Chrysler 300/300 Touring/300C, Dodge Magnum. Manual - part 2184
1. If the windshield (1) is being reused, remove the as
much original urethane (3) as possible from the
glass surface using a razor knife (2).
NOTE: To prevent corrosion, do not damage paint
on windshield fence when removing original ure-
thane.
NOTE: The windshield fence should be cleaned of
most of its old urethane adhesive. A small amount
of old urethane, approximately 1 mm in height
should remain on the fence. Do not completely
remove all old urethane from the fence, the paint
finish and bonding strength will be adversely
affected. Support spacers located near the cowl at
the bottom of the windshield fence should be
replaced with new spacers. Replace any missing
or damaged spacers around the perimeter of the
windshield fence.
2. Using a razor knife (2), level the original bead of urethane (1) on the windshield fence (3) to a thickness of
approximately 1 mm (0.04 in.) and remove the loose adhesive.
3. Install a new rubber seal (1) along the top of the
windshield (2).
4. Using an assistant, position the windshield into the
windshield opening and against the windshield
fence (3).
5. Verify the windshield lays evenly against the fence
at the top, bottom and sides of the opening. If not,
the fence must be formed to the shape of the wind-
shield.
6. Mark the windshield and the windshield fence with
a grease pencil or pieces of masking tape to use
as a reference for installation.
7. Using an assistant, remove the windshield from the
windshield opening and place it on a suitable pad-
ded work surface.
23 - 284
STATIONARY GLASS
LX
