CONTROL VALVE (S/N 509640660 & Above, S/N Main Relief Valve (Cont’d) Disassembly (Cont’d) Remove the glid ring (Item 1) [A] & [B] from the main relief Remove the O–rings (Item 2) [B] and back–up ring (Item Port Relief Valve Disassembly Remove the port relief valve (Item 1) [C]. Remove the O–rings (Item 1) [D] and back–up ring (Item A P–08970 1 C P–08972 1 D P–08973 E–01509 1 1 2 2 1 –2–34– 773 BICS Loader Service Manual B P–08971 B–6764 1 2 3 2 2 3 1 |
