Chapter Three Special Tools
I. Connotation of Special Tool Number In order to know or find the tool clearly according to parts number and improve maintenance efficiency, special tools numbering is stipulated as follows: □□□□□ ○ ○ ○ ○ □
□ indicates a letter ○ indicates an Arabic numeral Nomenclature of the tool: for a standard part, please use the brand and model recommended by Chery company as reference. For example, CH indicates a non standard part, which means it is a special tool for repair of this part verified by After Sales Service Department of Chery Automobile Sales Co., Ltd. HAZET indicates a standard tool produced by this company. Connotation of system code corresponding to the tool: Number Position
1
Chassis 2
Engine 3
Transmission 4
Accessory 5
Body Corresponding series number of tools: from 001 to 999. Times of modifications of the tool: Number Modification
A
First modification B Second modification C Third modification D Fourth modification Note: In alphabetical order. Bigger SN means more modification times. For example: CH-1002A means it is the 2# special tool for repair of chassis system that has been verified by After Sales Service Department of Chery Automobile Sales Co., Ltd., who commits Please use the special tools that we designated to perform maintenance, otherwise it will cause accident or damage the machine. Maintemance times coresponding to tools SN coresponding to tools System code coresponding to tools Tools name |
