Acura TLX (2021 year). Manual in english - page 27

Continued

429

uu

AcuraWatch

TM

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

■

How to activate the system

1

Adaptive Cruise Control (ACC) with Low Speed Follow

For directions on the proper handling of the radar
sensor, refer to the following page.

2

Radar Sensor

 P. 482

You can read about handling information for the
camera equipped with this system.

2

Front Sensor Camera

 P. 480

The radar sensor for ACC with Low Speed Follow is
shared with the Collision Mitigation Braking System

TM



(CMBS

TM

).

2

Collision Mitigation Braking System

TM



(CMBS

TM

)

 P. 417

ACC with Low Speed Follow may not work properly
under certain conditions.

2

ACC with Low Speed Follow Conditions
and Limitations

 P. 436

When not using ACC with Low Speed Follow: Turn
off adaptive cruise by pressing the

 button.

■

Press the

 button on the

steering wheel.

 (white) is on in the

instrument panel.
ACC with Low Speed

Follow is ready to use.

How to use

uu

AcuraWatch

TM

u

Adaptive Cruise Control (ACC) with Low Speed Follow

430

Driving

1

Adaptive Cruise Control (ACC) with Low Speed Follow

Do not use ACC with Low Speed Follow under the
following conditions:

•

Driving in continuous stop and go traffic.

•

On roads with sharp turns.

•

On roads with steep downhill sections, as the set
vehicle speed can be exceeded by coasting. In such
cases, ACC with Low Speed Follow will not apply
the brakes to maintain the set speed.

•

On roads with toll collection facilities or other
objects between lanes of traffic, or in parking
areas, or facilities with drive through access.

Continued

431

uu

AcuraWatch

TM

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

When driving at about 25 mph (40 km/h) or above:

Take your foot off the

pedal and press down the

RES/+

/

SET/–

 switch when you reach the desired speed.

The moment you release the switch, the set speed is fixed, and ACC with Low Speed
Follow begins.

When driving slower than about 25 mph (40 km/h):

If the vehicle is moving

and the brake pedal is not depressed, pressing the switch fixes the set speed to
about 25 mph (40 km/h) regardless of current vehicle speed. If your vehicle is
stationary, you can set the vehicle speed even with the brake pedal depressed.

■

To Set the Vehicle Speed

1

To Set the Vehicle Speed

You can switch the displayed set speed
measurements on the multi-information display or
audio/information screen between mph and km/h.

2

Speed/Distance Units

 P. 103

2

Customized Features

 P. 300

The vehicle stability assist

TM

 (VSA

®

) system, vehicle

stability assist

TM

 (VSA

®

) OFF, adaptive cruise control

(ACC) with low speed follow, and safety support
indicators may come on in amber along with a
message in the multi-information display when you
set the power mode to ON after reconnecting a
battery.
Drive a short distance at more than 12 mph (20
km/h).
Each indicator should go off. If any do not, have your
vehicle checked by a dealer.

On when ACC with Low

Speed Follow begins

Press down and release

RES/+

/

SET/−

 Switch

 (green) is on.

432

uu

AcuraWatch

TM

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

When ACC with Low Speed Follow starts
operating, the vehicle icon, interval bars and
set speed appear on the multi-information
display.

When you use ACC with Low Speed Follow,
Straight Driving Assist (a feature of the Electric
Power Steering system) is activated.
By enabling the steering system to
automatically compensate for natural steering
pull, Straight Driving Assist makes it easier for
you to keep your vehicle in a straight line.

Set Vehicle Speed

Set Vehicle Interval

 (green)

Continued

433

uu

AcuraWatch

TM

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

■

There is a vehicle ahead

ACC with Low Speed Follow monitors if a vehicle ahead of you enters the ACC with
Low Speed Follow range. If a vehicle is detected doing so, the ACC with Low Speed
Follow system maintains or decelerates your vehicle’s set speed in order to keep the
vehicle’s set following-interval from the vehicle ahead.

2

To Set or Change Following-interval

 P. 440

When a vehicle whose speed is slower than
your set speed is detected in front of you, your
vehicle starts to slow down.

■

When in Operation

1

When in Operation

If the vehicle detected ahead of you slows down
abruptly, or if another vehicle is detected cutting in
front of you, a beeper sounds and a message appears
on the multi-information display, and the head-up
warning lights

*

 come on.

Depress the brake pedal, and keep an appropriate
interval from the vehicle ahead.

Beep

Head-up

Warning

Lights

*

ACC with Low Speed Follow Range: 394 ft. (120 m)

A vehicle icon appears on the

multi-information display

* Not available on all models

uu

AcuraWatch

TM

u

Adaptive Cruise Control (ACC) with Low Speed Follow

434

Driving

■

There is no vehicle ahead

Your vehicle maintains the set speed without
having to keep your foot on the brake or
accelerator pedal.
If there previously was a vehicle detected
ahead that kept your vehicle from traveling at
the set speed, ACC with Low Speed Follow
accelerates your vehicle to the set speed, and
then maintains it.

■

When you depress the accelerator pedal

You can temporarily increase the vehicle speed. In this case, there is no audible or
visual alert even if a vehicle is in the ACC with Low Speed Follow range.
ACC with Low Speed Follow stays on unless you cancel it. Once you release the
accelerator pedal, the system resumes the set speed.
There are times when the vehicle speed will decrease when the accelerator pedal is
lightly applied.

A vehicle icon with dotted-line

contour appears on the multi-

information display

1

When in Operation

Even if the interval between your vehicle and the
vehicle detected ahead is short, ACC with Low Speed
Follow may start accelerating your vehicle under the
following circumstances:

•

The vehicle ahead of you is going at almost the
same speed as, or faster than, your vehicle.

•

A vehicle that cuts in front of you is going faster
than your vehicle, gradually increasing the interval
between the vehicles.

You can also set the system to beep when a vehicle in
front of you comes in and goes out of the ACC with
Low Speed Follow detecting range. Change the

ACC

Forward Vehicle Detect Beep

 setting.

2

Customized Features

 P. 300

Limitations

You may need to use the brake to maintain a safe
interval when using ACC with Low Speed Follow.
Additionally, ACC with Low Speed Follow may not
work properly under certain conditions.

2

ACC with Low Speed Follow Conditions
and Limitations

 P. 436

Continued

435

uu

AcuraWatch

TM

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

■

A vehicle detected ahead is within ACC with Low Speed Follow range and
slows to a stop

Your vehicle also stops, automatically. The

Stopped

 message appears on the multi-

information display.
When the vehicle ahead of you starts again,
the vehicle icon on the multi-information
display blinks. If you press the

RES/+

/

SET/–



switch up or down, or depress the accelerator
pedal, ACC with Low Speed Follow operates
again within the prior set speed.

If no vehicle is ahead of you before you
resume driving, depressing the accelerator
pedal will resume operation of ACC with Low
Speed Follow within the prior set speed.

1

A vehicle detected ahead is within ACC with Low Speed Follow
range and slows to a stop

3

WARNING

Exiting a vehicle that has been stopped
while the ACC with Low Speed Follow
system is operating can result in the vehicle
moving without operator control.

A vehicle that moves without operator
control can cause a crash, resulting in
serious injury or death.

Never exit a vehicle when the vehicle is
stopped by ACC with Low Speed Follow.

 (green)

 (green)

uu

AcuraWatch

TM

u

Adaptive Cruise Control (ACC) with Low Speed Follow

436

Driving

The system may automatically shut off and the

 indicator will come on under

certain conditions. Some examples of these conditions are listed below. Other
conditions may reduce some of the ACC functions.

2

Front Sensor Camera

 P. 480

2

Radar Sensor

 P. 482

■

Environmental conditions

Driving in bad weather (rain, fog, snow, etc.).

■

Roadway conditions

Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks, reflected
lights, road spray, high contrast).

■

Vehicle conditions

•

The outside of the windshield is blocked by dirt, mud, leaves, wet snow, etc.

•

An abnormal tire or wheel condition (Wrong sized, varied size or construction,
improperly inflated, compact spare tire

*

, etc.).

•

The camera temperature gets too high.

•

The parking brake is applied.

•

The front grille is dirty.

•

The vehicle is tilted due to a heavy load or suspension modifications.

•

Tire chains are installed.

■

ACC with Low Speed Follow Conditions and Limitations

1

ACC with Low Speed Follow Conditions and Limitations

If you need the radar sensor to be repaired, or
removed, or the radar sensor cover is strongly
impacted, turn off the system by pressing the



button and take your vehicle to a dealer.

Have your vehicle checked by a dealer if you find any
unusual behavior of the system (e.g., the warning
message appears too frequently).

* Not available on all models

Continued

437

uu

AcuraWatch

TM

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

■

Detection limitations

•

A vehicle suddenly crosses in front of you.

•

The interval between your vehicle and the vehicle ahead of you is too short.

•

A vehicle cuts in front of you at a slow speed, and it brakes suddenly.

•

You accelerate rapidly and approach the vehicle ahead of you at high speed.

•

The vehicle ahead of you is a motorcycle, bicycle, mobility scooter, or other small
vehicle.

•

There are animals in front of your vehicle.

•

You drive on a curved or winding or undulating road that makes it difficult for the
sensor to properly detect a vehicle in front of you.

•

The speed difference between your vehicle and a vehicle in front of you is
significantly large.

•

An oncoming vehicle suddenly comes in front of you.

•

Your vehicle abruptly crosses over in front of an oncoming vehicle.

1

ACC with Low Speed Follow Conditions and Limitations

If the front of the vehicle is impacted in any of the
following situations, the radar sensor may not work
properly. Have your vehicle checked by a dealer:

•

The vehicle mounted onto a bump, curb, chock,
embankment, etc.

•

You drive the vehicle where the water is deep.

•

Your vehicle has a frontal collision.

438

uu

AcuraWatch

TM

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

•

Driving through a metal bridge.

•

The vehicle ahead of you brakes suddenly.

•

The vehicle ahead of you has a unique shape.

•

Your vehicle or the vehicle ahead of you is driving on one edge of the lane.

Radar detects upper section

of an empty carrier truck.

Panel truck, tanker

truck, etc.

Continued

439

uu

AcuraWatch

TM

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

Increase or decrease the vehicle speed using the

RES/+

/

SET/–

 switch on the steering

wheel.

•

Each time you press the switch up or down, the vehicle speed is increased or
decreased by about 1 mph or 1 km/h accordingly.

•

If you keep the switch pressed up or down, the vehicle speed increases or
decreases by about 5 mph or 5 km/h accordingly.

■

To Adjust the Vehicle Speed

1

To Adjust the Vehicle Speed

If a vehicle detected ahead is going at a speed slower
than your increased set speed, ACC with Low Speed
Follow may not accelerate your vehicle. This is to
maintain the set interval between your vehicle and
the vehicle ahead.

You can switch the displayed set speed
measurements on the audio/information screen or
multi-information display between mph and km/h.

2

Speed/Distance Units

 P. 103

2

Customized Features

 P. 300

When you depress the accelerator pedal and then
push and release the

SET/–

 switch, the current speed

of the vehicle is set.

To increase speed

To decrease speed

440

uu

AcuraWatch

TM

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

Press the interval button to change the ACC
with Low Speed Follow following-interval.
Each time you press the button, the following-
interval (the interval behind a vehicle detected
ahead of you) setting cycles through short,
middle, long, and extra long following-
intervals.

Determine the most appropriate following-
interval setting based on your specific driving
conditions. Be sure to adhere to any
following-interval requirements set by local
regulation.

■

To Set or Change Following-interval

Interval Button

441

uu

AcuraWatch

TM

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Continued

Driving

The higher your vehicle’s following-speed is, the longer the short, middle, long or
extra long following-interval becomes. See the following examples for your
reference.

When your vehicle stops automatically because a vehicle detected ahead of you has
stopped, the interval between the two vehicles will vary based on the ACC with Low
Speed Follow interval setting.

Following-interval

When the Set Speed is:

50 mph (80 km/h)

65 mph (104 km/h)

Short

83 feet

25 meters

1.1 sec

100 feet

31 meters

1.1 sec

Middle

110 feet

33 meters

1.5 sec

137 feet

42 meters

1.5 sec

Long

154 feet

47 meters

2.1 sec

200 feet

61 meters

2.1 sec

Extra
Long

204 feet

62 meters

2.8 sec

265 feet

81 meters

2.8 sec

uu

AcuraWatch

TM

u

Adaptive Cruise Control (ACC) with Low Speed Follow

442

Driving

To cancel ACC with Low Speed Follow, do any
of the following:

•

Press the

CANCEL

 button.

u

The

 indicator (green) on the multi-

information display changes to the



indicator (white).

•

Press the

 button.

u

 indicator (green) goes off.

•

Depress the brake pedal while the vehicle is
moving forward.

u

The

 indicator (green) on the multi-

information display changes to the



indicator (white).

■

To Cancel

1

To Cancel

Resuming the prior set speed: After you have
canceled ACC with Low Speed Follow, you can
activate the ACC with Low Speed Follow with the
prior set speed displayed on the multi-information
display (in gray) by pressing the

RES/+

/

SET/–

 switch

up even if the vehicle is stopped.
When you turn the ACC with Low Speed Follow off
by pressing the

CANCEL

 button or depressing the

brake pedal, the prior set speed is displayed on the
multi-information display in gray.
When pressing the

RES/+

/

SET/–

 switch, the ACC

with Low Speed Follow is activated with displayed
speed.
Then, when the

 indicator (white) is displayed and

you press the

RES/+

/

SET/–

 switch during the prior

set speed (in gray) is not displayed, the current vehicle
speed is set as same as the condition of operating the

RES/+

/

SET/–

 switch.

CANCEL



Button

 Button

Continued

443

uu

AcuraWatch

TM

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

■

Automatic cancellation

The beeper sounds and a message appears on the multi-information display when
ACC with Low Speed Follow is automatically canceled. Any of these conditions may
cause the ACC with Low Speed Follow to automatically cancel:

•

Bad weather (rain, fog, snow, etc.)

•

When the radar sensor behind the emblem gets dirty.

•

The vehicle ahead of you cannot be detected.

•

An abnormal tire condition is detected, or the tires are skidding.

•

Driving on a mountainous road, or driving off road for extended periods.

•

Abrupt steering wheel movement.

•

When the ABS, VSA

®

 or CMBS

TM

 is activated.

•

When the ABS or VSA

®

 system indicator comes on.

•

When the vehicle is stopped on a very steep slope.

•

When you manually apply the parking brake.

•

When the detected vehicle within the ACC with Low Speed Follow range is too
close to your vehicle.

•

The camera behind the rearview mirror, or the area around the camera, including
the windshield, gets dirty.

•

When the Maximum Load Limit is exceeded.

•

The vehicle has repeatedly applied the brakes to maintain the set speed (for
example, you are descending a long slope).

The ACC with Low Speed Follow automatic cancellation can be also triggered by the
following causes. In these cases, the parking brake will be automatically applied.

•

The driver’s seat belt is unfastened when the vehicle is stationary.

•

The vehicle stops for more than 10 minutes.

•

The engine is turned off.

1

To Cancel

The set speed cannot be set or resumed when ACC
with Low Speed Follow has been turned off using the

 button. Press the

 button to activate the

system, then set the desired speed.

Adaptive Cruise Control (ACC)

with Low Speed Follow Indicator

(White)

Prior Set Speed (Gray)

uu

AcuraWatch

TM

u

Adaptive Cruise Control (ACC) with Low Speed Follow

444

Driving

Press and hold the interval button for one
second.

Cruise Mode Selected

 appears on

the multi-information display for two seconds,
and then the mode switches to Cruise.
The

 comes on.

•

Green: The system is on.

•

White: The system is standby.

To switch back to ACC with Low Speed
Follow, press and hold the interval button
again for one second.

■

When to use

Desired speed in a range above roughly 25 mph (40 km/h) ~.

Take your foot off the pedal and press the

RES/+

/

SET/–

 switch down when you

reach the desired speed.
The moment you release the

RES/+

/

SET/–

 switch, the set speed is fixed, and cruise

control begins. The indicator

 (green) comes on.

When you use cruise control, Straight Driving Assist (a feature of the Electric Power
Steering system) is activated.
By enabling the steering system to automatically compensate for natural steering
pull, Straight Driving Assist makes it easier for you to keep your vehicle in a straight
line.

■

To Switch ACC with Low Speed Follow to Cruise Control

1

To Switch ACC with Low Speed Follow to Cruise Control

Always be aware which mode you are in. When you
are driving in Cruise mode, the system will not assist
you to maintain a following-interval from a vehicle
ahead of you.

You can switch the displayed set speed
measurements on the audio/information screen or
multi-information display between mph and km/h.

2

Speed/Distance Units

 P. 103

2

Customized Features

 P. 300

ACC with

Low Speed

Follow ON

Cruise

Control ON

Press and hold the

interval button

 (white)

 (white)

Interval Button

■

To Set the Vehicle Speed
