Controls Technology for driving comfort and safety
Active steering
Defect
If there is a defect, a corresponding text mes-
The concept
sage appears. Have the system checked.
Active steering varies the turning angle of the
front wheels in relation to steering wheel move-
ments. It also varies the steering force required
Servotronic
to turn the wheels depending on the speed at
which you are driving.
The concept
When you are driving in the low speed range,
The Servotronic varies the steering force
e.g. in a town or when parking, the steering
required to turn the wheels relative to the
angle is increased, i.e. steering becomes very
vehicle speed.
direct and less effort is required to turn the
At low speeds, the steering force is strongly
wheels. In the higher speed range, on the other
assisted, i.e. less force is needed for steering.
hand, the steering angle is reduced as the
As the vehicle speed increases, the steering
speed increases. This improves the handling of
assisting power is reduced.
your BMW over the entire speed range.
This system functions automatically.
In critical situations, the system can make tar-
geted corrections to the steering angle pro-
Malfunctions
vided by the driver and thus stabilize the vehicle
The warning lamp lights up. A mes-
before the driver intervenes. This stabilizing
sage appears on the Control Display.
intervention is simultaneously deactivated
Servotronic is malfunctioning or has
when DSC is switched off, refer to page 89.
failed. Steering response will be different. You
can continue your journey, but moderate your
Malfunction
speed and exercise due caution. Have the
The warning lamps come on. Active
system checked as soon as possible.
steering is malfunctioning or is tem-
porarily deactivated. At low speeds,
greater steering wheel movements
Brake Force Display
are required, whereas at higher speeds the
vehicle reacts more sensitively to steering
wheel movements. The stability-enhancing
feature may also be deactivated. Drive cau-
tiously and think well ahead.
Deactivation
Active steering is deactivated to perform an ini-
tialization. A message indicates that the feature
is deactivated. Initialization may take several
minutes.
On the left: normal braking.
If the message does not disappear during the
On the right: sharp braking.
current trip, have the system checked.
When the rear fog lamps are switched on, the
Brake Force Display is not active and the illumi-
nated area for normal braking is reduced by
approximately half.
96
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Technology for driving comfort and safety Controls
Airbags
The following airbags are located under the
over the backrests. Do not attempt to remove
marked covers:
the airbag retention system from the vehicle. Do
not modify the individual components of the
1
Front airbags
system or its wiring in any way. This includes
2
Coupe: head airbags
the upholstered covers on the steering wheel,
3
Side airbags in the seat backrests
instrument panel, seats and roof posts, as well
4
Convertible: knee airbags
as the sides of the roof lining. Do not attempt to
remove or dismantle the steering wheel.
Protective action
Do not touch the individual components imme-
Observe the adjustment instructions on
diately after the system has been triggered,
page 49 to ensure the best possible
because there is a danger of burns.
personal protection.<
In the event of faults, immobilization, or after the
airbag system has been triggered, only have the
The front airbags help protect the driver and
testing, repair, or disassembly and scrapping of
front passenger by responding to frontal
gas generator performed by your BMW center
impacts in which safety belts alone cannot pro-
or a workshop that has the required explosives
vide adequate restraint. When needed, the
licenses. Unprofessional attempts to work on
head and side airbags help provide protection in
the system could lead to failure in an emer-
the event of side impact. The relevant side air-
gency or to undesired airbag activation, either
bag supports the side upper body area. The
of which could result in personal injury.<
head air bag supports the head.
Warning notices and information about the
The airbags have been designed to not be trig-
airbags can also be found on the sun visors.
gered in every collision situation, e.g. not in
minor accidents or rear-end collisions.
Automatic deactivation of the front
Do not apply adhesive materials to the
passenger airbags
cover panels of the airbags, cover them or
An analysis of the impression in the front pas-
modify them in any other way.
senger seat cushion determines whether and
Keep the dashboard and window on the front
how the seat is occupied. The front and side air-
passenger side clear, i.e., do not cover with
bags for the front passenger are activated or
adhesive labels or coverings, and do not attach
deactivated by the system accordingly.
holders such as for navigation instruments and
mobile phones.
The indicator lamp above the interior
Do not attach seat covers, cushions or other
rearview mirror shows the current status
objects not specifically approved for seats with
of the front passenger airbags, deactivated or
integral side airbags to the front seats. Do not
activated, refer to Status of front passenger
hang items of clothing such as coats or jackets
airbags below.<
97
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Controls Technology for driving comfort and safety
Before transporting a child on the front
Most child seats are detected by the
passenger seat, read the safety precau-
system. This particularly applies to
tions and handling instructions under Trans-
child seats that were required by NHTSA at
porting children safely, refer to page 58.
the time of manufacture of the vehicle. After
The front and side airbags can also be deacti-
mounting a child seat, ensure that the indi-
vated by adolescents and adults sitting in cer-
cator lamp for the front passenger airbag is
tain positions; the indicator lamp for the front
lit. It indicates that the child seat has been
passenger airbags lights up. In such cases, the
detected and that the front passenger air-
passenger should change his or her sitting
bags are deactivated.<
position so that the front passenger airbags are
> The indicator lamp does not come on when,
activated and the indicator lamp goes out. If the
for example, a person of sufficient size and
desired airbag status cannot be achieved by
in a correct sitting position is detected on
changing the sitting position, transport the rele-
the seat.
vant passenger on a rear seat. Do not attach
The front and side airbags for the front
seat covers, seat cushion padding, ball mats or
passenger are activated.
other items to the front passenger seat unless
> The indicator lamp does not light up if the
they are specifically recommended by BMW.
seat is empty.
Do not place any items under the seat which
The front and side airbags for the front
could press against the seat from below. Other-
passenger are not activated.
wise, a correct analysis of the seat cushion is
not ensured.<
Operational readiness of airbag system
Status of front passenger airbags
As of radio readiness, refer to page 61, the
warning lamp lights up briefly to indicate that
The indicator lamp for the front passenger air-
the entire airbag system and the belt tensioners
bags shows the functional status of the front
are operational.
passenger front and side airbags in accordance
with whether and how the front passenger seat
Airbag system malfunction
is occupied. The indicator lamp shows whether
the front passenger airbags are activated or
> Warning lamp does not light up at radio
deactivated.
readiness or beyond.
> The indicator lamp lights up when a child in
> Warning lamp remains permanently on.
a specially designated child restraint sys-
In the event of a fault in the airbag system,
tem is detected, as intended, on the seat.
have it checked without delay; otherwise,
The front and side airbags for the front
there is the risk that the system will not function
passenger are not activated.
as intended even if a sufficiently severe acci-
dent occurs.<
98
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Technology for driving comfort and safety Controls
Convertible: rollover
4. Push the protection bar down until it snaps
into place.
protection system
The rollover protection system is activated
automatically in the event of an accident of suf-
ficient severity or an extreme tilt in the car's lon-
gitudinal axis. The protection bars behind the
rear head restraints deploy within fractions of a
second.
As a supplementary system to the reinforced
windshield frame, the rollover protection
system increases the safety of the vehicle
occupants.
5. Repeat the procedure for the other protec-
tion bar.
Always keep the area of movement of the
rollover protection system clear.
Have the rollover protection system checked
In minor accidents, you are protected by the
after an unexpected activation.
fastened safety belt and, depending on acci-
If the rollover protective system is
dent severity, by the safety belt tensioner and
extended, do not operate the convertible
multi-phase airbag retention system.<
top.
Do not make any modifications to the individual
Resetting
components of the rollover protection system
If the rollover protection system was not
or its cabling.
impacted after being automatically activated, it
Work on the rollover protection system should
can be reset by lowering the protection bars to
be performed only by your BMW center.
their original positions. This does not require
Faulty repair may lead to the failure of the sys-
tools.
tem or malfunctions.
To check the system and ensure flawless long-
1. Push the locking lever to one side and hold
term operation, always observe the service
it there.
intervals, refer to page 80.<
2. Push the protection bar halfway down from
above.
3. Release the locking lever.
99
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Controls Lamps
Lamps
Vehicle equipment
Parking lamps
In switch position 1, the front, rear and side
In this chapter, all production, country, and
vehicle lighting is switched on. You can use the
optional equipment that is offered in the model
parking lamps for parking.
range is described. For this reason, descrip-
tions will be given of some equipment that may
With halogen headlamps: when the ignition is
not be available in a vehicle, for example due to
switched off and the switch is in position 1, only
the special options or national-market version
the outside sections of the rear lamps are illumi-
selected. This also applies to safety related
nated, refer to page 246.
functions and systems.
The parking lamps will discharge the bat-
tery. Therefore, do not leave them on for
unduly long periods of time; otherwise, the bat-
Overview
tery might not have enough power to start the
engine. It is preferable to switch on the left-
hand or right-hand roadside parking lamps,
refer to page 102.<
Low-beam headlamps
The low beams light up when the light switch is
in position 2 and the ignition is on.
Automatic headlamp control
When the switch is in position 3, the low beams
0
Lamps off,
are switched on and off automatically depend-
daytime running lights
ing on ambient lighting conditions, e.g. in a tun-
1
Parking lamps and daytime running lights
nel, in twilight, or if there is precipitation. The
Adaptive Light Control is active. The LED next
2
Low beams,
to the symbol is illuminated when the low
welcome lamps
beams are on. You can also activate the daytime
3
Automatic headlamp control, daytime run-
running lights, refer to page 101. In the situa-
ning lights, welcome lamps, High-beam
tions described above, the lamps then automat-
Assistant, Adaptive Light Control
ically switch from daytime running lights to low
beams.
The headlamps may also come on when the
Parking lamps/low beams,
sun is sitting low on a blue sky.
automatic headlamp control
The low beams remain switched on inde-
pendent of the ambient lighting condi-
General information
tions when you switch on the fog lamps.<
When the driver's door is opened with ignition
The automatic headlamp control cannot
switched off, then the exterior lighting is auto-
serve as a substitute for your personal
matically switched off if the light switch is in
judgment in determining when the lamps
position 0, 2, or 3.
should be switched on in response to ambient
100
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Lamps Controls
lighting conditions. For example, the system
4. Set the duration.
cannot detect fog or hazy weather. To avoid
safety risks, you should always switch on the
low-beam headlamps manually under these
conditions.<
Welcome lamps
If you leave the light switch in position 2 or 3
when you park the car, the parking lamps and
the interior lamps light up briefly when you
unlock the vehicle.
The setting is stored for the remote control
currently in use.
Activating/deactivating welcome
lamps
Daytime running lights
1. "Settings"
The daytime running lights light up in switch
2. "Lighting"
position 0, 1, and 3. They output less light than
3. "Welcome light"
the low beams.
The tail lamps may also light up.
Activating/deactivating daytime
running lights
1. "Settings"
2. "Lighting"
3. "Daytime running lamps"
The setting is stored for the remote control
currently in use.
Pathway lighting
If the headlamp flasher is activated after switch-
ing off the ignition with the lamps switched off,
the low beams come on and remain on for a
certain time.
The setting is stored for the remote control
Setting duration
currently in use.
1. "Settings"
2. "Lighting"
Adaptive Light Control
3. "Pathway light.:"
The concept
Adaptive Light Control is a variable headlamp
control system that enables better illumination
of the road surface. Depending on the steering
101
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Controls Lamps
angle and other parameters, the light from the
Roadside parking lamps, left or right
headlamp follows the course of the road.
There is an additional option of switching on the
In tight curves such as on switchbacks or when
lamps on the side of the car facing the road
turning, at speeds up to approx. 40 mph/
when parked.
70 km/h, an additional, cornering light is
switched on that lights up the area inside the
Switching on
curve.
After parking the vehicle, press the lever up or
down beyond the pressure point for approx.
Activating Adaptive Light Control
1 second, arrow 3.
With the ignition switched on, turn the light
The roadside parking lamps drain the bat-
switch to position 3, refer to page 100.
tery. Therefore, do not leave them on for
The corner-illuminating lamp is switched on
unduly long periods of time; otherwise, the bat-
automatically, depending on the steering wheel
tery might not have enough power to start the
angle or turn signal indicator.
engine.<
Standstill function: to avoid blinding oncoming
traffic, the Adaptive Light Control does not
Switching off
direct light toward the driver's side when the
Press the lever in the opposite direction to the
vehicle is at a standstill.
pressure point, arrow 3.
When you are reversing, only the corner-illumi-
nating lamps are switched on and active on
both sides.
High-beam Assistant
Malfunction
The concept
The warning lamp lights up. A mes-
This system automatically switches the high
sage appears on the Control Display.
beams on and off. The procedure is controlled
The Adaptive Light Control is mal-
by a sensor on the front of the interior rearview
functioning or failed. Have the system checked
mirror. The assistant ensures that the high
as soon as possible.
beams are switched on whenever the traffic sit-
uation allows. It handles this task for you and
gives you the benefit of the best possible view.
High beams/roadside parking
You can intervene at any time and switch the
lamps
high beams on and off as usual.
Activating the system
1. Turn the light switch to position 3, refer to
page 100.
2. With the low beams switched on, briefly
push the turn signal/high beam lever in the
direction of the high beam.
The indicator lamp in the instrument
cluster lights up when the high beams
1
High beams
are activated. The system automati-
cally switches from high beams to low beams
2
Headlamp flasher
3
Roadside parking lamps
102
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Lamps Controls
and vice versa in response to oncoming traffic,
> In tight curves, on hilltops or in depressions,
traffic ahead of you, and adequate ambient
in cross traffic or half-obscured oncoming
lighting, e.g. on city streets.
traffic on highways
> In poorly lit towns and cities and in the
Switching the high beams on and off
presence of highly reflective signs
manually
> At low speeds
Whenever you wish, or when the situation
> When the windshield in front of the interior
requires, you can intervene:
rearview mirror is fogged over, dirty or cov-
> If the High-beam Assistant switches on the
ered with stickers, etc.
high beams, but you would like to drive with
> If the sensor is dirty. Clean the sensor on
the low beams, simply switch off the high
the front of the interior rearview mirror using
beams using the turn signal/high beam
a cloth moistened with a small amount of
lever. This deactivates the High-beam
glass cleaner.
Assistant.
To reactivate the system, briefly push the
Activating via iDrive
turn signal/high beam lever toward the high
beams again.
1. "Settings"
> If the High-beam Assistant switches on the
2. "Lighting"
low beams, but you would like to drive with
3. "High beam assistant"
the high beams, switch on the high beams
as usual. This deactivates the system and
the high beams need to be switched off
manually, if necessary.
To reactivate the system, briefly push the
turn signal/high beam lever toward the high
beams again.
> Use the headlamp flasher as usual with the
low beams switched on.
System limitations
The setting is stored for the remote control
The High-beam Assistant cannot serve
currently in use.
as a substitute for the driver's personal
judgment of when to use the high beams.
Therefore, manually switch off the high beams
Fog lamps
in situations where this is required to avoid a
safety risk.<
The system is not fully functional in situations
such as the following, and driver intervention
may be necessary:
> In very unfavorable weather conditions,
such as fog or heavy precipitation
> In detecting poorly-lit road users, such as
pedestrians, cyclists, horseback riders and
wagons; when driving close to train or ship
To switch on/off, press the button.
traffic; and at animal crossings
103
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Controls Lamps
The parking lamps or low beams must
3. Push button 1 up or down to select the
be switched on for the fog lamps to
desired brightness level.
operate. The green indicator lamp in
4. Press button 2.
the instrument cluster lights up whenever the
The display again shows the outside
fog lamps are on.
temperature and the time.
The fog lamps are switched off while you acti-
vate the headlamp flasher or switch on the high
beams.
Interior lamps
If the automatic headlamp control is acti-
The interior lamps, the footwell lamps, entry
vated, the low beams will come on auto-
lamps, trunk lamp, and courtesy lamps are
matically when you switch on the fog lamps.<
controlled automatically.
The LEDs for the courtesy lamps are set in the
door handles and illuminate the ground in front
Instrument lighting
of the doors.
You can adjust the brightness of the instrument
To reduce the drain on the battery, a few
lighting only when the parking lamps or the low
minutes after the radio readiness is
beams are switched on.
switched off, refer to Start/Stop button on
page 61, all lights in the vehicle's passenger
compartment are switched off.<
Switching interior lamps on/off
manually
1. Push button 1 in the turn signal/high beam
lever up or down repeatedly until the appro-
priate symbol appears in the display,
accompanied by the brightness level and
the word "SET".
2. Press button 2.
Interior lamps, front and rear:
To switch on and off, press the button.
To switch off the interior lamps, footwell lamps,
entry lamps, and courtesy lamps permanently,
press the button for the front interior lamps for
about 3 seconds.
104
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Lamps Controls
Reading lamps
There are reading lamps at the front and rear,
next to the interior lights. To switch on and off,
press the button.
105
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Controls Climate
Climate
tions will be given of some equipment that may
Vehicle equipment
not be available in a vehicle, for example due to
In this chapter, all production, country, and
the special options or national-market version
optional equipment that is offered in the model
selected. This also applies to safety related
range is described. For this reason, descrip-
functions and systems.
Overview
1
Airflow directed toward the windshield and
4
Air distribution, manual
side windows
5
Temperature, left side
2
Air to the upper body area:
6
Maximum cooling
Draft-free ventilation
109
7
AUTO program
3
Air to the footwell
106
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Climate Controls
8
Air volume, manual adjustment; AUTO
Temperature
intensity
Turn to set the desired tempera-
9
Display
ture.
10 Automatic recirculated air control AUC/
The automatic climate control
Recirculated air mode
achieves this temperature as
quickly as possible regardless of the season,
11 Temperature, right side
using maximum cooling or heating power if
12 ALL program
necessary, and then maintains it.
13 Defrosting windows and removing
Avoid rapid switching between different tem-
condensation
perature settings. The automatic climate con-
14 Switching air conditioning on/off manually
trol will not have sufficient time to adjust the set
15 Rear window defroster
temperature.
16 Seat heating, right side
54
Maximum heating power can be obtained with
the highest setting, regardless of the outside
17 Interior temperature sensor, please keep
temperature.
clear
The system cools steadily in the lowest setting,
18 Seat heating, left side
54
regardless of the outside temperature.
Maximum cooling
Automatic climate control
Press the button.
The system is set to the lowest
Comfortable interior climate
temperature, maximum air volume
AUTO program 7 offers the ideal air distribution
and recirculated air mode.
and air volume for almost all conditions, refer to
AUTO program below. All you need to do is
Air flows out of the vent outlets for the upper
select an interior temperature which is comfort-
body region. Open them for this purpose.
able for you.
Air is cooled as quickly as possible
The following sections inform you in detail
> Above an outside temperature of approx.
about how to adjust the settings.
327/06
Most settings are stored for the remote control
> When the engine is running
currently in use, refer also to Personal Profile
settings on page 33.
AUTO program
Press the button.
Adjusting air distribution manually
Air volume, air distribution and
The air distribution can be
temperature are controlled auto-
switched on and off manually. The
matically.
air is directed to the windshield, to
Depending on the selected temperature, AUTO
the upper body area and to the
intensity and outside influences, the air is
footwell.
directed toward the windshield, the side
The automatic air distribution can be switched
windows, the upper body and the footwell.
back on by pressing the AUTO button. The air
Pressing the AUTO button automatically
conditioning is switched on automatically and
switches on the air conditioning.
the manual air distribution setting is cleared.
107
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Controls Climate
At the same time, a condensation sensor
Automatic recirculated air control
controls the program so as to prevent window
AUC/Recirculated air mode
condensation as much as possible.
You can respond to unpleasant odors or pollut-
The program is switched off when the air distri-
ants in the immediate environment by tempo-
bution is set manually or the button is pressed
rarily suspending the supply of outside air. The
again.
system then recirculates the air currently within
the vehicle.
Intensity of the AUTO program
Press the button repeatedly to
With the AUTO program switched on, auto-
select an operating mode:
matic control of the air volume and air
distribution can be adjusted:
> LED off: outside air flows in continuously.
Press the left side of the button to
> Left-hand LED on, AUC mode: a sensor
reduce the intensity. Press the
detects pollutants in the outside air and
right side of the button to
controls the shut-off automatically.
increase it.
> Right-hand LED on, recirculated air mode:
The selected intensity is shown on the display
the supply of outside air is permanently
of the automatic climate control.
shut off. If the windows fog over, switch off
recirculated air mode and increase the air
Convertible Program
volume, if necessary. Make sure that air can
The Convertible Program is active when the
flow onto the windshield.
convertible top is open and the AUTO program
is switched on. During the Convertible Program,
The recirculated air mode should not be
the automatic climate control is optimized for
used continuously for lengthy periods;
driving with the soft top down. In addition, the
otherwise, the quality of the air inside the car
air volume is increased as vehicle speed
will gradually deteriorate.<
increases.
Via the button on the steering wheel
The effectiveness of the Convertible
You can switch quickly between the recircu-
Program can be enhanced considerably
lated air mode and the previous mode using a
by installing the wind deflector.<
button on the steering wheel, refer to page 13.
Adjusting air volume manually
ALL program
To be able to manually adjust the air volume,
switch off the AUTO program first.
Press the button.
Press the left side of the button to
The current temperature setting
reduce the air volume. Press the
on the driver's side is transferred to
right side of the button to
the front passenger side.
increase it.
If the temperature setting on the driver's side is
The air flow rate is lowered or switched off
changed, the temperature on the front passen-
entirely to reduce the drain on the battery. The
ger side is changed as well.
display remains the same.
The program is switched off when the setting
is adjusted on the front passenger side or the
button is pressed again.
108
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Climate Controls
Defrosting windows and removing
Switching on
condensation
Press any button, except the buttons for the
Press the button.
ALL program or the rear window defroster.
Quickly removes ice and conden-
sation from the windshield and
Ventilation
front side windows.
For this purpose, also switch on the air
conditioning.
Switching air conditioning on/off
The passenger compartment can only be
cooled while the engine is running.
Press the button.
The air is cooled and dehumidified
and - depending on the tempera-
1
Use the thumbwheels to smoothly open
ture setting - warmed again.
and close the air vents
Depending on the weather, the windshield may
2
Use the levers to change the direction of the
fog up briefly when the engine is started.
airflow
Pressing the AUTO button automatically
Ventilation for cooling
switches on the air conditioning.
Adjust the vent outlets to direct the flow of cool
air in your direction, e.g. if it has become too hot
Rear window defroster
in the car.
Press the button.
The defroster is switched off auto-
Draft-free ventilation
matically after a certain time.
Set the vent outlets so that the air flows past
Depending on your vehicle's equipment, the
you and not straight at you.
upper wires serve as an antenna and are not
part of the rear window defroster.
Microfilter/activated-charcoal filter
The microfilter traps dust and pollen in the
Switching the system on/off
incoming air. The activated-charcoal filter pro-
vides additional protection by filtering gaseous
Switching off
pollutants from the outside air. Your BMW cen-
Press and hold the left button or
ter replaces this combined filter during routine
press the left button at the lowest
maintenance.
level.
All displays are cleared except for the rear
window defroster if it is switched on.
The outside air supply is blocked when
the automatic climate control is switched
off. If the air quality deteriorates or the window
fogs over, switch the system back on and
increase the air volume.<
109
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Controls Climate
Parked car ventilation
Preselecting switch-on times
1.
"Settings"
The concept
2.
"Climate"
The parked car ventilation provides ventilation
3.
"Activate Timer 1" or "Activate Timer 2"
to the passenger compartment and lowers its
4.
"Timer 1:" or "Timer 2:"
temperature, if necessary.
For any outside temperature, the system can be
switched on or off directly or via a preset
switch-on time. It will remain on for 30 minutes.
Due to its high power consumption, the parked
car ventilation system should not be switched
on twice in a row without driving in between to
allow the battery to recharge.
Open the vents so that air can flow out.
They can be operated via iDrive.
5.
Turn the controller: set the hours.
Switching on and off directly
6.
Press the controller: the setting is
accepted.
1. "Settings"
7.
Turn the controller: set the minutes.
2. "Climate"
8.
Press the controller: the setting is
3. "Activate parked-car vent."
accepted.
The symbol on the automatic climate Control
Display lights up.
The symbol on the automatic climate Control
Display flashes when the system has switched
on.
The respective system is switched on
within the next 24 hours only. After these
have elapsed, it must be reactivated.<
The symbol on the automatic climate control
display flashes.
110
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Practical interior accessories Controls
Practical interior accessories
Vehicle equipment
Compatibility
If this symbol appears on the package
In this chapter, all production, country, and
or in the instructions supplied with the
optional equipment that is offered in the model
device to be operated, you can gener-
range is described. For this reason, descrip-
ally assume that the device is compatible with
tions will be given of some equipment that may
the Integrated universal remote control.
not be available in a vehicle, for example due to
the special options or national-market version
For additional questions, please consult:
selected. This also applies to safety related
> Your BMW center.
functions and systems.
> www.homelink.com on the Internet.
HomeLink is a registered trademark of Johnson
Controls, Inc.
Integrated universal remote
control
Controls on the interior rearview mirror
The concept
The Integrated universal remote control can be
used to operate up to 3 functions of remote-
controlled devices such as garage door open-
ers or lighting systems. The Integrated univer-
sal remote control thus replaces as many as
three different hand-held transmitters. To oper-
ate them, the buttons on the interior rearview
mirror must be programmed with the desired
functions. Programming requires the hand-held
1
LED
transmitter for the respective device.
2
Buttons
To prevent possible damage or injury,
3
Hand-held transmitter, required for
before programming or using the inte-
programming.
grated universal remote control to operate a
device, always inspect the immediate area to
Programming
make certain that no people, animals or objects
are within the pivoting or travel range of the
General information
device being operated.
1. Switch on the ignition.
Also follow the safety instructions supplied with
2. Initial operation:
the hand-held transmitter.<
Simultaneously hold down the right and
For security reasons, make sure to delete the
left buttons on the inside mirror for approx.
stored functions before selling the vehicle, refer
20 seconds until the LED on the inside
to page 113.
mirror flashes.
All programs of the buttons on the rearview
mirror are deleted.
111
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Controls Practical interior accessories
3.
Hold the hand-held transmitter of the
For information about synchronizing can also
device to be controlled about 1 in/2.5 cm to
be found in the operating instructions for the
3 in/8 cm away from the buttons on the
device to be set.
inside mirror.
Programming will be easier with the aid of a
The required distance depends on the
second person.
hand-held transmitter.
Synchronizing:
4.
Simultaneously press and hold the button
1. Park your vehicle within the range of the
of the desired function on the hand-held
remote-controlled device.
transmitter and the button to be pro-
2. Program the Integrated universal remote
grammed on the inside mirror.
control as described above.
The LED on the inside mirror will flash
3. Locate and press the synchronization
slowly at first.
button on the device to be set. You have
5.
As soon as the LED flashes rapidly, release
approx. 30 seconds to perform the next
both buttons. The rapid flashing indicates
step.
that the button on the inside mirror has
4. Hold down the programmed button on the
been programmed.
inside mirror for approx. 3 seconds and then
If the LED does not flash rapidly within
release it. Repeat this operation, up to three
60 seconds, change the distance between
times if necessary, to complete the syn-
the inside mirror and the hand-held trans-
chronization. If the synchronization has
mitter and repeat this step. This may
succeeded, the programmed function is
require several attempts. Allow at least
performed.
15 seconds between attempts.
6.
To program additional functions on the
Reprogramming individual buttons
other buttons of the inside mirror, repeat
1.
Switch on the ignition.
steps 3 through 5.
2.
Hold the hand-held transmitter of the
The buttons on the inside mirror can be used to
device to be controlled about 1 in/2.5 cm to
operate the devices if the ignition is switched
3 in/8 cm away from the buttons on the
on.
inside mirror.
The required distance depends on the
Special procedure with alternating-
hand-held transmitter.
code systems
3.
Press the desired button on the inside
If the device fails to function even after repeated
mirror.
programming, check whether the device to be
controlled uses an alternating-code system.
4.
If the LED on the inside mirror flashes
slowly after approx. 20 seconds, press the
To do so, either read the instructions for the
transmit key of the hand-held transmitter.
device or hold down the programmed button on
the inside mirror. If the LED on the inside mirror
5.
As soon as the LED flashes rapidly, release
flashes quickly at first and then remains lit for
both buttons.
2 seconds, the device uses an alternating-code
If the LED does not flash rapidly after
system. The LED flashes and lights up repeat-
approx. 60 seconds, alter the distance and
edly for approx. 20 seconds.
repeat the step.
In devices with an alternating-code system, the
Integrated universal remote control and the
device must also be synchronized.
112
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Practical interior accessories Controls
Canada: if the LED does not flash rapidly
Digital compass
after approx. 60 seconds, alter the distance
and repeat this step or, if the programming
by means of the hand-held transmitter was
interrupted, hold down the button on the
inside mirror and then press and release the
button on the hand-held transmitter several
times, holding it down for 2 seconds each
time.
Operation
To prevent possible damage or injury,
1
Adjustment button
before programming or using the inte-
2
Display
grated universal remote control to operate a
device, always inspect the immediate area to
The display shows you the main or secondary
make certain that no people, animals or objects
compass direction in which you are driving.
are within the pivoting or travel range of the
device being operated.
Operating principle
Also follow the safety instructions supplied with
You can call up various functions by pressing
the hand-held transmitter.<
the adjustment button with a pointed object
such as a pen or similar item. The following
The button on the inside mirror can be used to
adjustment options are displayed one after the
operate the device, for example the garage
other, depending on how long you keep the
door, if the engine is running or the ignition is
adjustment button pressed:
switched on. To do so, within the reception
range of the device, press the button of the
> Press briefly: switch display on/off
device until the function is triggered. The LED
> 3 to 6 seconds: set compass zone
on the inside mirror remains lit during transmis-
> 6 to 9 seconds: calibrate compass
sion of the radio signal.
> 9 to 12 seconds: set left-hand/right-hand
steering
Deleting stored functions
> 12 to 15 seconds: setting the language
Simultaneously hold down the right and left
buttons on the inside mirror for approx. 20 sec-
Setting compass zones
onds until the LED on the inside mirror flashes
rapidly. All stored functions are deleted. The
Set the compass zone corresponding to your
functions cannot be deleted individually.
vehicle's geographic location so that the com-
pass can function correctly; refer to the world
map with compass zones.
113
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Controls Practical interior accessories
To set the compass zones, press the setting
3. Convertible: ensure that the convertible top
button for approx. 3-4 seconds. The number of
is fully closed.
the compass zone set is shown in the display.
4. Press the setting button approx.
To change the zone setting, briefly press the
6-7 seconds to call up C. Then drive in a
adjustment button repeatedly until the display
complete circle at least once at a maximum
shows the number of the compass zone corre-
speed of 4 mph/7 km/h.
sponding to your current location.
If the calibration is successful, display C is
replaced with the points of the compass.
The compass is operational again after approx.
10 seconds.
5. Convertible: open the convertible top fully
and repeat step 4.
Calibrating the digital compass
The digital compass must be calibrated in the
Setting right-hand/left-hand steering
following situations:
Your digital compass is factory-set to right-
hand or left-hand steering, in accordance with
> An incorrect compass direction is shown.
your vehicle.
> The compass direction shown does not
change although the direction of travel
Setting the language
does.
You can set the language of the display:
> Not all compass directions are shown.
Press the setting button for approx.
12-13 seconds. Briefly press the adjustment
Procedure
button again to switch between English, "E",
1. Make sure that no large metal objects or
and German, "O".
overhead power lines are in the vicinity of
The setting is automatically saved after approx.
your vehicle and that you have enough
10 seconds.
space to drive in a circle.
2. Set the currently valid compass zone.
114
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Practical interior accessories Controls
Glove compartment
Observe the following when connecting:
> Do not forcibly connect the plug to the USB
Opening
interface.
> Do not connect devices such as fans or
lamps to the USB interface.
> Do not connect USB hard discs.
> Do not use the USB interface to recharge
external devices.
Center armrest
Pull the handle.
Storage compartment
The light in the glove compartment comes on.
The center armrest between the front seats
To prevent injury in the event of an acci-
contains a credit card holder and, depending on
dent while the vehicle is being driven,
the equipment version, a compartment or a
close the glove compartment immediately after
snap-in adapter.
use.<
Closing
Fold the cover up.
Locking
To lock the glove compartment, use the
integrated key of the remote control, refer to
page 32.
USB interface for data transmission
Opening
Press the button, see arrow.
Connection for external audio device
You can connect an external audio device such
as a CD or MP3 player and play audio tracks
over the vehicle speakers:
> AUX-IN port, refer to page 177.
> USB audio interface/extended connectivity
of the music player in the mobile phone,
Port for importing and exporting data on USB
refer to page 178.
devices, e.g. music collections, refer to
page 173.
115
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
Controls Practical interior accessories
Storage compartments inside
the vehicle
Compartments are located next to the steering
column, on the doors, in the center console, and
in the rear between the seats.
Do not place unsecured objects in them;
otherwise, they could endanger the car's
occupants, e.g. in the event of braking or
evasive maneuvers.<
You can mount an attachable cupholder on the
Do not place non-slip pads, e.g. anti-slip
side of the center console.
mats, on the dashboard; the materials of
these pads may damage it.<
Ashtray
Coupe: clothes hooks
There are clothes hooks in the rear.
Opening
Items of clothing hung from the hooks
must not obstruct the driver's view. Do
not hang heavy objects from the hooks; other-
wise, they could endanger the car's occupants,
e.g. in case of heavy braking or sudden
swerving.<
Cupholders
Use lightweight and shatterproof contain-
Push the ridge on the cover.
ers and do not transport hot beverages;
otherwise, there is an increased risk of injury in
Emptying
the event of the accident. Do not force contain-
ers that are too large into the cupholders; other-
wise, damage could result.<
Lift out the insert.
There is one cupholder in the center console.
116
Online Edition for Part no. 01402911223 - © 06/13 BMW AG















Content      ..     3      4      5      6     ..
