ALTERNATOR BELT Adjustment Stop the engine. Raise the operator cab. (See Page 1–9.) Loosen the alternator mounting bolt (Item 1) [A]. Loosen the adjustment bolt (Item 2) [A]. Move the alternator until the belt has 5/16 inch (8,0 mm) Tighten the adjustment bolt and mounting bolt. Lower the operator cab. FAN GEARBOX See the SERVICE SCHEDULE Page 1–3 for the correct Checking And Maintaining Raise the operator cab. (See Page 1–9.) Remove the plug (Item 1) [C] to check the lubricant level. If the level is low, add SAE 90W gear lube through the Install and tighten the plug. Lower the operator cab. (See Page 1–10.) Revised Jan. 99 –1–22– 773 BICS Loader Service Manual A P–10323 1 2 B P–03975 1 Gear Lube Level |
