321

Features

HomeLink

®

 Universal Transceiver

The HomeLink

®

 Universal Transceiver can be programmed to operate up to three

remote controlled devices around your home, such as garage doors, lighting, or
home security systems.

Refer to the safety information that came with your garage door opener to test that
the safety features are functioning properly. If you do not have the safety
information, contact the manufacturer.

Before programming HomeLink, make sure that people and objects are out of the
way of the garage or gate to prevent potential injury or damage.

When programming a garage door opener, park just outside the garage door’s
path.

■

Important Safety Precautions

1

HomeLink

®

 Universal Transceiver

Before programming HomeLink to operate a garage
door opener, confirm that the opener has an external
entrapment protection system, such as an “electronic
eye,” or other safety and reverse stop features. If it
does not, HomeLink may not be able to operate it.

322

uu

HomeLink

®

 Universal Transceiver

u

Training HomeLink

Features

Training HomeLink

If it is necessary to erase a previously entered
learned code:

•

Press and hold the two outside buttons for
about 20 seconds, until the red indicator
blinks. Release the buttons, and proceed to
step 1.

•

If you are training the second or third
button, go directly to step 1.

The instructions on the next page should work for most gate or garage openers, but
may not work for all. For detailed instructions about your specific remote opener,
visit

http://www.homelink.com

 or call (800) 355-3515.

Red Indicator

323

uu

HomeLink

®

 Universal Transceiver

u

Training HomeLink

Features

■

Training a Button

1

Training HomeLink

Retraining a Button
If you want to retrain a programmed button for a
new device, you do not have to erase all button
memory. You can replace the existing memory code
using this procedure:

1.

Press and hold the desired HomeLink button
until the HomeLink indicator begins to blink.

2.

Continue to hold the HomeLink button and
follow steps 1 - 3 under “Training a Button.”

Indicator remains on
for about 25 secs.

Standard transmitter

Indicator blinks rapidly for
2 secs, then remains on for
about 23 secs.

Rolling code transmitter

Erasing Codes
To erase all the codes, press and hold the two outside
buttons until the HomeLink indicator begins to blink
(about 10 to 20 secs). You should erase all codes
before selling the vehicle.

If you have any problems, see the device’s
instructions, visit

www.homelink.com

, or call

HomeLink at (800) 355-3515.

HomeLink

®

 is a registered trademark of Gentex

Corporation.

4.

a.

3.

2.

5.

a.

b.

1.

Position the remote transmitter you wish to link 1 to 3 inches (3 - 8 cm) from the
HomeLink button you want to program.

Press and hold the desired HomeLink button and the button on
the remote transmitter. Does the HomeLink indicator (LED)
blink after 10 secs?

Press and hold the
programmed HomeLink
button for about a sec.
Does the device (garage
door opener) work?

Press and hold the remote and the HomeLink
button at the same time. Then, while
continuing to hold the HomeLink button,
press and release the button on the remote
every 2 secs.
Does the LED blink within 20 secs?

Training
Complete

Press and hold the HomeLink button again.

Press and hold the HomeLink
button again.
The remote-controlled device
should operate.

Training Complete

The remote has a rolling code. Press the
“learn” button on the remote-controlled
device (e.g. garage door opener).

Within 30 secs, press and hold the
programmed HomeLink button for 2 secs.

HomeLink indicator blinks for 2 secs,

then remains on.

HomeLink LED

is on.

YES

NO

YES

YES

NO

NO

324

Features

Bluetooth

®

 HandsFreeLink

®

Bluetooth

®

 HandsFreeLink

®

 (HFL) allows you to place and receive phone calls using

your vehicle’s navigation system, without handling your cell phone.

Using HFL

 (Pick-up) button:

Press to go to the

Speed Dial

/

Call History

 on the multi-

information display or the head-up display, or to answer an incoming call.

 (Hang-up/back) button:

Press to end a call, to cancel a command or to

clear the phone information on the multi-information display or the head-up display.

 (Talk) button:

Press to give HFL voice commands.

PHONE button:

Press to go directly to the Phone screen.

Interface dial:

Rotate

 to select an item on the screen, then press

. Move

,

,

 or

 to select secondary menu.

■

HFL Buttons

1

Bluetooth

®

 HandsFreeLink

®

Place your phone where you can get good reception.

To use HFL, you need a

Bluetooth

-compatible cell

phone. For a list of compatible phones, pairing
procedures, and special feature capabilities:

•

U.S.: Visit

www.Handsfreelink.com/Acura

, or call

1-888-528-7876.

•

Canada: For more information on smartphone
compatibility, call 1-888-528-7876.

To use HFL, the

Bluetooth

 setting must be

On

.

2

Customized Features

 P. 295

Voice control tips:

•

Aim the vents away from the ceiling and close the
windows, as noise coming from them may interfere
with the microphone.

•

Press and release the

 button when you want to

call a number using a stored voice tag, a
phonebook name, or a number. Speak clearly and
naturally after a beep.

•

If the microphone picks up voices other than yours,
the command may be misinterpreted.

•

To change the volume level, use the audio system’s
volume knob or the remote audio controls on the
steering wheel.

State or local laws may prohibit the operation of
handheld electronic devices while operating a
vehicle.

Talk Button

Volume up

Microphone

Hang-up/Back Button

Pick-up
Button

Volume down

Interface
Dial

PHONE



Button

325

uu

Bluetooth

®

 HandsFreeLink

®

u

Using HFL

Features

The audio/information screen notifies you when there is an incoming call.

Certain manual functions are disabled or
inoperable while the vehicle is in motion.
You cannot select a grayed-out option until
the vehicle is stopped.

Only previously stored speed dial entries with
voice tags, phonebook names, or numbers
can be called using voice commands while the
vehicle is in motion.

2

Speed Dial

 P. 341

■

HFL Status Display

1

Bluetooth

®

 HandsFreeLink

®

Bluetooth

®

 Wireless Technology

The

Bluetooth

®

 word mark and logos are registered

trademarks owned by Bluetooth SIG, Inc., and any
use of such marks by Honda Motor Co., Ltd., is under
license. Other trademarks and trade names are those
of their respective owners.

HFL Limitations
An incoming call on HFL will interrupt the audio
system when it is playing. It will resume when the call
is ended.

If you receive a call while using the audio system, the
system resumes its operation an after ending the call.

1

HFL Status Display

The information that appears on the audio/
information screen varies between phone models.

You can change the system language.

2

Customized Features

 P. 295

■

Limitations for Manual Operation

Bluetooth

®

 Indicator

Comes on when your phone
is connected to HFL.

Signal Strength

HFL Mode

Battery Level
Status

Roam Status

Caller’s Name

Caller’s Number

Disabled Option

326

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

HFL Menus

The power mode must be in ACCESSORY or ON to use HFL.

■

Phone Settings screen

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Phone Settings

, then

press .

1

HFL Menus

To use HFL, you must first pair your

Bluetooth

-

compatible cell phone to the system while the vehicle
is parked.

Some functions are limited while driving. A message
appears on the screen when the vehicle is moving
and the operation is canceled.

Edit the user name of a paired phone.

Phone

Edit Device

Name

Connect

Phone

*1

Bluetooth

Device List



(Existing

entry list)

*1



Replace This

Device

Add Bluetooth

Device

Disconnect a paired phone from the system.

Connect a phone to the system.

*1: Appears when a phone has already been paired to HFL.

Disconnect



(Existing entry list)





Pair a phone to the system.

Edit PIN



Create a security PIN for a paired phone.

Replace a previously paired phone with a
new phone.

Delete This

Device

Delete a previously paired phone.









Add Bluetooth

Device

Pair a phone to the system.



327

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Continued

Features

Select a text/e-mail message account.

Text/Email

*1

Manual Input

Edit Speed

Dial

*1

New Entry



Import from

Call History

*1: Appears only when a phone is connected to HFL.







Import from

Phonebook







Delete All

Delete all the previously stored speed dial numbers.

Select a phone number from the call
history to store as a speed dial number.
Select a phone number from the
phonebook to store as a speed dial number.

Enter a phone number to store as a speed
dial number.



Edit



Delete



(Existing

entry list)

Edit a previously stored speed dial number.

●

Change a number.

●

Create or delete a voice tag.

Delete a previously stored speed dial number.



Set calls to automatically transfer from your phone to HFL when you enter the
vehicle.

Auto Transfer

Auto Answer

Ring Tone

Set whether to automatically answer an incoming call after about four
seconds.
Select the ring tone.

Use Contact Photo

Set phonebook data to be automatically imported when a phone is paired to
HFL.
Display a caller’s picture on an incoming call screen.

Automatic Phone Sync

*1









Select Account



Enable Text/Email

Turn the text/e-mail message function on and off.

New Text/Email Alert

Select whether a pop-up alert comes on the screen when HFL receives a new
text/e-mail message.



Cancel/Reset all customized items in the

Phone Settings

 group as default.

Default



328

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

■

Phone screen

1.

Press the

PHONE

 button.

2.

Press the

MENU

 button to display the

menu items.

Select a phone number from the call history to store as a
speed dial number.

Speed Dial

*1

Manual Input

New Entry



Import from

Call History

Import from

Phonebook

Select a phone number from the phonebook to store as a
speed dial number.

Enter a phone number to store as a speed dial number.

More Speed Dials

Display another paired phone’s speed dial list.

*1: Appears only when a phone is connected to HFL.

(Existing entry list)

Dial the selected number in the speed dial list.











Phonebook

*1

Dial

*1

Display the paired phone’s phonebook.

Enter a phone number to dial.

329

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Continued

Features

Text/Email

*1

Message is

read aloud.

See the previous message.

(Read/Stop)

Previous

Next

See the next message.

System reads received message aloud, or stop message
from being read.

Reply

Call

Reply to a received message using one of six fixed phrases.

Make a call to the sender.

Select Account

Select a message
and press

.

Select a mail or text message account.

Redial

*1

Redial the last number dialed in the phone’s history.

Display the last 20 outgoing, incoming and missed calls.

Call History

*1

All

Dialed

Received

Display the last 20 outgoing calls.
Display the last 20 incoming calls.

Missed

Display the last 20 missed calls.

Roadside Assistance

*1

Makes a call to the number for the Roadside Assistance service.

*1: Appears only when a phone is connected to HFL.

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

330

Features

■

To pair a cell phone (when there is no
phone paired to the system)

1.

Press the

PHONE

 button.

2.

Rotate

 to select

Yes

, then press

.

3.

Make sure your phone is search or
discoverable mode, then press

.

u

HFL automatically searches for a

Bluetooth

 device.

4.

When your phone appears on the list, select
it by pressing

.

u

If your phone does not appear, you can
select

Refresh

 to search again.

u

If your phone still does not appear, move

 to select

Device Not Found?

 and

search for

Bluetooth

 devices using your

phone. From your phone, select

HandsFreeLink

.

5.

HFL gives you a pairing code on the audio/
information screen.

u

Confirm if the pairing code on the screen
and your phone match.
This may vary by phone.

6.

You will receive a notification on the screen
if pairing is successful.

■

Phone Setup

1

Phone Setup

Your

Bluetooth

-compatible phone must be paired to

HFL before you can make and receive hands-free
calls.

Phone Pairing Tips:

•

You cannot pair your phone while the vehicle is
moving.

•

Up to six phones can be paired.

•

Your phone’s battery may drain faster when it is
connected to HFL.

•

If your phone is not ready for pairing or not found
by the system within three minutes, the system will
time out and returns to idle.

Once you have paired a phone, you can see it
displayed on the screen with one or two icons on the
right side.
These icons indicate the following:

: The phone can be used with HFL.
: The phone is compatible with

Bluetooth

®

 Audio.

When pairing is completed, an

Automatic Phone

Sync

 prompt appears. Select

On

 if you want your call

history and phonebook automatically imported to
HFL.

2

Changing the Automatic Phone Sync
setting

 P. 340

331

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Continued

Features

■

To pair a cell phone (when a phone has
already been paired to the system)

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Phone Settings

, then

press .

3.

Move

or

to

select

the

Phone

 tab.

4.

Rotate

 to select the

Connect Phone

,

then press

.

u

Repeat the procedure to select

Add

Bluetooth Device

.

5.

Make sure your phone is in search or
discoverable mode, then press

.

u

HFL automatically searches for a

Bluetooth

 device.

6.

When your phone appears on the list, select
it by pressing

.

u

If your phone does not appear, you can
select

Refresh

 to search again.

u

If your phone still does not appear, move

 to select

Device Not Found?

 and

search for

Bluetooth

 devices using your

phone. From your phone, select

HandsFreeLink

.

7.

HFL gives you a pairing code on the audio/
information screen.

u

Confirm if the pairing code on the screen
and your phone match.
This may vary by phone.

8.

You will receive a notification on the screen
if pairing is successful.

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

332

Features

■

To change the pairing code setting

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

System Settings

, then

press .

3.

Move

 or

 to select the

Bluetooth

 tab.

4.

Rotate

 to select

Edit Pairing Code

,

then press

.

5.

Rotate

 to select

Fixed

 or

Random

,

then press

.

1

To change the pairing code setting

The pairing code may be six or four digits depending
on your phone.

The default pairing code is

0000

 until you change the

setting.
To create your own, select

Fixed

, and delete the

current code, then enter a new one.

For a randomly generated pairing code each time you
pair a phone, select

Random

.

Continued

333

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

■

To replace an already-paired phone
with a new phone

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Phone Settings

, then

press .

3.

Move

 or

 to select the

Phone

 tab.

4.

Rotate

 to select

Bluetooth Device List

,

then press

.

5.

Rotate

 to select a paired phone you

want to replace, then press

.

6.

Rotate

 to select

Replace This Device

,

then press

.

7.

HFL enters the pairing process and searches
for a new phone.

u

Follow the prompts to pair a new phone.

8.

You will receive a notification on the screen
if pairing is successful.

1

To replace an already-paired phone with a new phone

The replaced phone will keep the same speed dial
entries, and security PIN information from the
previously paired phone.

334

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

■

To delete a paired phone

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Phone Settings

, then

press .

u

Repeat the procedure to select

Bluetooth Device List

.

3.

Move

 or

 to select the

Phone

 tab.

4.

Rotate

to

select

Bluetooth Device List

,

then press

.

5.

Rotate

 to select a phone you want to

delete, then press

.

6.

Rotate

 to select

Delete This Device

,

then press

.

7.

You will receive a confirmation message on
the screen. Rotate

 to select

Yes

, then

press .

8.

You will receive a notification on the screen
if it is successful.

Continued

335

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

■

To turn on or off the text/e-mail
message function

1.

Press the

SETTINGS

 button.

2.

Rotate

to

select

Phone Settings

, then

press .

3.

Move

 or

 to select the

Text/Email



tab.

4.

Rotate

to

select

Enable Text/Email

,

then press

.

u

A pop-up menu appears on the screen.

5.

Rotate

to

select

On

 or

Off

, then press

.

■

To turn on or off the text/e-mail
message notice

1.

Press the

SETTINGS

 button.

2.

Rotate

to

select

Phone Settings

, then

press .

3.

Move

 or

 to select the

Text/Email



tab.

4.

Rotate

to

select

New Text/Email

Alert

, then press

.

u

A pop-up menu appears on the screen.

5.

Rotate

to

select

On

 or

Off

, then press

.

■

To Set Up a Text/E-mail Message Option

1

To Set Up a Text/E-mail Message Option

To use the text/E-mail message function, you need a

Bluetooth

-compatible cell phone. For a list of

compatible phones, pairing procedures, and special
feature capabilities:

•

U.S.: Visit

www.Handsfreelink.com/Acura

, or call

1-888-528-7876.

•

Canada: For more information on smartphone
compatibility, call 1-888-528-7876.

1

To turn on or off the text/e-mail message notice

On

: A pop-up notification comes on every time you

receive a new message.

Off

: The message you receive is stored in the system

without notification.

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

336

Features

You can protect each of the six cell phones with a security PIN.

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Phone Settings

, then

press .

3.

Move

 or

 to select the

Phone

 tab.

4.

Rotate

to

select

Bluetooth Device List

,

then press

.

5.

Rotate

 to select a phone you want to

add a security PIN to, then press

.

6.

Rotate

 to select

Edit PIN

, then press

.

7.

Enter a new four-digit number.

u

Rotate

 to select, then press

.

Move

 to delete. Rotate

 to select

OK

 to enter the security PIN.

u

You can also enter a number using the
icons.

8.

Re-enter the four-digit number.

u

The screen returns to the screen in step
4.

■

To Create a Security PIN

1

To Create a Security PIN

If the phone is already security PIN protected, you
need to enter the current security PIN before clearing
the PIN or creating a new one.

Audio/information screen

On Demand Multi-Use Display

TM

Audio/information screen

On Demand Multi-Use Display

TM
