Автомобили Chery: руководства по ТО - часть 61





深 圳 市 元 征 科 技 股 份 有 限 公 司

  LAUNCH TECH CO., LTD.



                                                                    深圳市元征软件开发有限公司      LAUNCH SOFTWARE DEVELOPMENT CO.,LTD.

地址:518112 广东省深圳市龙岗区坂雪岗工业区五和大道北元征工业园

ADD:

 LAUNCH INDUSTRIAL PARK,NORTH OF WUHE ROAD,BANXUEGABF,LONGGANG DISTRICT, SHENZHEN,P.R,CHINA.



电话

TEL:86-755-84528427  传真 FAX:86-755-84528454









保留一切解释权，处置权，包括复印及传达至第三方。








编写：黄惠生    2008-9-11      15:01    第 195 页      总 274 页

"29","Vehicle speed sensor malfunction "
"31","Reverse/low solenoid malfunction "
"32","UD SOL.OPEN "
"33","2 gear solenoid open circuit "
"34","Overdrive solenoid circuit malfunction "
"36","Damper clutch system control solenoid malfunction "
"41","First gear, ration out of limits "
"42","Second gear, ration out of limits "
"43","Third gear, ration out of limits "
"44","Fourth gear, ration out of limits "
"46","Reverse gear, ration out of limits "
"51","CAN data bus interface malfunction "
"52","DCC digital command system malfunction "
"54","Electrical relay open circuit "
"56","Neutral indicator lamp open circuit "

7.3 防抱死刹车系统

;0x8321
"C0011", "ABS Warning Lamp Fault"
"C0012", "Brake Warning Lamp Fault"
"C0014", "System Relay Contacts Open"
"C0017", "Pump Motor Power Circuit Open Fault"
"C0018", "Pump Motor Ground High Resistance Fault"
"C0021", "Left Front Wheel Speed = 0 kph"
"C0022", "Right Front Wheel Speed = 0 kph"
"C0023", "Left Rear Wheel Speed = 0 kph"
"C0024", "Right Rear Wheel Speed = 0 kph"
"C0025", "Left Front Excessive Wheel Speed Variation"
"C0026", "Right Front Excessive Wheel Speed Variation"
"C0027", "Left Rear Excessive Wheel Speed Variation"
"C0028", "Right Rear Excessive Wheel Speed Variation"
"C0032", "Left Front Wheel Speed Circuit Open or Shorted to Ground/Battery"
"C0033", "Right Front Wheel Speed Circuit Open or Shorted to Ground/Battery"
"C0034", "Left Rear Wheel Speed Circuit Open or Shorted to Ground/Battery"
"C0035", "Right Rear Wheel Speed Circuit Open or Shorted to Ground/Battery"
"C0036", "Low Voltage Condition"
"C0037", "High Voltage Condition"

PDF 文件使用 "pdfFactory Pro" 试用版本创建

ÿ















www.fineprint.com.cn

深 圳 市 元 征 科 技 股 份 有 限 公 司

  LAUNCH TECH CO., LTD.



                                                                    深圳市元征软件开发有限公司      LAUNCH SOFTWARE DEVELOPMENT CO.,LTD.

地址:518112 广东省深圳市龙岗区坂雪岗工业区五和大道北元征工业园

ADD:

 LAUNCH INDUSTRIAL PARK,NORTH OF WUHE ROAD,BANXUEGABF,LONGGANG DISTRICT, SHENZHEN,P.R,CHINA.



电话

TEL:86-755-84528427  传真 FAX:86-755-84528454









保留一切解释权，处置权，包括复印及传达至第三方。








编写：黄惠生    2008-9-11      15:01    第 196 页      总 274 页

"C0042", "Pump Motor Circuit Open"
"C0043", "Pump Motor Stalled"
"C0048", "DRP Disabled"
"C0055", "ECU Internal Fault"
"C0056", "System Relay Shorted On"
"C0061", "Left Front Apply Solenoid Fault"
"C0062", "Left Front Release Solenoid Fault"
"C0063", "Right Front Apply Solenoid Fault"
"C0064", "Right Front Release Solenoid Fault"
"C0065", "Left Rear Apply Solenoid Fault"
"C0066", "Left Rear Release Solenoid Fault"
"C0067", "Right Rear Apply Solenoid Fault"
"C0068", "Right Rear Release Solenoid Fault"
"C0091", "Brake Pedal Not Applied with Decel"
"C0093", "Brake Pedal Not Applied with Decel on Previous lgnition Cycle"
"C0094", "Brake Pedal Always Applied Without Decel Fault"
"C0095", "Brake Switch Open"
"C0118", "Left Rear Apply Solenoid Correlation Fault"
"C0121", "Right Rear Apply Solenoid Correlation Fault"
"C0122", "Release or Front Apply Solenoid Correlation Fault"
"C0127", "Brake Pedal Always Applied Without Decel on Previous Ignition Cycle Fault"
"C0151", "Left Front Wheel Release Too Long"
"C0152", "Right Front Wheel Release Too Long"
"C0153", "Left Rear Wheel Release Too Long"
"C0154", "Right Rear Wheel Release Too Long"
"C0166", "Longitudinal Accelerometer Sensor Out of Range"
"C0167", "Longitudinal Accelerometer Bias Fault"
"C0191", "No Pump Motor Starting Current"
"C0192", "Pump Motor Excess Operation Current"
"C0194", "Pump Motor Short Circuit Current"
"C0198", "Misfire Rough Road PWM Output Fault"

7.4 车身控制器系统

7.4.1 车身控制器系统

N/A

PDF 文件使用 "pdfFactory Pro" 试用版本创建

ÿ















www.fineprint.com.cn

深 圳 市 元 征 科 技 股 份 有 限 公 司

  LAUNCH TECH CO., LTD.



                                                                    深圳市元征软件开发有限公司      LAUNCH SOFTWARE DEVELOPMENT CO.,LTD.

地址:518112 广东省深圳市龙岗区坂雪岗工业区五和大道北元征工业园

ADD:

 LAUNCH INDUSTRIAL PARK,NORTH OF WUHE ROAD,BANXUEGABF,LONGGANG DISTRICT, SHENZHEN,P.R,CHINA.



电话

TEL:86-755-84528427  传真 FAX:86-755-84528454









保留一切解释权，处置权，包括复印及传达至第三方。








编写：黄惠生    2008-9-11      15:01    第 197 页      总 274 页

7.4.2 亚华车身控制器系统

;0x4682
"B1000","Left Turn Lights Control Circuit Low Current"
"B1001","Left Turn Lights Control Circuit Shorted to Ground"
"B1004","Right Turn Lights Control Circuit Low Current"
"B1005","Right Turn Lights Control Circuit Shorted to Ground"
"B1100","Dome Light Control Circuit Low Voltage"
"B1101","Dome Light Control Circuit High Voltage"
"B1102","Key Lamp Control Circuit Low Voltage"
"B1103","Key Lamp Control Circuit High Voltage"
"B1201","Front Wiper Control Circuit Low Voltage"
"B1204","Front Wiper Park Switch Circuit No Signal"
"B1206","Rear Defroster Control Circuit Open"
"B1207","Rear Defroster Control Circuit Low Voltage"
"B1208","Rear Defroster Control Circuit High Voltage"
"B1210","Mirror Defroster Control Circuit Open"
"B1211","Mirror Defroster Control Circuit Low Voltage"
"B1212","Mirror Defroster Control Circuit High Voltage"
"B1301","Central Lock Control Circuit Low Current"
"B1302","Central Lock Control Circuit High Current"
"B1303","Central Lock Control Circuit Stuck On"
"B1305","Central Unlock Control Circuit Low Current"
"B1306","Central Unlock Control Circuit High Current"
"B1307","Central Unlock Control Circuit Stuck On"
"B1310","FL Window Up Control Circuit Low Current"
"B1312","FL Window Up Control Circuit Stuck On"
"B1314","FL Window Down Control Circuit Low Current"
"B1316","FL Window Down Control Circuit Stuck On"
"B1319","FR Window Up Control Circuit Low Current"
"B1321","FR Window Up Control Circuit Stuck On"
"B1323","FR Window Down Control Circuit Low Current"
"B1325","FR Window Down Control Circuit Stuck On"
"B1328","RL Window Up Control Circuit Low Current"
"B1330","RL Window Up Control Circuit Stuck On"
"B1332","RL Window Down Control Circuit Low Current"
"B1334","RL Window Down Control Circuit Stuck On"

PDF 文件使用 "pdfFactory Pro" 试用版本创建

ÿ















www.fineprint.com.cn

深 圳 市 元 征 科 技 股 份 有 限 公 司

  LAUNCH TECH CO., LTD.



                                                                    深圳市元征软件开发有限公司      LAUNCH SOFTWARE DEVELOPMENT CO.,LTD.

地址:518112 广东省深圳市龙岗区坂雪岗工业区五和大道北元征工业园

ADD:

 LAUNCH INDUSTRIAL PARK,NORTH OF WUHE ROAD,BANXUEGABF,LONGGANG DISTRICT, SHENZHEN,P.R,CHINA.



电话

TEL:86-755-84528427  传真 FAX:86-755-84528454









保留一切解释权，处置权，包括复印及传达至第三方。








编写：黄惠生    2008-9-11      15:01    第 198 页      总 274 页

"B1337","RR Window Up Control Circuit Low Current"
"B1341","RR Window Down Control Circuit Low Current"

7.5 安全气囊系统

7.5.1 东方久乐系统

;0x4675
"B1301",  "Airbag ECU internal failure"
"B1302",  "Battery voltage is too high"
"B1303",  "Battery voltage is too low "
"B1304",  "Driver airbag resistor is too high "
"B1305",  "Driver airbag resistor is too low"
"B1306",  "Driver airbag is shorted to ground "
"B1307",  "Driver airbag is shorted to power"
"B1308",  "Passenger airbag resistor is too high"
"B1309",  "Passenger airbag resistor is too low "
"B1310",  "Passenger airbag is shorted to ground"
"B1311",  "Passenger airbag is shorted to power "
"B1312",  "Driver belt pretensioner resistor is too high"
"B1313",  "Driver belt pretensioner resistor is too low "
"B1314",  "Driver belt pretensioner is shorted to ground"
"B1315",  "Driver belt pretensioner is shorted to power "
"B1316",  "Passenger belt pretensioner resistor is too high "
"B1317",  "Passenger belt pretensioner resistor is to low "
"B1318",  "Passenger belt pretensioner is shorted to ground "
"B1319",  "Passenger belt pretensioner is shorted to power"
"B1320",  "Warning lamp is shorted to ground or disconnected"
"B1321",  "Warning lamp is shorted to power "
"B1322",  "Option Fault "
"B1323",  "Crash output short to ground "
"B1324",  "Key-switch shortedned to ground"
"B1325",  "Key-switch resistance undefined"
"B1326",  "Key-switch shortend to plus or open"
"B1327",  "Airbag passenger off Lamp Shortened to ground or disconnected"
"B1328",  "Airbag passenger of Lamp Shortened to plus "
"B1329",  "Side airbag driver resistor too high "

PDF 文件使用 "pdfFactory Pro" 试用版本创建

ÿ















www.fineprint.com.cn
