Operating the Switches Around the Steering Wheel

u

Light Switches

Continued

Co
ntrols

Light Switches

Rotating the light switch turns the lights on
and off, regardless of the power mode
setting.

■

High beams

Push the lever forward until you hear a click.

■

Low beams

When in high beams, pull the lever back to
return to low beams.

■

Flashing the high beams

Pull the lever back, and release it.

■

Lights off

Turn the lever to

OFF

 either when:

•

The transmission is in

(

P

.

•

The parking brake is applied.

To turn the lights on again, turn the lever to

OFF

 to cancel the lights off mode. Even if you

do not cancel the lights off mode, the lights
come on automatically when:

•

The transmission is taken out of

(

P

 and the

parking brake is released.

•

The vehicle starts to move.

■

Manual Operation

1

Light Switches

If you leave the power mode in VEHICLE OFF (LOCK)
while the lights are on, a chime sounds when the
driver’s door is opened.

When the lights are on, the lights on indicator in the
instrument panel will be on.

2

Lights On Indicator

 P. 96

Do not leave the lights on when the power system is
off because it will cause the 12-volt battery to
discharge.

If you sense that the level of the headlights is
abnormal, have the vehicle inspected by a dealer.

Your vehicle is equipped with the automatic
headlight adjusting system that automatically adjusts
the vertical angle of the high/low beam headlights. If
you find a significant change in the vertical angle of
the headlights, there may be a problem with the
system. Have your vehicle checked by a dealer.

Models without automatic headlight adjusting system

Models with automatic headlight adjusting system

High Beams

Flashing the high beams

Low Beams

Turns on parking, side marker,
tail, and rear license plate lights

Turns on headlights, parking,
side marker, tail, and rear
license plate lights

uu

Operating the Switches Around the Steering Wheel

u

Light Switches

176

Co
ntrols

Automatic lighting control can be used when
the power mode is in ON.

When the light switch is in

AUTO

, the

headlights and other exterior lights will switch
on and off automatically depending on the
ambient brightness.

The headlights come on when you unlock a
door in dark areas with the headlight switch in

AUTO

.

u

Once you lock the door, the headlights
will go off.

■

Automatic Operation (automatic lighting control)

1

Automatic Operation (automatic lighting control)

We recommend that you turn on the lights manually
when driving at night, in a dense fog, or in dark areas
such as long tunnels or parking facilities.

The light sensor is in the location shown below.

You can adjust the auto light sensitivity as follows:

2

Customized Features

 P. 131, 362

Setting

The exterior lights come on

when the ambient light is at

Max

High

Mid

Low

Min

Light Sensor

U.S. models

Bright

Dark

177

uu

Operating the Switches Around the Steering Wheel

u

Light Switches

Co
ntrols

The headlights automatically come on when the wipers are used several times within
a certain number of intervals with the headlight switch in

AUTO

.

The headlights automatically go off a few minutes later if the wipers are stopped.

The headlights, all other exterior lights, and the instrument panel lights turn off 15
seconds after you set the power mode to VEHICLE OFF (LOCK), take the remote with
you, and close the driver’s door.

If you set the power mode to VEHICLE OFF (LOCK) with the headlight switch on, but
do not open the door, the lights turn off after 10 minutes (3 minutes, if the switch
is in the

AUTO

 position).

The lights turn on again when you unlock or open the driver’s door. If you unlock
the door, but do not open it within 15 seconds, the lights go off. If you open the
driver’s door, you will hear a lights on reminder chime.

■

Headlight Integration with Wiper

■

Automatic Lighting Off Feature

1

Headlight Integration with Wiper

This feature activates while the headlights are off in

AUTO

.

The instrument panel brightness does not change
when the headlights come on.

At dark ambient light levels, the automatic lighting
control feature turns on the headlights, regardless of
the number of wiper sweeps.

1

Automatic Lighting Off Feature

You can change the headlight auto off timer setting.

2

Customized Features

 P. 131, 362

178

uu

Operating the Switches Around the Steering Wheel

u

Fog Lights

*

Co
ntrols

Fog Lights

*

When the low beam headlights are on, turn
the fog light switch on to use the fog lights.

Daytime Running Lights

The daytime running lights come on when the following conditions have been met:

•

The power mode is in ON.

•

The headlight switch is in

AUTO

 or

.

•

The parking brake is released.

The lights remain on even if you set the parking brake. Setting the power mode to
VEHICLE OFF (LOCK) will turn off the daytime running lights.

The daytime running lights are off once the headlight switch is turned on, or when
the head light switch is in

AUTO

 and it is getting darker outside.

Fog Light Switch

* Not available on all models

179

uu

Operating the Switches Around the Steering Wheel

u

Auto High-Beam

Continued

Co
ntrols

Auto High-Beam

The front sensor camera detects the light sources ahead of the vehicle such as the
lights of a preceding or oncoming vehicle, or street lights. When you are driving at
night, the system automatically switches the headlights between low beam and high
beam depending on the situation.

When all of the following conditions have been met, the auto high-beam indicator
comes on and the auto high-beam is activated.

•

The power mode is in ON.

•

The light switch is in

AUTO

.

•

The lever is in the low beam position.

•

The headlights have been automatically
activated.

•

It is dark outside the vehicle.

If the auto high-beam indicator does not come on even when all the conditions have
been met, carry out the following procedure and the indicator will come on.

•

Pull the lever toward you for flashing the high beams then release it while driving.

1

Auto High-Beam

The auto high-beam system does not always operate
in every situation. This system is just for assisting the
driver. Always observe your surroundings and switch
the headlights between high beam and low beam
manually if necessary.

If you find the timing of beam changes inconvenient
for driving, change the headlight beams manually.

The range and the distance at which the camera can
recognize varies depending on conditions
surrounding your vehicle.

Regarding the handling of the camera mounted to
the inside of the windshield, refer to the following.

2

Front Sensor Camera

 P. 475

For the auto high-beam to work properly:

•

Do not place an object that reflects light on the
dashboard.

•

Keep the windshield around the camera clean.

•

When cleaning the windshield, be careful not to
apply the windshield cleanser to the camera lens.

•

Do not attach an object, sticker or film to the area
around the camera.

•

Do not touch the camera lens.

If the camera receives a strong impact, or repairing of
the area near the camera is required, consult a dealer.

■

How to Use the Auto High-Beam

Front Sensor Camera

Light Switch

Auto High-Beam

Indicator

uu

Operating the Switches Around the Steering Wheel

u

Auto High-Beam

180

Co
ntrols

■

Automatic switching between high-beam and low-beam

When auto-high beam is active, the headlights switch between high beam and low
beam based on the following conditions.

■

Manual switching between high-beam and low-beam

If you want to manually switch the headlights between high beam and low beam,
follow either of the procedures below. Note that when you do this, the auto high-
beam indicator will turn off and the auto high-beam will be deactivated.

Using the lever:

Pull the lever toward you for flashing the high beams then release it within about
one second while driving.

u

To reactivate the auto high-beam, pull the lever toward you for flashing the
high beams then release it while driving. The auto high-beam indicator will
come on.

Using the light switch:

Turn the light switch to

.

u

To reactivate the auto high-beam, turn the light switch to

AUTO

 when the

lever is in the low beam position, the auto high-beam indicator will come on.

Switching to high beam:

Switching to low beam:

All of the following conditions must
be met before the high beams turn
on.

●

Your vehicle speed is 45 mph (72
km/h) or more.

●

There are no preceding or
oncoming vehicle with headlights
or taillights turned on.

●

There are few street lights on the
road ahead.

One of the following conditions
must be met before the low beams
turn on.

●

Your vehicle speed is 30 mph (48
km/h) or less.

●

There is a preceding or oncoming
vehicle with headlights or
taillights turned on.

●

There are many street lights on
the road ahead.

1

How to Use the Auto High-Beam

In the following cases, the auto high-beam system
may not switch the headlights properly or the
switching timing may be changed. In case of the
automatic switching operation does not fit for your
driving habits, please switch the headlights manually.

•

The brightness of the lights from the preceding or
oncoming vehicle is intense or poor.

•

Visibility is poor due to the weather (rain, snow,
fog, windshield frost, etc.).

•

Surrounding light sources, such as street lights,
electric billboards and traffic lights are illuminating
the road ahead.

•

The brightness level of the road ahead constantly
changes.

•

The road is bumpy or has many curves.

•

A vehicle suddenly appears in front of you, or a
vehicle in front of you is not in the preceding or
oncoming direction.

•

Your vehicle is tilted with a heavy load in the rear.

•

A traffic sign, mirror, or other reflective object
ahead is reflecting strong light toward the vehicle.

•

The oncoming vehicle frequently disappears under
roadside trees or behind median barriers.

•

The preceding or oncoming vehicle is a motorcycle,
bicycle, mobility scooter, or other small vehicle.

The auto high-beam system keeps the headlight low
beam when:

•

Windshield wipers are operating.

•

The camera has been detected a dense fog.

181

uu

Operating the Switches Around the Steering Wheel

u

Auto High-Beam

Co
ntrols

You can turn the auto high-beam system off. If you want to turn the system off or
on, set the power mode to ON, then carry out the following procedures while the
vehicle is stationary.

To turn the system off:

With the light switch is in

AUTO

, pull the lever

toward you and hold it for at least 40 seconds.
After the auto high-beam indicator light blinks
twice, release the lever.

To turn the system on:

With the light switch is in

AUTO

, pull the lever

toward you and hold it for at least 30 seconds.
After the auto high-beam indicator light blinks
once, release the lever.

■

How to Turn Off the Auto High-Beam

1

How to Use the Auto High-Beam

If the

Some Driver Assist Systems Cannot

Operate: Camera Temperature Too High

 message

appears:

•

Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the airflow directed toward the camera.

•

Start driving the vehicle to lower the windshield
temperature, which cools down the area around
the camera.

If the

Some Driver Assist Systems Cannot

Operate: Clean Front Windshield

 message

appears:

•

Park your vehicle in a safe place, and clean the
windshield. If the message does not disappear after
you have cleaned the windshield and driven for a
while, have your vehicle checked by a dealer.

1

How to Turn Off the Auto High-Beam

If you turn the auto high-beam system off, the system
does not operate until you turn the system on.

Park in a safe place before turning the system off or
on.

AUTO

 Position

182

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

Co
ntrols

Wipers and Washers

The windshield wipers and washers can be
used when the power mode is in ON.

■

MIST

The wipers run at high speed until you release
the lever.

■

Wiper switch (OFF, AUTO, LO, HI)

Move the lever up or down to change the
wiper settings.

■

Washer

Sprays while you pull the lever toward you.
When you release the lever for more than one
second, the spray stops, the wipers sweep two
or three more times to clear the windshield,
then stop.

■

Windshield Wipers/Washers

1

Wipers and Washers

NOTICE

Do not use the wipers when the windshield is dry.
The windshield will get scratched, or the rubber
blades will get damaged.

NOTICE

Turn the washers off if no washer fluid comes out.
The pump may get damaged.

The wiper motor may stop motor operation
temporarily to prevent an overload. Wiper operation
will return to normal within a few minutes, once the
circuit has returned to normal.

NOTICE

In cold weather, the blades may freeze to the
windshield.
Operating the wipers in this condition may damage
the wipers. Use the defroster or heated windshield

*



to warm the windshield, then turn the wipers on.

If the wipers stop operating due to an obstacle such
as the build-up of snow, park the vehicle in a safe
place.

Rotate the wiper switch to

OFF

, and set the power

mode to ACCESSORY or VEHICLE OFF (LOCK), then
remove the obstacle.

MIST

AUTO

OFF

LO

: Low speed wipe

HI

: High speed wipe

Pull to

use

washer.

* Not available on all models

Continued

183

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

Co
ntrols

When you push the lever down to

AUTO

, the

windshield wipers sweep once, and go into
the automatic mode.

The wipers operate intermittently, at low
speed, or at high speed and stops in
accordance with the amount of rainfall the
rainfall sensor detects.

■

Auto sensitivity adjustment

When the wiper function is set to

AUTO

, you

can adjust the sensitivity of the rainfall sensor
(using the adjustment ring) so that wipers will
operate in accordance with your preference.

Sensor sensitivity

■

Automatic Intermittent Wipers

1

Automatic Intermittent Wipers

The rainfall sensor is in the location shown below.

NOTICE

AUTO

 should always be turned

OFF

 before the

following situations in order to prevent severe
damage to the wiper system:

•

Cleaning the windshield

•

Driving through a car wash

•

No rain present

Rainfall Sensor

Adjustment Ring

Low sensitivity

High sensitivity

184

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

Co
ntrols

The rear wiper and washer can be used when
the power mode is in ON.

■

Wiper switch (OFF, INT, ON)

Change the wiper switch setting according to
the amount of rain.

■

Washer (

)

Sprays on the rear window while you rotate
the switch to this position.
Hold it to activate the rear wiper and to spray
the washer. Once released, the washer spray
will stop and the rear wiper will return to its
selected switch setting after a few sweeps.

■

Operating in reverse

When you select the transmission to

(

R

 with the windshield wipers activated, the

rear wiper operates automatically as follows even if its switch is off.

■

Rear Wiper/Washer

INT

: Intermittent

OFF

ON

: Continuous wipe

Washer

Windshield Wiper Operation

Rear Wiper Operation

Intermittent

Intermittent

Low speed wipe

High speed wipe

Continuous

185

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

Co
ntrols

Turn the headlights on and press the
headlight washer button to operate.
The headlight washers also operate when you
turn the windshield washers for the first time
after the power mode is set to ON.

■

Headlight Washers

Canadian models

1

Headlight Washers

The headlight washers use the same fluid reservoir as
the windshield washers.

186

uu

Operating the Switches Around the Steering Wheel

u

Brightness Control

Co
ntrols

Brightness Control

When the power mode is in ON, you can use
the

(

+

 or

(

-

 button to adjust instrument

panel brightness.

Brighten:

Press the

(

+

 button.

Dim:

Press the

(

-

 button.

You will hear a beep when the brightness
reaches minimum or maximum. Several
seconds after adjusting the brightness, you
will be returned to the previous display.

■

Brightness level indicator

The brightness level is shown on the MID
while you are adjusting it.

1

Brightness Control

The brightness of the instrument panel will be
reduced when the following conditions:

•

The power mode is in ON.

•

The light switch is in any position other than

OFF



and it is dark outside.

To cancel the reduced instrument panel brightness
when the exterior lights are on, press the

(

+

 button

until the brightness display is up to max, the beeper
sounds.

The brightness can be set differently for when the
exterior lights are on, and when they are off.

(

+

 Button

(

-

 Button

187

uu

Operating the Switches Around the Steering Wheel

u

Rear Defogger/Heated Door Mirror Button

Co
ntrols

Rear Defogger/Heated Door Mirror Button

Press the rear defogger and heated door mirror button to defog the rear window
and mirrors when the power mode is in ON.

The rear defogger and heated door mirrors
automatically switch off after 10-30 minutes
depending on the outside temperature.

Heated Windshield Button

*

Press the heated windshield button to deice
the windshield at the wiper park area and
along the driver side edge of the windshield
when the power mode is in ON.
The heated windshield will automatically
switch off after 15 minutes.

1

Rear Defogger/Heated Door Mirror Button

This system consumes a lot of power, so turn it off
when the window has been defogged. Also, do not
use the system for a long time while the power
system is stopped. This may weaken the 12-volt
battery, making it difficult to turn the power system
on.

When the power mode is set to ON and the outside
temperature is below 41°F (5°C), the heated door
mirror may automatically activate for 10 minutes.

1

Heated Windshield Button

*

This system consumes a lot of power, so turn it off
when the window has been deiced. Also, do not use
the system for a long period when the power system
is stopped. This may weaken the 12-volt battery,
making it difficult to turn the power system on.

When the power mode is set to ON and the outside
temperature is below 39°F (4°C), the heated
windshield may automatically activate for up to 15
minutes.

* Not available on all models

188

uu

Operating the Switches Around the Steering Wheel

u

Driving Position Memory System

Co
ntrols

Driving Position Memory System

You can store two driver’s seat (except for power lumbar), steering wheel and door
mirror positions with the driving position memory system.
When you unlock and open the driver’s door with a remote transmitter, or keyless
access system, door mirrors adjust to one of the two preset positions and the seat
adjusts to retracted positions of one of the two preset positions automatically.

The steering wheel and the seat will move to the stored position when you set the
power mode to ACCESSORY.

When you enter the vehicle, the MID briefly shows you which remote transmitter
you used to unlock the vehicle.

•

DRIVER 1

 transmitter is linked to memory button 1.

•

DRIVER 2

 transmitter is linked to memory button 2.

The driver’s seat moves rearward and steering
wheel fully up depending on the set seating
position once you

•

Stop the vehicle.

•

Put the transmission in

(

P

.

•

Turn the power system off.

•

Then open the driver’s door.

Once the power mode is in the ACCESSORY
position, the driver’s seat and steering wheel
moves to the

DRIVER 1

 or

2

 preset position.

1

Driving Position Memory System

Using the information screen or MID, you can disable
the automatic seat, steering wheel and door mirrors
adjustment function.

2

Customized Features

 P. 131, 362

The driver’s seat easy exit feature can be turned ON/
OFF.

2

Customized Features

 P. 131, 362

System Operation

The system will not operate if:

•

The vehicle speed is above 3 mph (5 km/h).

•

Either memory position button is pressed while the
seat or steering wheel is in motion.

•

The seat or steering wheel position is adjusted
while in operation.

•

The memory 1 or 2 position is set fully to the rear.

DRIVER 1

DRIVER 2

189

uu

Operating the Switches Around the Steering Wheel

u

Driving Position Memory System

Co
ntrols

1.

Set the power mode to ON. Adjust the
driver’s seat, the steering wheel and the
door mirrors to the desired position.

2.

Press the

SET

 button.

u

You will hear the beeper, and the
memory button indicator light will blink.

3.

Press and hold memory button

(

1

 or

(

2



within five seconds of pressing the

SET



button.

u

Once the seat, the steering wheel and
the outside mirror positions have been
memorized, the indicator light on the
button you pressed stays on and you will
hear the double-beep.

1.

Put the transmission into

(

P

.

2.

Apply the parking brake.

3.

Press a memory button (

(

1

 or

(

2

).

u

You will hear the beeper, and the
indicator light will blink.

The seat, the steering wheel and the door
mirrors will automatically move to the
memorized positions. When it has finished
moving, you will hear the beeper, and the
indicator light stays on.

■

Storing a Position in Memory

1

Storing a Position in Memory

After you press the

SET

 button, the storing operation

will be canceled when:

•

You do not press the memory button within five
seconds.

•

You readjust the seat, the steering wheel or the
outside mirror position before the double-beep.

•

You set the power mode to any position except
ON.

Memory Button 1

Memory Button 2

SET

 Button

■

Recalling the Stored Position

1

Recalling the Stored Position

The seat, the steering wheel and the door mirrors will
stop moving if you:

•

Press the

SET

 button or memory button

(

1

 or

(

2

.

•

Adjust the seat position, door mirrors, or steering
wheel.

•

Put the transmission into a position other than

(

P

.

Memory Buttons

190

uu

Operating the Switches Around the Steering Wheel

u

Adjusting the Steering Wheel

Co
ntrols

Adjusting the Steering Wheel

The steering wheel height and distance from your body can be adjusted so that you
can comfortably grip the steering wheel in an appropriate driving posture.

Push and hold the adjustment switch to move
the steering wheel in, out, up or down.

u

Make sure you can see the instrument
panel gauges and indicators.

1

Adjusting the Steering Wheel

3

WARNING

Adjusting the steering wheel position while
driving may cause you to lose control of the
vehicle and be seriously injured in a crash.

Adjust the steering wheel only when the
vehicle is stopped.

Adjustment Switch
