12

Quick

 Referenc

e Guide

Energy Efficiency

As with a gasoline-powered vehicle, hybrid vehicle fuel efficiency and driving range is most impacted by your driving style. Aggressive
acceleration and high-speed driving can easily trigger the system to switch the propulsion source to the gasoline-powered engine.
In addition, heavy climate control system use negatively affects vehicle range and efficiency. Either of these use patterns will more quickly
reduce the High Voltage battery's state of charge.

Battery Types

There are two types of batteries used in this vehicle: a standard 12-volt battery that powers the airbags, the interior and exterior lights, and
other standard 12-volt systems; and a high voltage battery that is used to power the propulsion motors and recharge the 12-volt battery.

Regenerative Energy and Regenerative Braking

When decelerating without the accelerator being depressed or the brake pedal being applied, or while driving downhill, the electric motors
act as generators that recover a portion of the electrical energy that was used to accelerate the vehicle. This regenerative braking slows the
vehicle in a manner similar to engine braking in a gasoline-powered vehicle.
When the high voltage battery is fully charged or its condition is affected by extreme temperatures or other factors, regenerative braking
may not work.

13

Quick

 Referenc

e Guide

Auto Engine Stop/Start

Your vehicle’s gasoline engine will automatically stop and start during vehicle operation as needed to meet driving and battery conditions.
These are some examples that could cause the gasoline engine to automatically start.

In the following cases, however, Auto Engine Stop may not activate.

●

When the Integrated Dynamics System is in SPORT+ mode.

●

The vehicle momentarily needs additional power for aggressive acceleration, driving uphill, or driving at high speeds.

●

The climate control system is in heavy use.

●

The High Voltage battery temperature is high or low.

●

The High Voltage battery state of charge is low.

●

When the gear position is in

(

S

 or

(

R

.

Sounds Unique to the SPORT HYBRID SH-AWD

®

 System

When you first start driving this vehicle, you will likely hear some unfamiliar sounds, particularly when you turn on the power system, or
while you are driving or accelerating from a stop. Some of these sounds are unique to this vehicle‘s powertrain, fuel, and climate control
systems; others are similar to sounds generated by conventional automobiles that typically are masked by louder noises absent from a
vehicle of this design.
These sounds are not a cause for concern, and you will soon recognize them as normal and thus be able to detect any new or unusual noise
should one develop.

14

Quick

 Referenc

e Guide

Safety Precautions

Do not touch the High Voltage system

Attempting to take a High Voltage system component apart or disconnect one of its wires
can cause severe electrical shock. Make sure that any maintenance or repairs to the High
Voltage system is performed by an Acura dealer.

If a crash occurs

●

Be careful of electric shock hazard.

u

If a severe crash damages your vehicle’s High Voltage system, there is a possibility of electrical shock

due to exposed High Voltage components or wires. If this happens, do not touch any of the High
Voltage system components or any of its orange wires.

●

Avoid contact with High Voltage battery fluid.

u

The High Voltage battery contains a flammable electrolyte that could leak as a result of a severe

crash. Avoid skin or eye contact with the electrolyte as it is corrosive. If you accidentally come into
contact with the electrolyte, rinse the exposed skin or flush your eyes with copious amounts of water
for at least five minutes, and seek medical attention immediately.

●

Use a fire extinguisher for an electrical fire.

u

Attempting to extinguish an electrical fire with a small quantity of water, from a garden hose for

instance, can be dangerous.

●

Anytime the vehicle is damaged in a crash, have it repaired by an Acura dealer.

Emergency Shutdown System for the High Voltage System

If the vehicle is involved in a crash, the emergency shutdown system will activate depending
on the severity of the impact. When the system activates, the High Voltage system
automatically shuts down, and the vehicle can no longer move under its own power. To
return the High Voltage system back to normal operation, consult an Acura dealer.

Acura collects and recycles High Voltage batteries used in its vehicles – consult an Acura
dealer for more information.

15

Quick

 Referenc

e Guide

Safe Driving

(P33)

Airbags

(P47)

●

Your vehicle is fitted with airbags to help protect you and
your passengers during a moderate-to-severe collision.

Child Safety

(P62)

●

All children 12 and younger should be seated in the rear seat.

●

Smaller children should be properly restrained in a forward-facing child seat.

●

Infants must be properly restrained in a rear-facing child seat.

Exhaust Gas Hazard

(P80)

●

Your vehicle emits dangerous exhaust gases that contain carbon
monoxide. Do not run the engine in confined spaces where carbon
monoxide gas can accumulate.

Before Driving Checklist

(P38)

●

Before driving, check that the front seats, head restraints,
steering wheel, and mirrors have been properly adjusted.

Seat Belts

(P39)

●

Fasten your seat belt and sit upright well
back in the seat.

●

Check that your passengers are wearing
their seat belts correctly.

Fasten your lap belt as

low as possible.

16

Quick

 Referenc

e Guide

Instrument Panel

(P83)

System Indicators

Malfunction Indicator

Lamp
Low Oil Pressure

Indicator

12-Volt Battery

Charging System

Indicator

Anti-lock Brake System

(

ABS

) Indicator

Vehicle Stability

Assist

TM

 (VSA

®

) System

Indicator
Vehicle Stability

Assist

TM

 (VSA

®

) OFF

Indicator

Speed-sensitive Electric

Power Steering (EPS)

System Indicator

Lights Indicators

Lights On Indicator

High Beam Indicator

Immobilizer System

Indicator

Seat Belt Reminder

Indicator

System Indicators

System Message

Indicator

Brake System

Indicator (Red)

Supplemental

Restraint System

Indicator

Low Fuel Indicator

Gauges

(P123)

/Multi-Information Display (MID)

(P125)

/System Indicators

(P84)

Low Tire Pressure/

TPMS Indicator

Turn Signal and

Hazard Warning

Indicators

Keyless Access System

Indicator

High Voltage Battery

Charge Level Gauge

Security System Alarm Indicator

Fuel

Gauge

Tachometer

MID

Speedometer

Gear Position Indicator

M

 (sequential mode) Indicator/

Sequential Mode Gear Selection

Indicator

Brake System

Indicator (Amber)

Blind spot information

System Indicator

System Indicators

Collision Mitigation

Braking System

TM



(CMBS

TM

) Indicator

Road Departure

Mitigation (RDM)

Indicator

Lane Keeping Assist System

(

LKAS

) Indicator

Adaptive Cruise Control (

ACC

)

with Low Speed Follow

Indicator

U.S.

Canada

U.S.

Canada

Fog Light Indicator

*

Automatic Brake Hold

System Indicator

Automatic Brake Hold

Indicator

U.S.

Canada

Electric Parking Brake

System Indicator

Electric Parking Brake

Indicator

U.S.

Canada

Auto High-Beam

Indicator

POWER SYSTEM



Indicator

High Temperature Indicator

Low Temperature Indicator

SPORT+

 Mode

Indicator

READY

 Indicator

17

Quick

 Referenc

e Guide

Controls

(P141)

Clock

(P142)

a

Enter the

Clock Adjustment

 screen.

2

Adjusting the Clock

(P142)

b

Rotate

 to change hour, then move

.

c

Rotate

 to change minute, then

press

.

The navigation system receives signals from
GPS satellites, updating the clock
automatically.

POWER Button

(P171)

Press the button to change the vehicle’s
power mode.

Turn Signals

(P174)

Lights

(P175)

Turn Signal Control Lever

Right

Left

Light Control Switches

Low Beam

High Beam

Flashing

*

 Not available on all models

18

Quick

 Referenc

e Guide

Wipers and Washers

(P182)

AUTO

 should always be turned

OFF

 before

the following situations in order to prevent
severe damage to the wiper system:

●

Cleaning the windshield

●

Driving through a car wash

●

No rain present

Wiper/Washer Control Lever

MIST
OFF
AUTO

: Wiper speed varies

automatically

LO

: Low speed wipe

HI

: High speed wipe

Pull toward

you to spray

washer fluid.

Adjustment Ring

(

-

: Low Sensitivity

(

+

: High Sensitivity

Steering Wheel

(P190)

●

To adjust, push and hold the adjustment
switch to move the steering wheel to the
desired position.

Unlocking the Front
Doors from the Inside

(P155)

●

Pull either front door inner handle to
unlock and open it at the same time.

Tailgate

(P164, 159)

●

Press the tailgate outer handle to unlock
and open the tailgate when you carry the
keyless access remote.

●

Press the power tailgate button on the
driver’s door or the remote transmitter to
open and close the power tailgate.

Tailgate Outer Handle

19

Quick

 Referenc

e Guide

Power Door Mirrors

(P192)

●

With the power mode in ON, move the
selector switch to

L

 or

R

.

●

Push the appropriate edge of the
adjustment switch to adjust the mirror.

●

Press the fold button to fold the door
mirrors.

Selector Switch

Adjustment Switch

Fold Button

Power Windows

(P168)

●

With the power mode in ON, open and
close the power windows.

●

If the power window lock button is in the
off position, each passenger’s window
can be opened and closed with its own
switch.

●

If the power window lock button is in the
on position (indicator is on), each
passenger’s window switch is disabled.

Power Window Lock Button

Window Switch

Indicator

20

Quick

 Referenc

e Guide

Climate Control System

(P222)

●

Press the

AUTO

 button to activate the climate control system.

●

Press the

 button to turn the system on or off.

●

Press the

 button or select the

Front



 icon to defrost the windshield.

Driver’s Side
Temperature
Control Switch

Air flows from floor and

windshield defroster vents.

Air flows from floor vents.

Air flows from floor and

dashboard vents.

Air flows from dashboard vents.

AUTO

 Button

Passenger’s Side
Temperature
Control Switch

 (On/Off) Button

Driver’s Side
Temperature Icon

Passenger’s Side
Temperature Icon

On Demand
Multi-Use
Display

TM

 (Windshield Defroster) Button

A/C

 (Air

Conditioning) and

SYNC



(Synchronization)
Icon

Recirculation/
Fresh Air Mode
Icon

Fan Control Icon

REAR

 (Rear Climate

Control) Icon

Vent Mode

Control Icon

Rear Climate Control

(P232)

●

Press the

AUTO

 button to activate the

rear climate control system.

●

Press the

 button to turn the system

on or off.

Rear Temperature
Control Buttons

 /



(Fan Control)
Button

AUTO

 Button

 (On/Off)

Button

Mode Control Button

Air flows from the rear floor vents.

Air flow from the rear console

vents and floor vents.

Air flows from the rear console vents.

21

Quick

 Referenc

e Guide

Features

(P235)

Audio System

(P243)



For navigation system operation



()

 See the Navigation System Manual

*1:Icons that appear on the screen vary by the source selected.

Information Screen

Audio Menu

 (CD Eject) Button

VOL

/

 (Volume/Power) Knob

BACK

 Button

Interface Dial (

ENTER/MENU



Button)

INFO

 Button

On Demand Multi-Use Display

TM

PHONE

 Button

 (Tune Down) Icon

*1

Source

 (Day/Night) Button

Tune

*1

CD Slot

 (Information) Icon

Preset Icons

*1

 (Tune Up) Icon

*1

Stations

*1

SCAN

*1

SMARTPHONE

 Button

SETTINGS

 Button

Front

/

Rear

*

NAV

 Button

HD Radio List

*, *1

*

 Not available on all models

22

Quick

 Referenc

e Guide

Models with rear entertainment system

Disc Slot

REAR



 (Power)

Button

 (Eject) Button

Audio Remote Controls

(P241)

●

SOURCE

 Button

Press to change the audio mode: FM/AM/
SiriusXM

®

/CD/Rear DVD

*

/HDD/USB/iPod/

Apple CarPlay/Android Auto/

Bluetooth

®



Audio/Pandora

®

*

/AUX.

●

Left Selector Wheel
Roll to adjust the volume up/down.
Radio:Move to a side to change the

preset station.
Move to a side and hold to select
the next or previous strong station.

CD/HDD/USB device:

Move to a side to skip to the
beginning of the next song or
return to the beginning of the
current song.
Move to a side and hold to change
a folder.

Left Selector Wheel

SOURCE

 Button

23

Quick

 Referenc

e Guide

Driving

(P447)

Electronic Gear Selector

(P465)

●

Always depress the brake pedal before selecting

(

P

 or changing the gear position from

(

P

.

●

Select

(

P

 and depress the brake pedal when turning on the power.

Park

Press the

(

P

 button.

Used when parking or before
turning the power on or off.
Transmission is locked.

Reverse

Pull back the

(

R

 button.

Used when reversing.

Neutral

Press the

(

N

 button.

Transmission is not locked.

Drive

Press the

 button.

Used for normal driving.
Sequential shift mode can be used

temporarily.

D/S

Gear Position Indicator

The gear position indicator and the
shift button indicator indicate the
current gear selection.

Gear Position Indicator

Shift Button
Indicator

Drive (S)

Press the

 button twice.

Sequential shift mode can be used.

D/S

Shifting

*

 Not available on all models

24

Quick

 Referenc

e Guide

Sequential Mode

(P472)

Paddle shifters allow you to shift gears much like a manual
transmission (1st through 7th). This is useful for regenerative braking.

When the transmission is in

(

D

●

The transmission will shift back to
automatic mode once the system
detects that the vehicle is cruising.

When the transmission is in

(

S

●

Holds the selected gear, and the

M

 (sequential mode) indicator

comes on.

●

The sequential mode gear
selection is shown in the
instrument panel.

Gear Position Indicator

Shift Down

(

-



Paddle Shifter

Shift Up

(

+



Paddle Shifter

Selected Gear Number

M

 Indicator

25

Quick

 Referenc

e Guide

VSA

®

 On and Off

(P507)

●

The Vehicle Stability Assist

TM

 (VSA

®

)

system helps stabilize the vehicle during
cornering and helps maintain traction
while accelerating on loose or slippery
road surfaces.

●

VSA

®

 comes on automatically every time

you turn on the power system.

●

To partially disable or fully restore VSA

®



function, press and hold the button until
you hear a beep.

CMBS

TM

 On and Off

(P529)

●

When a possible collision is likely
unavoidable, the CMBS

TM

 can help you to

reduce the vehicle speed and the severity
of the collision.

●

The CMBS

TM

 is turned on every time you

start the power system.

●

To turn the CMBS

TM

 on or off, press and

hold the button until you hear a beep.

Tire Pressure Monitoring System (TPMS) with Tire
Fill Assist

(P513, 646)

●

The TPMS monitors tire pressure.

●

TPMS is turned on automatically every time you turn on the power system.

●

TPMS fill assist provides audible and visual guidance during tire pressure adjustment.

Refueling

(P557)

a

Press the fuel fill door
release button.

b

After refueling, wait for
about five seconds
before removing the
filler nozzle.

Fuel recommendation: Unleaded premium gasoline, pump octane number 91 or

higher

Fuel tank capacity: 19.4 US gal (73.3 L)

Wait for five seconds

26

Quick

 Referenc

e Guide

AcuraWatch

TM

AcuraWatch

TM

 is a driver support system

which employs the use of two distinctly
different kinds of sensors, a radar sensor
located behind the emblem and a front
sensor camera mounted to the interior side
of the windshield, behind the rearview
mirror.

The camera is located
behind the rearview
mirror.

Front Sensor
Camera

Radar Sensor

The radar sensor is
behind the emblem.

Adaptive Cruise Control
(ACC) with Low Speed
Follow

(P477)

Helps maintain a constant vehicle speed and
a set following-interval behind a vehicle
detected ahead of yours and, if the detected
vehicle comes to a stop, can decelerate and
stop your vehicle, without you having to
keep your foot on the brake or the
accelerator.

Road Departure
Mitigation (RDM) System

(P493)

Alerts and helps to assist you when the
system detects a possibility of your vehicle
unintentionally crossing over detected lane
markings and/or leaving the roadway
altogether.

Lane Keeping Assist
System (LKAS)

(P498)

Provides steering input to help keep the
vehicle in the middle of a detected lane and
provides tactile and visual alerts if the
vehicle is detected drifting out of its lane.

Collision Mitigation
Braking System

TM



(CMBS

TM

)

(P526)

Can assist you when there is a possibility of
your vehicle colliding with a vehicle or a
pedestrian detected in front of yours. The
CMBS

TM

 is designed to alert you when a

potential collision is determined, as well as
to reduce your vehicle speed to help
minimize collision severity when a collision is
deemed unavoidable.

27

Quick

 Referenc

e Guide

Maintenance

(P561)

Under the Hood

(P569)

●

Check engine oil, engine coolant, windshield washer fluid
and inverter coolant. Add when necessary.

●

Check brake fluid.

●

Check the 12-volt battery condition monthly.

a

Pull the hood release handle under the corner of the
dashboard.

b

Locate the hood latch lever, push it to the side, and then
raise the hood. Once you have raised the hood slightly, you
can release the lever.

c

When finished, close the hood and make sure it is firmly
locked in place.

Lever

Lights

(P582)

●

Inspect all lights regularly.

Wiper Blades

(P587)

●

Replace blades if they leave streaks
across the windshield.

Tires

(P591)

●

Inspect tires and wheels regularly.

●

Check tire pressures regularly.

●

Install snow tires for winter
driving.
