BYD F0. Service Manual - part 4
BYD AUTO
F0 Owner’s Manual
Notice
When the engine oil level is very low, the
(g) Low fuel level warning light
light can also shine. This light is not used
The light will shine if the fuel in the fuel
Shining of the light during
for showing low engine oil levels; the
tank nearly runs out. Add plenty of fuel as
engine operation indicates faults of
engine oil level should be determined with
soon as possible.
the charging system or break of the
an oil measuring tape.
When the vehicle is climbing a steep slope
engine belt. Please drive the vehicle
or turning, the low fuel level warning light
away from the road and park it in a
Notice
may shine earlier than usual due to shake of
safety place and then immediately
the fuel in the fuel tank.
stop the engine. Inform a BYD
Do not drive the vehicle—even
authorized service station for help.
(h) “ABS” warning light (optional)
for
a short distance—when the
When the ignition key is turned to position
indicator is shining; otherwise, the
“II”, the warning light will shine. If the
engine may be damaged.
(d) Low engine oil pressure indicator
ABS system works normally, the warning
The light is used for indicating that the
light will go out after a few seconds. If the
engine oil pressure is too low.
(e) Engine fault indicator
system has faults, the warning light will
In driving, if the light flashes or keeps
The light will shine if the electronic fuel
shine again.
shining, drive away from the lane and park
injection system of engine has faults or the
the vehicle in a safety place and then
pollutant emission has exceeded the control
When the “ABS” warning light is shining
immediately stop the engine. Ask a BYD
standard.
(the brake system warning light is out), the
authorized service station for help.
If the light turns on in driving, inform a
ABS system won’t work, but the brake
BYD authorized service station to examine
system can still work normally.
The light may flash occasionally when the
the vehicle as soon as possible.
engine is idling or shine temporarily after
When the “ABS” warning light is shining
emergency braking.
(f) Door-open warning light
(the brake system warning light is out), the
Whatever position the key is in, the warning
However, if it goes out when the engine
light will shine as long as there is a door
ABS system won’t work, so in emergency
accelerates gradually, the problem may be
open.
braking or braking on slippery roads, the
neglected.
wheels will be locked.
48
BYD AUTO
F0 Owner’s Manual
Both of the conditions can indicate certain
(i) SRS warning light (optional)
(j) Lighting indication buzzer
monitoring parts in the warning light system
The ignition key turned to position “II”,
When the parking lights or head lights are
have faults. If either of the conditions
the light turns on for about 5s and then goes
on, the ignition key is turned to position
happens, contact a BYD authorized service
out, indicating the airbag system is working
“0” or taken away, and the door at the
station as soon as possible to have the
normally.
driver side is not closed, the buzzer will
vehicle checked.
sound to remind the drive to turn off the
The warning light system is used for
parking lights or head lights before leaving
z
When the ignition key is turned to
monitoring the airbag ECU, the collision
the vehicle.
position
“II”, the light shine is on
sensor, the inflation device, the warning
continually or can not turn on.
lights, wires and the power supply.
z
The light turns on in driving.
If any of the conditions happens, it means
In operation, temporary shining of the
certain parts monitored by the warning light
warning light does not suggest problem
system have faults. Contact a BYD
existence.
authorized service station as soon as
possible to have the vehicle checked.
Friendly Tips
z
When the ignition key is turned to
z
If the
“ABS” warning light
position “II”, the light turns on for about
turns on when the brake system
5s and then keeps flashing.
warning light is shining, park the
z
When the ignition key is turned to
vehicle in a safe place immediately
position “II”, the light won’t shine or
and contact a BYD authorized
flash.
service station.
z
The light turns on in driving.
Under such cases, not only the ABS
system won’t work in braking, but
also the vehicle will become
extremely unstable.
49
BYD AUTO
F0 Owner’s Manual
Section 1-6
Operation of Instruments and Controllers
6. Ignition switch and parking brake
Ignition switch with steering wheel self-locking mechanism
51
Parking brake
51
50
BYD AUTO
F0 Owner’s Manual
Ignition switch with steering wheel
This is the position for normal driving.
Notice
self-locking mechanism
“Ⅰ”——Accessory apparatuses, e.g. the
radio, can operate, but the engine stops.
When the engine is free, to
prevent battery discharge, do
not
“0”——The engine stops and the steering
keep the key in position “I”.
wheel is locked. The key can be taken off
only when in this position.
Parking brake
The key can be turned from position “I”
to “0” only after pressed in.
In engine startup, the key seems to be
caught in position “0”. To release it, first
make sure it is completely inserted in and
then rotating the steering wheel when
turning the key.
When the ignition key is turned to position
“III”, “I” or “0”, if dials of the
speedometer and the tachometer returns to
the bottom or only swing a little, faults are
indicated.
In parking, lift up the parking brake firmly
to prevent the vehicle from sliding.
Friendly Tips
Applying: Lift the handle of the parking
brake. To get better retaining force, push
z
It is forbidden to take the key
and hold the brake pedal with your foot
out in driving; otherwise, the steering
“Ⅲ”——Start the starter. After released,
until the parking brake is lifted up.
wheel will be locked and the steering
the key will return to position “II”.
operation will go out of control.
For the starting method, refer to Section 3.
Release: Lift the handle of the parking brake
“Ⅱ”—— Start engine operation and
lightly (1), press in the lock-release button
powering all accessory electric appliances.
(2) and then put the parking brake down (3).
51
BYD AUTO
F0 Owner’s Manual
The parking brake indicator will shine until
the parking brake is released to show the
parking brake has been set.
Friendly Tips
z
Before driving, make sure the
parking brake is completely released
and the parking brake indicator is out.
52
BYD AUTO
F0 Owner’s Manual
Section 1-7
Operation of Instruments and Controllers
7. Auto audio system
Audio system reference
54
Function instruction of the central control interface
55
Operation of the audio system
56
53
BYD AUTO
F0 Owner’s Manual
Audio system reference
Functions and characteristics
1.
CD play
2.
Built-in AM/FM radio
3.
Shock-proof structure
4.
30W×4 maximum power output (loudspeaker)
5.
Audio input support
6.
Clock display
54
BYD AUTO
F0 Owner’s Manual
Function instruction of the central
Each key can save two AM channels and
“Power” key
control interface
three FM channels. (When the “AM/FM”
Press the “Power” key to turn on or turn
key is pressed, the LCD will show
off the audio system. When the ignition key
“AM1”, “AM2”, “FM1”, “FM2”
is in position
“II” or “I”, the audio
and “FM3” in sequence.) If power supply
system can work.
of the audio system is cut off (the system is
“VOL (∧ / ∨)” key
disconnected from the battery or the fuse is
burnt out), the saved channels will be
Press the “VOL (∧/∨)” key to adjust
cleared.
the sound volume.
“AM/FM” key
Disc unloading key “
”
Press the
“AM/FM” key to switch
Press this key to unload the CD disc.
between AM and FM.
“1 2 3 4 5 6” keys
“SEEK/SKIP (∧ / ∨)” key
The keys are used for saving channels and
“SCAN” key
AM FM radio：Press the “SEEK/SKIP (∧
listening to programs of the saved channels.
In AM/FM radio mode, hold this key to
/ ∨ ) ” to select channels of different
automatically save channels. Press this key
frequencies.
Save a channel: You can save the current
to fast browse the saved channels.
channel by holding down a numerical key.
Hold down the “SEEK/SKIP (∧/∨)”
The corresponding figure can be displayed
key to search channels with signals
“AUDIO” key
on the LCD screen at the same time.
automatically.
Press the
“AUDIO” key to enter the
audio-effect adjustment mode and select
Listen to programs of a saved channel: You
CD player: Press the “SEEK/SKIP (∧/
audio effect from the cycle of
“bass
can listen to programs of a saved channel by
∨)” key to play the next/previous music
(BAD)-treble
(TRE)-balance
(BAL)-front
pressing the corresponding numerical key.
file.
and rear direction (FRD)”. When a certain
The corresponding figure and the channel
Hold the “SEEK/SKIP (∧/∨)” key to
mode is switched to, press the “VOL (∧/
frequency will be displayed on the LCD
enter fast-forward or fast-backward mode;
∨)” key for adjustment.
screen at the same time.
release the key to recover normal playing.
55
BYD AUTO
F0 Owner’s Manual
“CLOCK” key
“INT” key
search radio signals again. In addition, FM
Hold this key to enter the clock adjustment
If you press this key, the LCD will show
radio signals are short wave signals which
mode. Press
“4(H)”,
“5(M)” and
“INT” and play the beginnings of the
may be intercepted by tall buildings or high
“6(R)” respectively for hour, minute
music files in the CD disc in a browsing
mountains. The radio is not to blame for bad
adjustment and minute zero-return.
mode. Press the “INT” again to cancel
receiving effect for such reasons.
the browsing play mode.
Radio antenna
“CD/AUX” key
The radio antenna can be detached by
CD play：Press “CD/AUX” key to switch
Operation of the audio system
rotating the antenna pole anticlockwise.
to the CD mode.
Notice
Notice
AUX play: If you want to listen to music
To use the audio system properly, the
files in a portable player, e.g. CD, MD or
following instructions should be
To prevent antenna damage, take it
MP3, you can connect the device to the
followed:
off before the vehicle enters a vehicle
vehicle system by the AUX interface with
Take care not to sprinkle drinks onto
cleaning station for cleaning.
an audio frequency cable and play the music
the audio system.
When the vehicle is parked in a
files.
Do not insert any foreign objects into
garage, take the antenna off if it
the CD slot except CD discs.
touches the ceiling.
“RDM” key
It’s normal that noise may be given
If you press this key, the LCD will show
out by the loudspeakers of the
CD player
“RDM” and then play the music files in
working audio system if a mobile
the CD disc in a random order. Press the
communication device, e.g. a mobile
In loading CD discs, please keep the surface
“RDM” again to cancel the random play
phone, is being used in or near the
with the label upward. The CD players will
mode.
vehicle.
play the files in the CD from the first to the
last and then replay the cycle.
Radio
“RPT” key
If you press this key, the LCD will show
Notice
The broadcasting range of the FM radio is
“RPT” and then repeat playing the music
Do not disassemble the CD player
about 40km. If the vehicle is far away from
files in the CD disc. Press the
“RPT”
without permission. Do not let oil or
signal emission towers of radio stations, the
again to cancel the repeating play mode.
other objects enter the CD player.
audio effect will become bad; you have to
56
BYD AUTO
F0 Owner’s Manual
Please use
12cm (4.7 inch) standard CD
discs.
CD player protection
z
The CD player is designed specially
for 12cm CD discs.
z
In extremely hot environment, do not
use the CD player. In summer whether,
please turn on the air conditioner after CD
disc playing.
z
When the vehicle is driving on a
uneven road, the CD player, if working,
z
Only standard CD discs as the above
Discs with special shapes
may have the noise jump problem.
figure shows can be played.
z
If there is moist in the CD player, no
z
Possibly, following CD discs cannot
song can be heard even when it is working.
be played:
You should take the CD disc out of the
player and not use the CD player until it is
Anti-copy CD
dry.
CD-R
CD-RW
Friendly Tips
CD-ROM
The CD player adopts invisible laser,
which, if radiating out of the CD
player, may lead to irradiation
hazard. Please operate the CD player
correctly according to the instruction.
Transparent and translucent discs
57
BYD AUTO
F0 Owner’s Manual
Notice
z
After listened to, the CD disc should
be taken out from the player and put into a
Please play legal discs. Do not use
plastic box away from moisture, heat
special-shape,
transparent,
resources and direct solar irradiation.
translucent, poor-quality or labeled
discs as shown above; otherwise, the
CD player may be damaged or the
disc cannot be played.
Discs of poor quality
Right
Wrong
CD disc cleaning: first wipe the CD disc
surface with a piece of soft and
z
CD discs should be loaded and
velveteen-free wet cloth and then wipe it
unloaded carefully. More care should be
dry with dry soft cloth. Do not apply alcohol
taken for inserting a disc into the CD player
or other detergent.
slot. Hold edge of the disc and do not twist
it. Do not leave your fingerprints on the CD
disc, especially the data storage surface.
Discs with labels
z
Filth, scratches, contortion, pin holes
or other damages on the disc may lead to
skip reading or track repeat.
58
BYD AUTO
F0 Owner’s Manual
Section 1-8
Operation of Instruments and Controllers
8. Air conditioning system
Air conditioning control panel
60
Air outlet mode settings
63
Operation instructions
65
Side air outlets
65
Air filter (optional)
66
59
BYD AUTO
F0 Owner’s Manual
Air conditioning control panel
With air conditioning
1.
air blower speed regulation knob
2.
“A/C” switch
3.
cool/hot wind selection knob
4.
inner-outer circulation mode selection slider
5.
outlet mode selection knob
60
BYD AUTO
F0 Owner’s Manual
Without air conditioning
1.
air blower speed regulation knob
2.
cool/hot wind selection knob
3.
outlet mode selection knob
61
BYD AUTO
F0 Owner’s Manual
(1)
Air blower speed regulation knob
1)
Instrument panel—air flows come
mainly from the air vents of the instrument
Turn this knob to regulate the fan speed of
panel.
the air blower—clockwise to increase the
2)
Double layer—air flows come mainly
wind speed and anticlockwise to decrease
from air vents of the floor and the
the wind speed.
instrument panel.
3)
Floor—air flows come mainly from
(2)
Cool/hot wind selection knob
air vents of the floor.
4)
Floor/windshield—air flows come
Turn this
knob to adjust
the
mainly from air vents of the floor and the
temperature—clockwise for increase and
1)
Inner circulation—to re-circulate air
windshield.
anticlockwise for decrease.
in the vehicle.
It is used together with the inner-outer
circulation mode selection slider in the outer
2)
Outer
circulation—to
introduce
(3)
Outlet mode selection knob
circulation position.
outside air in the vehicle.
5)
Windshield—air flows come mainly
Turn this knob to adjust the direction of the
from air vents of the windshield. It is used
(5)
“A/C” switch
gas flow outlet.
together with the inner-outer circulation
To turn on the air conditioning system, first
mode selection slider in the outer circulation
position.
turn the air blower speed regulation knob to
a position other than
“
“ and then
For settings of the outlet mode selection
press the “A/C” switch. At the same time,
knob, refer to the
“—outlet mode
the working indicator of the switch will
settings” introduced below.
shine. Press the “A/C” switch again or
turn the air blower speed regulation knob to
(4)
Inner-outer
circulation
mode
selection slider (with air conditioner)
position
“
“ to turn off the air
conditioning system.
62
BYD AUTO
F0 Owner’s Manual
Air outlet mode settings
（1） Hot wind
To get the best effect, set the controller as
follows:
1)
With air conditioning
air blower speed——any position other
than “
“
temperature——heating position
(red
region)
air introduction——outer circulation
(outside air)
air flow——floor
air conditioner——off
For fast temperature rise, select the inner
circulation mode and keep it for minutes.
Then, to prevent mist accumulation on the
windows, select the outer circulation mode
after the temperature in the vehicle is
increased to a certain level.
Press the “A/C” to remove moisture
brought by heating.
Select floor/windshield mode air
flows to heat the vehicle interior and
63
