehicle movement and possible

injury or damage.



Your vehicle could move and injure you and

others if it is not in PARK. Check by trying to

move the transmission gear selector out of

PARK with the brake pedal released. Make

sure the transmission is in PARK before

exiting the vehicle.



The transmission may not engage PARK if the

vehicle is moving. Always bring the vehicle to a

complete stop before shifting to PARK, and

verify that the transmission gear position indi

cator solidly indicates PARK (P) without

blinking. Ensure that the vehicle is completely

stopped, and the PARK position is properly

indicated, before exiting the vehicle.



It is dangerous to shift out of PARK or

NEUTRAL if the engine speed is higher than

idle speed. If your foot is not firmly pressing

the brake pedal, the vehicle could accelerate

quickly forward or in reverse. You could lose

control of the vehicle and hit someone or

something. Only shift into gear when the

engine is idling normally and your foot is firmly

pressing the brake pedal.

WARNING!



Unintended movement of a vehicle could

injure those in or near the vehicle. As with all

vehicles, you should never exit a vehicle while

the engine is running. Before exiting a vehicle,

always come to a complete stop, then apply

the parking brake, shift the transmission into

PARK, and turn the ignition OFF. When the

ignition is in the OFF position, the transmis

sion is locked in PARK, securing the vehicle

against unwanted movement.



When exiting the vehicle, always make sure

the ignition is in the OFF position, remove the

key fob from the vehicle, and lock the vehicle.



Never leave children alone in a vehicle, or

with access to an unlocked vehicle. Allowing

children to be in a vehicle unattended is

dangerous for a number of reasons. A child or

others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the transmis

sion gear selector.



Do not leave the key fob in or near the vehicle

(or in a location accessible to children), and do

not leave the ignition in the ACC or ON/RUN

position. A child could operate power

windows, other controls, or move the vehicle.

WARNING!

134

STARTING AND OPERATING

To Turn On The Engine Using ENGINE START/STOP

Button
1. The transmission must be in PARK or

NEUTRAL.

2. Press and hold the brake pedal while pushing

the ENGINE START/STOP button once.

To release the parking brake manually, the ignition

switch must be in the ON/RUN position. Press on

the brake pedal, then push the parking brake

switch momentarily.

If the driver shifts into PARK while moving, the

vehicle may Park.
PARK will engage ONLY when vehicle speed is

1.2 mph (1.9 km/h) or less.
The message “Vehicle Speed is Too High to Shift

to P” will display in the instrument cluster display if

vehicle speed is above 1.2 mph (1.9 km/h). The

gear position indicator will blink continuously until

the gear selector is returned to the proper position,

or the requested shift can be completed.

OLD

EATHER

PERATION

ELOW

–22°F O

−30°C)

To ensure reliable starting at these temperatures,

use of an externally powered electric engine block

heater (available from an authorized dealer) is

recommended.

FTER

TARTING

— W

ARMING

NGINE

The idle speed is controlled automatically and it

will decrease as the engine warms up.

NGINE

AILS

TART

CAUTION!

Damage to the transmission may occur if the

following precautions are not observed:



Shift into or out of PARK or REVERSE only after

the vehicle has come to a complete stop.



Do not shift between PARK, REVERSE,

NEUTRAL, or DRIVE when the engine is above

idle speed.



Before shifting into any gear, make sure your

foot is firmly pressing the brake pedal.

WARNING!

If vehicle speed is not below 1.2 mph (1.9 km/h)

when the driver shifts into PARK, the

transmission will default to NEUTRAL until the

vehicle speed drops below 1.2 mph (1.9 km/h)

and the above conditions are met, enabling

AutoPark. A vehicle left in the NEUTRAL position

can roll. As an added precaution, always apply

the parking brake when exiting the vehicle.

WARNING!



Never pour fuel or other flammable liquid into

the throttle body air inlet opening in an

attempt to start the vehicle. This could result

in flash fire causing serious personal injury.



Do not attempt to push or tow your vehicle to

get it started. Vehicles equipped with an auto

matic transmission cannot be started this

way. Unburned fuel could enter the catalytic

converter and once the engine has started,

ignite and damage the converter and vehicle.



If the vehicle has a discharged battery,

booster cables may be used to obtain a start

from a booster battery or the battery in

another vehicle. This type of start can be

dangerous if done improperly

page 300.

STARTING AND OPERATING

135

URN

NGINE

SING

ENGINE START/STOP B

UTTON

1. Place the gear selector in PARK, then push

and release the ENGINE START/STOP button.

2. The ignition switch will return to the OFF

position.

3. If the gear selector is not in PARK, the ENGINE

START/STOP button must be held for two

seconds or three short pushes in a row with

the vehicle speed above 5 mph (8 km/h)

before the engine will shut off. The ignition

switch position will remain in the ACC position

until the gear selector is in PARK and the

button is pushed twice to the OFF position.

If the gear selector is not in PARK and the

ENGINE START/STOP button is pushed once,

the instrument cluster will display a “Vehicle

Not In Park” message and the engine will

remain running. Never leave a vehicle out of

the PARK position, or it could roll.

NOTE:

If the ignition switch is left in the ACC or ON/RUN

(engine not running) position and the transmission

is in PARK, the system will automatically time out

after 30 minutes of inactivity and the ignition will

switch to the OFF position.

ENGINE BLOCK HEATER — IF EQUIPPED

The engine block heater warms the engine and

permits quicker starts in cold weather.
Connect the cord to a 110-115 Volt AC electrical

outlet with a grounded, three-wire extension cord.
For ambient temperatures below 0°F (-18°C), the

engine block heater is recommended. For ambient

temperatures below -20°F (-29°C), the engine

block heater is required.
The engine block heater cord is routed under the

hood, behind to the passenger’s side headlamp.

Follow these steps to properly use the engine block

heater:
1. Locate the engine block heater cord (behind

the passenger’s side headlamp).

2. Undo the hook-and-loop strap that secures the

heater cord in place.

3. Pull the cord to the front of the vehicle and

plug it into a grounded, three-wire extension

cord.

4. After the vehicle is running, reattach the cord

to the hook-and-loop strap and properly stow it

away behind the passenger’s side headlamp.

NOTE:



The engine block heater cord is a factory

installed option. If your vehicle is not equipped,

heater cords are available from an authorized

dealer.



The engine block heater will require 110 Volt AC

and 6.5 Amps to activate the heater element.



The engine block heater must be plugged in at

least one hour to have an adequate warming

effect on the engine.

ENGINE BREAK-IN RECOMMENDATIONS

A long break-in period is not required for the engine

and drivetrain (transmission and axle) in your

vehicle.
Drive moderately during the first 300 miles

(500 km). After the initial 60 miles (100 km),

speeds up to 50 or 55 mph (80 or 90 km/h) are

desirable.

WARNING!

Remember to disconnect the engine block

heater cord before driving. Damage to the

110-115 Volt electrical cord could cause

electrocution.

136

STARTING AND OPERATING

While cruising, brief full-throttle acceleration within

the limits of local traffic laws contributes to a good

break-in. Wide-open throttle acceleration in low

gear can be detrimental and should be avoided.
The engine oil installed in the engine at the factory

is a high-quality energy conserving type lubricant.

Oil changes should be consistent with anticipated

climate conditions under which vehicle operations

will occur. For the recommended viscosity and

quality grades

page 315.

NOTE:

A new engine may consume some oil during its first

few thousand miles (kilometers) of operation. This

should be considered a normal part of the break-in

and not interpreted as a problem.

PARKING BRAKE

LECTRIC

ARK

RAKE

(EPB)

Your vehicle is equipped with an EPB that offers

simple operation, and some additional features

that make the parking brake more convenient and

useful.
The parking brake is primarily intended to prevent

the vehicle from rolling while parked. Before

leaving the vehicle, make sure that the parking

brake is applied. Also, be certain to leave the

transmission in PARK.
You can engage the parking brake in two ways;



Manually, by applying the EPB switch.



Automatically, by enabling the Auto Park Brake

feature in the customer programmable features

page 188.

The EPB is located in the integrated center stack.

Electric Park Brake Switch

To apply the parking brake manually, push the

switch momentarily. You may hear a sound from

the back of the vehicle while the parking brake

engages. Once the parking brake is fully engaged,

the BRAKE warning lamp in the instrument cluster

and an indicator on the switch will illuminate.

If your foot is on the brake pedal while you apply

the parking brake, you may notice a small amount

of brake pedal movement. The parking brake can

be applied even when the ignition switch is OFF,

however, it can only be released when the ignition

switch in the ACC or ON/RUN position.
NOTE:

The EPB fault lamp will illuminate if the EPB switch

is held for longer than 180 seconds. The light will

extinguish upon releasing the switch.

CAUTION!

Never use Non-Detergent Oil or Straight Mineral

Oil in the engine or damage may result.

STARTING AND OPERATING

137

(Continued)

If the Auto Park Brake feature is enabled, the

parking brake will automatically engage whenever

the transmission is placed into PARK. Once the

parking brake is engaged, the BRAKE warning

lamp in the instrument cluster and the LED

indicator on the switch will illuminate. If your foot is

on the brake pedal, you may notice a small amount

of brake pedal movement while the parking brake

is engaging.
The parking brake will release automatically when

the ignition is cycled to the ON/RUN position, the

transmission is in DRIVE or REVERSE, and the

driver seat belt is buckled and an attempt is made

to drive the vehicle away by pressing the

accelerator pedal.
To release the parking brake manually, the ignition

switch must be in the ON/RUN position. Press on

the brake pedal, then push the parking brake

switch momentarily. You may hear a sound from

the back of the vehicle while the parking brake

disengages. You may also notice a small amount of

movement in the brake pedal. Once the parking

brake is fully disengaged, the BRAKE warning lamp

in the instrument cluster and the LED indicator on

the switch will extinguish.

NOTE:

When parking on a hill, it is important to turn the

front wheels toward the curb on a downhill grade

and away from the curb on an uphill grade. Apply

the parking brake before placing the gear selector

in PARK, otherwise the load on the transmission

locking mechanism may make it difficult to move

the gear selector out of PARK. The parking brake

should always be applied whenever the driver is

not in the vehicle.

WARNING!



Never use the PARK position as a substitute

for the parking brake. Always apply the

parking brake fully when parked to guard

against vehicle movement and possible injury

or damage.



When exiting the vehicle, always make sure

the ignition is in the OFF position, remove the

key fob from the vehicle, and lock your vehicle.



Never leave children alone in a vehicle, or with

access to an unlocked vehicle. Allowing chil

dren to be in a vehicle unattended is

dangerous for a number of reasons. A child or

others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the transmis

sion gear selector.



Do not leave the key fob in or near the vehicle,

(or in a location accessible to children), and do

not leave the ignition in the ACC or ON/RUN

position. A child could operate power

windows, other controls, or move the vehicle.



Be sure the parking brake is fully disengaged

before driving; failure to do so can lead to

brake failure and a collision.



Always fully apply the parking brake when

leaving your vehicle, or it may roll and cause

damage or injury. Also be certain to leave the

transmission in PARK. Failure to do so may

allow the vehicle to roll and cause damage or

injury.



Driving the vehicle with the parking brake

engaged, or repeated use of the parking brake

to slow the vehicle may cause serious damage

to the brake system.

CAUTION!

If the Brake System Warning Light remains on

with the parking brake released, a brake system

malfunction is indicated. Have the brake system

serviced by an authorized dealer immediately.

WARNING!

Chrysler Pacifica (2022 year). Manual in english - page 8
