Chrysler RG Voyager. Manual - part 471
DESCRIPTION
N·m
Ft. Lbs.
In. Lbs.
Front Engine Cover Bolts
11.8
8
96
Transmission to Engine Bolts
83.4
62
—
Cylinder Head Cover / Intake Manifold Bolts
27.5
20
—
Camshaft Access Plugs
80
59
—
Oil Separator Bolts
10.8
8
96
Camshaft Position Sensor Bolt
10.8
8
96
Boost Pressure / Intake Air Temp. Sensor
Bolts
5.4
—
48
Accessory Drive Bracket Bolts
47.1
35
—
Vacuum Line Fitting Bolt
56.9
42
—
Rail Pressure Sensor
35
26
—
Fuel Pump Nuts
27.5
21
—
Fuel Line Fittings at Pump
27.5
21
—
Inner Timing Belt Cover Bolts
8mm
10.8
8
96
10mm
47.1
35
—
Outer Timing Belt Cover Bolts
3mm
6
—
54
8mm
10.8
8
96
Engine Mount Bracket to Cylinder Head
Bolts
47.1
35
—
Intake Inlet Tube Bolts
10.1
8
89
Camshaft Sprocket Bolts
108
80
—
Timing Belt Idler Pulley Bolt
47.1
35
—
Timing Belt Tensioner Bolt
34.7
26
—
Fuel Pump Nut
88.3
65
—
Engine Lift Hook Bolts
32.4
24
—
Thermostat Housing Bolts
27.5
21
—
Turbocharger Oil Feed Line Fitting
24.5
18
217
Exhaust Manifold Nuts (Must recheck each
nut after tightening sequence is completed)
36
26.5
—
Exhaust Manifold Heatshield Bolts
27.5
21
—
EGR Valve Nuts
32.4
24
—
EGR Pipe to EGR Bolts
32.4
24
—
Turbocharger Downpipe Nuts
32.4
24
—
Turbocharger Bracket Bolts
47.1
35
—
Vibration Damper to Crankshaft Hub Bolts
27.5
21
—
Crankshaft Support Bolts
44.1
33
—
Turbocharger to Exhaust Manifold Nuts
32.4
24
—
9 - 16
ENGINE
RG
ENGINE 2.5L/2.8 TURBO DIESEL (Continued)
