205

uu

Adjusting the Seats

u

Armrest

Co
ntrols

Pull down the armrest in the center backrest.

The console lid can be used as an armrest.

To adjust:

Slide the armrest to a desired position.

Pull down the armrest.

■

Using the Rear Seat Armrest

Models with bench seat

Models with rear console compartment

Models with captain seat
Models without rear console
compartment

206

Co
ntrols

Interior Lights/Interior Convenience Items

Interior Lights

■

ON

The interior lights come on regardless of
whether the tailgate and doors are open or
closed.

■

Door activated

The interior lights come on in the following
situations:

•

When the tailgate or any of the doors are
opened.

•

You unlock the driver’s door.

•

When the power mode is set to VEHICLE
OFF (LOCK).

■

OFF

The interior lights remain off regardless of
whether the tailgate or any doors are open or
closed.

■

Interior Light Switches

1

Interior Light Switches

In the door activated position, the interior lights fade
out and go off about 30 seconds after the doors are
closed.
The lights go off after about 30 seconds in the
following situations:

•

When you unlock the driver’s door but do not open
it.

•

When you set the power mode to VEHICLE OFF
(LOCK) but do not open a door.

You can change the interior lights dimming time.

2

Customized Features

 P. 126, 358

The interior lights go off immediately in the following
situations:

•

When you lock the driver’s door.

•

When you close the driver’s door in ACCESSORY
mode.

•

When you set the power mode to ON.

To avoid draining the battery, do not leave the
interior light on for an extended length of time when
the engine is off.

If you leave any of the tailgate or doors open in
VEHICLE OFF (LOCK) mode, the interior lights go off
after about 15 minutes.

Door Activated Position

Off

On

207

uu

Interior Lights/Interior Convenience Items

u

Interior Lights

Co
ntrols

■

Front

The map lights can be turned on and off by
pressing the

 (map light) button.

■

Second and third row

The map lights can be turned on and off by
pressing the

 (map light) button when the

front interior light switch is in the door
activated position.

■

ON

The light comes on when you open the
tailgate, and goes off when closed.

■

OFF

The light stays off with or without opening the
tailgate.

■

Map Lights

1

Map Lights

When the interior light switch is in the door activated
position and any door is open, the map light will not
go off when you press the

 button.

Front

Second and third row

■

Cargo Area Lights

Off

On

208

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

Interior Convenience Items

Press the button to open the glove box. You
can lock the glove box with the built-in key.

■

Removable shelf

The shelf in the glove box is detachable. To
remove it, disengage the tabs.

The removed shelf can be stored upside down
in the glove box.

■

Glove Box

1

Glove Box

3

WARNING

An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.

Always keep the glove box closed while
driving.

Glove Box

To Lock

Shelf

Tabs

209

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Continued

Co
ntrols

Pull the passenger’s side handle to open the
console compartment.

Pull the driver’s side handle to open the utility
tray in the console lid.

■

Console Tray

Slide or lift the tray when you use the console
compartment.

u

To lift this tray, slide it rearward, then
pull it up.

■

Front and Rear

*

 Console Compartment

* Not available on all models

210

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

Press the raised detent to open the lid. To
close the lid, push it down until it latches.

Pull the handle to open the cargo floor lid.

■

Center Pocket

Press

■

Under-floor Storage Area

Continued

211

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

■

Front seat beverage holders

Are located in the console between the front
seats.

■

Door side beverage holders

Are located on the both of the front and rear
door side pockets.

■

Beverage Holders

1

Beverage Holders

NOTICE

Spilled liquids can damage the upholstery, carpeting,
and electrical components in the interior.

Be careful when you are using the beverage holders.
Hot liquid can scald you.

Front

Rear

212

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

■

Second row seat beverage holders

*

Fold the armrest down to use the rear seat
beverage holders.

Are located in the console between the
second row seats.

■

Third row seat beverage holders

Models with bench seat

Models with rear console compartment

* Not available on all models

Continued

213

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The accessory power sockets can be used when the power mode is in ACCESSORY
or ON.

■

Accessory power socket (center pocket)

Open the lid and the cover to use it.

■

Accessory power socket (front console
compartment)

*

Pull the handle and open the cover to use it.

■

Accessory Power Sockets

1

Accessory Power Sockets

NOTICE

Do not insert an automotive type cigarette lighter
element. This can overheat the power socket.

The accessory power sockets are designed to supply
power for 12-volt DC accessories that are rated 180
watts (15 amps) or less.

To prevent battery drain, only use the power socket
with the engine running.

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

214

Co
ntrols

■

Accessory power socket (cargo area)

Open the cover to use it.

The AC power outlet can be used when the engine is running.

Open the cover to use it. Plug in the appliance
slightly, turn it 90° clockwise, then push it all
the way.

■

AC Power Outlet

*

1

AC Power Outlet

*

NOTICE

Do not use the AC power outlet for electric
appliances that require high initial peak wattage,
such as cathode-ray tube type televisions,
refrigerators, electric pumps, etc. It is not suitable for
devices that process precise data, such as medical
equipment, and that require an extremely stable
power supply, such as microcomputer-controlled
electric blankets, touch sensor lamps, etc.

The AC power outlet is designed to supply power for
up to 115 volt appliances that are rated 150 watts or
less.

Continued use of any electric appliance/device
exceeding these ratings may result in damage to the
appliance/device.

* Not available on all models

Continued

215

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

There is a coat hook on the rear grab handle
of both sides. Pull it down to use it.

The tie-down anchors on the cargo area floor
can be used to install a net for securing items.

■

Coat Hooks

1

Coat Hooks

The coat hooks are not designed for large or heavy
items.

■

Tie-down Anchors

1

Tie-down Anchors

Do not let anyone access items in the cargo area
while driving. Loose items can cause injury if you have
to brake hard.

Anchor

Anchor

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

216

Co
ntrols

To open the sunglasses holder, press and
release the indent. To close, press it again until
it latches.

You can store eyeglasses and other small
items in this holder.

The power mode must be in ON to use the
heated steering wheel.

Press the button on the left side of the
steering wheel.

When a comfortable temperature is reached,
press the button again to turn it off.

The heated steering wheel is turned off every
time you start the engine, even if you turned it
on the last time you drove the vehicle.

■

Sunglasses Holder

1

Sunglasses Holder

Keep the holder closed while driving except when
accessing stored items.

Press

■

Heated Steering Wheel

*

1

Heated Steering Wheel

*

Do not use the heated steering wheel continuously
when the engine is off. Under such conditions, the
battery may be weakened, making the engine
difficult to start.

Indicator

Heated Steering Wheel Button

* Not available on all models

Continued

217

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The power mode must be in ON to use the
seat heaters and ventilators

*

.

1.

Select .

2.

Change the setting with one of the
following:
The

Low

 icon: The LO setting (one indicator

on)
The

Mid

 icon: The MID setting (two

indicators on)
The

High

 icon: The HI setting (three

indicators on)

Auto

: The system automatically selects the

setting most suitable to the ambient
environment.

Off

: Turn off the system.

When the power mode is turned on after it is
turned off, the previous setting of front seat
heaters and ventilators

*

 are maintained.

■

Front Seat Heaters and Seat Ventilation

*

1

Front Seat Heaters and Seat Ventilation

*

Do not use the seat heaters and the seat ventilation
even in LO when the engine is off. Under such
conditions, the battery may be weakened, making
the engine difficult to start.

After a certain period of time, the strength setting for
the seat heaters will automatically be reduced by one
level at a time until the seat heater shuts off. The
elapsed time varies according to the interior
environment.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

Models with seat ventilation

Models without seat ventilation

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

218

Co
ntrols

The power mode must be in ON to use the
seat heaters.

Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

Pull the tab and roll up the sunshade all the
way. Use the hooks to hang it.

■

Second Row Outer Seat Heaters

*

1

Second Row Outer Seat Heaters

*

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

After a certain period of time, the strength setting for
the seat heaters will automatically be reduced by one
level at a time until the seat heater shuts off. The
elapsed time varies according to the interior
environment.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

■

Integrated Sunshades

*

1

Integrated Sunshades

*

Use the sunshades only when the windows are fully
closed. Using the shade while a window is open can
unhook and blow off the shade, hitting and hurting
anyone sitting near the window.

Tab

Hook

* Not available on all models

219

Continued

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that raises or lowers
the interior temperature to your preference as quickly as possible.

Use the system when the engine is running.

1.

Press the

AUTO

 button.

2.

Adjust the interior temperature using the driver’s side or passenger’s side
temperature control switch.

3.

Press the

 (On/Off) button to cancel.

1

Using Automatic Climate Control

If any buttons/icons on the touch screen are pressed
while using the climate control system in auto, the
function of the button/icon that was pressed will take
priority.
The AUTO indicator will go off, but functions
unrelated to the button/icon that was pressed will be
controlled automatically.

During idle-stops, air-conditioning is suspended, and
only the blower remains active.
If you do not want air-conditioning suspended, press
the Auto Idle Stop

OFF

 button to cancel idle-stop.

To prevent cold air from blowing in from outside, the
fan may operate at low speed for a while after the

AUTO

 button has been pressed.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on auto, and setting the
temperature to low. Change the fresh air mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit,

Lo

 or

Hi

 is displayed.

Pressing the

 button switches the climate control

system between on and off. When turned on, the
system returns to your last selection.

 (On/Off) Button

AUTO

 Button

On Demand Multi-Use Display

TM

Driver’s Side
Temperature
Control Switch

Passenger’s
Side
Temperature
Control Switch

Passenger’s
Side
Temperature

Driver’s Side
Temperature

uu

Climate Control System

u

Using Automatic Climate Control

220

Co
ntrols

In addition to the button/switch controls, you can operate the climate control system
from the On Demand Multi-Use Display

TM

 touch screen.

■

Operating from the On Demand Multi-Use Display

TM

1

Using Automatic Climate Control

When you unlock the doors with your remote, the
driver’s ID (

Driver 1

 or

Driver 2

) is detected, and the

climate control settings are turned to the respective
mode automatically when you set the power mode to
ON.

On Demand Multi-Use Display

TM

A/C

 (Air Conditioning) and

SYNC

 (Synchronization) Icon

Driver’s Side
Temperature
Control Icon

Recirculation/
Fresh Air mode
Icon

Fan Control Icon

Passenger’s Side
Temperature
Control Icon

Vent Mode Icon
