Acura MDX (2020 year). Manual in english - page 25

397

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Continued

Features

Manual Input

Edit Speed

Dial

*1

New Entry



Import from

Call History



Import from

Phonebook







Delete All

Delete all the previously stored speed dial numbers.

Select a phone number from the call
history to store as a speed dial number.

Select a phone number from the
phonebook to store as a speed dial number.

Enter a phone number to store as a speed
dial number.



Edit



Delete



(Existing

entry list)

Edit a previously stored speed dial number.

●

Change a name

*

 and number.

●

Create or delete a voice tag.

Delete a previously stored speed dial
number.



Set calls to automatically transfer from your phone to HFL when you enter the
vehicle.

Auto Transfer

Auto Answer

Ring Tone

Set whether to automatically answer an incoming call after about four
seconds.
Select a fixed ring tone or the one from the connected cell phone.

Use Contact Photo

Set phonebook data to be automatically imported when a phone is paired to
HFL.
Display a caller’s picture on an incoming call screen.

Automatic Phone Sync

*1









*1: Appears only when a phone is connected to HFL.

Phone



Changes a pairing code.

Edit Pairing Code





Add Bluetooth Device

Pair a phone to the system.

* Not available on all models

398

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

Select a text or e-mail message account.

Text/Email

*1

*1: Appears only when a phone is connected to HFL.



Select Account



Enable Text/Email

Turn the text/e-mail message function on and off.

New Text/Email Alert

Select whether a pop-up alert comes on the screen when HFL receives a new
text/e-mail message.





Message Auto Reading

*

Selects whether the system automatically reads out messages, and, if selected,
whether only when driving.

* Not available on all models

399

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Continued

Features

■

Phone Menu screen

Press the

PHONE

 button to display the menu

items.

Speed Dial

*1

Manual Input

New Entry



Import from

Phonebook

Select a phone number from the phonebook to store as a
speed dial number.

Enter a phone number to store as a speed dial number.

*1: Appears only when a phone is connected to HFL.

(Existing entry list)

Dial the selected number in the speed dial list.







Phonebook

*1

Display the paired phone’s phonebook.



Display the last 20 outgoing, incoming and missed calls.

Call History

*1

All

*2

Dialed

Received

Display the last 20 outgoing calls.
Display the last 20 incoming calls.

Missed

Display the last 20 missed calls.

More Speed Dials

Display another paired phone’s speed dial list.









*2: This function is not available if your phone is not supported.

Select a phone number from the call history to store as a
speed dial number.

Import from

Call History

Roadside

Assistance

*

Makes a call to the number for the Roadside Assistance service.



* Not available on all models

400

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

Text/Email

*1, *2

Message is

read aloud.

Read Message

Aloud

/

Stop

Reading

Messages

System reads received message aloud, or stop message
from being read.

Reply

Call

Reply to a received message using one of six fixed
phrases.

Make a call to the sender.

Select Account

Select a message
and press

.

Select a text or e-mail message account.

Redial

*1

Redial the last number dialed in the phone’s history.

*1: Appears only when a phone is connected to HFL.
*2: This function is not available if your phone is not supported.

See the previous message.

Previous

Next

See the next message.

View Full

Message

Displays the entire message.

Bluetooth/

Phone Settings

Display the

Bluetooth/Phone Settings

 screen.







Dial

*1

Enter a phone number to dial.



Continued

401

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

■

To pair a cell phone (when there is no
phone paired to the system)

1.

Press the

PHONE

 button.

2.

Rotate

 to select

Yes

, then press

.

3.

Make sure your phone is search or
discoverable mode, then press

.

u

HFL automatically searches for a

Bluetooth

 device.

4.

When your phone appears on the list, select
it by pressing

.

u

If your phone does not appear, you can
select

Options...

 and

Refresh

 to search

again.

u

If your phone still does not appear, select

Options...

 to select

Device Not Found?



and search for

Bluetooth

 devices using

your phone. From your phone, select

HandsFreeLink

.

5.

HFL gives you a pairing code on the
information screen.

u

Confirm if the pairing code on the screen
and your phone match.
This may vary by phone.

6.

A notification appears on the screen if
pairing is successful.

■

Phone Setup

1

Phone Setup

Your

Bluetooth

-compatible phone must be paired to

HFL before you can make and receive hands-free
calls.

Phone Pairing Tips:

•

You cannot pair your phone while the vehicle is
moving.

•

Up to six phones can be paired.

•

Your phone’s battery may drain faster when it is
connected to HFL.

•

If your phone is not ready for pairing or not found
by the system within three minutes, the system will
time out and returns to idle.

Once you have paired a phone, you can see it
displayed on the screen with one or two icons on the
right side.
These icons indicate the following:

: The phone can be used with HFL.
: The phone is compatible with

Bluetooth

®

 Audio.

When pairing is completed, an

Automatic Phone

Sync

 prompt appears. Select

On

 if you want your call

history and phonebook automatically imported to
HFL.

2

Changing the Automatic Phone Sync
setting

 P. 412

If there is an active connection to Apple CarPlay,
pairing of additional

Bluetooth

-compatible devices is

unavailable.

402

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

■

To pair a cell phone (when a phone has
already been paired to the system)

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Bluetooth/Phone

Settings

, then press

.

u

Repeat the procedure to select

Bluetooth Device List

, then

Add

Bluetooth Device

.

3.

Make sure your phone is in search or
discoverable mode, then press

.

u

HFL automatically searches for a

Bluetooth

 device.

4.

When your phone appears on the list, select
it by pressing

.

u

If your phone does not appear, you can
select

Options...

 and

Refresh

 to search

again.

u

If your phone still does not appear, select

Options...

 to select

Device Not Found?



and search for

Bluetooth

 devices using

your phone. From your phone, select

HandsFreeLink

.

5.

HFL gives you a pairing code on the
information screen.

u

Confirm if the pairing code on the screen
and your phone match.
This may vary by phone.

6.

A notification appears on the screen if
pairing is successful.

Continued

403

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

■

To change the currently paired phone

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Bluetooth/Phone

Settings

, then press

.

u

Repeat the procedure to select

Bluetooth Device List

.

3.

Select a phone to connect.

u

HFL disconnects the connected phone
and starts searching for another paired
phone.

4.

Select

Connect to Phone

,

Connect to

Audio

, or

Connect Both

, then press

.

■

To change the pairing code setting

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Bluetooth/Phone

Settings

, then press

.

u

Repeat the procedure to select

Edit

Pairing Code

.

3.

Rotate

 to select

Fixed

 or

Random

,

then press

.

1

To change the pairing code setting

The pairing code may be four or six digits depending
on your phone.

The default pairing code is

0000

 until you change the

setting.
To create your own, select

Fixed

, and delete the

current code, then enter a new one.

For a randomly generated pairing code each time you
pair a phone, select

Random

.

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

404

Features

■

To replace an already-paired phone
with a new phone

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Bluetooth/Phone

Settings

, then press

.

u

Repeat the procedure to select

Bluetooth Device List

.

3.

Rotate

 to select a paired phone you

want to replace, then press

.

4.

Rotate

 to select

Replace This Device

,

then press

.

5.

HFL enters the pairing process and searches
a new phone.

u

Follow the prompts to pair a new phone.

6.

A notification appears on the screen if
pairing is successful.

1

To replace an already-paired phone with a new phone

The replaced phone will keep the same speed dial
entries, and security PIN information from the
previously paired phone.

405

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Continued

Features

■

To delete a paired phone

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Bluetooth/Phone

Settings

, then press

.

u

Repeat the procedure to select

Bluetooth Device List

.

3.

Rotate

 to select a phone you want to

delete, then press

.

4.

Rotate

 to select

Delete This Device

,

then press

.

5.

A confirmation message appears on the
screen. Rotate

 to select

Yes

, then press

.

6.

A notification appears on the screen if
pairing is successful.

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

406

Features

■

To turn on or off the text/e-mail
message function

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Bluetooth/Phone

Settings

, then press

.

3.

Rotate

 to select

Enable Text/Email

.

4.

Press

 to select

On

 or

Off

.

■

To turn on or off the text/e-mail
message notice

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Bluetooth/Phone

Settings

, then press

.

3.

Rotate

 to select

New Text/Email

Alert

.

4.

Press

 to select

On

 or

Off

.

■

To Set Up a Text/E-mail Message Option

1

To Set Up a Text/E-mail Message Option

To use the text/e-mail message function, you need a

Bluetooth

-compatible cell phone. For a list of

compatible phones, pairing procedures, and special
feature capabilities:

•

U.S.: Visit

www.handsfreelink.com/Acura

, or call 1-

888-528-7876.

•

Canada: For more information on smartphone
compatibility, call 1-855-490-7351.

Some text/e-mail message features may not be
available depending on a cellular phone.

1

To turn on or off the text/e-mail message notice

On

: A pop-up notification comes on every time you

receive a new text message.

Off

: The message you receive is stored in the system

without notification.

Continued

407

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

■

To set up the auto reading option

*

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Bluetooth/Phone

Settings

, then press

.

3.

Rotate

 to select

Message Auto

Reading

.

4.

Press

to

select

On

 or

Off

.

1

To set up the auto reading option

*

On

: A text/e-mail message is always read aloud.

Off

: A text/e-mail message is not read aloud.

* Not available on all models

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

408

Features

You can protect each of the six cell phones with a security PIN.

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Bluetooth/Phone

Settings

, then press

.

u

Repeat the procedure to select

Bluetooth Device List

.

3.

Rotate

 to select a phone you want to

add a security PIN to, then press

.

4.

Rotate

 to select

Edit PIN

, then press

.

5.

Enter a new four-digit number.

u

Select

 to delete. Select

 of the

right side upper screen, the screen
returns to the previous screen.

6.

Select

OK

 to enter the security PIN.

7.

Re-enter the four-digit number.

u

The screen returns to the screen in step
4.

■

To Create a Security PIN

1

To Create a Security PIN

If the phone is already security PIN protected, you
need to enter the current security PIN before clearing
the PIN or creating a new one.

Information Screen

On Demand Multi-Use Display

TM

X

X

409

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Continued

Features

Edit the user name of a paired phone as
follows:

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Bluetooth/Phone

Settings

, then press

.

u

Repeat the procedure to select

Bluetooth Device List

.

3.

Rotate

 to select a phone you want to

edit, then press

.

4.

Rotate

 to select

Edit Device Name

,

then press

.

5.

Enter a new name of the phone.

u

Use the keyboard on the On Demand
Multi-Use Display

TM

 to enter the name,

then select

OK

.

■

Editing User Name

*

* Not available on all models

410

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

If you get into the vehicle while you are on the phone, the call can be automatically
transferred to HFL.

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Bluetooth/Phone

Settings

, then press

.

3.

Rotate

 to select

Auto Transfer

.

4.

Press

 to select

On

 or

Off

.

You can set HFL to automatically answer an incoming call in four seconds.

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Bluetooth/Phone

Settings

, then press

.

3.

Rotate

 to select

Auto Answer

.

4.

Press

 to select

On

 or

Off

.

■

Automatic Transferring

■

Auto Answer

Continued

411

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

You can change the ring tone setting.

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Bluetooth/Phone

Settings

, then press

.

u

Repeat the procedure to select

Ring

Tone

.

3.

Rotate

 to select

Fixed

,

Mobile Phone



or

Off

, then press

.

You can display a caller’s picture on an incoming call screen.

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Bluetooth/Phone

Settings

, then press

.

3.

Rotate

 to select

Use Contact Photo

.

4.

Press

to

select

On

 or

Off

.

■

Ring Tone

1

Ring Tone

Fixed

: The fixed ring tone sounds from the speaker.

Mobile Phone

: Depending on the make and model

of the cell phone, the ring tone stored in the phone
will sound if the phone is connected.

Off

: No ring tones sound from the speaker.

■

Use Contact Photo

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

412

Features

■

When Automatic Phone Sync is set to
On:

When your phone is paired, the contents of its
phonebook and call history are automatically
imported to HFL.

■

Changing the Automatic Phone Sync
setting

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Bluetooth/Phone

Settings

, then press

.

u

Repeat the procedure to select

Automatic Phone Sync

.

3.

Rotate

 to select

On

 or

Off

, then press

.

■

Automatic Import of Cellular Phonebook and Call History

1

Automatic Import of Cellular Phonebook and Call History

When you select a person from the list in the cellular
phonebook, you can see up to three category icons.
The icons indicate what types of numbers are stored
for that name.

On some phones, it may not be possible to import the
category icons to HFL.

The phonebook is updated after every connection.
Call history is updated after every connection or call.

Preference

Home

Mobile

Work

Pager

Fax

Car

Other

Voice
