NOTE: All three scan tool Line Pressure readings should be steady and ± 14 kPa or 2.0 psi of the reading Did the Line Pressure read within ± 14 kPa or 2.0 psi in all three positions? Yes >> Replace the Line Pressure Sensor per the Service Information. Perform 42RLE TRANSMISSION VERIFICATION TEST - VER 1. (Refer to 21 - TRANSMISSION/ No >> Go To 3 3. CHECK THE (K900) SENSOR GROUND CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the Transmission Simulator, Miller tool #8333 and the Elec- Disconnect the PCM C2 harness connector and connect Miller tool CAUTION: Do not probe the PCM harness connectors. Probing the Is the resistance above 5.0 ohms? Yes >> Repair the (K900) Sensor Ground circuit for an open. Perform 42RLE TRANSMISSION VERIFICATION TEST - No >> Go To 4 21 - 618 AUTOMATIC TRANSMISSION 42RLE - ELECTRICAL DIAGNOSTICS LX |
