Chrysler RG Voyager. Manual - part 310
__AIRBAG VERIFICATION TEST - VER 1
APPLICABILITY
1. Remove any special tools or jumper wires and reconnect all previously disconnected
components - except the Battery.
2. WARNING: TO AVOID PERSONAL INJURY OR DEATH, TURN THE IGNITION ON,
THEN RECONNECT THE BATTERY.
3. Connect the DRBIII
t to the Data Link Connector - use the most current software available.
4. Use the DRBIII
t and erase the stored codes in all airbag system modules.
5. Turn the ignition off, and wait 15 seconds, then turn the ignition on.
6. Wait one minute, and read active codes and if there are none present read the stored codes.
7. Note: If equipped with Airbag On - Off switch, read the DTC’s in all switch positions.
8. Note: Read the DTC’s in all airbag system related modules.
9. If the DRBIII
t shows any active or stored codes, return to the Symptom list and follow path
specified for that trouble code. If no active or stored codes are present, the repair is complete.
Are any DTC’s present or is the original condition still present?
All
YES
Repair is not complete, refer to appropriate symptom list.
NO
Repair is complete.
1209
VERIFICATION TESTS
Verification Tests —
Continued
