Emergency situation

75

Emergency situation

Emergency situation

77

Emergency situation

Driver's tool

Spare tire

Driver's tool and spare tire are all stored
in the place for spare tires  under
luggage compartment floor.

Type

of

Jack

Scalable

Maximum
operating load

600kg

Lubricant

type

Lithium

type

Notice

1

Attach spare tire and driver's tool

tightly so as to prevent injures in the case
of emergency braking or accident2

The

jack supplied here is only applied for the
specified vehicle and not allowed to
support any other vehicle or weight;3
After vehicle is jacked ,engine is not
permitted to start in case accident should
happen.;4

If some operations must be

done under vehicle, be sure to support
vehicle securely with proper brace.

Wheel replacement

To avoid accident , following suggestions
should taken when  a tire needs to be
replaced:

·

Drive vehicle out of driveway

to clear safe area .
-Park vehicle on   horizontal road.
-Turned off ignition switch and remove
ignition key.

-Turn on hazard warning flashlight and
apply hand brake, put transmission in "
1"gear or "R" gear if necessary.
-Apply an wedge after or before the
wheel diagonal to the wheel which is to
be replaced to guard vehicle.
-Set a trigonometry warning plate 10m
away from vehicle.
-Have all passengers out of vehicle to
safe area.
Replacement steps
-Remove wheel cover.
-Loosen all wheel bolts a full turn with
wheel spanner , but do not remove bolts
before wheel is lifted from ground.
-There are recesses in the front and rear
bottom of vehicle for mounting jack.
Jacking points are marked by semicircle
cuts. Locate jack vertically near the front
or back of the wheel which is to be
replaced.Turn jack bolt clockwise by
hand until jack head contacts chassis..
