BYD M6. Service Manual - part 5





BYD M6 AUTO Owner’s Manual
Tilt and Telescopic
Exterior rearview Mirrors
Steering Column
Adjust the exterior rearview mirrors so
To change the steering wheel height,
that you can see side of the vehicle.
press down the steering wheel
In case that the rearview mirror is not
adjusting handle and adjust the steel
wheel to desired height. Release the
clear, press the rear window defroster
adjusting handle to allow the lever to
switch to eliminate humidity.
return to the lock position.
CAUTION
CAUTION
y Never adjust the rearview mirror
y Never adjust the steering wheel
while the vehicle is moving,
while the vehicle is moving,
otherwise it could cause the loss
otherwise it could cause the loss
of control of the vehicle.
of control of the vehicle.
y After turning on the defroster,
To change the steering wheel angle,
y After adjustment, shake the
the mirror will become hot. Do
hold the steering wheel, press down
the steering wheel adjusting handle
steering wheel to make sure it is
not touch the mirror!
and adjust the steel wheel to desired
locked firmly.
angle. Release the adjusting handle
to allow the lever to return to the lock
position.
Steering Wheel and Rearview Mirror 1-60
BYD M6 AUTO Owner’s Manual
Power Mirror Control
Adjust Rearview Mirror
NOTICE
Adjust the rearview mirror with the
When the rearview mirror is frozen,
following switches:
don't operate the control switch or
Selection switch - select the rearview
wipe the mirror. Use a spraying
mirror you want to adjust.
deicer to eliminate the ice first.
Press L/R on the switch to select a
After adjustment, turn the selection
mirror.
switch to the center OFF position. At
Regulating switch
- adjust the
this time, the regulating switch is
rearview mirror as you desire.
disabled to prevent accidental mirror
operation.
Press the switch in the direction you
want.
The ignition switch must be at ACC or
ON.
1. Selection switch
2. Power folding button
3. Regulating switch
Steering Wheel and Rearview Mirror 1-61
BYD M6 AUTO Owner’s Manual
Power Folding Mirror (if equipped)
Manual Folding Mirror (if equipped)
To park the vehicle in narrow space,
you can fold the power mirrors to
protect the mirror against impact.
The ignition switch must be at ACC or
ON.
Position 1 - fold the power mirrors.
Position 2 - reset the power mirrors.
When activating anti-theft status, the
power mirrors will fold; when
deactivating anti-theft status, the
power mirrors will unfold.
(See
To park the vehicle in narrow space,
Anti-theft System in section 1.1)
fold the rearview mirrors backward to
prevent damage.
CAUTION
Push the mirrors backwards to fold
y When adjusting the power
them.
mirror, don’t touch it to prevent
personal injury and damage to
CAUTION
the mirror.
Don’t adjust the rearview mirror
y Don’t adjust the power mirror
when the vehicle is moving. Unfold
when the vehicle is moving.
and properly adjust both rearview
Unfold and properly adjust both
mirrors before driving the vehicle.
power mirrors before driving the
vehicle.
Steering Wheel and Rearview Mirror 1-62
BYD M6 AUTO Owner’s Manual
Anti-dazzle Inner
Calibrate Interior Rearview Mirror
Rearview Mirror
Daylight driving - set the control lever
1. Pay attention to the followings
to position 1.
before calibration:
The mirror provides the clearest view
(1) The direction displayed in the
in this mode.
interior rearview mirror is the
Night driving - set the control lever to
straight ahead direction for the
position 2.
vehicle. But under calibration
As the intensity of reflected light drops,
status, the text shown in the
the sharpness of the mirror image
interior rearview mirror is only for
also reduces.
information
purpose,
not
indicating the actual straight
CAUTION
ahead direction.
Never adjust the rearview mirror
Adjust the interior rearview mirrors so
while the vehicle is moving,
that you can see the rear of the
otherwise it could cause the loss of
vehicle.
control of the vehicle.
The interior rearview mirror works in
daylight mode when driving in daylight
and in night mode when driving at
night. The night mode can reduce the
intensity of the light emitted by rear
vehicles.
Steering Wheel and Rearview Mirror 1-63
BYD M6 AUTO Owner’s Manual
(2) A paper clip is required for
2. Calibration procedure
calibration.
(1) Start the engine. There is text
(3) Select open ground or a circular
shown at the top right of the
OK
road for the calibration. Identify
interior rearview mirror, which can
the directions of the east, west,
be any one of east, south, west,
south and north, as shown in the
north,
northwest, southwest,
figure below.
northeast and southwest.
North
(2) Select the starting position. It can
be any one of east, south, west
and north.
“North” will be displayed in the mirror.
It will flash for two times and then
(3) To enter the compass calibration
stop.
West
East
status, press OK button on the
rear side of the interior rearview
(4) Drive the vehicle for a complete
mirror using a paper clip.
circle at low speed (less than 8
km/h) and stop at the starting
position with the engine running.
South
Don’t stop the engine before you
complete a circle clockwise or
anticlockwise.
Steering Wheel and Rearview Mirror 1-64
BYD M6 AUTO Owner’s Manual
(5) Change the orientation of the
Otherwise, if “West” is displayed when
vehicle until the front end pointing
pressing OK button again, shut down
the south. Press OK, “South” will
the engine and repeat the procedure
be displayed in the mirror. At this
above from step (1). If any text other
time, press Ok again, if “South”
than “West” is displayed, repeat the
flashes for 2 times and then stops,
procedure above from step (2) without
the calibration is completed. The
turning off the engine.
mirror will exit calibration and
(6) After calibration, drive the vehicle
return to normal status.
for another circle to check
whether correct text is displayed
for each direction. If abnormal,
repeat the calibration procedure
Display
from step (1).
window
Steering Wheel and Rearview Mirror 1-65
BYD M6 AUTO Owner’s Manual
Steering Wheel and Rearview Mirror 1-66
BYD M6 AUTO Owner’s Manual
Chapter 1 Instruments & Control System
1.4 Switches
Headlight Switch
1-68
Front / Rear Fog Light Switch
1-69
Turn Signal Light Switch
1-71
Hazard Warning Flasher Switch
1-72
Front Windshield Wiper / Washer
1-72
Rear Windshield Wiper / Washer
1-73
Rear Windshield and Exterior Rearview Mirror Defrosters
1-74
Switches 1-67
BYD M6 AUTO Owner’s Manual
Headlight Switch
High/low beam: to use the high
Headlight Flashing
The rotation switches
(AUTO, OFF,
and
) on the lever controls
beams, turn on the headlights and
No matter what position the headlight
the
width-indicator
lights
and
push the lever outward away from the
switch is, if you pull the lever
headlights.
steering wheel. To use the low beams,
backward to the steering wheel side,
pull back the lever.
the high beams stay flashing. Release
- turn on front/rear width-indicator
the lever to allow it to return to the
lights, number plate lights and
previous position, and the high (low)
backlights.
beams go out. The high beams stay
- turn on headlights (low beam).
on as long as you pull the lever
backward.
AUTO
- turn on/off headlights
according to the intensity of ambient
The position of the headlight switch is
light.
indicated by indicators
(see the
relevant part in section 1.5).
Switches 1-68
BYD M6 AUTO Owner’s Manual
Adjust Headlight Beam Direction
Front
/ Rear Fog Light
Switch
The position of headlights varies with
the load the vehicle. You can adjust
the headlight beam direction to
prevent other drivers from being
dazzled.
Rotate the knob to adjust the
headlight beam direction.
The higher value of the knob, the
lower the headlight beam direction is.
Front/rear fog light switch
The front/rear fog light switch is
located beside the headlight switch
(front fog light
, rear fog light
).
When the light switch is at
or
, you can turn on the front fog light
with this switch. When the light switch
is at
or when the front fog lights
turned on, you can turn on the rear
fog lights with this switch.
When the light switch is at
or
, turn the switch upward from OFF
Switches 1-69
BYD M6 AUTO Owner’s Manual
(x) to
to turn on the front fog lights;
Fog lights are turned out: (1) When
Automatic Light-off Function
at this time the
indicator on the
the rear fog lights are turned on while
Enable automatic light-off function:
instrument panel is turned on for
the front fog lights remaining off, if the
when the headlight switch is at
or
reminding. Turn the switch downward
headlights are turned off, the rear fog
, turn the key from II to I position to
from
to OFF (x) to turn off the front
lights will be turned off; (2) When the
enable this function.
fog lights; at this time the
indicator
light switch is turned to OFF, both
goes off.
front and rear fog lights will be turned
When enabled, this function will
off. If the light switch is turned to
,
automatically turn off the headlights,
When the light switch is at
, turn
the front fog lights will be turned on
width-indicator lights, front/rear fog
the fog light switch downward from
while the rear fog lights remaining off.
lights and high beam lights
10
OFF (x) to
, the rear fog lights are
If you want to turn off the front fog
seconds after the front doors are
turned on and the switch returns to (x)
lights, rotate the fog light switch
closed.
position; turn the fog light switch
downward to (x) position; to turn on
downward from OFF (x) to
again,
When enabled, this function will
the rear fog lights again, turn the light
the rear fog lights go out and the
automatically turn off the headlights,
switch to
or turn on the front fog
switch returns to (x) position. When
width-indicator lights, front/rear fog
lights, and then rotate the fog light
the front fog lights are turned on, turn
lights and high beam lights
10
switch.
the fog light switch upward from
to
minutes after either front door is open.
, the rear fog lights will be turned on
After light-off, if you operate the light
with the front fog lights staying on,
switch, the relevant lights will be
and the fog light switch will return to
turned on; if the conditions for
; turn the fog light switch upward
automatic light-off remain valid, the
from
to
again, the rear fog
light-off function will be triggered
lights will go out and the fog light
again.
switch will return to .
Switches 1-70
BYD M6 AUTO Owner’s Manual
After light-off, open either front door to
Turn Signal Light Switch
off. Push the turn signal lever
turn on the relevant lights which have
upward/downward to give turn
been turned off automatically.
signals.
Disable automatic light-off function:
Push the turn signal lever
turn the key to II position to disable
upward/downward partially and hold it
this function so that the light knob will
there to give lane change signals.
operate lights normally.
If the vehicle enters anti-theft status
Turn signal lever
after automatic light-off, when the
anti-theft status is deactivated, the
Turn signal lights, which give turn or
lights which have been turned off will
lane change signals to other drivers,
be turned on again. If neither front
are operated independently of other
door is opened within 10 seconds, the
lights.
light-off function will be triggered
Push the turn signal lever upward, all
again. If either door is opened, the
turn signal lights on the right side are
automatic light-off function will turn off
turned on and keep flashing, even if
the lights within 10 minutes.
you release the lever.
Push the turn signal lever downward,
all turn signal lights on the left side are
turned on and keep flashing, even if
you release the lever.
Reset the turn signal lever to the
center, all turn signal lights are turned
Switches 1-71
BYD M6 AUTO Owner’s Manual
Hazard Warning Flasher
Front Windshield Wiper /
to adjust the interval of wiping circles.
Rotate the knob upward to increase
Switch
Washer
the interval, and downward to reduce
Use the lever to operate the wind-
the interval.
shield wipers.
The wipers operate steadily at LO and
HI.
For Mist wiping, push the lever
upward from OFF. The wipers will
operate at high speed until you
release the control lever. In this mode
the windshield can be cleaned rapidly.
Mist: wipe for a single cycle.
Press the switch shown in the figure
OFF: turn off the wipers.
NOTICE
to turn on the hazard warning
flashers.
INT: wipe intermittently.
y
Do not use the wipers when the
LO: wipe steadily at low speed.
All turn signal lights keep flashing on
windshield is dry. Or the
and off. Press the switch again to turn
HI: wipe steadily at high speed.
windshield glass could be
the flashers off.
scratched.
If you have to operate the vehicle
under hazardous conditions, such as
parking it near moving traffic, turn on
the hazard warning flashers to warn
other drivers.
Park the vehicle away from the road.
When the hazard warning flashers are
When the wiper control lever is at INT,
on, the turn signal lights will not work.
rotate the knob marked with INT Time
Switches 1-72
BYD M6 AUTO Owner’s Manual
NOTICE
Rear Windshield Wiper /
Washer
y
Regularly check the wiper
blades and, if necessary, clean
them with cotton cloth and
rubbing alcohol.
y
When the windshield is stained
with heavy dust, first flush it with
water and then use the wipers to
Rotate the knob on the control lever to
To wash the windshield, pull the wiper
clean it.
turn on the rear windshield wipers.
control lever backward.
y
Do not use any detergent other
Rotate the knob to ON to start the rear
When the wipers are not working,
than the windshield washer fluid,
wipers;
they will wipe for several times after
or the wiper blades could be
the washer fluid is sprayed.
damaged.
Rotate the knob to OFF to stop the
rear wipers;
If the control lever is released shortly,
the wipers will not operate after
When you rotate the knob downward
washer fluid spraying; if the control
from ON to
, or upward from OFF
lever is hold for long time, the wipers
to
, the rear washers and blades
will wipe at low speed, and when you
will start.
release the lever, the wipers will
continue to wipe for several times
before stopping.
Switches 1-73
BYD M6 AUTO Owner’s Manual
Rear Windshield and
The defroster will stop after working
NOTICE
for 15 minutes.
Exterior Rearview Mirror
y
Do not use the wipers when the
Defrosters
When the rear defroster is working, if
windshield is dry, or the
you turn off the ignition switch, the
windshield glass could be
defroster will stop too; when the
scratched.
engine is started again, the defroster
will also be turned on.
y
Do not lift up the wiper arms too
far, or they could be broken.
The heating element of the rear
y
Regularly check the wiper
defroster
could
be damaged
blades and, if necessary, clean
accidentally. When cleaning the rear
them with cotton cloth and
windshield, only wipe in horizontal
rubbing alcohol.
direction.
y
When the windshield is stained
Press the
button on the A/C
NOTICE
with heavy dust, first flush it with
panel to turn on/off the rear defroster.
water and then use the wipers to
y When cleaning the inside of the
The ignition switch must be at ON.
clean it.
rear windshield, do not scratch
The indicator on the button is turned
y
Do not use any detergent other
or damage the heating element
on, indicating the rear defroster is
than the windshield washer fluid,
or its connector.
working.
or the wiper blades could be
y To prevent battery discharge, do
damaged.
The rear defroster can remove fog,
not start the defroster when the
frost and thin ice from the windshield.
engine is not running.
Press the button again to turn off the
defroster.
Switches 1-74
BYD M6 AUTO Owner’s Manual
Chapter 1 Instruments & Control System
1.5 Instrument and Multifunction Display
Combination Instrument
1-76
Tachometer
1-77
Speedometer
1-77
Odometer
1-77
Trip Odometer
1-77
Coolant Thermometer
1-77
Fuel Gauge
1-77
Coolant Thermometer
1-78
Gear Display (if equipped)
1-78
Mileage Information Display
1-78
Indicators and Buzzer
1-79
Multifunction Display
1-85
Instrument and Multifunction Display 1-75















Content      ..     3      4      5      6     ..
