(5) Remove EGR tube. Discard old gasket. If nec- essary clean EGR passage. INSTALLATION Use new gaskets on both ends of the EGR tube. num screws to 11 N·m (95 in. lbs) torque. (3) Tighten the EGR tube to EGR valve screws to 11 N·m (95 in. lbs.) torque. (4) Install the air cleaner cover and hose. SPECIFICATIONS TORQUE Description Torque EGR valve to cyl. head . . . . . . 22 N·m (200 in. lbs.) JX EMISSION CONTROL SYSTEMS 25 - 35 REMOVAL AND INSTALLATION (Continued) |
